iSCSI Extensions for RDMA (iSER)

1
iSCSI Extensions for RDMA (iSER)

• draft-ko-iwarp-iser-02
• Mike Ko
• IBM
• August 2, 2004

2
Agenda

• What is iSER?
• iSER connection setup
• Open issues
• iSER flow control
• Open issues

3
iSCSI Datamover with RDMA Extensions

• The Datamover Architecture defines an abstract
  model in which the movement of data between iSCSI
  end nodes is logically separated from the rest of
  the iSCSI protocol
• Allows a datamover protocol layer to offload the
  tasks of data movement and placement from the
  iSCSI layer
• The iSCSI Extensions for RDMA (iSER) protocol is
  one such datamover protocol
• Applies the Datamover Architecture in extending
  the data transfer capabilities of iSCSI to
  include RDMA (Remote Direct Memory Access) as
  defined in the iWARP protocol suite
• Allows iSCSI implementations to have data
  transfers which achieve true zero copy behavior
  using generic RDMA network interface controllers
  (RNICs)

SCSI
iSCSI
Datamover Interface
iSER
Verbs
RDMAP
DDP
iWARP
MPA
TCP
4
Connection Setup for iSER-assisted Modeat the
Initiator

• Negotiated key values may be passed by the iSCSI
  layer to the iSER layer by invoking the
  Notice_Key_Values Operational Primitive
• Before sending the final Login Request, the iSCSI
  layer invokes the Allocate_Connection_Resources
  Operational Primitive to request the iSER layer
  to allocate the iWARP resources for the
  connection
• After the target returns the final Login
  Response, the iSCSI layer at the initiator
  invokes the Enable_Datamover Operational
  Primitive to request the iSER layer to transition
  into iSER-assisted mode
• The first message sent by the iSER layer at the
  initiator to the target is the iSER Hello Message

5
Connection Setup for iSER-assisted Modeat the
Target

• Negotiated key values may be passed by the iSCSI
  layer to the iSER layer by invoking the
  Notice_Key_Values Operational Primitive
• Before sending the final Login Response, the
  iSCSI layer invokes the Allocate_Connection_Resour
  ces Operational Primitive to request the iSER
  layer to allocate the iWARP resources for the
  connection
• The iSCSI layer invokes the Enable_Datamover
  Operational Primitive to enable the iSER mode
  qualified with the final Login Response PDU
• The iSER layer sends the final Login Response PDU
  in byte stream mode and then transitions into
  iSER-assisted mode
• After receiving the iSER Hello Message from the
  initiator, the iSER layer at the target responds
  by sending the iSER HelloReply Message

6
Example of Successful iSER Connection Setup
A. SCSI Login Request PDU with
RDMAExtensionsYes B. SCSI Login Response PDU
with RDMAExtensionsYes C. Optional
Notice_Key_Values to pass values of negotiated
keys D. Allocate_Connection_Resources to set up
iWARP resources E. SCSI Login Request PDU with
T1 and NSGFullFeaturePhase F. Enable_Datamover
to go into iSER mode ( send last iSCSI PDU in
byte stream mode) G. SCSI Login Response PDU in
byte stream mode with T1 and NSGFullFeaturePhase
H. iWARP Send Message containing iSER Hello J.
iWARP Send Message containing iSER HelloReply
target
initiator
iSCSI Layer
iSER Layer
iSER Layer
iSCSI Layer
A
B
. . .
C
D
E
C
D
F
G
F
H
J
7
Negotiation of RDMAExtensions in Leading
Connection Only

• From section 2.3 of iSER draft iSER-assisted
  mode is negotiated during the iSCSI Login for
  each connection, but an entire iSCSI session MUST
  operate in one mode ...
• Question Since RDMAExtensions is leading-only,
  this statement is incorrect
• Proposed change
• Replace the sentence with iSER-assisted mode is
  negotiated during the iSCSI Login for each
  session, and an entire iSCSI session MUST operate
  in one mode ...

8
CRC32C Protection in the Layer Below iSER

• From section 5.1 of iSER draft when the
  RDMAExtensions key is negotiated to "Yes", the
  HeaderDigest and the DataDigest keys MUST be
  negotiated to "None" ... because ... the iWARP
  protocol suite provides a CRC32c-based error
  detection for all iWARP Messages
• Recent updates to the MPA draft renders the use
  of CRC optional
• Disabling of CRCs should only be done when it is
  clear that the connection through the network has
  data integrity at least as good as a CRC
• RDDP WGs position is that all ULPs can assume
  CRC level or equivalent data protection
• Proposed change Add the explicit requirement
  that end-to-end CRC32C based error detection or
  equivalent be provided in a layer below iSER

9
Order of RDMAExtensions Key Negotiation and
Allocate_Connection Resources

• From section 5.1.1 (and similarly for section
  5.1.2) If the outcome of the iSCSI negotiation
  is to enable iSER-assisted mode, then on the
  initiator side, ... the iSCSI Layer MUST invoke
  the Allocate_Connection_Resources Operational
  Primitive
• Question The alternative approach of invoking
  Allocate_Connection_Resources before negotiating
  for iSER-assisted mode should be allowed
• Current approach results in the connection being
  torn down if the required resources cannot be
  allocated
• Alternative approach avoids this problem
• Resources must be deallocated if login fails
• Resources may have to be deallocated if the
  negotiated values are less than the allocated
  value
• Proposed change Update the draft to allow the
  alternative approach with the proviso that it is
  the responsibility of the implementation to
  deallocate the resources if the login fails or if
  the negotiation values are less than the
  allocated value

10
Clarification on the Usage of the
Notice_Key_Values Primitive

• From section 5.1.1 Optionally, the iSCSI Layer
  MAY invoke the Notice_Key_Values Operational
  Primitive before invoking the Allocate_Connection_
  Resources Operational Primitive
• Question The word optionally is ambiguous
• Could mean the iSCSI layer may choose to invoke
  the primitive
• Or the iSCSI layer may choose to use that
  primitive, or some other defined or undefined
  primitive
• Proposed change Remove the word optionally

11
Requiring the Use of the Notice_Key_Values
Primitive

• From section 5.1.1 The iSCSI Layer MAY invoke
  the Notice_Key_Values Operational Primitive to
  request the iSER Layer to take note of the
  negotiated values of the iSCSI keys for the
  Connection
• Question The word MAY should be replaced with
  MUST to enforce the invocation of the primitive
• Proposed change None
• If the default values are accepted for all the
  negotiated keys, then there is no new information
  to be passed from the iSCSI layer to the iSER
  layer
• Requiring a "MUST" instead of a "MAY would
  require this primitive be invoked even though it
  is not necessary
• Also, it is not architecturally required for the
  iSCSI layer to issue the Notice_Key_Values
  primitive

12
HeaderDigest, DataDigest, OFMarker, IFMarker in
iSER-assisted Mode

• From section 6.1 and 6.6 These 4 keys must be
  negotiated to none or no if the
  RDMAExtensions key is negotiated to yes
• Question Draft seems to imply that these 4 keys
  must be negotiated even for the defaults
• Suggestion Negotiations resulting in
  RDMAExtensionsYes for a session implies
  HeaderDigestNone, DataDigestNone, OFMarkerNo,
  and IFMarkerNo on all connections in that
  session
• Override both the default and explicit settings
• Proposed change Update the draft to reflect the
  suggested change

13
Scope of RDMAExtensions Key

• From section 6.3 RDMAExtensions key has
  session-wide scope
• Question Should iSER support mixed mode
  sessions
• Argument for
• Open an iSCSI connection when there are
  insufficient resources to support an
  iSER-assisted connection in allegiance
  reassignment and the session is in iSER-assisted
  mode
• Flexibility on general principles
• Argument against
• RFC 3720 assumes homogeneous connections in a
  session
• Introducing mixed mode sessions would require
  that the RFC3720 semantics be carefully thought
  through to ensure correctness
• The task states maintained by an iSCSI connection
  may be different from those for an iSER-assisted
  connection
• iSER-assisted connection may require different LO
  key values for optimization compared with iSCSI
  connection
• Test and debug effort will increase 2x to 3x for
  mixed mode support
• Proposed change None

14
Clarification on the Order of RDMAExtensions Key
Negotiation

• From section 6.3 If the RDMAExtensions key is
  to be negotiated, it must be offered only on the
  initial Login Request PDU or Login Response PDU
  of the leading connection, and if offered, the
  response must be sent in the immediately
  following Login Response or Login Request PDU
  respectively.
• Question Clarify when the negotiation response
  is to be returned if the key is offered in a PDU
  where the C-bit is set
• Question Clarify that the negotiation takes
  place in the LoginOperationalNegotiation stage of
  the leading connection
• Question Section 5.2.2 of RFC3720 states that a
  response is optional if the Boolean function is
  "AND" and the value "No" is received
• iSER draft always requires a response to be
  returned
• However, since the default for RDMAExtensions is
  no, it is unlikely that the key-value pair of
  RDMAExtensionsno will be offered

15
Clarification on the Order of RDMAExtensions Key
Negotiation (cont.)

• Proposed change Replace sentence with However,
  if the RDMAExtensions key is to be negotiated, an
  initiator MUST offer the key on the first Login
  Request PDU in the LoginOperationalNegotiation
  stage of the leading connection, and a target
  MUST offer the key on the first Login Response
  PDU with which it is allowed to do so (i.e., the
  first Login Response issued after the first Login
  Request with the C bit set to 0) in the
  LoginOperationalNegotiation stage of the leading
  connection. In response to the offered keyvalue
  pair of RDMAExtensionsyes, an initiator MUST
  respond on the next Login Request PDU with which
  it is allowed to do so, and a target MUST respond
  on the next Login Response PDU with which it is
  allowed to do so.

16
Order of RDMAExtensions Key Negotiation Response

• From section 6.3 RDMAExtensions key must be
  offered for negotiation in the first PDU that a
  node is allowed to do so and the response must be
  returned in the immediately following PDU in
  which a node is allowed to respond
• Question Why must the RDMAExtensions key be
  negotiated first?
• Negotiating the RDMAExtensions key first allows a
  node to optimally negotiate the value of other
  keys
• Certain iSCSI keys such as MaxBurstLength,
  MaxOutstandingR2T, ErrorRecoveryLevel,
  InitialR2T, ImmediateData, etc., may have
  different optimization points depending on
  whether iSER-assisted mode is to be enabled in
  the iSCSI session
• Proposed change Update the draft to include the
  rationale for the order requirement

17
Key Ordering Within a PDU

• From section 6.3 The RDMAExtensions key must
  precede any other login keys which may be
  affected by the outcome of the negotiation of the
  RDMAExtensions key
• Question This can be interpreted as requiring
  key ordering within a PDU which is contrary to
  RFC3720
• Proposed change Remove the sentence from the
  draft

18
iSER Flow Control

• For RDMA Send Type Messages
• The iSER protocol does not provide additional
  flow control beyond that provided by the iSCSI
  layer on control-type PDUs
• An implementation should be able to take
  advantage of iWARP Verbs mechanisms such as the
  Shared Receive Queue mechanism to effectively
  address the Send Message flow control question
• For RDMA Read Resources
• In the iSER Hello Message, the iSER layer at the
  initiator declares the maximum number of RDMA
  Read Requests that the initiator can receive on
  the particular RDMAP Stream (iSER-IRD) to the
  target
• This allows the iSER layer at the target to
  adjust its resources if it can issue more RDMA
  Read Requests than the initiator can handle
• In the iSER HelloReply Message, the iSER layer at
  the target declares the maximum number of RDMA
  Read Requests that the target can issue on a
  particular RDMAP Stream (iSER-ORD) to the
  initiator
• This allows the iSER layer at the initiator to
  adjust its resources if it can handle more RDMA
  Read Requests than the target can issue
• The iSER layer at the target will flow control
  the RDMA Read Request Messages to not exceed
  iSER-ORD

19
Flow Control for Control-Type PDU

• From section 8.1 The iSER Layer SHOULD
  provision enough Untagged buffers for handling
  incoming RDMAP Send Message Types to prevent a
  buffer underrun condition
• Question Should some form of send side flow
  control be established for iSCSI control-type
  PDUs?
• Latest DDP draft, draft-ietf-rddp-ddp-02, no
  longer mandates that a DDP stream be disabled for
  a buffer underrun condition
• Proposed change Further discussion is needed
