Statistics for Proficiency Testing

1
Statistics for Proficiency Testing

• Hong Kong Accreditation Service
• 10 September, 2009
• Daniel Tholen, M.S.

2
Overview of Statistical Methods

• Requirements for statistical methods from ISO/IEC
  17043
• Overview of statistical procedures in the major
  standards
• Determining the assigned value
• Determining the performance score
• Checking homogeneity and stability
• Examples from ISO, APLAC PT, class

3
Overview of Modules 2-4

• Cover all areas of PT
• Chemical testing
• Medical testing
• Calibration
• Concepts and procedures cover inspection
• Practical application with examples from PT
  projects.

4
Documents for PT Statistics

• ISO/IEC FDIS 17043 Conformity Assessment
  General requirements for Proficiency Testing (was
  Guide 43-1)
• ISO 13528 Statistical Methods for use in
  Proficiency Testing by Interlaboratory
  Comparisons
• IUPAC Harmonized Protocol for PT of Chemical
  Analytical Laboratories, 2006
• Previous APLAC Statistical procedures

5
ISO/IEC 17043 Annex B

• Same basic methods as ISO/IEC Guide 43-1 Annex A
  on Statistical Methods
• Adds considerations for semi-quantitative and
  categorical data
• Main topics
• Determine Assigned Value
• Calculate Performance Statistic
• Evaluate Performance
• Determination of Homogeneity and Stability

6
17043 Annex B

• References ISO 13528 (2005) and IUPAC Harmonized
  Protocol (2006)
• Adds considerations for GUM

7
ISO 13528

• Companion to ISO Guide 43-1, Annex A
• Written as a Standard
• High interest / widely used
• Goal is to describe optimal procedures, but to
  allow other procedures as long as they are
• Statistically valid
• Fully described to participants

8
ISO 13528

• Written by ISO TC69, SC6
• Approved work item in 1997
• Published in 2005
• Reaffirmed in 2009
• Proposal to revise for ISO/IEC 17043
• Correction for discovered gaps
• Add qualitative and ordinal data
• Harmonize with GUM and VIM
• Other? from Seminar?

9
Reporting considerations ISO 13528, section 4.6

• Possible conflicts with requirement for
  laboratories to treat and report PT same as for
  customer
• NO TRUNCATED RESULTS (!!??)
• Less than values not allowed
• Possible resolution
• Restriction only applies to consensus

10
Reporting considerations ISO 13528, section 4.6

• Rounding
• Independently estimate typical repeatability sr
• Do not round digits by more than sr/2
• Number of replicates
• Concern for getting accurate estimate of bias
• When a methods repeatability is large, it can
  confuse interpretation of scores
• Determine number n of replicates so that
• sr /vn lt 0.3sP

11
Limiting the effect of repeatability Example

• Say sP5 and sr 2
• Then sr /vn lt 0.3sP
• So 2/vn lt 0.3(5) or
• 2/1.5 lt vn ? (1.77)2 lt n ? 3.13 lt n
• Or n4 replicates
• This criterion can lead to large n replicates.

12
IUPAC Harmonized Protocol (2006)

• Available free at IUPAC website
• Revision of 1996 Version
• Update to ISO 13528
• Revises selected portions
• Homogeneity criteria
• Detection of bimodality (kernal analysis)
• Strong opinions

13
APLAC PT Committee

• Historically followed NATA (Australia) procedures
• Convention gradually changing to ISO 13528 and
  IUPAC
• No standard procedures
• Statistically valid
• Explained to participants

14
(No Transcript)
15
Requirements for Statistical Methods ISO/IEC
17043

• 4.4.1.4 Access to the necessary technical
  expertise, including statistics
• 4.4.3.2 Procedures for ensuring homogeneity and
  stability in accordance with appropriate
  statistical designs, including random selection
  of items

16
Statistical Methods in 17043 4.4.4 Statistical
Design

• 4.4.4.1 Designs shall meet the objectives of the
  scheme, based on the nature of the data
• NOTE 1 Covers the process of planning,
  collection, analysis and reporting
• NOTE 2 Data analysis methods could vary from the
  very simple to the complex
• NOTE 3 Statistical design and data analysis
  methods can be taken directly from specifications
  by regulatory agencies or customers.
• NOTE 4 In the absence of reliable information, a
  preliminary interlaboratory comparison can be
  used.
• .

17
Statistical Design 4.4.4

• 4.4.4.2 Documented statistical design and data
  analysis methods to identify the assigned value
  and evaluate participant results. Demonstrate
  that the statistical assumptions are reasonable.

18
Statistical Design 4.4.4

• 4.4.4.3 Give careful consideration to the
  following
• the accuracy and measurement uncertainty required
  or expected
• the minimum number of participants
• number of significant figures and decimal places
• number of proficiency test items and repeat
  tests
• procedures to establish evaluation criteria
• procedures to be used to handle outliers
• procedures for the evaluation of excluded values

• the objectives to be met for the design and
  frequency of proficiency testing rounds.

19
ISO/IEC 17043 Other

• 4.4.4.5 Requirements for assigned values
  (traceability and uncertainty) calibration,
  testing, consensus
• 4.7.1 Data analysis
• 4.7.2 Evaluation of performance
• 4.8 Reports
• including summary statistics for methods used by
  other participants

20
ISO 17043 Annex B

• B.1 General
• Many types of PT, many types of data
• Reference ISO 13528 and IUPAC Harmonized Protocol
• Note that ISO 13528 allows other techniques if
  they are statistically valid and explained to
  participants

21
ISO 17043 Annex B

• B.2 Determining the assigned value and its
  uncertainty
• Definition
• 3.1 assigned value
• value attributed to a particular property of a
  proficiency test item

22
B.2 Determining the assigned value

• Various procedures available listed below in an
  order of increasing uncertainty
• known values by formulation (e.g. manufacture
  or dilution)
• certified reference values (for quantitative
  tests)
• reference values
• consensus values from expert participants
• consensus values from participants.

23
Determining the assigned value

• Procedures for qualitative data (nominal or
  categorical), or semi-quantitative values
  (ordinal) are not in ISO 13528 or the IUPAC
  Harmonized Protocol.
• Generally determined by expert judgment or
  manufacture.
• May use a consensus value, such as agreement of a
  predetermined percentage of responses (e.g., 80)
• May use median or mode, not mean

24
Determining the assigned value

• No such thing as standard deviation
• IT IS NOT APPROPRIATE to calculate the mean or SD
  of semi-quantitative values.

25
Example Semi-Quantitative

• Measurand Level of reaction, by category
• 1 no reaction, normal
• 2 mild reaction
• 3 moderate reaction
• 4 severe reaction
• 2 PT samples, A and B
• 50 participants

26
Example Semi-Quantitative

• Sample A
• 1 20 results (40)
• 2 18 results (36)
• 3 10 results (20)
• 4 2 results (4)
• Sample B
• 1 8 results (16)
• 2 12 results (24)
• 3 20 results (40)
• 4 10 results (20)

27
Responses for Samples A and B
28
Determining the assigned value

• Other considerations
• If consensus, control outliers
• If consensus, check trueness of process
• Criteria for acceptability on the basis of
  uncertainty of the assigned value (for all a.v.,
  especially consensus)

29
ISO 13528 Procedures

• Calculate Summary Statistics
• Outlier detection and removal are allowed if done
  in a statistically valid way
• Robust measures are preferred
• Mean
• SD
• Preferred robust method is given, others are
  allowed if
• Statistically valid
• Fully described to participants

30
ISO 13528 Procedures

• Determine Assigned Value
• Determined before PT shipment
• Result from formulation
• Certified reference value
• Other reference values
• Determined from PT data
• Consensus of experts
• Consensus of participants
• Control the uncertainty of the assigned value

31
13528 - Robust Analysis

• Algorithm A for mean and SD
• Starts with xmedian
• s1.483xmedianxi-x
• Limit data at x1.5s and x-1.5s
• Extreme values trimmed to 1.5s
• Option to use initial x and s and skip
  iterations
• (Per NATA and many APLAC studies)

32
13528 - Robust Analysis

• Calculate new x(Sxi)/p
• s1.134vS(xi-x)2/(p-1)
• Trim data again, at 1.5s
• Recalculate new x and s
• Repeat until convergence

33
13528 Quality check Section 5.7

• When AV is determined prior to PT
• Compare AV with robust mean or results
• Determine uncertainty of comparison ud
• If difference exceeds 2ud then investigate
• When AV is determined from consensus
• Compare AV with a reference value from a
  competent laboratory (could come from homogeneity
  data)
• Compare robust SD with experience

34
Determine the Standard Uncertainty of the
Assigned Value

• Determined before PT shipment
• Result from formulation
• Uncertainty per manufacture process, usually very
  small relative to measurement uncertainty
• Certified reference value
• Uncertainty provided with certificate
• Other reference values
• Uncertainty calculated per GUM or other procedure

35
Determine the Standard Uncertainty of the
Assigned Value

• Determined from data in PT shipment
• Consensus of expert laboratories (p of them)
• Each lab should know their MU, and report it
• ux 1.25(v(Sui2))/p for robust mean (median)
• Caution about bias in experts
• Consensus of participants (p of them)
• Calculate robust mean and SD (s)
• ux 1.25(s)/vp
• Caution about bias due to method mix
• Caution about lack of consensus

36
Limiting the uncertainty of the Assigned Value
(X) 13528 Section 4.2

• Establish limits for uncertainty of AV
• u(X) lt 0.3sP
• When using fixed limits (E)
• u(X) lt 0.3(E/3)
• u(X) lt E/10

37
Limiting the uncertainty of the Assigned Value
(X) 13528 Section 4.2

• If this cannot be met then
• Look for a better way to determine AV
• Incorporate uncertainty in score
• z
• En
• zeta
• Advise participants of large uncertainty

38
(No Transcript)
39
Limiting the uncertainty of the Assigned Value
(X) Example

• When consensus mean and SD are used to determine
  performance
• Then u(X) SD/vn
• So one can have very small uncertainty with large
  number of labs.
• What n is needed to assure criterion is met?

40
Limiting the uncertainty of the Assigned Value
(X) Example

• What n is needed to assure criterion is met?
• Need 1/vn lt 0.3, or n gt (1/0.3)2 or n12
• If n11, then cannot meet criterion.
• If robust mean is used ngt 1.25 (11) or
• n 14

41
B.3 Calculating performance statistics

• Quantitative results
• D and D
• Z, z
• En, Zeta
• Qualitative/semi-quantitative results
• Combined performance scores

42
Calculate Performance Statistic

• Estimates of bias
• Difference D(x-X)
• Percentage Difference D100(x-X)/X
• D and D can be evaluated with Fixed Limits
• Estimates of Relative Performance
• rank or percentage rank (not recommended)
• z score (recommended) z(x-X)/s

43
Determine Performance Interval

• Fixed Limits (or Fitness for Purpose)
• Can come from methods for SD
• Not widely used
• Preferred for interpretation
• Fixed percentage across range
• Fixed value across range
• Mixed or segmented.

44
SD for Proficiency Assessment

• SD for proficiency sP
• 5 ways to get SD for Proficiency (for z scores)
• By prescription (set by Accreditor or advisors)
• By experience (perception) of experts
• From a general model (e.g.,Horwitz)
• By a precision experiment (ISO 5725-2)
• From participant data (robust SD)
• Should be chosen as fitness for purpose, under a
  common model for all analytes

45
SD for proficiency testing

• Discussed in detail in section 6 of 13528
• SD as used in z scores
• Can also be thought of as 1/3 of evaluation
  interval
• (when zgt3 is action signal)
• For example if fixed interval is E 10...
• Then E 3 sP
• sP E/3 10/3 3.3

46
Scores that use uncertainty

• En and zeta consider uncertainty of participant
  result and assigned value
• Requires consistent determination of uncertainty
  by all laboratories
• En in common use in calibration
• z uses uncertainty of assigned value only
• Useful when too much uncertainty in assigned
  value.
• Same as z when small uncertainty

47
Scores that use uncertainty

• En score (Error, normalized)
• En (x-X)/v(U2labU2ref)
• z scores (like z, includes ux)
• z (x-X)/v(s2u2X)
• zeta scores (like En, but with std. uncertainty)
• Zeta (x-X)/v(u2labu2ref)

48
Evaluate performance

• Compare performance statistic against criteria,
  determine acceptability i.e.,
• For fixed limits
• Bias lt Limit ? acceptable
• Bias Limit ? unacceptable

49
Evaluate performance

• Compare performance statistic against criteria,
  determine acceptability i.e.,
• For z z zeta
• -2lt z lt2 ? acceptable
• -3lt z -2 or 2 z lt3 ? warning signal
• z -3 or z 3 ? unacceptable

50
Evaluate performance

• En lt1 ? acceptable
• En 1 ? unacceptable

51
Combined performance scores

• Analyze data for each item independently
• Special process for Youden pairs
• Can be other reasons to combine results
• Precision
• Linearity
• Can count number of satisfactory scores
• Not recommended to combine performance scores
  (such as average z)

52
Graphic Reports for PT round

• Rank vs. Result (with or without MU)
• Used to check Normal distribution
• Used to visualize data

53
(No Transcript)
54
(No Transcript)
55
Graphic Reports for PT round
56
Graphic Reports for PT round

• Histograms of results or scores

57
(No Transcript)
58
(No Transcript)
59
Combined Performance Scores

• Generally discouraged in 17043 and 13528
• Can miss problem on one sample or measurand
• OK only for statistics that have the same
  distribution (rare) sometimes true for
  performance scores.

60
Graphic Reports for PT round

• Bar plot of standardized performance statistics
  (z h k)
• z, or other standardized scores ( error)
• h and k plots from 5725
• h same as z, except always from sample SD
• k for repeatability (n2 replicates)

61
(No Transcript)
62
Graphic Reports for PT round

• Youden plot (usually w/median lines)
• In this document uses only z scores.
• Should use sample results, for clarity
• Provides evidence of related results, which can
  suggest consistent bias
• Consistent bias can suggest lack of clearly
  defined method.
• Confirm with rank correlation test.

63
(No Transcript)
64
Youden Plot Example
65
(No Transcript)
66
(No Transcript)
67
Graphic Reports for More than One PT Round

• Line plot (Shewhart plot) for scores on previous
  rounds
• Use any standardized score
• Show evaluation intervals
• Show test dates

68
(No Transcript)
69
Graphic Reports for more than One PT Round

• Dot Plot
• Show all samples on same chart
• Show evaluation intervals
• Show dates or scheme codes

70
(No Transcript)
71
Graphic Reports for More than One PT Round

• CUSUM control chart
• Can show trends affecting bias
• Choose some number to use (rolling sum)
• Sums should trend to zero
• Not sensitive to current problems

72
(No Transcript)
73
Graphic Reports for More than One PT Round

• Plot of Standardized Laboratory Biases against
  assigned value
• Shows relationship between score and level
• Can mask time effectdo both

74
(No Transcript)
75
Demonstration of homogeneity and stability in
17043

• Ensure sufficient homogeneity so as to not impact
  evaluation of performance
• Different needs for determining HS in PT and in
  for Reference Materials (ISO Guides 34 and 35)
• PT (and RM) needs to ensure sufficient
• CRM needs to estimate SD between samples, and
  instability as part of uncertainty of assigned
  value

76
Homogeneity - 13528

• Homogeneity
• 10 or more samples, 2 replicates
• SDS for samples (ANOVA calculation)
• SDS lt 0.3 sP
• No F test
• Can use experience to reduce testing
• When evidence and theory prove homogeneous

77
Homogeneity IUPAC (2006)

• Similar to 13528, larger criterion for
  acceptance, more complex statistics.
• 10 or more samples, in duplicate
• Sufficient repeatability san lt 0.5sp
• Cochran test for duplicates
• Visual check for anomalies
• Non-random differences between replicates
• Time trend across manufacture

78
Homogeneity IUPAC (2006)

• Calculate variances
• S2an (between replicates)
• S2sam (between samples)
• s2all (0.3sp)2
• Calculate acceptance criterion
• Take F1 and F2 from Tables
• c F1s 2all F2s2an
• If S2sam lt c then acceptable homogeneity
• Since F1gt0 and s2angt0 and s2all 13528
  criterion, this is always an easier criterion

79
Homogeneity - traditional

• F test (allowed, not recommended)
• F (SDS2/sr2)
• Sr repeatability SDS ANOVA treatment
• Fcrit F(.05,k-1, s(n-1)) k samples n
  replicates
• High Sr ?insensitive test (large SDS passes)
• Low Sr ?too sensitive test (small SDS fails)

80
Stability - 13528

• Stability
• Analysis on or after closing date
• (2-)3 samples, (1-)2 replicates, depending on
  experience
• Calculate overall mean
• Mean(H) Mean(S) lt 0.3 sP
• No statistical t test
• High Sr ?insensitive test (big difference passes)
• Low Sr ?too sensitive test (small difference
  fails)

81
Stability - practical

• Can use experience and technical knowledge
  (backed by data)
• Same measurand, same manufacture process, same
  matrix
• For calibration artefact, homogeneity and
  stability are usually the same

82
APLAC (NATA) Robust procedure

• Calculate Quartiles Q1, median, Q3
• IQR Q3-Q1
• Median is an estimate of mean
• Normalized IQR is an estimate of SD
• IQRN 0.7413 x IQR

83
APLAC performance statistics

• Calculate relative performance measures
• Between lab agreement
• Si (AiBi)/v2
• Within lab agreement
• Di (Ai-Bi)/v2 if median (Ai)gtmedian(Bi)
• (Bi-Ai)/v2 if median(Ai)ltmedian(Bi)
• Calculate z-scores for these measures

84
(No Transcript)
85
The End

• Thank you!
