Evaluating in vivo Biomarkers with
Multi-Modality Molecular Imaging
2
Biomarkers and Surrogate Endpoints
Biomarker A laboratory measurement or physical
sign used as an indication for a clinically
meaningful endpoint. Surrogate Endpoint A
laboratory measurement or physical sign used as a
substitute for a clinically meaningful endpoint.
Clinically Meaningful Endpoint
Surrogate Endpoint
Disease
Ideal Relationship Therapy induces change
surrogate endpoint, which reflects changes in
clinically meaningful endpoint.
3
Biomarkers and Surrogate Endpoints
Biomarker A laboratory measurement or physical
sign used as an indication for a clinically
meaningful endpoint. Surrogate Endpoint A
laboratory measurement or physical sign used as a
substitute for a clinically meaningful endpoint.
Clinically Meaningful Endpoint
Surrogate Endpoint
Disease
Failure 1 Surrogate Endpoint not in causal
physiologic pathway. Example Focal white matter
lesions identified by MRI may not be responsible
for secondary progression in Multiple Sclerosis.
4
Biomarkers and Surrogate Endpoints
Biomarker A laboratory measurement or physical
sign used as an indication for a clinically
meaningful endpoint. Surrogate Endpoint A
laboratory measurement or physical sign used as a
substitute for a clinically meaningful endpoint.
Clinically Meaningful Endpoint
Surrogate Endpoint
Disease
Failure 2 Surrogate Endpoint not in only causal
physiologic pathway. Example Some types of
chemotherapy can shrink tumors, but this has no
effect on metastasis and survival.
5
Biomarkers and Surrogate Endpoints
Biomarker A laboratory measurement or physical
sign used as an indication for a clinically
meaningful endpoint. Surrogate Endpoint A
laboratory measurement or physical sign used as a
substitute for a clinically meaningful endpoint.
Clinically Meaningful Endpoint
Disease
Surrogate Endpoint
Failure 3 Surrogate Endpoint not in therapeutic
pathway. Example CXR reduces pneumonia, but no
short-term improvement in lung MRI.
6
Biomarkers and Surrogate Endpoints
Biomarker A laboratory measurement or physical
sign used as an indication for a clinically
meaningful endpoint. Surrogate Endpoint A
laboratory measurement or physical sign used as a
substitute for a clinically meaningful endpoint.
Clinically Meaningful Endpoint
Surrogate Endpoint
Disease
Failure 4 Therapy acts after Surrogate
Endpoint. Example Recombinant Tissue Plasminogen
Activator rescues at risk tissue after ischemic
stroke, but no short-term improvement in MRI.
7
Biomarkers and Surrogate Endpoints
Biomarker A laboratory measurement or physical
sign used as an indication for a clinically
meaningful endpoint. Surrogate Endpoint A
laboratory measurement or physical sign used as a
substitute for a clinically meaningful endpoint.
Clinically Meaningful Endpoint
Biomarker
Disease
Biomarker
Molecular Signature Multiple Molecular Biomarkers
MARTY PAGEL
Molecular Signatures may require 10 Molecular
Biomarkers
8
Biomedical Imaging of Molecular Biomarkers
Reduces Animal Sacrifices
Conventional Serial Sacrifice
1 day
2 days
4 days
7 days
Molecular Imaging
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
1 day
2 days
4 days
7 days
9
Biomedical Imaging of Molecular Biomarkers
Provides Better Sampling Over Time
Conventional Serial Sacrifice
day 1
day 2
day 3
day 4
day 5
day 6
day 7
day 8
Molecular Imaging
day 1
day 2
day 3
day 4
day 5
day 6
day 7
day 8
10
Biomedical Imaging Modalities
No single modality is best for all molecular
biomarkersA trade-off between Resolution and
Sensitivity
11
Biomedical Imaging Modalities
12
Drug Discovery Development Pipeline
in vivo Pre-Clinical Testing is a critical
bottleneck

• 4 - 7 years
• Avg 478M

Clinical 200M Marketing gt 1B

• 2 - 3 years
• Avg 220M

• 1 - 2 years
• Avg 115M

in vitro Compound Screening
in vivo Pre-Clinical Testing
Target ID
Clincal Phase I
Clincal Phase II
Clincal Phase III
Clincal Phase IV

• In vivo Pre-clinical High Throughput Screening
  (HiTS)
• 22,000 25,000 human genes
• screening 1 dominant gene 20,000 animals
• screening 1 recessive gene gt 20,000 animals
• 5,000 10,000 drug targets
• screening 1 drug target 8,000 animals (plus
  1,000-3,000 humans for FDA-approved drug)

13
Drug Discovery Development Pipeline
in vitro Compound Screening
in vivo Pre-Clinical Testing
Target ID
Clincal Phase I
Clincal Phase II
Clincal Phase III
Clincal Phase IV
14
Molecular Imaging Visual representations of
cellular and molecular processes within intact
living organisms
Radiology
Molecular Imaging
Cell / Molecular Biology
Chemistry

• Multi-Modal Molecular Imaging
• Multiple agents in 1 animal in 1 detector
• 1 agent in multiple animals in 1 detector
• 1 agent in 1 animal in multiple detectors
• Multiple agents in multiple animals in multiple
  detectors

15
Multiple agents in 1 animal in 1 detector
16
Multiple agents in 1 animal in 1 detector
Predicting Topotecan Chemotherapy ResponseUsing
two PET imaging agents
Multi-SPECT agents Tc-99 In-111 I-125
Topo- red FDG black Drug and disease do not
coincide
FDG shows cancer
Topotecan chemotherapy Shows location of drug
Ray Muzic, Ph.D., CWRU
17
Multiple agents in 1 animal in 1 detector
NMR Spectrum
PARACESTPARAmagnetic Chemical
ExchangeSaturation Transfer
RF Saturation
RF Saturation
RF Saturation
NH
H2O
Tm-DOTAM-Gly
O
N
H
H
O
O
O
N
H
O
H
N
N
O
Tm
O
without sat.
without sat.
N
N
H
N
H
O
with sat.
with sat.
O
O
O
H
H
H
N
O
HOH
HOH
18
Multiple agents in 1 animal in 1 detector
PARACEST MRI Detection of Enzyme Activity
deconvolutions
PARACEST MRI
after reaction
before reaction
2nd agent(control agent)
19
Multiple agents in 1 animal in 1 detector
PARACEST MRI detection of pH
amide
Yb-DO3a-oAA
amine
amine
amide
PARACEST
H
N
pH
tumor
pH Map
water
8
pH 6.9 with agent
7
6
20
Multiple agents in 1 animal in 1 detector
PARACEST MRI detection of pharmacokinetics
(Eu-DOTAMGly)96-G5 PAMAM Dendrimer
Tat-DEVD-(Tm-DOTA)
MR Water Signal
-51 ppm
Saturation Frequency (ppm)
flank tumor
21
Multiple agents in 1 animal in 1 detector
PARACEST MRI detection of pharmacokinetics
(Eu-DOTAMGly)96-G5 PAMAM Dendrimer
Tat-DEVD-(Tm-DOTA)
flank tumor
22
1 agent in Multiple Animals in 1 detector
Challenge 1 Limited Bore Diameter
23
1 agent in Multiple Animals in 1 detector
Approach 2 1 agent in multiple animals in 1
detector
Challenge 2 Reduced Sensitivity and/or
Resolution with larger bore diameters
PET
MRI
Mouse Scanner
Mouse Brain Images
Human Scanner
24
1 agent in Multiple Animals in 1 detector
Challenge 3 Physiological Monitoring
Secured to slide, nose cone, rectal thermometer
Placed in cradle, Pulse Oximiter, ECG,
respiration sensor, phantom
Tail vein catheter
Computer-Controlled Monitoring and Temperature
Stabilization
Side View
Top View
25
1 agent in Multiple Animals in 1 detector
Yet in vivo imaging of Multiple Animals is
possible
BLI of anti-metastatic cancer therapy
MRI of anti-angiogenic cancer therapy
treated
untreated
treated
untreated
Modality Setup time Scan Time MRI 30 min
120 min BLI 5 min 20 min
26
1 agent in Multiple Samples in 1 detector
HiTS of in vitro or ex vivo samples
HiTS of biological tissues in 24-well plates to
assess fat content2,592 samples/hour
HiTS of ex vivo legbones to assess
anti-metastatic chemotherapy 30 samples/hour
27
1 agent in 1 animal in Multiple Detectors
Two combined modalities for molecular
biomarkersA compliment between SENSITIVITY and
RESOLUTION
28
1 agent in 1 animal in Multiple Detectors
PET-CT and SPECT-CT
Detecting cell receptors with a labeled antibody
fragment
Tracking mesenchymal stem cells with a Na/I-
symporter reporter gene
PET / SPECT Molecular ImagingCT Anatomical
Imaging
Zhenghong Lee, Ph.D., CWRU
29
1 agent in 1 animal in Multiple Detectors
MRI-PET
Monitoring of anti-tumor photodynamic therapy
Monitoring of anti-tumor photodynamic therapy
Heart
Tumor
Bladder
Overlay
MRI
PET
Overlay
MRI
PET
PET Molecular ImagingMRI Anatomical Imaging
Baowei Fei, Ph.D., CWRU
Zhenghong Lee, Ph.D., CWRU
30
1 agent in 1 animal in Multiple Detectors
BLI-CT
Tracking mesenchymal stem cells in implanted
ceramic cubes
Stem Cells were transduced with Lentiviral SIN
vectors to incorporate reporter genes for BLI,
fluorescence, and PET imaging for cross-validation
BLI reporter gene
fluorescence imaging reporter gene
PET imaging reporter gene
Zhenghong Lee, Ph.D., CWRU
31
1 agent in 1 animal in Multiple Detectors
Future Directionsmolecular imaging of
complimentary biomarkers
32
