Low Power and Reliable Sensor NODE DesigN

1
Low Power and Reliable Sensor NODE DesigN

• Baeg, Sanghyeon
• Reliable high Speed Computing Lab.
• Hanyang University

2
Introduction
3
Sensor Nodes
4
Components of Sensor node
External Memory
Sensors
Micro Controller
Communication device
Power Source
5
Why low power ? (1/2)

• Energy is typically more limited in sensor
  networks than in other wireless networks because
  of the nature of the sensing devices and the
  difficulty in recharging their power sources.
• Power consumption in the sensor node is for the
  Sensing, Communication and Data Processing.
• Ex) monitoring or at detecting phenomena.
  Examples include office building environment
  control, wild-life habitat monitoring, etc.

6
Why low power ? (1/2)

• More energy is typically required for data
  communication in sensor node. Energy expenditure
  is less for sensing and data processing.
• The energy cost of transmitting 1 Kb a distance
  of 100 m is approximately the same as that for
  the executing 3 million instructions by 100
  million instructions per second/W processor

7
Why reliability ? (1/2)

• IC should perform in accordance with expectations
  for a predetermined period.
• Sudden death of sensor nodes cost replacing and
  management efforts.
• Sensor nodes are typically exposed to extreme
  environmental situations such as temperature
  changes, weathers, animals.

8
Why reliability ? (2/2)

• Mission critical sensor nodes needs high
  probability of surviving through
  self-guarding/diagnosis features.

9
Memory Low Power

• Power reduction for memories used in sensor
  network

10
Memory Reliability

• Research for cross talks in memory cells

• Increasing memory density and decreasing
  technology geometry
• ? Increasing capacitive cross talks
• Reduced reliability because of additional power
  consumption and noise paths
• ? Becomes the source of intermittent failure
• Crosstalk in marginal size is not detected by
  normal test
• ? Increasing costs for test
• Test method using negative voltage stress
• ? Testable method with low cost

11
Communication Interconnect

• Analysis for High-speed Interface Issues

12
Interface I/O Design

• Chip Schematic Test Result

13
low power micro processor

• Micro Processor(8051) as underlying uP
• Implement Processor in FPGA as initial stage with
  reduced instruction for power saving

14
Custom IP Implementation

• Customized IP Design is beneficial in low power
  design by reducing unnecessary capacitance in
  design.

15
Design and Test Environment

• Equipment for development and testing

• Logic Analyzer
• Function Generator
• BER Tester
• Oscilloscope
• Power Supply

• FPGA Board
• for Development
• Testing

16
Chip and Board design Examples

• Chip Test
• Board(Interconnection
• Testing Board)

• Memory Test Board

17
Summary

• In the second year of sensor hardware nodes
• Focused on development in low power and reliable
  sensor node system
• Currently focusing on IP development
• Will be moving to FPGA system development
• Eventually, single chip solution

18

• Thanks
