Human Health Risk Assessment Libby, MT Superfund Site

1
Human Health Risk AssessmentLibby, MT Superfund
Site

• Texas AM University
• CVEN610/PHEO650
• April 29, 2004
• Presented by Cristina Baker, Fuman Zhao,
• Dhananjay Kulkarni Robert Wilcox

2
(No Transcript)
3
I have determined that, as a first plan of
action, the Buy Water plan with ordinance at
the Libby, Montana ground water contamination
site is a cost-effective remedy, is consistent
with a permanent remedy, and as a first plan of
action provides protection of public health,
welfare, and the environment. John
G.Welles Regional EPA Administrator Septembe
r 26, 1986
4
City of Libby -- Demographics

• Population 2,626 people, 1,132 households, 669
  families
• EPA estimates a total surrounding population of
  11,000
• Ethnic Demographics
• 95.51 White
• 1.26 Native American
• 1.22 Hispanic
• 0.61 Asian
• 0.15 African American
• 0.53 from other races

5
Site Location Description

• Libby, Montana Site Lincoln County
• Name Libby Groundwater Contamination
  (aka Champion Mill Site)
• Size 1,500 acres
• Site Champion Mill and the City of Libby
• Bordering Highways, Railways Waterways
• Highways 2 40
• Burlington Northern Railroad
• Rivers Creeks
• North Kootenai River
• East Libby Creek
• West Flower Creek

6
(No Transcript)
7
Site History

• Source of Contamination arises from the abandoned
  wood treating operations of the the Stimson
  Lumber Companys Mill Site
• Wood treating operations began in 1946 and ended
  in 1969
• First reported complaint of creosote odors from
  private water well in April of 1979

8
Site History

• On site Waste water was dumped/stored in
  on-site pits. Also, stored in the pits was the
  sludge that was periodically drudged up from the
  bottom of the treatment tanks.
• Over the next twenty-three years, 45,000 cubic
  yards of soil would become contaminated with PAH,
  PCP, Creosote, and heavy metals.

9
Site History

• Site first became a concern in 1979 due to an
  increase use of well water and the installation
  of new private wells
• Field monitoring began in June 1981 (EPA, ROD
  1986)
• 32 of the private off-site ground water wells are
  known to be contaminated with PCP, VOCs, PAH
  (Creosote)

10
Site History--Timeline

• 1946-1957 J. Neils Lumber Co.
• 1957-1985 St. Regis Paper Co.
• 1979 Public complains that well water smells
  like creosote
• 1981(June) EPA begins field monitoring
• 1982 (December) Proposed NPL site
• 1983 (Spring) Phase I confirmed groundwater
  contamination
• 1983 (September) Finalized NPL site
• 1985- 1993 Champion International Corp.

11
Site History--Timeline

• 1985 (Summer) Champion International Corp.
  begins offering Buy Water plan to owners of
  identified and contaminated wells.
• 1986 (July) City of Libby enacts new groundwater
  ordinance (1344)
• 1986 (September) First ROD
• 1988 (December) Second ROD
• 1989 Champion signs Consent Decree
• 1993- Current Stimson Lumber Co.
• 1993 (September) EPA begins clean-up of lower
  aquifer

12
Cristina . . .
13
Chemicals Found at the Site

1 Attempts to set an EPA drinking water
standard have been hindered by the lack of data
and presence as a complex mixture of various
PAHs. Drinking standard listed reflects
Floridas drinking water standard.
2 No geometric mean concentration is estimated
since the compound was either detected in only
one well or only one time during the 1985
sampling program. (EPA, ROD 1986)
3 Attempts to set an EPA drinking water
standard have been hindered by the lack of data
and presence as a complex mixture of various
PAHs. Drinking standard listed reflects
Wisconsins drinking water standard.
4 An upper limit estimate of the national
background exposure (ATSDR, Public Health
Statement, August 1995)
14
Principle Contaminant Groups

• Creosote A complex mixture of gt 200 organic
  compounds and contains 85 PAHs, 12 phenolic
  compounds, 3 heterocyclic nitrogen, oxygen, and
  sulfur compounds.
• PCP (Pentachlorophenol) Initial concentrations
  detected were about 3,200 µg/L. EPA standards
  for drinking water are .022or.1 mg/L.

15
CoC Assumptions

• Arsenic and lead was isolated to only one well or
  was detected only once
• Benzo(a)pyrene will represent all known
  carcinogenic PAHs present in the soil
• Substantial contamination of ground water by PCP
  renders it a CoC
• It is assumed that contact with contaminated
  ground water would contaminate the irrigated soil

16
Chemicals of Concern
17
Principle Contaminant PCP

• Technical grade contains additional impurities
  including dibenzo-p-dioxins and dibenzofurans.
  May present actual cause for toxic effects.
• Mode of Operation Inhibits oxidative
  phosphorylation ? Increased body temperature,
  tachypnea, tachycardia.

18
PCP

• Target Organs
• Hepatocellular Degeneration
• Reproductive
• Neurological (Indirectly)
• Immune System

19
(No Transcript)
20
Secondary Contaminant Benzene

• Benzene is absorbed via inhalation, ingestions
  and skin applications. Humans can absorb up to
  80.
• Mode of Operation Targets hematopoetic organs ?
  Reduces red blood cell production ? Myeloblastic
  and erythroblastic leukemias (cancer)

21
Benzene

• Target Organs
• Hematopoetic Tissues
• Central Nervous System
• Immune System

22
Fuman . . .
23
Exposure Assessment Pathways
24
Exposure Assessment Population

• Potentially exposed population
• All 2,622 residents of the City of Libby
• Sensitive receptors
• Children
• Pregnant women

25
Exposure Assessment Exclusions

• Pathways excluded
• Air contamination
• Injection
• Major Assumption
• All residents of Libby are exposed
• Residents used contaminated well water either for
  drinking or irrigation

26
Exposure Assessment Conclusion

• The major pathway of exposure is
• Potable Water (PWI) Ingestion of contaminated
  groundwater from wells
• The secondary pathway of exposure is
• Showering and Bathing (ShB) -- Inhalation of
  aromatic vapors from steam and by dermal exposure
  (Benzene only)
• Children are at the greatest risk for both
  scenarios

27
Exposure Assessment Results
28
Dhananjay . . .
29
Risk Characterization

• Ingestion of potable water
• Hazard index for non-carcinogens

30
Risk Characterization
Libby 1986 Potable Water Non-Cancer Risks for
Adults
31
Risk Characterization
Libby 1986 Potable Water Non-Cancer Risks for
Children
32
Risk Characterization
33
Risk Characterization
Libby 1986 Potable Water Cancer Risks for Adults
34
Risk Characterization
Libby 1986 Potable Water Cancer Risks for
Children
35
Risk Characterization Summary

• LCR adults 1.26E-4
• LCR children 5.88E-5
• The following pathways contribute less than 1/100
  of a percent of the total risk when compared to
  the Potable Water scenario
• Soil Dust Ingestion
• Homegrown Vegetable Exposure/Ingestion
• Showering and Bathing Inhalation/Dermal

36
Conclusion Summary of Risks

• PCP poses the maximum carcinogenic risk
• Exposure to PCP through the Potable Water pathway
  is the primary contributor towards total
  carcinogenic risk
• Recent data shows a 53 decline in total
  carcinogenic risk after 15 years of groundwater
  remediation (Texas AM 2000 data)
• Benzene test results for the ShB pathway were not
  available in the Texas AM 2000 data

37
(No Transcript)
38
Cristina . . .
39
Libby, MT Groundwater Asbestos
http//www.highplainsfilms.org/mov/libby_t1.mov
40
QA
