Overview of Anemia - I
Morey A. Blinder, M.D. Associate Professor of
Medicine and Pathology Immunology
Department of Internal Medicine Division of
Hematology
2
Anemia

• Anemia - I
• Overview
• Laboratory testing of anemia
• Hypoproliferative anemia

• Anemia - II
• Hemolytic anemia
• Peripheral smears
• RBC transfusions

3
Hematology Consults (BJH)
Evaluations No known hematologic illness n390
(74)
4
Hematology Consults (BJH)
Treatment of known hematologic illness n135 (26)
5
Hematology Inpatient Consults (BJH)
Evaluation of anemia (n79)
9
13
18
60
6
Regulation of Erythropoiesis
Kidney
Epo mRNA
Epo
Oxygen sensor
Blood vessel
7
Anemia

• Understanding anemia
• Disease - to be treated on its own merits
• Condition - a secondary manifestation of another
  disease
• Causes
• Decreased production
• Blood loss
• Hemolysis

8
Classification of Anemia

• Acute vs. chronic
• Signs and symptoms
• Red cell kinetics
• Determined by reticulocyte count
• Red cell size
• Determined by MCV

9
Laboratory Evaluation of Anemia

• Complete blood count
• Reticulocyte count
• Peripheral smear

10
Reticulocyte Count

• Relative reticulocyte count
• of all RBC (normal 0.8-1.5)
• Absolute reticulocyte count
• Relative reticulocyte count x RBC count
• Normal 50,000-75,000/µl
• Examples

1.1 x 4.96 x106 55,000/ml 12..2 x 2.05 x106
250,000/ml
11
Classification of Anemia Based on RBC Kinetics
and Size
MCV
Microcytic Normocytic
Macrocytic Low Common Common
Common High Uncommon Common Uncommon
Retic count
12
Microcytic Hypochromic Anemia Diagnosis

• Mild (MCV gt 70 fl)
• Iron deficiency
• Thalassemia
• Lead toxicity
• Sideroblastic anemia
• Anemia of chronic disease

• Severe (MCV lt 70 fl)
• Iron deficiency
• Thalassemia

13
Thalassemia Impaired globin gene prouction
Hgb A tetramer
14
Globin chain synthesis
Development period
Globin chain component
a cluster - chromosome 16
of adult Hgb
Hgb name
a1
a2
z
z2e2 Gower 1 z2g2 Portland Embryonic a2e2 Gower
II a2g2 F Fetal lt1 a2d2 A2 1.5-3.5 Ad
ult a2b2 A gt95
e
Gg
d
b
Ag
b cluster - chromosome 11
15
Thalassemia

• Decreased production of normal globin chains
• a thalassemia deficiency of a gene(s)
• b thalassemia deficiency of b gene(s)

16
Alpha Thalassemia Laboratory Findings

• Hemoglobin
• ? chains Hgb (g/dl) MCV (fl) RDW Analysis
• ??/?? Normal Normal Normal Normal
• ??/-? 12-14 75-85 Normal Normal
• ?-/?- or 11-13 70-75 Normal with
• -/?? Hgb Barts
• -/- ? 7-10 50-60 Normal with
• Hgb Barts
• - -/- - - - - Not viable

17
Alpha Thalassemia Clinical features

• Absence of 1-2 alpha chains
• Common
• Asymptomatic
• Does not require therapy
• Absence of 3 alpha chains
• Microcytic anemia (Hgb 7-10)
• Splenomegaly
• Absence of 4 alpha chains
• Hydrops fetalis (non-viable)

X
X
X
X
X
X
X
X
X
X
X
X
18
Beta Thalassemia
Clinical Hgb Syndrome Genotype Hgb
(g/dl) analysis
Minor (Trait) ?/? or ?/? 10-13 Hgb A2,
Hgb F Intermedia ?/? 7-10 Hgb A2,
Hgb F Major (Cooleys) ?/? or ?/?
lt 7 Hgb A2, Hgb F
19
Iron Deficiency Anemia

• A world-wide problem
• 3 of toddlers age 1-2 years
• 2-5 of women of child bearing age
• Iron metabolism
• Iron stores
• Laboratory findings of iron deficiency
• Causes of iron deficiency
• Treatment

20
Body Iron Distribution and Storage
Duodenum
Dietary iron
(average, 1 - 2 mg
Utilization
Utilization
per day)
Plasma
transferrin
(3 mg)
Bone
Muscle
marrow
(myoglobin)
(300 mg)
Circulating
(300 mg)
erythrocytes
Storage
(hemoglobin)
iron
(1,800 mg)
Sloughed mucosal cells
Desquamation/Menstruation
Other blood loss
(average, 1 - 2 mg per day)
Reticuloendothelial
Liver
macrophages
(1,000 mg)
Iron loss
(600 mg)
21
Major Iron Compartments

• Metabolic
• Hemoglobin 1800-2500 mg
• Myoglobin 300-500 mg
• Storage
• Iron storage 0-1000 mg
• Transit
• Serum iron 3 mg
• Total 3000-4000 mg

22
Development of Iron Deficiency

• Depletion of iron stores Ferritin low BM
  iron absent
• Compromised iron delivery Serum iron
  low TIBC high sTfR high
• Iron deficient anemia Hgb low MCV low

23
Ferritin µg/l
Bone marrow iron stores
24
Systemic Manifestations of Iron Deficiency

• Behavioral and neuropsychiatric manifestations
• Pica (pagophagia)
• Angular stomatitis
• Glossitis
• Esophageal webs and strictures
• Koilonychia

25
Systemic Manifestations of Iron Deficiency
Glossitis
Koilonychia
Angular chelitis
26
Causes of Iron Deficiency

• Increased iron requirements
• Blood loss
• Gastrointestinal tract
• Genitourinary tract
• Blood donation
• Pregnancy and lactation

• Inadequate iron supply
• Insufficient dietary iron
• Impaired iron absorption
• Gastric surgery
• Intestinal malabsorption
• Celiac disease

27
Unexplained iron deficiencyGastrointestinal
sideropenia

• Consider in patients with relapsed/refractory
  iron deficiency
• Celiac disease
• Atrophic body gastritis
• H. pylori infection
• Gastric bypass surgery

28
Treatment with Oral Iron General Principles

• Ferrous salts are absorbed better than ferric
• All ferrous salts are absorbed to the same extent
• Ascorbic acid increases absorption and toxicity
• Iron is absorbed best on an empty stomach
• Iron should not be given with antacids
• Iron polysaccharide complex (Niferex) seems to be
  better tolerated than other iron salts

29
Use of Parenteral Iron

• Agents available
• Iron dextran (total dose replacement 1/300
  anaphylaxis)
• Iron polysaccharide (125 mg/d maximum 1/1000
  anaphylaxis)
• Indications
• Malabsorption
• Iron-limited response to erythropoietin
• Toxicity/noncompliance with oral iron
• Response
• Maximal increase in hemoglobin synthesis
• Rapid increase in iron stores

30
Normal Hypochromic Microcytic
31
Hypochromia without Anisocytosis Thalassemia
Trait
32
Severe Hypochromia Iron Deficiency Anemia
33
Mixed Population Treated Iron Deficiency Anemia
34
Microcytic Hypochromia Alpha Thalassemia (?-/--)
35
Microcytic Hypochromia Beta Thalassemia Major
36
Microcytic Hypochromia Beta Thalassemia Major
37
Normocytic Anemia with Low Reticulocyte Count

• Decreased stimulation of bone marrow
• Anemia of chronic disease
• Chronic renal insufficiency
• Metabolic disorders
• Isolated decrease in RBC precursors
• Bone marrow damage
• Fibrosis
• Stem cell damage
• Infiltration with tumor/infection
• Intrinsic bone marrow disease
• Myelodysplasia/sideroblasticanemia

38
Distinguishing iron deficiency from other anemias
with low reticulocyte count

• Decreased stimulation of RBC production in bone
  marrow
• Beta thalassemia
• Anemia of chronic disease
• Chronic renal insufficiency
• Isolated decrease in RBC precursors (Red cell
  aplasia)
• Bone marrow damage
• Fibrosis
• Stem cell damage
• Infiltration with tumor/infection
• Intrinsic bone marrow disease
• Myelodysplasia/sideroblastic anemia

39
Anemia of Chronic Disease

• Associated conditions Prevalence
• Infection 20-95
• Viral, bacterial, TB, parasitic, fungal
• Autoimmune disease 8-17
• RA, SLE, Sarcoidosis, IBD, Vasculitis
• Cancer 30-77
• Chronic solid organ rejection 8-70
• Characteristics
• Anemia of variable severity (mild-severe)
• Low erythropoietin level
• Low reticulocyte count
• WBC and platelet counts are normal

40
Laboratory diagnosis of iron deficiencySerum
transferrin receptor (STfR)

• Transferrin receptor located on surface of
  erythroid precursors in bone marrow
• Small amount of transferrin released into
  circulation (sTfR)
• Iron deficiency anemia associated with increased
  sTfR

41
sTfR Distinguish iron deficiency from other
hypoproliferative anemias
Overall results of sTfR Sensitivity
100 Specificity 69 Accuracy 88
42
Iron Transfer Between Cells and TissuesImpaired
in Anemia of Chronic Disease
X
X
Blocked in Anemia of chronic disease
Hentze, et.al, Cell 117 285 (2004)
43
Iron Transfer Between Cells and TissuesMediated
by Hepcidin
Iron overload Anemia of chronic disease Iron
deficiency Increased iron demand (hemolysis)
Hepcidin
Hentze, et.al, Cell 117 285 (2004)
44
Summary

• Hepcidin plays a pivotal role in control of iron
• Increased hepcidin Anemia of chronic disease
• Decreased hepcidin Hemochromatosis
• Decreased hepcidin transcription in liver (HFE,
  Hemojuvelin orTfR2)

45
Anemia of Chronic Disease

• Treatment options
• Underlying condition
• RBC transfusion
• Erythropoietic agent
• Iron supplement not usually indicated
• Hepcidin inhibitors (?)

46
Anemia of Chronic Renal Disease

• Characteristics
• Widespread - 8 of US population has increased
  creatinine
• 23 of patients with chronic renal disease have
  HCT 30
• Long-term anemia is a risk for LVH
• Risk factor for mortality
• Etiology
• Insufficient production of erythropoietin

47
Anemia in the Elderly

• General principles
• Anemia in elderly defined as Hgb lt13 g/dl for
  men Hgb lt 12 g/dl for women
• 3 million individuals in the US age gt65 are
  anemic
• Anemia more common in females lt75 years more
  common in males gt75 years

48
Anemia in persons age 65 years
28.0
27.5
Male Female
25
20.4
20
15
11.5
11.0
10.2
9.2
9.3
10
8.7
7.5
5
Other
Non-hispanic White
Total population
Non-hispanic Black
Hispanic
49
Distribution of types of anemia in US in persons
gt 65 years
Type of anemia Percent Blood
loss/nutritional 34 Iron deficiency B12
or Folate 20 Folate and/or B12
deficiency 14 Chronic disease (Epo
deficiency) 32 Chronic renal disease
8 Anemia of chronic disease 20 CRD
and ACD 4 Unexplained 34
NHANES III
50
Potential Mechanisms of Anemia in the Elderly

• Dysregulation of the inflammatory response
• Blunting of hypoxia/erythropoietin sensing
  mechanism
• Sarcopenia
• Alterations in the stem cells
• Decrease in sex steroids (testosterone)
• Frequent co-morbid medical conditions
• Polypharmacy

51
Pure Red Cell Aplasia

• Normocytic anemia with reticulocyte count lt 0.5
• Absent erythroid precursors in marrow
• Caused by Parvovirus B19
• Clinical setting
• Immunocompetent patients with chronic hemolysis
• Immunodeficient patients with persistent viremia

52
Pure Red Cell AplasiaParvovirus B19 in an
immunocompetent host
53
Macrocytic Anemia with Low Reticulocyte Count

• Megaloblastic anemia
• Vitamin B12 deficiency
• Folate deficiency
• Non-megaloblastic macrocytic anemia
• Liver disease
• Hypothyroidism
• Drug-induced (DNA synthesis block)
• Myelodysplastic syndrome

54
Folate and Cobalamin Daily Requirements
Diet Vitamin B12 (Cobalamin)
Folate Source Animal products Widespread Bo
dy stores 5 mg 5 mg Daily requirement 2-5
µg 50-200 µg Daily intake 10-20 µg 400-800
µg Dietary deficiency Rare Common
55
(No Transcript)
56
Metabolic Testing for the Diagnosis ofVitamin
B12 and Folate Deficiency

• High Values
• Normal Vitamin B12 Folate Deficiency
  Deficiency
• Methylmalonic Acid lt 3 gt 95 lt 3
• Homocysteine lt 3 gt 95 gt 95

57
Enteric Processing and absorption of Cobalamin
Food-Cbl
Stomach
Peptic digestion
H
Cbl R-binder
R-Cbl
Duodenum
Pancreatic enzymes
Cbl-TC complex
R-Cbl
IF Cb
OH -
Cbl-IF
Distal ileum
IF receptor
Cbl TC
Cbl-IF
58
Vitamin B12 Deficiency Common Mechanisms

• Intragastric events
• Inadequate dissociation of cobalamin from food
  protein
• Total or partial gastrectomy
• Absent intrinsic factor secretion
• Proximal small intestine
• Impaired transfer of cobalamin from R protein to
  intrinsic factor
• Usurpation of luminal cobalamin
• Bacterial overgrowth
• Diphylobothrium latum (fish tapeworm)
• Distal small intestine
• Disease of the terminal ileum

59
Pernicious Anemia

• Most common cause of vitamin B12 deficiency
• Occurs in all ages and ethnic backgrounds
• Associated with other autoimmune diseases
• Screen for thyroid disease every 1-2 years
• Pernicious anemia is a systemic disease
• Gastrointestinal tract involvement
• Neurologic involvement

60
Pernicious Anemia Laboratory Diagnosis

• Anti-intrinsic factor antibodies
• Specific but not sensitive
• Anti-parietal cell antibodies
• Sensitive but not specific
• Schilling test
• Procedure
• Absorption of radiolabeled cobalamin Intrinsic
  factor
• Measure urinary excretion of radioactivity
• Specific but not sensitive

61
Megaloblastic anemia
Macro-Ovalocytes
Hypersegmented Neutrophils
62
Treatment of Vitamin B12 Deficiency

• Parenteral cobalamin
• 1 mg/day x 7 days
• 1 mg/week x 4 weeks
• 1 mg/month for life
• Oral cobalamin
• 1 mg/day for life
