Title: Networks


1
Lecture 10
  • Networks

2
This lecture
  • Introduction.
  • Graph theory.
  • Types of Networks.
  • Path analysis.
  • Flow analysis.
  • Kevin Bacon and the spread of diseases.

3
Introduction
  • Types of networks
  • Vehicle / Distribution
  • Motorways, rail, electricity grid, water, nerves,
    circuits.
  • Socio-economic
  • Trade, politics, friendship.
  • Spatial-temporal
  • Timetables, zonal maps, chemical structures.
  • Almost any set of complex relationships between
    variables can be represented as a network in
    variable space.

4
Graph Theory
  • The study of networks as graphs.
  • How do we efficiently move around networks?
  • How do networks break down?
  • Can we add links to improve networks?
  • How do things spread around networks?

5
What is a graph?
  • Combination of (potentially disconnected)
    Vertices and Edges.
  • Can be Directional (sometimes called digraphs)

6
Representing networks
  • Vertices are the points on a network, edges are
    the relationships. The degree of a vertex is the
    number of edges it has connected to it.
  • Note that it is only the connections that matter,
    not how theyre draw.
  • E.g. contiguousness in maps.

7
Types of graph
  • There are various types

Complete each vertex is connected to all the
others. Regular each vertex has the same
number of edges. Simple no loops or multiple
paths.
8
Walks, Trails and Paths
  • A Walk any sequence of adjacent edges.
  • A Trail any sequence of unrepeated adjacent
    edges.
  • A Path any sequence of adjacent edges that dont
    visit the same vertex more than once.

A path that ends where it begins is called a
Cycle.
A trail, but not a path.
9
Eulerian networks
  • A graph is Eulerian is there is a trail
    containing every edge in a graph.
  • Euler solved the Königsberg Bridges problem can
    you cross all the bridges and return to your
    starting point, crossing each once and once only

A
D
B
C
10
Eulerian networks
  • A graph will contain a cycle if each vertex has a
    degree of 2.
  • A connected graph is Eulerian if, and only if,
    the degree of each vertex is even.
  • A semi-Eulerian network is the same but doesnt
    end up at its start.
  • A connected graph is semi-Eulerian when only two
    of its vertices are odd.
  • Uses
  • Designing one-way systems.
  • Designing diversions / flow alterations.

11
Fleurys Algorithm
  • How to construct a Eulerian trail in a Eulerian
    graph.
  • Start with any vertex, and travel through the
    edges, following these rules
  • As you go through each edge, mark it as taboo.
  • If you create isolated vertices, mark them as
    taboo.
  • Only use a bridge as a last resort.
  • A bridge is an edge connecting two otherwise
    disconnected graphs

12
Hamiltonian networks
  • A graph is Hamiltonian if theres a path taking
    in every vertex once only, that ends where it
    began.
  • A graph is semi-Hamiltonian if theres a trail
    taking in every vertex once only that doesnt end
    where it began.
  • Diracs Theorem
  • A simple graph with n vertices (more than two) is
    Hamiltonian if the degree of each vertex is
    greater than n/2.
  • Note that there may be more Hamiltonian
    situations.

13
Weighted graphs
  • So far weve only been interested in connections,
    but we can add strength, capacity, or length of
    connections.
  • This gives much more realistic networks, and
    allows us to study real path optimisation
    problems.

3
4
1
1
3
Path length 5
2
3
14
Path optimisation problems
  • Three major problems
  • Shortest Path Problem
  • What is the shortest path between two points?
  • Chinese Postman Problem
  • What is the shortest way around a network back to
    the start taking in each edge (imagining the
    edges to be roads of houses)?
  • Travelling Salesman Problem
  • What is the shortest way around a network back to
    the start taking in each vertex (imagining each
    to be a city)?

15
Shortest Path Problem
  • Find the shortest path across a weighted graph.

16
Shortest Path Problem algorithm
  • Move from A to B, treating all the vertices at
    each distance from the start in turn.
  • Attribute the value of the shortest path to each
    vertex to that vertex, then reassess each of its
    neighbours to see if the path is now shorter to
    them.
  • Continue until at the destination and follow back
    shortest path.

9
8
9
5
9
5
3
3
14
3
A
0
A
0
2
2
1
1
2
2
17
Chinese Postman Problem
  • Suggested by Mei-Ku Kwan
  • Find the shortest walk taking in all the weighted
    edges and coming back to the start.
  • If the graph is Eulerian we can use Fleurys
    method.
  • If not we find a semi-Eulerian trail using
    Fleurys to take in all the edges.
  • We then use the Shortest Path algorithm to find
    our way back to the start.

18
Travelling Salesman Problem
  • Find the shortest weighted path needed to visit a
    number of cities once (i.e. the shortest
    Hamiltonian path).
  • No efficient accurate algorithm.
  • Could calculate all the possible Hamiltonians and
    pick the shortest.
  • However, for 20 cities on a Hamiltonian graph,
    there are about 6 x 1016 such possible paths.
  • One solution is to use a Minimum Connector.

19
The Minimum Connector Problem
  • Work out the smallest sub-network to connect a
    set of vertices on a weighted network a
    spanning tree.
  • Choose the smallest weighted edge.
  • Continue picking the next smallest connected
    edges but not using edges that form cycles with
    the ones already picked.

3
3
3
2
2
2
1
6
1
6
1
6
5
5
5
20
The Travelling Salesman revisited
  • If we remove a vertex from a Hamiltonian path, we
    end up with a spanning tree.
  • To get an good approximation for the Travelling
    Salesman path, we
  • Remove a vertex from the graph, and its
    associated edges.
  • Form the minimum connector for the rest of the
    graph.
  • Add in the vertex and the two of its edges with
    the minimum weights.
  • This will give us a semi-Hamiltonian which the
    solution cant be better than, and which the
    solution will be close to.
  • Alternatively use AI to search the solution space.

21
Network flows strong connection
  • Strongly connected graphs are those digraphs
    where every vertex can be reach from every other.
  • A graph can be made into a strongly connected one
    if each edge is in a cycle.
  • I.e. you cant make a purely one-way system in a
    town split by a single bridge.

Strongly connected
Not strongly connected
22
Maximum Flow Minimum Cut
  • Given each part of a network has a capacity, what
    is the maximum capacity of the network?
  • It equals the minimum capacity cut of the
    graph.
  • A cut is a set of edges which a flow must pass
    through one of.

Maximum flow 6
1
5
1
9
2
7
B
A
1
3
4
Cut 3
Cut 1
Cut 2
23
Other things Graph Theory can help with
  • Finding the distribution of flow in
    interconnected networks with resistances and
    inputs/outputs.
  • Calculating whether graph lines, e.g. railways,
    need to cross.
  • Calculating the number of rearrangements possible
    between vertices on a graph.
  • The maximum number of different paths between two
    places.
  • Timetabling (using rooms and people as
    components).
  • How many colours it takes to colour a zonal map.
  • How long it takes to do a number of parallel
    tasks.
  • Magic squares.
  • Arranged marriages.

24
Summary
  • Graph theory encapsulates the mathematics of
    networks.
  • Eulerian graphs are those where you can visit all
    the edges one and end up at the start.
  • Hamiltonian graphs are those where you can visit
    all the vertices once and end up at the start.
  • The rules for these graphs help us design network
    systems.

25
Summary
  • By giving weights to edges we can model real
    dynamic systems.
  • We can find out optimal paths.
  • We can work out transport loads.

26
?? Its a small world afterall ??
  • How is it we often meet complete strangers with
    whom we have a mutual acquaintance?
  • Its said that youre only six mutual associates
    away from anyone in the world (Six Degrees of
    Separation).
  • Stanley Milgram (1967) sent packages to people in
    Nebraska and Kansas, with instructions to pass
    them to people they thought might be closer to
    targets in Massachusetts. Took an average of 5
    steps to arrive.
  • How can this be possible given the following..?
  • Every person knows only around a thousand people.
  • There are six billion people on the globe.

27
The Kevin Bacon Game
  • Can you link any actor to Bacon via co-stars in
    films?
  • Anyone whose co-starred in a film with Kevin
    Bacon has a Bacon Number of one.
  • Anyone whos been in a film with a co-star of
    Bacon has a Bacon Number of two, etc.

28
Six Degrees of Kevin Bacon
  • Peggy Mitchell has a Bacon number of three.
  • Barbara Windsor was in Comrades (1987) with
    Robert Stephens
  • Robert Stephens was in Chaplin (1992) with Diane
    Lane
  • Diane Lane was in My Dog Skip (2000) with Kevin
    Bacon
  • Frank Butcher has a Bacon number of two.
  • Mike Reid was in Snatch (2000) with Brad Pitt.
  • Brad Pitt was in Sleepers (1996) with Kevin
    Bacon.

29
Is Kevin Bacon the centre of the Universe?
  • The Internet Movie Database has 225226 connected
    films. Each film has an average number of actors
    of 61.
  • Yet the maximum Bacon Number found so far is only
    11.
  • The average number of films between any actor and
    Bacon is only 2.878 films.
  • So why is this so?
  • Because social groups are a form of network known
    as Small World graphs.

30
Small World graphs
  • A mix of strongly Clustered groups with a few
    individuals who know many groups (cause the
    social groups to overlap).
  • Fall between extremes in the level of local
    clustering and Global Path Length the average
    edges between two vertices.

Kevin
31
Characteristics of Small World graphs
  • Small World graphs have high clustering and low
    global path lengths because of the lynchpin /
    shortcut individuals.
  • Small Worlds are like Random Graphs with each
    vertex being a cluster.

Random graph connected to near and far randomly
Caveman graphs
Trees
Low clustering, Short global path
High clustering, No global path length
Low clustering, Long global path length
32
More characteristics
  • In Random and Small World graphs
  • Global Path Length is proportional to
    ln(vertices).
  • Global Path Length is inversely proportional to
    ln(associates).
  • The Global path length decreases extremely
    rapidly as lynchpins / shortcuts increase
    slightly from nothing.
  • Shortcuts cross vast areas of variable space to
    link with unexpected groups.

33
Spatial graphs
  • Graphs where the distance over which connections
    occur are much more limited because of resources.
  • Shortcuts are rare (its easier to link to nearby
    nodes than stretch to the other side of a net) so
    they rarely show Small World characteristics.
  • In such networks the Global Path Length scales
    more linearly with the number of vertices.

34
Uses of Small World theory
  • The spread of disease (Watts, 1999).
  • Spreading is controlled by
  • The length of time that someone is infectious.
  • The length of time someone is removed (sick but
    not infectious, or if infinite immune or dead).
  • The infection probability / rate between 0 and 1.
  • People are either Susceptible, Infectious or
    Removed.
  • Watts mapped the proportions of these groups in
    Small World societies and physically limited
    networks for different disease parameters.

35
Violent deadly diseasesSmall World
  • Such diseases reach equilibrium when people are
    removed faster than the disease spreads.
  • Theres a massive difference in deaths dependent
    on shortcuts.
  • Hence cutting off diseased population is vital.

1
Equilibrium fraction of Susceptible people
0
0
1
Probability of infection
Tipping point Disease takes off
Everyone dies
36
Other characteristics of disease spread
  • If the disease infects the whole population, the
    time to do so is also strongly dependent on the
    fraction of shortcuts.
  • In physically limited graphs, however, the spread
    is about the same whatever the range over which
    vertices can connect.
  • Diseases are worse in Small World situations, but
    more easily controlled.

37
Foot and Mouth daily cases
  • Cutting movements improved on 1967.
  • Cases decreased when probability of inflection
    lowered.

Source BBC / MAFF 4 May 2001
1967
24hr cull policy
50
Healthy cull policy
Initial May 5th predictions 400d-1
40
30
20
10
0
24 Feb
10 Mar
24 Mar
7 Apr
29 Apr
38
Other uses of Small World theory
  • Spread of information / fashion / memes.
  • The resilience of networks to attack.
  • The efficiency of distribution systems.

39
Software
  • Masses of software
  • E.g. Inflow
  • Network Centrality
  • Small-World Networks
  • Cluster Analysis
  • Network Density
  • Prestige / Influence
  • Structural Equivalence
  • Network Neighborhood
  • External / Internal Ratio
  • Weighted Average Path Length
  • Shortest Paths Path Distribution

40
Summary
  • Graph theory encapsulates the mathematics of
    networks.
  • Eulerian graphs are those where you can visit all
    the edges one and end up at the start.
  • Hamiltonian graphs are those where you can visit
    all the vertices once and end up at the start.
  • The rules for these graphs help us design network
    systems.

41
Summary
  • By giving weights to edges we can model real
    dynamic systems.
  • We can find out optimal paths.
  • We can work out transport loads.
  • The dynamics of networks can be strongly
    determined by the difference in local clustering
    and interconnections.
  • Small world graphs are useful for many situations
    that are partly physically controlled but also
    have shortcuts over long distances.

42
Next lecture
  • Pulling it together and doing it.
Write a Comment
User Comments (0)
About PowerShow.com
