MATLAB Second Seminar

1
MATLABSecond Seminar
2
Previous lesson

• Last lesson We learnt how to
• Interact with MATLAB in the MATLAB command window
  by typing commands at the command prompt.
• Define and use variables.
• Plot graphs

It would be nice if you didn't have to manually
type these commands at the command prompt
whenever you want to use them.
3
Problem

• Write a script that asks for a temperature (in
  degrees Fahrenheit)
• computes the equivalent temperature in degrees
  Celcius.
• The script should keep running until no number is
  provided to convert.
• use isempty

4
Solution

• while 1 use of an infinite loop
• TinF input('Temperature in F ') get input
• if isempty(TinF) how to get out
• break
• end
• TinC 5(TinF - 32)/9 conversion
• disp(' ')
• disp(' gt Temperature in C ',num2str(TinC))

• disp(' ')
• end

5
Functions

• Functions describe subprograms
• Take inputs, generate outputs
• Have local variables (invisible in global
  workspace)
• Core MATLAB (Built-in) Functions
• sin, abs, exp, ...
• Cant be displayed on screen
• MATLAB-supplied M-file Functions
• mean, linspace,
• Ca be displayed on screen
• User-created M-file Functions

6
Core MATLAB (Built-in) Functions

• Elementary built-in functions
• gtgt help elfun a list of these functions
•
• Special Math functions
• gtgt help specfun
• Special functions - toolboxes
• Each toolbox has a list of special functions that
  you can use

sin         Sine. exp         Exponential.
abs         Absolute value. round
Round towards nearest integer.
lcm         Least common multiple. cart2sph
Transform Cartesian to spherical
coordinates.
7
Structure of a Function M-file
function y mean(x) MEAN Average or mean
value. For vectors, MEAN(x) returns the mean
value. For matrices, MEAN(x) is a row vector
containing the mean value of each column. m,n
size(x) if m 1 m n end y sum(x)/m
8
Multiple Input Output Arguments
Multiple Input Arguments ( , )

• function r ourrank(X,tol)
• OURRANK Rank of a matrix
• s svd(X)
• if (nargin 1)
• tol max(size(X))s(1)eps
• end
• r sum(s gt tol)

Multiple Output Arguments ,
function mean,stdev ourstat(x) OURSTAT Mean
std. deviation m,n size(x) if m 1 m
n end mean sum(x)/m stdev sqrt(sum(x.2)/m
mean.2)

• RANK ourrank(rand(5),0.1)
• MEAN,STDEV ourstat(199)

9
nargin, nargout, nargchk

• nargin number of input arguments
• - Many of Matlab functions can be run with
  different number of input variables.
• nargout number of output arguments
• - efficiency
• nargchk check if number of input arguments is
  between some low and high values

10
Workspaces in MATLAB

• MATLAB (or Base) Workspace
• For command line and script file variables.
• Function Workspaces
• Each function has its own workspace for local
  variables.
• Name of Input/output variables can be either
  equal or different then the variable name in the
  calling workspace.
• Communicate to Function Workspace via inputs
  outputs.
• Global Workspace
• Global variables can be shared by multiple
  workspaces.
• (Must be initialized in all relevant workspaces.)

• Initialize global variables in all relevant
  workspaces
• global variable_name
• Initialize global variables in the source
  workspace before referring to them from other
  workspaces.

11
Tips for using Global Variables

• DONT USE THEM
• If you absolutely must use them
• Avoid name conflicts
• gtgtwhos global shows the contents of the global
  workspace
• gtgtclear global erases the variable from both
  local and global workspaces.
• gtgtisglobal()

12
MATLAB Calling Priority

• High
• variable
• built-in function
• subfunction
• private function
• MEX-file
• P-file
• M-file
• Low

cos'This string.' cos(8) ans r clear
cos cos(8) ans -0.1455
13
Visual Debugging
Select Workspace Set Auto- Breakpoints
Set Breakpoint Clear Breaks Step In Single
Step Continue Quit Debugging
14
Example Visual Debugging (2)

• Editor/Debugger opens the relevant file and
  identifies the line where the error occurred.

Current Location
Current Workspace (Function)
15
Example Visual Debugging (3)
Error message
Access to Functions Workspace
Debug Mode
16
Some Useful MATLAB commands

• what List all m-files in current directory
• dir List all files in current directory
• ls Same as dir
• type test Display test.m in command window
• delete test Delete test.m
• cd a Change directory to a
• chdir a Same as cd
• pwd Show current directory
• which test Display current directory path to
• test.m
• why In case you ever needed a reason

17
Problem

• Write a function that asks for a temperature (in
  degrees Fahrenheit)
• computes the equivalent temperature in degrees
  Celcius.
• The function should give an error massage in case
  no number is provided to convert.
• use nargin.

18
Solution

• function TinCtemp2(TinF)
• TinF input('Temperature in F ') get input
• if nargin0 if there is no input
• disp('no temparture was entered')
• TinCnan
• else
• TinC 5(TinF - 32)/9 conversion
• disp(' ')
• disp(' gt Temperature in C ',num2str(TinC))

• disp(' ')
• end

19
MATLAB Input

• To read files in
• if the file is an ascii table, use load
• if the file is ascii but not a table, file I/O
  needs fopen and fclose
• Reading in data from file using fopen depends on
  type of data (binary or text)
• Default data type is binary

20
What Is GUIDE?

• Graphical User Interface Design Environment
• provides a set of tools for creating graphical
  user interfaces (GUIs).
• GUIDE automatically generates an M-file that
  controls how the GUI operates.
• Starting GUIDE
• gtgt guide
• OR

Push buttons
axes
Static text
Pop-up menu
21
GUIDE Tools - The Layout Editor

• In the Quick Start dialog, select the Blank GUI
  (Default) template
• Display names of components File
  preferences Show names in component
  palette
• Lay out your GUI by dragging components
• (panels, push buttons, pop-up menus, or axes)
• from the component palette, into the layout area

Component panel
Drag to resize
Layout area
22
Using the Property Inspector

• Labeling the Buttons
• Select Property Inspector from the View menu.
• Select button by clicking it.
• Fill the name in the String field.

Activate GUI
Property Inspector
23
Programming a GUI

• Callbacks are functions that execute in response
  to some action by the user.
• A typical action is clicking a push button.
• You program the GUI by coding one or more
  callbacks for each of its components.
• A GUI's callbacks are found in an M-file that
  GUIDE generates automatically.
• Callback template for a push button

24
Handles structure

• Save the objects handles handles.objectname
• Save global data can be used outside the
  function.
• Example popup menu
• Value user choice of the popup menu
