Title Slide

1
Title Slide
Astronomy 204 Lecture 19 Spectral Classification
the HR Diagram
2
Lecture Summary

• Spectral Classification
• Balmer Thermometer
• Spectral Type
• HR Diagram
• Special Problems
• Why are bright stars bright?
• What are the most common stars?
• Distance Determination Techniques
• Main Sequence Fitting
• Spectroscopic Parallax

3
Stellar Spectrum
4
Balmer Thermometer
- Balmer absorption lines are produced by
hydrogen atoms whose electrons are in the second
energy level.

• Cool stars ? weak Balmer lines
• Hot stars ? weak Balmer lines
• Medium Temperature stars ? strong Balmer lines

5
Beyond Balmer Lines
6
Beyond Balmer Lines
You Try It Estimate the surface temperature of
a star that has very strong ionized calcium
absorption lines?
Answer 4800 K
7
Spectral Classification
The original classification was done by Annie
Cannon at Harvard Observatory 1920.
8
Example of Spectral Types
9
More Examples of Spectral Types
O and B stars have wavelength peaks in the
Ultraviolet.
A,F,G,and K stars have wavelength peaks in the
visual.
M stars have wavelength peaks in the infrared.
10
Spectral Class Chart
You Try It What is the approximate surface
temperature of a star with spectral type B5?
Answer 14,000 K
11
Shapes of Spectral Lines

• Natural Width the thin, but finite width owing
  to quantum uncertainty
• Rotational Broadening spinning blue and
  redshifts the lines
• Doppler Broadening the Doppler shift from the
  thermal motion of the molecules
• Collisional Broadening collisions spread out
  the lines, highly dependent on density

12
Rotational Broadening
13
UBV Filters

• Spectral shape on the cheap

The V designation is the apparent brightness of
an object through the V filter and is sometimes
also written as mV
14
Color Index

• The blackbody curve can be inferred from just 2
  points

15
The Sizes of Stars(Hertzsprung-Russell Diagram)
16
A Colorful HR Diagram
17
Yet Another HR Diagram
18
Lines of Equal Radius
19
Possible stellar sizes
20
Conceptual HR Diagram

• Luminosity increases upward
• Temperature increases to the left
• Radius increases to the upper right

21
Main Sequence Fitting

• Plot observed HR diagram of a cluster of stars
  (in a cluster the stars are all approximately
  the same distance)
• Assume the stars will obey the same HR
  relationship as other stars
• Adjust distance to fit the cluster onto the
  main sequence

22
Example Main Sequence Fitting
(m-M)
23
Spectroscopic Parallax

• Ia Bright Supergiant
• Ib Supergiant
• II Bright Giant
• III Giant
• IV Subgiant
• V Main-sequence star

24
Luminosity Classes
25
Spectroscopic Parallax

• Determine the spectral class of the star from the
  types of spectral lines present
• Determine the luminosity class of the star from
  the thickness of the spectral lines
• Plot the point on the HR Diagram at the
  intersection of the spectral type and luminosity
  class
• Read off M on the HR Diagram for this star
• Observe m
• Use the distance modulus m M to determine the
  distance to the star.
