Programming Languages Fundamentals

1
Programming Languages Fundamentals

• Cao Hoaøng Truï
• Khoa Coâng Ngheä Thoâng Tin
• Ñaïi Hoïc Baùch Khoa TP. HCM

2
Contents

• Evolution and classification
• Formal syntax and semantics
• Compilation and interpretation

3
Machine Language

CPU
Memory
0101001001101011
1101111001001001
I/O
0001101010101010
4
Machine Language

Instruction
Operation Code
Operands
10110011010010010011010110110001
5
Assembly Language

A B C if A 0 then body MOV r0, B move
B into register r0 ADD r0, C add MOV A, r0
store BNE L1 branch if result not equal
0 body L1
6
Language Levels

Natural Language
High-Level
Low-Level
Machine Language
7
What Makes a Good Language?

• Clarity, simplicity, unity of language concepts
• Clarity of program syntax
• Naturalness for the application
• Support for abstraction
• Ease of program verification

8
What Makes a Good Language?

• Programming environment
• Portability of programs
• Cost of use
• program execution
• program translation
• program creation, testing, use
• program maintenance

9
Language Classification

• Imperative
• von Neumann Fortran, Pascal, Basic, C
• object-oriented Smalltalk, Eiffel, C, Java
• Declarative
• functional Lisp, ML, Haskell
• dataflow Id, Val
• logic Prolog, VisiCalc

10
Von Neumann Languages

• Most familiar and successful
• Imperative statements
• Modification of variables
• Fortran, Pascal, Basic, C,

11
Object-Oriented Languages

• Imperative statements
• Message passing among objects
• Smalltalk, Eiffel, C, Java

12
Functional Languages

• Recursive definition of functions
• (lambda calculus)
• Expressions of function composition
• Lisp, ML, Haskell

13
Logic Languages

• Logical facts and rules
• (predicate logic)
• Computation as theorem proving
• Prolog, VisiCalc

14
Dataflow Languages

• Computation as token flow among nodes
• Inherently parallel model
• Id, Val

15
Contents

• Evolution and classification
• Formal syntax and semantics
• Compilation and interpretation

16
Formal Syntax and Semantics

• Computer languages must be precise
• Both their form (syntax) and meaning (semantics)
  must be specified without ambiguity
• Both programmers and computers can tell what a
  program is supposed to do

17
Formal Syntax

• Abstract syntax
• Context-free grammars
• Backus-Naur formalism (BNF)
• Syntax diagrams
• Derivations and parse trees

18
Abstract Syntax

• Syntactic class
• Syntactic form

19
Example Expressions

• Syntactic class
• E expression
• I identifier
• C constant
• O operator
• Syntactic form
• E I C E O E (E)

20
Example Expressions

• a (2 b)
• E O E

21
Example Expressions

• a - b - c
• E O E

22
Abstract Syntax

• Advantage simple
• Disadvantages
• No terminal symbols defined
• Ambiguous

23
Context-Free Grammars

• Start symbol
• Non-terminals
• Terminals
• Productions A ? a1 a2 an
• (Noam Chomsky, 1959)

24
Example Unsigned Integers

• 6 2 5 7 3
• ltdigitgt ltunsigned_integergt

25
Example Unsigned Integers

• Start symbol ltunsigned_integergt
• Non-terminals ltunsigned_integergt, ltdigitgt
• Terminals 0, 1, 2, 3, 4, 5, 6, 7, 8, 9
• Productions
• ltunsigned_integergt ? ltdigitgt ltdigitgt
  ltunsigned_integergt

26
Backus-Naur Formalism

• ltunsigned_integergt ltdigitgt ltdigitgt
  ltunsigned_integergt
• (John Backus, 1960)

27
Example Expressions

• ltfactorgt
• 12 3 4
• lttermgt

28
Example Expressions

• Start symbol ltexpressiongt
• Non-terminals ltexpressiongt, lttermgt, ltfactorgt,
• ltunsigned_integergt, ltterm_opgt,
• ltfactor_opgt
• Terminals 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, , -, ,
  /

29
Example Expressions

• Productions
• ltexpressiongt ? lttermgt ltexpressiongt
  ltterm_opgt lttermgt
• lttermgt ? ltfactorgt lttermgt ltfactor_opgt ltfactorgt
• ltfactorgt ? ltunsigned_integergt (ltexpressiongt)
• ltterm_opgt ? -
• ltfactor_opgt ? /

30
Syntax Diagrams
expression
term
expression
term_op
term
31
Derivations

• ltexpressiongt
• ? ltexpressiongt ltterm_opgt lttermgt
• ? lttermgt ltfactorgt
• ? lttermgt ltfactor_opgt ltfactorgt
  ltunsigned_integergt
• ? ltfactorgt ltunsigned_integergt 4
• ? ltunsigned_integergt 3 4
• ? 12 3 4

32
Parse Trees
ltexpressiongt
ltexpressiongt
ltterm_opgt
lttermgt

lttermgt
ltfactorgt
lttermgt
ltfactorgt
ltfactor_opgt
ltfactorgt

ltunsigned_integergt
ltunsigned_integergt
ltunsigned_integergt
3
4
12
33
Parse Trees
ltexpressiongt
ltexpressiongt
ltterm_opgt
lttermgt

lttermgt
ltfactorgt
lttermgt
ltfactorgt
ltfactor_opgt
ltfactorgt

ltunsigned_integergt
ltunsigned_integergt
ltunsigned_integergt
3
4
12
34
Formal Semantics

• Operational semantics
• Denotational semantics
• Axiomatic semantics

35
Operational Semantics

• A virtual computer to execute a program.
• A set of formally defined operations to specify
  how the internal state of the virtual computer
  may change.

36
Denotational Semantics

• Each program construct is a function that maps an
  input to an output.
• A program is a composition of functions.

37
Axiomatic Semantics

• The effect of a statement is defined via its
  precondition and postcondition.
• A set of axioms and rules to define the effect of
  program constructs.

38
Axiomatic Semantics
P S Q
precondition
statement
postcondition
39
Axiomatic Semantics

• Axiom

Px?E x E P
40
Axiomatic Semantics
x ? 2 x x 1 x ? 3
E x 1 P x gt 3 Px?E x 1 gt 3 x gt 2
41
Axiomatic Semantics

• Rule

if (P S1 Q) ? (Q S2 R) then P S1
S2 R
42
Contents

• Evolution and classification
• Formal syntax and semantics
• Compilation and interpretation

43
Compilation and Interpretation
Compiler
Source program
Target program
Target program
Input
Output
Interpreter
Source program
Output
Input
44
Compilation and Interpretation

• Interpreter better flexibility and diagnostics
• Compiler better performance

45
Phases of Compilation
Character stream
Scanner (lexical analysis)
Token stream
Parser (syntactic analysis)
Parse tree
Semantic analysis
Intermediate code
Machine-independent code optimisation
Optimised intermediate code
Target code generation
Target code
Machine-specific code optimization
Optimised target code
46
Phases of Compilation
c a b 7
Scanner (lexical analysis)
id1 id2 id3 7
Parser (syntactic analysis)
47
Phases of Compilation
id1 id2 id3 7
Parser (syntactic analysis)
48
Phases of Compilation
Semantic analysis
CNV (7, , t1) (id3, t1, t2) (id2, t2, t3) ASS
(t3, , id1)
49
Phases of Compilation
CNV (7, , t1) (id3, t1, t2) (id2, t2, t3) ASS
(t3, , id1)
Machine-independent code optimisation
(id3, 7.0, t1) (id2, t1, id1)
50
Phases of Compilation
(id3, 7.0, t1) (id2, t1, id1)
Target code generation
MOV reg, id3 MUL reg, 7.0 ADD reg, id2 MOV id1,
reg
51
Exercises

• Define a formal syntax for a simple language
  supporting only the assignment statement and
  arithmetic expressions.
• Write the derivation and draw the parse tree of
  c (a b) 7 using the defined syntax.
