Lattice QCD, RHIC, and LHC

1
Lattice QCD, RHIC, and LHC
Masayuki Asakawa
Former Aggie Department of Physics, Osaka
University
2
QCD Phase Diagram
T
QGP (quark-gluon plasma)
CP(critical point)
160-190 MeV
crossover
1st order
order ?
Hadron Phase

• chiral symmetry breaking
• confinement

CSC (color superconductivity)
mB
5-10r0
3
One of the most striking findings _at_RHIC
Possible Formation of Strongly Interacting
Matter
The beginning of the universe is a drop?
The quark is liquid
Asahi Shinbun (Newspaper), April 2005
4
Is (Q)GP really close to perfect liquid?
Two lattice calculations (Pure Gauge, Nf 0)
Meyer, 2007
Nakamura and Sakai, 2004

• Both have problems

• assumption for the spectral function
• direct inversion from Euclidean data to
  Minkowski NOT unique

Unless we know T-dependence of viscosities,
unable to discuss validity of hydrodynamical
calculation at RHIC and LHC
LQGP collaboration in progress
5
Strong coupling not necessarily perfect liq.

• Low viscosity Little momentum transport

Long range and many body correlation leads to
large viscosity
What is generally experienced in condensed matter
physics
6
Importance of Understanding Hadrons _at_Finite T

• v2M(pTM) v2 B(pTB) 2 3 for pTM pTB
  2 3

7
Constituent Quark Number Scaling

• v2M(pTM) v2 B(pTB) 2 3 for pTM pTB
  2 3

• Partons are flowing and Partons recombine to
  make mesons and baryons

Assumption
All hadrons are created at hadronization
simultaneously
8
Hadrons above Tc?
Hadrons above Tc

• No a priori reason that no hadrons exist above
  Tc
• QGP looks like strongly interacting system (low
  viscosity...etc.)

• Definition of Spectral Function (SPF)

• Information on
• Dilepton production
• Photon Production
• J/y suppression...etc.

encoded in SPF
9
Microscopic Understanding of QGP
Importance of Microscopic Properties of
matter, in addition to Bulk Properties

• In condensed matter physics, common to start
  from one particle states,
• then proceed to two, three, ... particle
  states (correlations)

Spectral Functions

• One Quark
• Two Quarks
• mesons
• color singlet
• octet
• diquarks
• Three Quarks
• baryons
• ......

10
Photon and Dilepton production rates

• Photon production rate

• Dilepton production rate

(for massless leptons)
where rT and rL are given by
rmn QCD EM current spectral function
11
Lattice calculation of spectral functions

• No calculation yet for finite momentum light
  quark spectral functions

LQGP collaboration, in progress
So far, only pQCD spectral function has been used

• Calculation for zero momentum light quark
  spectral functions by two groups

rT rL _at_ zero momentum
Since the spectral function is a real time
quantity, necessary to use MEM (Maximum Entropy
Method)
12
QGP is strongly coupled, but...
DEnterria, LHC workshop _at_CERN 2007
13
Lattice calculation of spectral functions

• No calculation yet for finite momentum light
  quark spectral functions

LQGP collaboration, in progress
So far, only pQCD spectral function has been used

• Calculation for zero momentum light quark
  spectral functions by two groups

rT rL _at_ zero momentum
Since the spectral function is a real time
quantity, necessary to use MEM (Maximum Entropy
Method)
14
Is Parametrization of SPF at finite T/m Easy?
Sometimes hear statements like
Finite T/m Spectral Functions are not always
given by shift broadening
15
A Good Example (for r meson)
and many more examples in many fields
Rapp and Wambach (1999)
Due to D-hole contribution, non-Lorentzian

• Lorentzian Assumption ab initio not justified

16
Lattice? But SPF cannot be measured ...

• Whats measured on the Lattice is
• Imaginary Time Correlation Function D(t )

K(t,w) Known Kernel
However,
c2-fitting inconclusive !

• Measured in Imaginary Time
• Measured at a Finite Number of discrete points
• Noisy Data Monte Carlo Method

Direct Inversion ill-posed !
17
Similar Difficulties in Many Areas

• Lattice

• Analytic Continuation to Imaginary Time is
  measured
• Measured at a Finite Number of discrete points
• Noisy Data

• X-ray Diffraction Measurement in Crystallography

• Fourier Transformed images are measured
• Measured at a Finite Number of data points
• Noisy Data

• Observational Astronomy

• Smeared Images due to Finite Resolution are
  measured
• Measured by a Finite Number of Pixels
• Noisy Data

18
Example of MEM Application

• Lattice

Will be shown shortly

• X-ray Diffraction Measurement in Crystallography

• Observational Astronomy

19
MEM

• Maximum Entropy Method

• a method to infer the most statistically
  probable image (such as A(w))
• given data, instead of solving the (ill-posed)
  inversion problem

• Theoretical Basis Bayes Theorem

• In Lattice QCD

20
Result of Mock Data Analysis
N( of data points)-b(noise level) dependence
21
Stat. and Syst. Error Analyses in MEM
Generally,
The Larger the Number of Data Points and the
Lower the Noise Level
The Closer the Result is to the Original Image
22
Lattice Parameters

• Lattice Sizes 323 Nt
• b 7.0, x0 3.5 x as/at 4.0
  (anisotropic)
• at 9.75 10-3 fm Ls 1.25 fm
• Standard Plaquette Action
• Wilson Fermion

• Heatbath Overrelaxation 1
  41000 sweeps between measurements
• Quenched Approximation
• Gauge Unfixed
• p 0 Projection
• Machine CP-PACS

23
Spectral Functions above Tc
at T/Tc 1.4
peak structure
spectral function
Lattice Artifact
Asakawa, Nakahara Hatsuda hep-lat/0208059
24
Another calculation
log scale!
massless quarks
smaller lattice
dilepton production rate
2 GeV _at_1.5Tc
Karsch et al., 2003
In almost all dilepton calculations from QGP,
pQCD expression has been used
How about for heavy quarks?
25
J/y non-dissociation above Tc
Lattice Artifact
J/y (p 0) disappears between 1.62Tc and 1.70Tc
Lattice Artifact
Asakawa and Hatsuda, PRL 2004
26
Result for PS channel (hc) at Finite T
hc (p 0) also disappears between 1.62Tc and
1.70Tc
Asakawa and Hatsuda, PRL 2004
27
Microscopic Understanding of QGP
Importance of Microscopic Properties of
matter, in addition to Bulk Properties

• In condensed matter physics, common to start
  from one particle states,
• then proceed to two, three, ... particle
  states (correlations)

Spectral Functions

• One Quark
• Two Quarks
• mesons
• color singlet
• octet
• diquarks
• Three Quarks
• baryons
• ......

28
Baryon Operators

• Nucleon current

• Euclidean correlation function at zero momentum

29
Spectral Functions for Fermionic Operators

• For Meson currents, SPF is odd

Thus, need to and can carry out MEM analysis in
-wmax, wmax
30
Analysis Details

• Default Model

At zero momentum,
Espriu, Pascual, Tarrach, 1983

• Relation between lattice and continuum currents

31
Stat. and Syst. Error Analyses in MEM
Generally,
The Larger the Number of Data Points and the
Lower the Noise Level
The Closer the Result is to the Original Image
32
Below Tc Light Baryon
33
Below Tc Charm Baryon
34
Above Tc Light Baryon
peak near zero symmetric and equally separated
peaks
35
_at_Higher T
only symmetric and equally separated peaks
36
Above Tc Charm Baryon
peak near zero symmetric and equally separated
peaks
37
_at_Higher T
only symmetric and equally separated peaks
38
Statistical Analysis Light Baryon _at_T0
Peaks are statistically significant
39
Statistical Analysis Charm Baryon _at_Finite T
Peak near zero is statistically significant
40
Origin of Near Zero Structure
Scattering Term
a.k.a. Landau damping

• This term is non-vanishing only for

• For J/y (m1m2), this condition becomes

zero mode
cf. QCD SR (Hatsuda and Lee, 1992)
41
Scattering Term (two body case)
(Boson-Fermion case, e.g. Kitazawa et al., 2008)
42
Scattering Term (three body case)
43
Negative parity a possible interpretation
anti-quark parity -
44
Origin of Symmetric Structure

• Wilson Doublers

Mass of Wilson Doublers with r 1 in the
continuum limit

• If quark mass can be neglected

• Masses of baryons with doublers
• Scattering term peaks with quark-doubler,
  doubler-doubler pairs

Approximately equally separated and symmetric in w
45
QCD Phase Diagram
Quark-antiquark correlations
T
Diquark correlations
Baryon correlations
CEP(critical end point)
160-190 MeV
crossover
100MeV 1012 K
1st order
order ?

• chiral symmetry breaking
• confinement

mB
5-10r0
46
Summary (Baryon Part)

• Baryons disappear just above Tc

• A sharp peak with negative parity near w0 is
• observed in baryonic SPF above Tc
• This can be due to diquark-quark scattering
  term and
• imply the existence of diquark correlation
  above Tc

• Diquarks disappear below meson disapperance
  temperature

• Direct measurement of SPF of one and two quark
  operators
• with MEM is desired

• To understand doubler contribution, calculations
  with finer lattices
• are desired

47
Ingredients of MEM

given by Shannon-Jaynes Entropy
For further details, Y. Nakahara, and T. Hatsuda,
and M. A., Prog. Part. Nucl. Phys. 46 (2001) 459
48
Error Analysis in MEM (Statistical)

• MEM is based on Bayesian Probability Theory

• In MEM, Errors can be and must be assigned
• This procedure is essential in MEM Analysis

• For example, Error Bars can be put to

Gaussian approximation
49
Meson-Baryon Universality
Partons are flowing and Partons recombine to make
mesons and baryons
Evidence of Deconfinement !
50
Statistical Analysis below Tc
