AsphaltBased Porous Pavements

1
Asphalt-Based Porous Pavements

• Howard Marks
• Director, Regulatory Affairs
• National Asphalt Pavement Association

in conjunction with Cahill Associates,
Environmental Consultants
2
(No Transcript)
3
(No Transcript)
4
(No Transcript)
5
(No Transcript)
6
(No Transcript)
7
(No Transcript)
8
(No Transcript)
9
(No Transcript)
10
(No Transcript)
11
(No Transcript)
12
Early Asphalt Binders and Pavements

• First record Babylon around 625 B.C
• TLA discovered ca. 1500s
• Asphalt refined from crude oil during late 1800s
• First asphalt pavements in US late 1800s

Early Paving Pennsylvania Ave.
Trinidad Lake Asphalt
13
HMA Pavements Today

• Dense graded
• Historically used for structural integrity
• Open Graded (Porous)
• OGFC used as surface course since 1970s
• Increases drainage and reduces splash/overspray
  and sound
• ATPB used as drainage layer below pavement
• Stone Matrix Asphalt (SMA)
• High AC content, durable, impervious

14
OGFC on Freeway
15
Changing Views

• OGFC successful in dispersing water for safer
  pavement
• Engineers and city planners developing other
  applications for using porous pavements
• Stormwater runoff historically managed using
  detention basins
• Controls peak runoff flow rate but not peak/total
  volume
• Stormwater runoff can be better managed using
  porous pavements
• Stand-alone or in combination with other Best
  Mgmt Practices e.g., forestry/vegetation,
  river-rock curbs

16
Porous Pavement

• What is it?
• Asphalt in which fine particles are kept to a
  minimum thereby increasing air voids
• Why?
• This allows rainfall to drain through the
  pavement rather than running off
• Where does the rainfall go?
• A bed beneath the pavement receives rainfall from
  the pavement as well as inflow from other areas

17
Porous Pavement with Recharge Bed
Pervious Asphalt
River Jacks Open Into Recharge Bed
Stone Bed w/ 40 Void Space For Storage/Recharge
18
Porous asphalt pavement

• Developed by the Franklin Institute 1972
• Tested in pilot projects during 1970s
• Hundreds of projects completed since 1980
• Universities, Industrial lots and now,
  communities and high-traffic roadways
• Highly successful in managing stormwater runoff

19
Construction of Porous Pavement/Recharge Bed
Systems
20
Diagram of infiltration bed at Morris Arboretum
21
Morris Arboretum Philadelphia,constructed in 1984
22
(No Transcript)
23
(No Transcript)
24
(No Transcript)
25
Stone Recharge Bed

• Place clean, single size, washed aggregate.
• Do not drive trucks on fabric
• Spread and grade with tracked equipment.
• Light compaction - static
• Protect pipes

26
Choker Course

• Place Choker course ½ clean washed
  aggregate.
• Locks-up surface for stable paving platform
• 1 2 thick
• Grade and compact

27
Paving and Compaction

• Paving as usual recommend track paver
• Minimize truck movement over aggregate
• Static compaction

28
Standard Pavement
Porous Pavement
Univ. NC addl parking lot constructed ca. 2002
29
Effect of Detention Peak Rate may be Controlled
but Volume Increase is Not Mitigated
Discharge volume
Time
30
Comparison of Detention vs. Infiltration System
31
(No Transcript)
32
Benefits of Porous Pavement

• Economic
• Reduces/Eliminates the land space consumed by
  conventional detention facilities
• Helps prevent excessive flooding and minimizes
  need for control measures
• Aesthetic
• Eliminates the need for unsightly detention
  basins
• Preserves areas such as woods/open space
• Environmental
• Limits peak stormwater discharge and improves
  water quality of any runoff
• Reduces amount of impervious surfaces

33
Additional Views and Applications

• OGFC successful in dispersing water for safer
  roadway pavement (quieter pavement also)
• Porous asphalt pavements used to better manage
  stormwater runoff from parking lots
• Controls peak flow rate and volume improves
  water quality
• What about building roadways with full-depth
  porous asphalt pavements?
• Arizona DOT experimental sections (1986)

34
Typical Section of AZ DOTs Experimental Porous
Pavement
35
20 years later, holding-up fine near Phoenix AZ
36
Other Applications?

• OGFC successful in dispersing water for safer
  roadway pavement (quieter pavement also)
• Porous asphalt pavements used to better manage
  stormwater runoff from parking lots
• Controls peak flow rate and volume
• Full-depth porous asphalt pavements are sturdy
  and manage stormwater
• Can porous asphalt pavement reduce surface temp?

37
Using porous asphalt pavement to mitigate UHI
thermal radiation
Below grade w/ sound walls
Above grade w/ landscape
¾ inch asphalt OGFC over dense-graded pavement
Below grade w/ sound walls
Satellite imagery and information courtesy of
Ariz. State Univ., Intl Inst. For Sustainability
