Extended Learning Module E

1

• Extended Learning Module E
• Network Basics
• A great module on your CD.

2
Presentation Overview

• Peer-to-Peer Home Networks
• Internet Access
• Business Networks
• LANs, MANs, WANs, and Communications Media
• Communications Service Providers

3
Introduction

• Computer network - two or more computers
  connected so that they can communicate with each
  other and share information, software, peripheral
  devices, and/or processing power.

4
IntroductionBasic Principles of Networks

• Each computer must have a network card.
• A network has at least one connecting device.
• There must be communications media connecting the
  network hardware devices.
• Each computer must have software that supports
  the movement of information.

5
Peer-to-Peer Home Network

• Peer-to-peer network - a network in which a small
  number of computers share hardware, software
  and/or information.

6
Peer-to-Peer Home NetworkHome Network Components

• Network interface card (NIC) - an expansion card
  or a PC Card that connects your computer to a
  network and provides the doorway for information
  to flow in and out.

7
Peer-to-Peer Home NetworkHome Network Components

• Ethernet card - the most common type of network
  interface card.

8
Peer-to-Peer Home NetworkHome Network Components

• Network hub - a device that connects multiple
  computers into a network.
• Switch - a device that connects multiple
  computers into a network in which multiple
  communications links can be in operation
  simultaneously.

9
Peer-to-Peer Home NetworkHome Network Components

• Router - a device that acts as a smart hub
  connecting computers into a network, and it also
  separates your network from any other network
  its connected to.

10
Peer-to-Peer Home NetworkHome Network Components
11
Peer-to-Peer Home NetworkHome Network Components

• Firewall - software and/or hardware that protects
  a computer or network from intruders.
• Cat 5, or Category 5 cable - a better-constructed
  version of the phone twisted-pair cable.

12
Peer-to-Peer Home NetworkWireless Access to Your
Home Network

• Wireless network access point or wireless access
  point - a device that allows computers to access
  a wired network using radio waves.

13
Peer-to-Peer Home NetworkWireless Access to Your
Home Network

• WiFi, Wireless Fidelity, or IEEE 802.11b - a way
  of transmitting information in wave form that is
  reasonably fast and is often used for notebooks.
• Bluetooth technology - provides entirely wireless
  connections for all kinds of communication
  devices.

14
Peer-to-Peer Home NetworkHome Network with
Existing Phone Wiring

• Home PNA (Home Phone line Networking Alliance) -
  allows you to network your home computers using
  telephone wiring.
• PNA adapter card - an expansion card that you put
  into your computer to act as an doorway for
  information flowing in and out.

15
Peer-to-Peer Home NetworkHome Network with
Existing Phone Wiring
16
Internet Access

• Ways to Access the Internet at Home
• Telephone line and a telephone or dial-up modem.
• Telephone line and a Digital Subscriber Line
  (DSL) modem.
• Cable TV line and a cable modem.
• Satellite dish and a satellite modem.
• Provider that offers wireless connection for your
  notebook.

17
Internet Access

• Broadband - a high-capacity telecommunications
  pipeline capable of providing high-speed Internet
  service.

18
Internet Access Telephone or Dial-Up Connection

• Telephone modem - a device that connects your
  computer to your phone line so that you can
  access another computer or network.

19
Internet Access Digital Subscriber Line (DSL)

• Digital Subscriber Line (DSL) - a high-speed
  Internet connection using phone lines, which
  allows you to use your phone for voice
  communications at the same time.

20
Internet Access Cable Modem

• Cable modem - a device that uses your TV cable to
  deliver an Internet connection.

21
Internet Access Internet over Satellite

• Satellite modem - a modem that allows you to get
  Internet access from a satellite dish.

22
Internet Access Internet Access on Multiple
Computers

• Network address translator (NAT) swaps messages
  between the private, internal IP addresses, and
  the public IP address, when moving information
  between the Internet and network computers.

23
Internet Access Wireless Internet Connection

• Wireless Internet service provider (wireless ISP)
  - does the same job as standard Internet service
  providers except that you dont need a wired
  connection for access.

24
Internet Access Wireless Internet Connection

• Personal digital assistant (PDA) - a small
  hand-held computer that helps you surf the Web
  and perform simple tasks such as note taking,
  calendaring, appointment scheduling, and
  maintaining an address book.
• Palms and Handspring - run on the Palm Operating
  System
• PocketPCs - run on Pocket PC OS

25
Business Networks

• Client/server network - a network in which one or
  more computers are servers and provide services
  to the other computers which are called clients.

26
Business NetworksClient/Server A Business View

• Client/server networks differ according to three
  factors
• Where the processing for the presentation of
  information occurs.
• Where the processing of logic or business rules
  occurs.
• Where the data management component (DBMS) and
  information (database) are located.

27
Business NetworksClient/Server A Business View
28
Business NetworksClient/Server A Business View

• The Five Models of Client/Server
• Distributed Presentation
• The server handles almost all functions,
  including a major portion of the presentation.
• Remote Presentation
• The client handles all presentation functions.
• Distributed Logic
• The server handles all data management and the
  client handles all presentation formatting, and
  the logic processing is shared.

29
Business NetworksClient/Server A Business View

• Remote Data Management
• The server handles data management only, and the
  client processes business rules and formats the
  presentation of results.
• Distributed Data Management
• The client handles all presentation formatting
  and business rule processing, and both the server
  and client share data management duties.

30
Client/Server A Business View
31
Business NetworksClient/Server A Physical View

• Communications protocol (protocol) - a set of
  rules that every computer follows to transfer
  information.

32
LANs, MANs, WANs, and Communications
MediaClassification of Networks by Geographic
Distance

• Local area network (LAN) - covers a limited
  geographic distance, such as an office, building,
  or a group of buildings in close proximity to
  each other.
• Municipal area network (MAN) - covers a
  metropolitan area.
• Wide area network (WAN) covers a large
  geographic distances, such as a state, a country,
  or even the entire world.

33
LANs, MANs, WANs, and Communications
MediaTelecommunications Media The Paths That
Carry Information

• Communications media - the paths, or physical
  channels, in a network over which information
  travels.
• Wired communications media - transmit information
  over a closed, connected path.
• Wireless communications media - transmit
  information through the air.

34
LANs, MANs, WANs, and Communications
MediaTelecommunications Media The Paths That
Carry Information

• Wired Communications Media include
• Twisted-pair cable
• Coaxial cable
• Optical Fiber
• Wireless Communications Media Include
• Microwave
• Satellite
• Infrared

35
(No Transcript)
36
LANs, MANs, WANs, and Communications
MediaBandwidth

• Bandwidth - refers to the amount of information
  that a communications medium can transfer in a
  given amount of time.

37
LANs, MANs, WANs, and Communications MediaWired
Communications Media

• The simplest type of twisted-pair phone cabling
  (Cat 1) provides a slow, fairly reliable path for
  information at up to 64 kilobits per second
  (Kbps).
• A better type (Cat 3) provides up to 10 megabits
  per second (Mbps).

38
4-Pair Unshielded Twisted Pair Cable with RJ-45
Connector
The cord terminates in an 8-pin RJ-45 connector,
which plugs into an RJ-45 jack in the NIC,
switch Or wall jack. Your home phone has a
6-pin RJ-11 plug. But only two wires Out of the
possible six are Used.
Pin 1 on left of Jack
8-Pin RJ-45 Connector
RJ-45 Jack
39
4-Pair Unshielded TwistedPair Cable with RJ-45
Connector
UTP Cord
RJ-45 Connector
40
4-Pair Unshielded TwistedPair Cable with RJ-45
Connector
With RJ-45 Connector
Pen
4 Pairs Separated
41
LANs, MANs, WANs, and Communications MediaWired
Communications Media

• Optical fiber - uses a very thin glass or plastic
  fiber through which pulses of light travel.

42
Optical Fiber Cabling
Two-fiber cords for full-duplex (two-way)
transmission
SC Connectors (Recommended)
ST Connectors (Popular)
43
Optical Fiber Cabling
ST Connectors (Push In and Snap)
ST Connectors (Bayonet Push In and Twist)
44
LANs, MANs, WANs, and Communications MediaWired
Communications Media

• Coaxial cable (coax) - one central wire
  surrounded by insulation, a metallic shield, and
  a final case of insulating material.
• Coax is the kind of cable that delivers cable
  television transmissions and also carries
  satellite TV from the dish to your house.

45
LANs, MANs, WANs, and Communications
MediaWireless Communications Media

• Wireless communications media radiate information
  into the air, either very narrowly beamed or in
  many directions like ripples from a pebble tossed
  into a pond.

46
LANs, MANs, WANs, and Communications
MediaInfrared and Omnidirectional Microware for
Short Distances

• Infrared - a wireless communications medium that
  uses radio waves to transmit signals or
  information.
• Microwave transmission - a type of radio
  transmission.
• Bluetooth
• WiFi

47
LANs, MANs, WANs, and Communications
MediaDirectional Microware for Medium Distances

• Repeater - a device that receives a radio signal,
  strengthens it and sends it on.

48
LANs, MANs, WANs, and Communications
MediaSatellites for Long Distance

• Communications satellites - microwave repeaters
  in space.

49
Communications Service Providers

• Communications service providers - third parties
  who furnish the conduit for information.
• Public network - a network on which your
  organization competes for time with others.

50
Communications Service Providers

• Private network - communications media that your
  organization owns or exclusively leases to
  connect networks or network components.
• Value-added network (VAN) - a semipublic network
  that provides services beyond the movement of
  information from one place to another.

51
Communications Service Providers

• Virtual private network (VPN) uses software to
  establish a secure channel on the Internet for
  transmitting data.

52
Communications Service ProvidersKey
Considerations for Communications Media

• To determine the most appropriate communications
  medium, you must consider
• Capacity
• Reliability
• Cost
• Distance
• Mobility
