Administration Tools for Managing Large Scale Linux Cluster

1
Administration Tools for Managing Large Scale
Linux Cluster

• CRC KEK Japan
• S.Kawabata, A.Manabe
• atsushi.manabe_at_kek.jp

2
Linux PC Clusters in KEK
3
PC Cluster 2 PenIII 800MHz 80CPU (40 nodes)
PC Cluster 1 PenIII Xeon 500MHz 144 CPUs (36
nodes)
4
PC Cluster 3 (Belle) Pentium III Xeon 700MHz
320CPU (80 nodes)
5
PC cluster 4 (Neutron simulation)

• Fujitsu TS225 50 nodes
• Pentium III 1GHz x 2CPU
• 512MB memory
• 31GB disk
• 100BaseTX x 2
• 1U rack-mount model
• RS232C x2
• Remote BIOS setting
• Remote reset/power-off

6
PC Cluster 5 (Belle) 1U server Pentium III
1.2GHz 256 CPU (128 nodes)
7
3U
PC Cluster 6 Blade server LP Pentium III
700MHz 40CPU (40 nodes)
8
PC clusters

• Already more than 400 (gt800CPUs) nodes Linux PC
  clusters were installed.
• Only gtmiddle size PC cluster are counted.
• A major exp. (Belle) group plan to install
  several x100 nodes of blade server in this year.
• All PC clusters are managed by individual user
  group themselves.

9
Center Machine (KEK CRC)

• Currently machines in KEK Computer Center(CRC)
  are UNIX(solaris,AIX) servers.
• Plan to have gt1000 nodes Linux computing cluster
  in near future (2004).
• Will be installed under 4years rental
  contract. (every 2 years HW update ?)

10
Center Machine

• The system will be share among many user groups.
  (dont dedicate to one gr. only)
• Their demand for CPU power vary with months.
  (High demand before intl-conference or so on)
• Of course, we use load-balancing Batch system.
• Big groups uses their own software frame work.
• Their jobs only run under some restricted version
  of OS(Linux) /middle-ware/configuration.

11
RD system

• Frequent change of system configuration/ cpu
  partition.
• To manage such size of PC cluster and such user
  request, we need to have some sophisticated
  admin. tools.

12
Necessary admin. tools

• System (SW) Installation /update
• Configuration
• Status Monitoring/ System Health Check
• Command Execution

13
Installation tool
14
Installation tool

• Two types of installation tool
• Disk Cloning
• Application Package Installer
• system(kernel) is an application in this term.

15
Installation tool (cloning)
Image Cloning
Install system/application on a master host.
16
Installation tool (package installer)
request
Package server
Image and control
Package Information DB
Clients
Package archive
17
Remote Installation via NW

• Cloning disk image
• SystemImager (VA) http//systemimager.sourceforge.
  net/
• CATS-i (soongsil Univ.)
• CloneIt http//www.ferzkopp.net/Software/CloneIt/
• Comercial ImageCast, Ghost,..
• Packages/Applications installation
• Kickstart rpm (RedHat)
• LUI (IBM) http//oss.software.ibm.com/developerwor
  ks/projects/lui
• Lucie (TiTec) http//matsu-www.is.titech.ac.jp/ta
  kamiya/lucie/
• LCFGng, Arusha

Public Domin Software
18
Dolly

• We developed image cloning via NW installer
  dolly.
• WHY ANOTHER?
• We install/update
• maybe frequently (according to user needs)
• 1001000 nodes simultaneously.
• Making packages for our own softwares is boring.
• Traditional Server/Client type software suffer
  server bottleneck.
• Multicast copy with GB image seems unstable.(No
  free soft ? )

19
(few) Server - (Many) Client model

• Server could be a daemon process.(you dont need
  to start it by hand)
• Performance is not scalable against of nodes.
• Server bottle neck. Network congestion

Multicasting or Broadcasting

• No server bottle neck.
• Get max performance of network which support
  multicasting in switch fabrics.
• Nodes failure does not affect to all the process
  very much, it could be robust.
• Since failed node need re-transfer. Speed is
  governed by the slowest node as in RING topology.
• Not TCP but UDP, so application must take care
  of transfer reliability.

20
Dolly and Dolly

• Dolly
• A Linux application software to copy/clone files
  or/anddisk images among many PCs through a
  network.
• Dolly is originally developed by CoPs project in
  ETH (Swiss) and an open software.
• Dolly features
• Sequential files (no limitation of over 2GB)
  and/or normal files (optinaldecompress and untar
  on the fly) transfer/copy via TCP/IP network.
• Virtual RING network connection topology to cope
  with server bottleneck problem.
• Pipeline and multi-threading mechanism for
  speed-up.
• Fail recovery mechanism for robust operation.

21
Dolly Virtual Ring Topology
Master host having original image

• Physical network connection is as you like.
• Logically Dolly makes a node ring chain which
  is specified by dollys config file and send data
  node by node bucket relay.
• Though transfer is only between its two adjacent
  nodes, it can utilize max. performance ability of
  switching network of full duplex ports.
• Good for network complex of many switches.

node PC
network hub switch
physical connection
Logical (virtual) connection
22
Cascade Topology

• Server bottle neck could be overcome.
• Cannot get maximum network performance but better
  than many client to only one serv. topology.
• Week against a node failure. Failure will spread
  in cascade way as well and difficult to recover.

23
PIPELINING multi threading
24
Performance of dolly
HW FujitsuTS225 PenIII 1GHz x2, SCSI disk,
512MB mem, 100BaseT NW
25
(No Transcript)
26
Fail recovery mechanism

• Only one node failure could be show stopper in
  RING (series connection) topology.
• Dolly provides automatic short cut mechanism
  against a node trouble.
• In a node trouble, the upper stream node detect
  it by sending time out.
• The upper stream node negotiate with the lower
  stream node for reconnection and retransfer of a
  file chunk.
• RING topology makes its implementation easy.

time out
27
Re-transfer in short cutting
BOF
EOF
1 2 3 4 5 6 7 8 9 ..
File chunk 4MB
6
9
8
7
6
network
Server
5
8
7
Node 1
network
5
7
6
Node 2
Works with even Sequential file.
Next node
28
Dolly How do you start it on linux
Config file example

• Server side (which has the original file)
• dollyS -v -f config_file
• Nodes side
• dollyC -v

iofiles 3 /dev/hda1 gt /tmp/dev/hda1 /data/file.gz
gtgt /data/file boot.tar.Z gtgt /boot server
n000.kek.jp firstclient n001.kek.jp lastclient
n020.kek.jp client 20 n001 n002
n020 endconfig
of files to Xfer master name of
client nodes clients names end code
The left of gt is input file in the server.
The right is output file in clients. 'gt' means
dolly does not modify the image. 'gtgt' indicate
dolly should cook (decompress , untar ..) the
file according to the name of the file.
29
How does dolly clone the system after booting.

• Nodes broadcast over the LAN in search of an
  installation server (Pre-eXecution Environment).
• PXE/DHCP server respond to nodes with information
  about the nodes IP and kernel download server.
• The kernel and ram disk image are Multicast
  TFTPed to the nodes and the kernel gets start.
• The kernel hands off to an installation script
  which run a disk tool and dolly .(scripts and
  appli. are in the ram disk image)

30
How does dolly start after rebooting.

• The code partitions the hard drive, creates file
  systems and start dolly client on the node.
• You start dolly master on the master host to
  start up a disk clone process.
• The code then configure unique node information
  such as Host name, IP addess from DHCP
  information.
• ready to boot from its hard drive for the first
  time.

31
PXE Trouble

• BY THE WAYwe suffered sometimes PXE mtftp
  transfer failure in the case of gt20 nodes booting
  simultaneously.
• If you have same trouble, mail me please.
• We start rewriting mtftp client code of RedHat
  Linux PXE server.

32
Configuration
33
(Sub)system Configuration

• Linux (Unix) has a lot of configuration file to
  configure sub-systems. If you have 1000nodes, you
  have to manage (many)x1000 config. files.
• To manage them, three types of solution
• Cetralized information service server (like
  NIS).
• Need support by sub-system (nsswitch)
• Automatic remote editing raw config. files
  (like cfengine).
• Must care about each nodes file separately.

34
Configuration--new proposal from CS.

• Program (configure) whole system with a source
  code by O.O way.
• Systematic uniform way configuration.
• Source reuse (inheritance) as much as possible.
• Template
• override to other-sites configuration.
• Arusha (http//ark.sourceforge.net)
• LCFGng (http//www.lcfg.org)

35
LCFGng (Univ. Edinburgh)
New Compile
36
LCFGng

• Good things
• Author says that it works on 1000 nodes.
• Fully automatic. (you just edit source code and
  compile it in a host.)
• Differences of sub-systems are hidden from user
  (administrator). (or move to components
  (DB-gtactual config file))

37
LCFGng

• Configuration Language is too primitive.
• Hostname.Component.Parameter Value
• Components are not so manyor you must write your
  own components scripts for each sub-system by
  yourself.
• far easier writing config. file itself than
  writing component.
• Activating timing of the config. change could not
  be controlled.

38
Status monitoring
39
Status Monitoring

• System state monitoring
• CPU/memory/disk/network utilization
• Ganglia1,plantir2
• (Sub-)system service sanity check
• Pikt3/Pica4/cfengine

1 http//ganglia.sourceforge.net 2
http//www.netsonde.com 3 http//pikt.org 4
http//pica.sourceforge.net/wtf.html
40
Ganglia ( Univ. Calfornia)

• Gmond (each node)
• All node multicast each system status info.
  each other and each node has current status of
  all nodes. -gt good redundancy and robust
• declare that it works on 1000 nodes
• Meta-deamon (Web server)
• stores volatile data of gmond in Round-robin DB
  and represent XML image of all nodes activity
• Web Interface

41
(No Transcript)
42
Plantir (Network adaption )

• Quick understanding of system status from One Web
  Page.

43
Remote Execution
44
Remote execution

• Administrator sometimes need to issue a command
  to all (part of ) nodes urgently.
• Remote execution could be rsh/ssh/pikt/cfengine/S
  UT(mpich) /gexec..
• Points are
• To make it easy to know the execution result
  (fail or success) at a glance.
• Parallel execution among nodes.
• Otherwise If it takes 1sec. at each node, then
  1000 sec for 1000 nodes.

) Scalable Unix tools for cluster
http//www-unix.mcs.anl.gov/sut/
45
WANI

• WEB base remote command executer.
• Easy to select nodes concerned.
• Easy to specify script or to type-in command
  lines to execute in nodes.
• Issue the commands to nodes in parallel.
• Collect result with error/failure detection.
• Currently, the software is in prototyping by
  combinations of existing protocol and tools.
  (Anyway it works!)

46
WANI is implemented on Webmin GUI
Start
Command input
Node selection
47
Command execution result
Switch to another page
Host name
Results from 200nodes in 1 Page
48
Error detection
BG color
49
(No Transcript)
50
Node hosts
execution
WEB Browser
Piktc_svc
PIKT server Webmin server
Piktc
error detector
print_filter
Lpd
51
Summary

• I reviewed admin. tools which can be used against
  1000 nodes Linux PC cluster.
• Installation dolly
• Install/Update/Switch hosts gt100 nodes very
  quickly.
• Configuration manager
• Not matured yet. But can expect a lot from
  DataGrid research.
• Status monitor
• seems several good software already exists.
• Extra daemons and network traffic.

52
Summary

• Remote Command Execution
• Result at a glance is important for quick
  iteration.
• Parallel execution is important.
• Some programs and links is /will be
• http//corvus.kek.jp/manabe
• Thank you for your listening.

53
(No Transcript)
