The Pied Pipers

1
The Pied Pipers

• Alyssa Visitacion
• Ken Shum
• Joanne Flores

2
Project Overview
To create an autonomous robotic mouse that
will navigate a maze
M
3
System Diagram
4
Program Module

• Tracking Algorithm

Sense walls If offset sensors turn on, you are no
longer centered. Increase speed on side of
offset sensors until centered

• Wall Hugger Algorithm

Go as long as there is a wall on the left if
there is a wall on the front, turn right if
there is no wall on the left, turn left
5
Mechanical Module

• Subsystems
• Chassis
• Sensor Placement
• Batteries
• Motor
• Electrical Circuitry

6
Chassis
7
Completed Chassis
8
Sensor Layout
9
Test Sensors
10
Completed Tasks

• Sensor layout
• Chassis
• Attached Wheels
• Determined type/placement of batteries
• Pillars
• Attained all necessary supplies

11
What Remains To Be Done

• Integrating the sensor circuit ( currently
  underway)
• Determine how many motor pulses needed to move
  one cell (pending)
• Attach motors to circuit (pending)
• Programming (in progress)
• Functionality Tests (in progress)

12
Potential Problems

• Subsystems not working as planned
• Parts breaking
• Too much time on troubleshooting
• Exams, quizzes, conflicting with working on
  project
• Spring Break team availability not optimal

13
Updated Project Timeline

• March

14
Project Timeline (cont)

• April

15

• May

16
Questions?
