Title: Geothermal Heat Pump Presentation


1

A Simplified Design Method for PEX Plastic
Downhole Heat Exchangers
by Andrew Chiasson
Geo-Heat Center Oregon Institute of
Technology Klamath Falls, Oregon, USA

GRC 2006 Annual Meeting San Diego, CA
2
Presentation Outline
  • Introduction, Motivation, Objectives
  • Background
  • PEX DHE installation and monitoring
  • Methodology
  • Field testing
  • Mathematical modeling
  • Results
  • Design chart
  • Example use
  • Concluding summary

3
IntroductionWhat are DHEs?
  • Closed-loop immersed in water wells
  • Known installations in U.S., Turkey, and New
    Zealand
  • Less common/experimental installations in
    Iceland, Hungary, Russia, Italy, Greece, Japan
  • In U.S., most concentrated uses are in Klamath
    Falls, OR and Reno, NV
  • Over 500 DHE installations exist in Klamath
    Falls, OR

4
IntroductionWhat are DHEs?
  • Some existing applications include
  • Space heating of homes
  • Space heating of schools
  • Snow melting

5
Project Motivation Objectives
  • Motivation
  • DHEs are black iron pipe gt subject to
    unpredictable corrosion rates (2 15 years)
  • Chiasson et al. (2005) reported on installation
    and monitoring of a cross-linked polyethylene
    (PEX) plastic DHE
  • Monitoring demonstrated that the PEX DHE was
    significantly over-designed
  • Current design methods are rules of thumb
  • Objectives
  • Develop a design method for PEX DHEs that is
    simple and reliable

6
Project BackgroundDHE Materials
PEX U-tube
PEX compression fitting
PEX tubing 1-in. x 300-ft spools with oxygen
barrier
PEX elbow
7
Project BackgroundInstalling the DHE
Steel pipe from old DHE used as installation
guide as well as a convection promoter by
leaving pipe open at the bottom and installing a
tee below the water level
8
Project BackgroundPerformance Monitoring
9
MethodologyField Testing
  • How much heat can actually be extracted from the
    well?
  • Heat extraction rate 184,000 Btu/hr or 54 kW

10
MethodologySimple Mathematical Model
  • How can the design length be calculated?
  • Kelvins classic Line Source Model (1882)
  • Applied to earth heat transfer by Ingersoll and
    Plass (1948)
  • A pure conduction heat transfer model
  • All effects of groundwater flow are lumped
    together to give an effective thermal
    conductivity

11
ResultsThe Effective Thermal Conductivity
  • keffective 55 Btu/(hr-ft-oF) or 95 W/(m-K)

12
ResultsDesign Tool (Heat Output per Unit Length)
13
ResultsVerification and Example Use
  • Determine peak heating load (98,000 Btu/hr or 29
    kW)
  • Determine the geothermal resource temperature
    (202oF or 94.4oC)
  • Determine the average DHE loop temperature at
    design conditions (TinTout)/2
  • Tout heating coil or radiator design
    temperature
  • Tin above temperature design temperature drop
  • (175oF 145oF)/2 160oF or 71oC
  • x-axis value Estimate or measure the effective
    thermal conductivity
  • y-axis value DT 42oF or 23oC
  • Predicted Design Output 550 Btu/hr/ft
    (7 lower than actual)

14
Concluding Summary
  • A prototype DHE constructed of PEX plastic has
    been installed in a retrofit application in
    Klamath Falls, OR
  • A simple design method to determine required PEX
    DHE length has been developed
  • The method produces favorable results, provided
    the user has a reasonable estimate of the rock
    effective thermal conductivity
  • Future work will attempt to check the design
    method at other locations with differing
    geothermal conditions
