Title: Mineral Stability Phase Diagrams


1
Mineral StabilityPhase Diagrams
  • Klein, 2002, p. 115-134

2
Mineral Stability
  • Phase diagrams / stability diagrams
  • Diagram with compositional temperature
    variation
  • Showing the stability of the different phases
  • This is a phase diagram.
  • Time to introduce
  • Phase
  • Phase diagram

temperature
composition
3
Mineral Stability
  • A PHASE is a homogenous substance with a
    well-defined set of physical chemical
    properties.
  • Looks like the definition of mineral but
  • well-defined (so no variations)
  • substance (so not only crystalline solid)
  • Examples
  • Low quartz is a low-temperature phase in system
    SiO2
  • Kyanite is a high pressure phase in system Al2SiO5

4
Mineral Stability
  • Solid solution is called phase region
  • Eg olivine forsterite (Mg-rich) to fayalite
    (Fe-rich)
  • Phase can be solid, liquid gaseous
  • Easy example
  • H2O ice (solid) water (liquid) steam (gas)

5
Mineral Stability
  • H2O phase diagram
  • Pressure Temperature phase diagram
  • aka P-T diagram
  • At 1 atmosphere
  • At 0o C ice/water
  • At 100o C water/steam

liquid
Pressure
solid
vapor
Temperature
6
Mineral Stability
  • H2O phase diagram
  • Along the curves two phases can coexist in
    equilibrium
  • Ice liquid water
  • Liquid water vapor

liquid
Pressure
solid
vapor
Triple Point
Temperature
TRIPLE POINT All 3 phases co-exist
7
Mineral Stability
  • This system of H2O (solid-liquid-vapor) is called
    a one-component system.
  • Al2SiO5 is a one-component system too.

8
Phase Rule
What is it used for?
  • How to study the formation of minerals in igneous
    rocks?
  • Most processes take place deep in the crust
    outside our realm of observation
  • The origin of rocks and minerals involves the
    application of physical chemistry to the
    formation of igneous or metamorphic rocks.

9
Phase Rule
  • How to study the formation of minerals in igneous
    rocks?
  • Laboratory experiments
  • Difficult because high pressure, high
    temperature, corrosive substance, and many
    elements involved.
  • Geologic observation
  • Direct observation of volcanic rocks forming
  • Observation of cooled plutonic rocks
  • Extrapolation of simple experiments
  • Laboratory experiments with only a few phases

10
Phase Rule
  • Watching volcanic rocks form

Hawaii
Iceland
Hawaii
11
Phase Rule
  • Direct observation of volcanic rocks forming
  • Lava is a silicate melt
  • Viscous
  • Emitting gasses
  • Gradually loses mobility
  • Freezing to glass mass of crystals or both
  • Measuring
  • The cooled rock composition (melt without gas)
  • Rate of temperature loss study of how melt
    becomes rock
  • Change in viscosity with cooling and composition
  • These observations can be extrapolated to
    plutonic rocks

12
  • Laboratory experiments
  • 2 approaches
  • 1. Melt an igneous rock in the lab and then cool
  • Glass forms from rapidly cooling lava
  • Crystals form from slow cooling lava
  • Silica-rich magmas more viscous than magma with
    higher MgO and FeO contents
  • This approach did not lead to all the desired
    results
  • 2. Experiment with simple silicate systems
  • This approach was more successful
  • IMPORTANT The guiding principle in working with
    simple silicate melts is Gibbs Phase Rule

13
Phase Rule
Josiah Willard Gibbs (1839-1903)
  • Gibbs was a theoretical physicist who derived the
    Phase Rule
  • F C-P2
  • where F degrees of freedom C no. of
    components P no. of phases
  • Here we are going to use the phase rule in the
    one component system H2O

14
Phase Rule
  • H2O Pressure Temperature phase diagram
  • Water vapor at constant pressure, decrease the
    temperature (cooling)
  • Suddenly liquid water appears
  • But the temperature does not decrease until all
    the vapor has disappeared

liquid
solid
vapor
Temperature
15
Phase Rule
Log Pressure (MPa)
  • H2O Pressure Temperature phase diagram
  • If all the liquid (water) has formed, temperature
    can decrease further to freezing point
  • Then ice starts forming, the temperature remains
    the same until all water is turned into ice

liquid
solid
vapor
Temperature
16
Phase Rule
  • H2O Pressure Temp. phase diagram
  • When only ice left, then temperature can drop
    further.

liquid
vapor
solid
Temperature
17
Phase Rule
  • Increasing pressure lowering melting point

Freezing point curve water and ice in equilibrium
18
Phase Rule
  • Example 1 We know from ice that increase of
    pressure will cause melting
  • EG Copper wire over ice block will move through
    ice block without cutting it.
  • The pressure causes melting, whereas the water
    refreezes above the wire

Melting as result of pressure
ice
19
Phase Rule
  • Example 2 Lower pressure, water boils at lower
    temperatures.
  • On Mount Kilimanjaro (6000 m) eggs take longer
    to boil and tea does not get very hot.

lower pressure lower boiling point
see Vapor pressure curve
20
Phase Rule
Critical point
  • H2O P-T diagram
  • Ice and water in equilibrium
  • Water and vapor in equilibrium
  • Ice and vapor in equilibrium
  • Triple point is where ice, water vapor are all
    in equilibrium
  • Critical point no difference between liquid and
    gas.

liquid
Pressure
solid
vapor
Temperature
21
Phase Rule
  • H2O P-T diagram
  • One component
  • 3 phases ice (solid), water (liquid), and steam
    (gas).
  • In the field of vapor at point X, we can vary
    pressure, P and temperature T and still have 1
    phase vapor
  • So 1 Phase 2 degrees of freedom

liquid
Pressure
solid
vapor
X
Temperature
22
Phase Rule
  • H2O P-T diagram
  • In the field of liquid at point X
  • Pressure and temperature can be varied
    independently and still only one phase liquid
    water
  • Or 1 component, 1 phase, and 2 degrees of freedom

X
liquid
Pressure
solid
vapor
Temperature
23
Phase Rule
  • H2O P-T diagram
  • Point X liquid
  • Increase T
  • Liquid up to where line reaches red curve
  • Here liquid and vapor (2 phases)
    co-exist
  • To keep 2 phases we would have to change P and T
    together

liquid
Pressure
X
solid
vapor
So now 2 phases, but only 1 variable, because P
and T have to be varied together
Temperature
24
Phase Rule
  • H2O P-T diagram
  • Point X liquid, solid and vapor together
  • Triple point
  • 1 component 3 phases
  • To keep the 3 phases we cannot change any of the
    variables (P or T), so 1 component, 3 phases and
    no variables (no degrees of freedom)

liquid
Pressure
solid
vapor
X
Temperature
25
Phase Rule
  • Summary
  • 1component 1 phase 2 degrees of freedom
  • 1component 2 phases 1 degree of freedom
  • 1component 3 phases 0 degrees of freedom

26
Phase Rule
  • Reminder Gibbs Phase Rule F C P 2
  • degrees of Freedom Components Phases 2

Gibbs Phase Rule
27
Phase Rule
  • 2 component or Binary systems
  • Two components so C2
  • Then FC-P2 or F2-P2
  • or when F1 then P3
  • 3-dimensional diagram
  • But if we keep the pressure constant we have 1
    degree of freedom less
  • So FC-P1

28
Phase Rule
  • 2 component or Binary systems
  • if FC-P1
  • We can draw TX diagrams (where TX temperature
    composition)
  • Temperature - composition diagrams depreciate the
    importance of pressure, but sometimes effects of
    pressure will be discussed.

29
Phase rule
  • 2 component or Binary systems
  • Both components mix completely
  • Solid solution system (eg plagioclase feldspar)
  • Both components do not mix
  • Eutectic relationship (eg diopside-anorthite)
  • NOTE The eutectic point is the minimum
    temperature point of the liquid field.

30
Phase Rule
  • 2 component or Binary systems
  • If 2 components mix completely - Solid solution
    series
  • Example Plagioclase system
  • NaAlSi3O8 to CaAl2Si2O8 2 components C2
  • Remember C minimum number of components to
    describe the system NaO, Al2O3, SiO2, and CaO
    are more than the minimum necessary
  • So Ab (albite) for NaAlSi3O8 and
  • An (anorthite) for CaAl2Si2O8

31
Phase rule
  • 2 component or Binary systems (Plagioclase)
  • Remember
  • Coupled substitution of Na1Si4 for Al3Ca2
  • In constant AlSi2O8 reference frame

IMPORTANT LIQUIDUS - points above which all of
mixture is melt. Also, it is a line or surface
along which compositions of melt are in
equilibrium with a crystalline phase SOLIDUS -
Points below which all of mixture is crystalline
solid. Also, it is a line along which
compositions of a crystalline phase are in
equilibrium with the melt NOTE All points
between liquidus solidus are mixture of melt
crystals
32
Phase rule
  • Plagioclase system
  • Isobaric temperature composition diagram

liquidus
Same pressure
Here 0.1 MPa (atmospheric pressure)
solidus
NOTE All diagrams are experimentally determined
33
Phase rule
  • Plagioclase system
  • TX diagram
  • In 1 component system, pure Ab melts at 1118oC
  • In 1 component system, pure An melts at 1553oC
  • Adding Ab to pure An lowers the melting
    temperature

34
Phase rule
a Xbulk
  • Plagioclase system
  • Composition
  • a Xbulk or bulk composition
  • Here 60 by weight of An or 40 wt Ab.
  • At a T 1600o C
  • C 2, P1 so F2

35
Phase rule
a Xbulk
  • Plagioclase system
  • Composition a Xbulk
  • 60wt An or 40 wt Ab.
  • Cooling to about 1487o first crystal to form is
    plagioclase with An 87. Composition of the
    liquid is An60

87
36
Phase Rule
a Xbulk
  • Plagioclase system
  • Composition a Xbulk or bulk composition
  • 1487o plagioclase with An 87. liquid is An60
  • F2-211 or 1 degree of freedom, so when T
    changes Xliq and Xsolid will have to change
    dependently
  • Composition of solid changes according to
    solidus, whereas liquid changes following the
    liquidus

An60
An87
liquidus
solidus
37
Phase rule
a Xbulk
  • Plagioclase system
  • Composition a Xbulk or bulk composition
  • Continuing cooling, continuous reaction between
    crystal and liquid, change in composition.
  • Solid will change composition following solidus
    until the solid has reached composition An60
  • At this point all liquid is used up and T keeps
    falling but X remains constant (An60)
  • The last drop of liquid, in equilibrium with the
    solid is An20

60
liquidus
20
solidus
38
Phase rule
a Xbulk
  • Plagioclase system
  • Equilibrium melting is the opposite
  • Partial melting
  • Start with solid composition An60
  • First melt An20 at 1330o
  • When T 1400o, melt escapes and intrudes country
    rock. This melt has composition of An35.
  • So partial melt is more felsic than mother (or
    parent) rock

35
liquidus
20
60
solidus
39
Phase rule
  • Plagioclase solid solution
  • With equilibrium melting, there is a continuous
    reaction between crystal liquid
  • Rather than react with the crystals in
    equilibrium, the liquid deposits a layer of new
    composition around the crystals
  • Compositional zoning

40
Phase rule
  • Binary eutectic system - Anorthite Diopside
  • Pure anorthite An crystallizes at 1553o
    (CaAlSi3O8)
  • Pure diopside Di crystallizes at 1392o
    (CaMgSi2O6)
  • Hence, adding diopside to anorthite will lower
    the melting/crystallization temperature
  • Adding anorthite to diopside will raise the
    melting/crystallization temperature

An
Di
These curves meet at the eutectic point. REMEMBER
that the eutectic point is the minimum temp. in
the liquid field.
41
Phase rule
Z
  • Binary eutectic system
  • At Pt Z, Bulk composition of melt is
  • 70 Anorthite 30 diopside (C2)
  • Equilibrium cooling
  • 1st crystal (anorthite) forms at 1450o
  • Cooling continues to 1274o then also diopside
    crystallizes
  • Pdi an liquid3
  • F2-310 so no degrees of freedom
  • Cooling will continue when all liquid
    crystallized, so P2 and F1
  • Final drop of melt 42An and 58 di
  • Final solid 70 An and 30 di

Final crystal
42
Phase rule
  • Binary eutectic system
  • Bulk melt comp 20 An 80 Di
  • 1st crystal of diopside _at_ 1360o
  • Cooling to 1274o now anorthite starts
    crystallizing
  • Liquiddian C3 so F0
  • Cooling continues when all liquid used up, final
    drop 42 An and 58 Di
  • Final solid 20 An and 80 Di

43
Phase Rule
  • Binary eutectic system
  • Equilibrium melting
  • Initial rock is at Z, rising Temp.
  • First melt is always the eutectic composition
  • Assume initial rock composition is 20An-80Di
  • First melt is eutectic (42 An and 58 Di)
  • Temperature will not increase until all anorthite
    is molten
  • When all anorthite in the melt has crystallized,
    temperature will rise with diopside melting.
  • Until at about 1360oC the entire rock is molten
    and melt is 80 Di - 20 An

Z
44
Phase rule
  • Binary eutectic system
  • Equilibrium melting
  • Initial rock composition 80An and 20 Di
  • First melt is always the eutectic composition
    (42 An, 58 Di)
  • Temperature will not rise until all diopside is
    molten.
  • Melting will continue until all the rock is
    molten at 1500 C

45
Phase Rule
  • Binary eutectic system
  • Partial melting
  • Initial rock composition at Z is 80 An 20 Di
  • First melt is always the eutectic composition
    (42 An, 58 di)
  • When about 10 melt is formed it can escape
  • At 1350oC the melt escapes
  • Melt composition 55 An 45 Di
  • When this melt cools at some other place it will
    finally crystallize as a rock with 45 Diopside
    and 55 Anorthite

Z
46
Phase rule
  • Binary eutectic system Partial melting
  • 1/ A melt can be formed with a lower temperature
    composition than the mother rock
  • 2/ This melt will cool and form a new rock with a
    different composition than the initial rock
    composition
Write a Comment
User Comments (0)
About PowerShow.com
