Introduction to enzymes

1
Introduction to enzymes
Ichiro Matsumura October 2, 2003
2
Biochemists study the chemical reactions that
make life possible

• Most essential reactions are catalyzed by
  proteins called enzymes.

For example Prof. Pallas protein phosphatase
2A Prof. Edmondson monoamine oxidases Prof.
Corbett nuclear transport me enzyme evolution
3
Enzymes catalyze nearly all chemical reactions in
a cell
Examples we've already encountered 1. DNA
polymerase 2. RNA polymerase 3. topoisomerase 4.
ribosomes These following are NOT enzymes 1.
sigma factors 2. single-strand DNA binding
protein 3. myoglobin and hemoglobin
4
How do enzymes

• increase reaction rates?
• enable reactions under mild conditions?
• increase reaction specificity?
• enable regulation?

And how much do you guys need to know?
5
Overview

• Review of free energy
• Catalysis
• Kinetics
• Inhibition
• Regulation
• Next time
• Basic metabolism and energetics

6
Thermodynamics the study of Free Energy
Life is like a ball rolling down a hill. The
hill Free Energy The ball everything All
balls tend to roll down hill.
Free Energy
All things tend to fall into the state of lowest
free energy.
7
Free Energy GChange in Free Energy DG
High G state - High energy - unstable.
Moving down, DG is negative, Favorable
Moving up, DG is positive, unfavorable - cant
do it without help.
Free Energy
Happiest of all - Lowest Free energy
8
Pre-equilibrium
Mountain top
Mountain height
elevation
Valley depth
The valley of the balls
9
Equilibrium
Mountain top
Mountain height
elevation
Valley depth
kF A kR B
The valley of the balls
10
Chemical equilibria
transition-state
energy of activation
reactants
change in free energy
products
11
Chemical free energy is a combination of
Enthalpy DH How much heat is absorbed Entropy
DS How much order is produced DG DH - T
DS Where T is the temperature. Thus, chemicals
release heat and/or become more disordered as
they lose free energy.
12
The equilibrium constant
Keq B/A DGº -RT ln Keq
Keq describes the ratio of B to A at
equilibrium. Thus
13
Enzymes accelerate reactions by decreasing DG
mountain top activation energy
Catalysts get the reaction to the equilibrium
faster, but dont affect Keq.
14
Catalysis
Enzymes poise all the reactants in a arrangement
that allows the reaction to proceed more rapidly
than it would otherwise.
15
Enzymes can stabilize all sorts of
transition-states

• Acid pKa conjugate base
• HCl -7 Cl-
• RCO2H 5 RCO2-
• H2CO3 6 HCO3-
• H2O 16 OH-
• CH4 62 CH3-

16
Non-enzymatic catalysts also accelerate chemical
reactions
2 NO ? N2 O2 2 NO2 ?N2 2 O2 2 CO O2 ? 2 CO2
Platinum/rhodium surface of catalytic converter
accelerates these reactions
17
Enzymes are more sophisticated catalysts

• Active Site
• Is complementary in shape and functionality with
  the substrate.
• Catalytic Efficiency
• Rate increased 103-108
• Specificity
• Reactions are extremely specific in both the
  substrates and the products.
• Regulation

18
Enzymes increase reaction specificity
19
Enzymes can be regulated
ATCase-CTP (inactive T state)
ATCase-ATP (active R state)
20
Overview

• Review of free energy
• Catalysis
• Kinetics
• Inhibition
• Regulation

21
How fast are enzyme catalyzed reactions?
In Liver, For when you eat
In other cells, For minute to minute energy
22
Biochemists are interested in enzyme kinetics
because they enable

• the elucidation of catalytic mechanisms.
• the understanding of the roles of enzymes within
  metabolic processes.
• the optimization of enzyme-catalyzed processes
  (PCR, cloning and ELISA).

23
Michaelis-Menten Equation
Simple reaction gives a hyperbolic curve for the
rate of the reaction vs. the substrate
concentration. Km reflects the affinity for the
substrate. Vmax reflects the rate of catalysis
and the concentration of enzyme.
24
Active-site saturation
S gtgt KM v0 Vmax
SltltKM v0 Skcat/KM
S KM v0 1/2 Vmax
25
The MM equation gets simple at the extremes.
26
The Lineweaver-Burk plots estimate KM and Vmax
These parameters are on the X and Y intercepts.
27
kcat and KM values vary a lot
28
Competitive inhibition

• Inhibitor competes with substrate for binding to
  enzyme
• Example 1 most drugs
• Example 2 Product inhibition
• Weve made enough, so stop catalyzing!

E S ? ES ? E P
29
Effect of Competitive Inhibition
Competitive inhibitors increase the apparent Km
of the substrate - That is they decrease the
effective affinity of the enzyme for the
substrate.
30
Non-competitive inhibition

• Inhibitor inactivates the enzyme by binding to a
  site different than the substrate-binding site.
• Example
• lead poisoning

31
Effects of Noncompetitive Inhibition
Noncompetitive inhibition inactivates a pool of
the enzyme - Thus reducing the effective
concentration of the enzyme.
32
Allosteric regulation exhibits cooperativity
33
Feedback inhibition of metabolic pathways
High concentrations of a downstream product of a
pathway signals an upstream enzyme to shut down.
34
Regulation by covalent modification of an enzyme
35
Overview

• Free energy which reactions are favorable?
• Catalysis how enzyme accelerate reactions
• Kinetics Michaelis-Menten equation
• Inhibition effect upon enzyme kinetics
• Regulation control of enzyme catalysis
• Next time
• Basic metabolism and energetics
