Title: VR Gadgets part 1


1
VR - Gadgets(part 1)
  • Jyun-Ming Chen
  • Fall 1999

2
Contents
  • Part 1
  • 3D position sensors
  • Trackballs
  • 3D probes
  • Sensing gloves
  • Part 2
  • Stereo viewing
  • 3D sound
  • Force feedback
  • Other sensors

3
VR System
  • reality engine
  • generate desired output from the cues of input
    sensors
  • for example
  • input pos/orient of head
  • output scene to HMD

4
Position Sensors
  • 6DOF (x,y,z, r,p,y)
  • contact vs. non-contact
  • potentiometer
  • magnetic, ultrasound, radar
  • absolute vs. relative

5
Sensor Parameters
  • update rate
  • measurement per sec.
  • latency
  • time delay between action result
  • accuracy
  • difference between actual measured
  • resolution
  • minimal detectable change
  • modes of operation
  • streaming sensor send data continuously
  • one-shot data sent when requested
  • working envelope
  • data property
  • noise, interference, limitations, ...

6
Magnetic Sensors
  • 3 stationary orthogonal antenna, producing a low
    freq. field
  • receiver another set of ortho. antennas
  • signals of receiver to determine pos/orient
  • hook up receiver to moving objects

7
Magnetic Sensors (cont)
  • Sensor noise
  • conditioning circuitry
  • increase near the limit of envelope
  • accuracy degrades near metallic objects
  • calibration method
  • Multiple receiver/transmitter
  • large envelope
  • moving objectS
  • data transmission speed up
  • Demo Bird

8
Ascension The Bird
9
Ascension Film
10
Ultrasound Sensors
  • from 9 distance between speaker-microphone,
    compute the pos/orient
  • c (167.6 0.6T)m/s
  • each speaker activates in cycles

11
Ultrasound (cont)
  • pros
  • cheaper
  • not subject to metallic interference
  • cons
  • line-of-sight constraint
  • lower update rate (than magnetic ones)
  • background noise (bounced off surfaces)
  • multiple spkr/mic possible

12
Logitech Product
13
Trackballs
  • relative sensor
  • drawbacks
  • sensor coupling (may be resolved by s/w)
  • openloop modes
  • small work envelope
  • suitable for CAD systems !?
  • Demo Spaceball

14
Trackballs
Spaceball 2003
Logitech Magellan
15
3D Probe
  • 6 joint angles to specify 6 DOF
  • direct kinematic calculation based on angle and
    link length
  • mode navigate or move objects
  • not affected by magnetic field
  • high update rate

16
Data Glove
  • most intuitive way to interface with virtual
    world
  • gesture human hands has a much richer vocabulary
    (than the 6 DOF)
  • original goal
  • Zimmerman, interested in computer music, wondered
    whether theres a way to make music by playing
    air guitar
  • 1987 optical fiber Lycra glove Polhemus
    Isotrack

17
Hand DOF
  • most gloves handle angle flexion only

18
Joint-Angle Measurement
  • technology determines the price and accuracy
  • optical fiber
  • strain gauge
  • conductive ink sensor
  • mechanical devices

19
(No Transcript)
20
Glove Calibration
  • apply least square on the following model
  • q a br c ln(r)
  • homework
  • before operation, each user need to calibrate
  • impossible to predict a priori how the glove
    suits a particular user
  • other issues
  • adduction/abduction sensor
  • extrapolating distal joint
  • q3 a - bq2 cq22
  • ergonomics (cyberglove)
  • palm finger removed for better ventilation,
    typing, writing

21
Commercial Gloves
General Reality
CyberGlove
22
Commercial Gloves
Pinch Glove (Fakespace)
PowerGlove (Nintendo, 1989) homework
DataGlove (JPL)
23
Glove Films
24
Review Questions
  • ex Bird on 9600 line given data format,
    compute update rate
  • principles of magnetic sensors pos/orient
  • Bird calibration importance and how
  • principles of ultrasound sensors power gloves
  • simple questions on kinematic computation (on
    probes)
  • on glove calibration model computation and
    whats the motivation of ln(r )? Why make a fist
    to calibrate?
