Statistical learning and optimal control:

1
Statistical learning and optimal control A
framework for biological learning and motor
control Lecture 1 Iterative learning and the
Kalman filter Reza Shadmehr Johns Hopkins School
of Medicine
2
State change
Goal selector
Motor command generator
Body environment
Belief about state of body and world
Predicted sensory consequences
Forward model
Integration
Sensory system Proprioception Vision Audition
Measured sensory consequences
3
Results from classical conditioning
4
(No Transcript)
5
(No Transcript)
6
(No Transcript)
7
Choice of motor commands optimality in saccades
and reaching movements
8

• Helpful reading
• Mathematical background
• Raul Rojas, The Kalman Filter. Freie Universitat
  Berlin.
• N.A. Thacker and A.J. Lacey, Tutorial The Kalman
  Filter. University of Manchester.
• Application to animal learning
• Peter Dayan and Angela J. Yu (2003) Uncertainty
  and learning. IETE Journal of Research
  49171-182.
• Application to sensorimotor control
• D. Wolpert, Z. Ghahramani, MI Jordan (1995) An
  internal model for sensorimotor integration.
  Science

9
Linear regression, maximum likelihood, and
parameter uncertainty
A noisy process produces n data points and we
form an ML estimate of w.
We run the noisy process again with the same
sequence of xs and re-estimate w
The distribution of the resulting w will have a
var-cov that depends only on the sequence of
inputs, the bases that encode those inputs, and
the noise sigma.
10

• Bias of the parameter estimates for a given X
• How does the ML estimate behave in the presence
  of noise in y?

The true underlying process
What we measured
Our model of the process
nx1 vector
ML estimate
Because e is normally distributed
In other words
11
Variance of the parameter estimates for a given X
For a given X, the ML (or least square) estimate
of our parameter has this normal distribution
mxm
12
The Gaussian distribution and its var-cov matrix
A 1-D Gaussian distribution is defined as
In n dimensions, it generalizes to
When x is a vector, the variance is expressed in
terms of a covariance matrix C, where ?ij
corresponds to the degree of correlation between
variables xi and xj

13
x1 and x2 are positively correlated
x1 and x2 are not correlated
x1 and x2 are negatively correlated
14

• Parameter uncertainty Example 1
• Input history

x1 was on most of the time. Im pretty certain
about w1. However, x2 was on only once, so Im
uncertain about w2.
15

• Parameter uncertainty Example 2
• Input history

x1 and x2 were on mostly together. The weight
var-cov matrix shows that what I learned is
that I do not know individual values of w1 and
w2 with much certainty. x1 appeared slightly more
often than x2, so Im a little more certain about
the value of w1.
16

• Parameter uncertainty Example 3
• Input history

x2 was mostly on. Im pretty certain about w2,
but I am very uncertain about w1. Occasionally
x1 and x2 were on together, so I have some reason
to believe that
17

• Effect of uncertainty on learning rate
• When you observe an error in trial n, the
  amount that you should change w should depend on
  how certain you are about w. The more certain
  you are, the less you should be influenced by the
  error. The less certain you are, the more you
  should pay attention to the error.

mx1
mx1
error
Kalman gain
Rudolph E. Kalman (1960) A new approach to linear
filtering and prediction problems. Transactions
of the ASMEJournal of Basic Engineering, 82
(Series D) 35-45. Research Institute for
Advanced Study 7212 Bellona Ave, Baltimore, MD
18
Example of the Kalman gain running estimate of
average
w(n) is the online estimate of the mean of y
Past estimate
New measure
As n increases, we trust our past estimate w(n-1)
a lot more than the new observation y(n)
Kalman gain learning rate decreases as the
number of samples increase
19
Example of the Kalman gain running estimate of
variance
sigma_hat is the online estimate of the var of y
20
Objective adjust learning gain in order to
minimize model uncertainty
Hypothesis about data observation in trial n
my estimate of w before I see y in trial n,
given that I have seen y up to n-1
error in trial n
my estimate after I see y in trial n
parameter error before I saw the data (a prior
error)
parameter error after I saw the data point (a
posterior error)
a prior var-cov of parameter error
a posterior var-cov of parameter error
21
Some observations about model uncertainty
We note that P(n) is simply the var-cov matrix of
our model weights. It represents the uncertainty
in our model. We want to update the weights so to
minimize a measure of this uncertainty.
22
Trace of parameter var-cov matrix is the sum of
squared parameter errors
Our objective is to find learning rate k (Kalman
gain) such that we minimize the sum of the
squared error in our parameter estimates. This
sum is the trace of the P matrix. Therefore,
given observation y(n), we want to find k such
that we minimize the variance of our estimate w.
23
Find K to minimize trace of uncertainty
24
Find K to minimize trace of uncertainty
scalar
25
The Kalman gain
If I have a lot of uncertainty about my model, P
is large compared to sigma. I will learn a lot
from the current error. If I am pretty certain
about my model, P is small compared to sigma. I
will tend to ignore the current error.
26
Update of model uncertainty
Model uncertainty decreases with every data point
that you observe.
27
Hidden variable
In this model, we hypothesize that the hidden
variables, i.e., the true weights, do not
change from trial to trial.
Observed variables
A priori estimate of mean and variance of the
hidden variable before I observe the first data
point
Update of the estimate of the hidden variable
after I observed the data point
Forward projection of the estimate to the next
trial
28
In this model, we hypothesize that the hidden
variables change from trial to trial.
A priori estimate of mean and variance of the
hidden variable before I observe the first data
point
Update of the estimate of the hidden variable
after I observed the data point
Forward projection of the estimate to the next
trial
29
Uncertainty about my model parameters
Uncertainty about my measurement

• Learning rate is proportional to the ratio
  between two uncertainties my model vs. my
  measurement.
• After we observe an input x, the uncertainty
  associated with the weight of that input
  decreases.
• Because of state update noise Q, uncertainty
  increases as we form the prior for the next trial.

30
Comparison of Kalman gain to LMS
See derivation of this in homework
In the Kalman gain approach, the P matrix depends
on the history of all previous and current
inputs. In LMS, the learning rate is simply a
constant that does not depend on past history.
With the Kalman gain, our estimate converges on a
single pass over the data set. In LMS, we dont
estimate the var-cov matrix P on each trial, but
we will need multiple passes before our estimate
converges.
31
Effect of state and measurement noise on the
Kalman gain
High noise in the state update model produces
increased uncertainty in model parameters. This
produces high learning rates.
High noise in the measurement also increases
parameter uncertainty. But this increase is
small relative to measurement uncertainty.
Higher measurement noise leads to lower learning
rates.
32
Effect of state transition auto-correlation on
the Kalman gain
Learning rate is higher in a state model that has
high auto-correlations (larger a). That is, if
the learner assumes that the world is changing
slowly (a is close to 1), then the learner will
have a large learning rate.
