Corpus Annotation

1
Corpus Annotation

• ?????????????????
• ?????????????????
• ???

2

• Apart from the pure text, a corpus can also be
  provided with additional linguistic information,
  called 'annotation'.

3
Types of annotation

• Certain kinds of linguistic annotation, which
  involve the attachment of special codes to words
  in order to indicate particular features, are
  often known as "tagging" rather than annotation,
  and the codes which are assigned to features are
  known as "tags".

4

• Part of Speech annotation
• Lemmatisation
• Parsing
• Semantics
• Discoursal and text linguistic annotation
• Phonetic transcription
• Prosody
• Problem-oriented tagging

5

• At the phonological level
• Phonetic/phonemic annotation (syllable
  boundaries)
• Prosodic annotation (prosodic features)
• At the morphological level
• Morphological annotation (prefixes, suffixes and
  stems)
• At the lexical level
• POS Tagging (Parts-of-speech annotation)
• Lemmatization (lemmas)
• Semantic annotation (semantic fields)
• At the syntactic level
• Parsing, treebanking or bracketing (syntactic
  analysis)
• At the discoursal level
• Coreference annotation (anaphoric relations)
• Pragmatic annotation (pragmatic information like
  speech acts)
• Stylistic annotation (stylistic features such as
  sppech or thought presentation)

6
Part-of-speech Annotation.

• This is the most basic type of linguistic corpus
  annotation - the aim being to assign to each
  lexical unit in the text a code indicating its
  part of speech. Part-of-speech annotation is
  useful because it increases the specificity of
  data retrieval from corpora, and also forms an
  essential foundation for further forms of
  analysis (such as syntactic parsing and semantic
  field annotation). Part-of-speech annotation also
  allows us to distinguish between homographs.

7

• Part-of-speech annotation was one of the first
  types of annotation to be formed on corpora and
  is the most common today. One reason for this is
  because it is a task that can be carried out to a
  high degree of accuracy by a computer. Greene and
  Rubin (1971) achieved a 71 accuracy rate of
  correctly tagged words with their early
  part-of-speech tagging program (TAGGIT). In the
  early 1980s the UCREL team at Lancaster
  University reported a success rate of 95 using
  their program CLAWS.

8

• The Brown Corpus, the LOB Corpus and the British
  National Corpus (BNC) are examples of
  grammatically annotated corpora.

9
Lemmatisation

• Lemmatisation is closely allied to the
  identification of parts-of-speech and involves
  the reduction of the words in a corpus to their
  respective lexemes. Lemmatisation allows the
  researcher to extract and examine all the
  variants of a particular lexeme without having to
  input all the possible variants, and to produce
  frequency and distribution information for the
  lexeme. Although accurate software has been
  developed for this purpose (Beale 1987),
  lemmatisation has not been applied to many of the
  more widely available corpora. However, the
  SUSANNE corpus does contain lemmatised forms of
  the corpus words, along with other information.
  See the example below - the fourth column
  contains the lemmatised words

10

• N120510g - PPHS1m He he
• N120510h - VVDv studied study
• N120510i - AT the the
• N120510j - NN1c problem problem
• N120510k - IF for for
• N120510m - DD221 a a
• N120510n - DD222 few few
• N120510p - NNT2 seconds second
• N120520a - CC and and
• N120520b - VVDv thought think
• N120520c - IO of of
• N120520d - AT1 a a
• N120520e - NNc means means
• N120520f - IIb by by
• N120520g - DDQr which which
• N120520h - PPH1 it it
• N120520i - VMd might may
• N120520j - VB0 be be
• N120520k - VVNt solved solve

11
Parsing

• Parsing involves the procedure of bringing basic
  morphosyntactic categories into high-level
  syntactic relationships with one another. This is
  probably the most commonly encountered form of
  corpus annotation after part-of-speech tagging.
  Parsed corpora are sometimes known as treebanks.
  This term alludes to the tree diagrams or "phrase
  markers" used in parsing.

12

• (Ssentence, NPnoun phrase, VPverb phrase,
  PPprepositional phrase, Nnoun, Vverb,
  ATarticle, Ppreposition.)
• Such visual diagrams are rarely encountered in
  corpus annotation - more often the identical
  information is represented using sets of labelled
  brackets.

13

• SNP Claudia_NP1 NPVP sat_VVD PP on_II NP
  a_AT1 stool_NN1 NP PP VP S
• Morphosyntactic information is attached to the
  words by underscore characters ( _ ) in the form
  of part-of-speech tags, whereas the constituents
  are indicated by opening and closing square
  brackets annotated at the beginning and end with
  the phrase type e.g. S ...... S

14

• Because automatic parsing (via computer programs)
  has a lower success rate than part-of-speech
  annotation, it is often either post-edited by
  human analysts or carried out by hand (although
  possibly with the help of parsing software).
• The disadvantage of manual parsing, however, is
  inconsistency, especially where more than one
  person is parsing or editing the corpus, which
  can often be the case on large projects. The
  solution - more detailed guidelines, but even
  then there can occur ambiguities where more than
  one interpretation is possible.

15
Semantics

• The marking of semantic relationships between
  items in the text, for example the agents or
  patients of particular actions. This has scarcely
  begun to be widely accepted at the time of
  writing, although some forms of parsing capture
  much of its import.

16

• There is no universal agreement about which
  semantic features ought to be annotated.

17
Discoursal and text linguistic annotation

• Aspects of language at the levels of text and
  discourse are one of the least frequently
  encountered annotations in corpora. However,
  occasionally such annotations are applied.

18
Discourse tags

• Stenström (1984) annotated the London-Lund spoken
  corpus with 16 "discourse tags". They included
  categories such as
• "apologies" e.g. sorry, excuse me
• "greetings" e.g. hello
• "hedges" e.g. kind of, sort of thing
• "politeness" e.g. please
• "responses" e.g. really, that's right

19

• Despite their potential role in the analysis of
  discourse these kinds of annotation have never
  become widely used, possibly because the
  linguistic categories are context-dependent and
  their identification in texts is a greater source
  of dispute than other forms of linguistic
  phenomena.

20
Anaphoric annotation

• Anaphoric annotation is the marking of pronoun
  reference - our pronoun system can only be
  realised and understood by reference to large
  amounts of empirical data, in other words,
  corpora.
• carried out by human analysts, since one of the
  aims of the annotation is to train computer
  programs with this data to carry out the task.
• There are only a few instances of corpora which
  have been anaphorically annotated one of these
  is the Lancaster/IBM anaphoric treebank

21
Phonetic transcription

• Spoken language corpora can also be transcribed
  using a form of phonetic transcription.
• carried out by humans rather than computers. Such
  humans have to be well skilled in the perception
  and transcription of speech sounds.
• Phonetic transcription is therefore a very time
  consuming task.
• "sounds" do not have such clear boundaries,
  therefore what phonetic transcription takes to be
  the same sound, might be different according to
  context.

22

• Phonetically transcribed corpora is extremely
  useful to the linguist who lacks the
  technological tools and expertise for the
  laboratory analysis of recorded speech.
• One such example is the MARSEC corpus (which is
  derived from the Lancaster/IBM Spoken English
  Corpus) and has been manipulated by the
  Universities of Lancaster and Leeds. The MARSEC
  corpus will include a phonetic transcription.

23
Prosody

• Prosody refers to all aspects of the sound system
  above the level of segmental sounds e.g. stress,
  intonation and rhythm. The annotations in
  prosodically annotated corpora typically follow
  widely accepted descriptive frameworks for
  prosody such as that of O'Connor and Arnold
  (1961). Usually, only the most prominent
  intonations are annotated, rather than the
  intonation of every syllable. The example below
  is taken from the London-Lund corpus

24
Problem-oriented tagging

• Problem-oriented tagging is the phenomenon
  whereby users will take a corpus, either already
  annotated, or unannotated, and add to it their
  own form of annotation, oriented particularly
  towards their own research goal. This differs in
  two ways from the other types of annotation we
  have examined in this session.

25

• It is not exhaustive. Not every word (or
  sentence) is tagged - only those which are
  directly relevant to the research. This is
  something which problem-oriented tagging has in
  common with anaphoric annotation.

26

• Annotation schemes are selected, not for broad
  coverage and theory-neutrality, but for the
  relevance of the distinctions which it makes to
  the specific questions that the researcher wishes
  to ask of his/her data.

27

• Although it is difficult to generalise further
  about this form of corpus annotation, it is an
  important type to keep in mind in the context of
  practical research using corpora.

28
Error Tagging
29
Problem-oriented annotation
30
Automatic or manual
31

• CLAWS tagger (online trial service)
• http//www.comp.lancs.ac.uk/computing/research/ucr
  el/claws/tagservice.html
• http//www.comp.lancs.ac.uk/computing/research/ucr
  el/claws/ (for licensed user)
• AMALGAM tagger (email)
• http//www.scs.leeds.ac.uk/ccalas/amalgam/amalgtag
  3.html
• Brills tagger
• http//www.cs.jhu.edu/brill/code.html
• GoTagger (free)
• http//uluru.lang.osaka-u.ac.jp/k-goto/download/d
  ownload.cgi?nameGoTagger07.zip
• TreeTagger (free, DOS, Windows GUI available but
  not user-friendly)
• http//www.ims.uni-stuttgart.de/projekte/corplex/T
  reeTagger/DecisionTreeTagger.html

32
(No Transcript)
33
(No Transcript)
34
(No Transcript)
35
(No Transcript)
36
Anno Tool
