Title: The Scientific Method


1
The Scientific Method
  • Lecture 3
  • Data Recording Transformation

2
Data Recording, Transformation and Descriptive
Statistics
  • In this lesson, we will
  • Discuss considerations in recording and
    transforming data
  • Explore the use and purpose of descriptive or
    summary statistics
  • Explain the concepts of frequency distribution,
    bar chart, histogram, mean, median, mode, range,
    variance, standard deviation
  • By the end of this exercise, you should be able
    to
  • Explain what is meant by data transformation and
    summarisation, using examples
  • Define the terms frequency distribution, bar
    chart, histogram, mean, median, mode, range,
    variance, standard deviation and demonstrate
    their application to data sets

3
Recording Data
Field or experimental data must be recorded in a
planned way Variables under investigation may be
direct measurements e.g. weight, length,
amount, pH category frequencies e.g. numbers of
a species, length range, colour derived
measurements e.g. , numbers / area, amount /
time, amount / area / time
  • Datalogging tables must
  • record all values needed to derive the value of a
    variable
  • permit derivation calculations to be recorded
    alongside the raw data
  • have clear headings and units for each value e.g.

4
Recording Data
Areas to be sampled can be measured out on a grid
system (eg 0.5 metre intervals for 0.5 x 0.5m
quadrats) and sample quadrat positions chosen
fromrandom number tables
Map references are given as Eastings (rows)
first, then Northings (columns) second
5
Recording Data
Fixed independent variables ie temperature,
humidity, container size which have the potential
to affect the value of the dependent variable
must also be recorded
Preliminary experiments may be needed to set
values for thesee.g. a temperature at which a
bacterial culture will grow well
laboratory instruments must be calibrated before
recording variable values eg pH meters are
checked / reset against buffer solutions
spectrophotometers must be zeroed against a
blank solution containing reagents but no
product, then read against a range of known
concentrations of the product - used to plot
a calibration curve for the instrument
Consistent rounding of decimal numbers (up or
down!) and correct choice of significant figures
to reflect the accuracy of measurements is very
important Rounding up is conventional in
scientific work
6
Data Transformation
Summarises and highlights trends in the data eg
Totals sum all the data values for a variable,
useful for comparison and other
purposes Percentages describe the proportion of
data falling into particular categories Rates
show how a variable changes with time and allow
comparison of data recorded over different time
periods Reciprocals (1 variable) reverse the
magnitude of a variable and can help data
interpretation Relative values expression of
data in relation to a standard value, providing
context or helping application e.g. egg output
per 1000 hens per month , energy requirement per
Kg body weight problem?
7
  • Now attempt the two data transformation exercises
    in your workbook!

8
Descriptive Statistics
Three important mathematical descriptions of the
distribution of data
Empirical frequency distributions Measures of
location Measures of dispersion
Frequency Distributions Show the frequency of
occurrence of observations in a data set
Qualitative, non-numerical and discrete data (for
at least one variable) are usually depicted in a
bar chart
9
Descriptive Statistics
10
Descriptive Statistics
Continuous data is usually depicted in a histogram
Class intervals must be even and clearly defined
such that an observation can fall INTO ONE CLASS
ONLY e.g. 0 - 0.99, 1.00 1.99, 2.00 2.99,
3.00 3.99
11
Descriptive Statistics
It is sometimes helpful when comparing two or
more frequency distributions where the total
numbers of observations differ to calculate
relative frequency or cumulative relative
frequency distributions
This type of data plot is called an ogive
12
Measures of Location (Averages)
Average refers to several measures of the central
tendency of a data set
The mean is a good measure of central tendency
when the data is distributed symmetrically but
will be distorted by a few excessively small or
large values of x (outliers)
13
median the central value in a set of n
observations arranged in rank order, with as many
observations above it as below it
Measures of Location (Averages)
If n is an even number, the median is half-way
between the value of the central two values
  • mode - the most commonly occurring observation
    in a data set.The modal class is the group or
    class into which most observations fall in a
    histogram

In a perfectly symmetrically distributed data
set, mean, median and mode have the same value
NOW ATTEMPT THE EXERCISE IN YOUR WORKBOOK
14
Measures of Dispersion
  • Four main expressions of the spread of data
  • Range the difference between the largest and
    the smallest observations
  • Interquartile range - the range of values
    enclosing the central 50 of the observations
    when they are arranged in order of magnitude
    (ranked )
  • Variance - determined by calculating the
    average of the deviation of each observation from
    the arithmetic mean
  • The variance is a very useful measure of data
    dispersion. Because some of the values will be
    negative, the deviations are squared to make them
    all positive and the variance ( s2 ) is
    calculated as

15
Measures of Dispersion
s2 is used to denote the sample variance and
distinguish it from the population variance
given the symbol s2 and calculated by dividing by
n
s2 mean of (squares minus the square of the
mean)
16
Measures of Dispersion
  • Standard deviation ( s or SD) is the square
    root of the variance and the most popular
    measure of dispersion

and represents the average of the deviations of
the observations from the arithmetic mean
The population standard deviation ( s ) is
calculated by using n rather than (n 1) in the
same way that s2 represents the population
variance. The population mean is given the symbol
µ (mu)
Exercise!
Calculate the range, variance and standard
deviation of the following data set The plasma
vitamin E concentration (?mol/l) in 12 heifers
showing clinical signs of a muscle condition were
as follows 4.2, 3.3, 7.0, 6.9, 5.1, 3.4, 2.5,
8.6, 3.5, 2.9, 4.9, 5.4
