Dos

1
Dos Dont of Concrete Construction Inspection

2
Concrete Certifications
Concrete Field Testing Concrete Laboratory
Testing Reinforced Concrete Special
Inspector Transportation Construction
Inspector Inspector in Training Flatwork
Finisher Flatwork Technician Strength
Testing Aggregate Testing
3
Concrete Materials

• Composition of Concrete
• Water
• Cement
• Categories. Type I
• . Type II
• . Type III
• . Type V
• Aggregates

4
Concrete Materials

• Composition of Concrete
• Water
• Cement
• Categories
• Aggregates3/8 to 11/2
• Clean, uniform and well-graded

5
Concrete Materials

• Admixtures
• Air-entraining
• Water-reducer.Low Range
• Mid Range
• .High Range
• Retarding
• Accelerating

6
Concrete Mixture

• Criteria
• Workability
• Consistency
• Durability
• Strength
• Mix design

7
Review Submittals

• Date
• Producer and plant
• Job
• Contractor
• Type and source of cement
• Class and source of fly ash

• Water content and max. W/C
• Admix types/sources
• Size and source of Agg. (Sp.Gr. and Absorption)
• Quantities of all materials

8
Review Submittals

• Class of concrete and descriptive details
• Proof of strength
• Trial Batch (s)
• Statistical record
• Aggregate qualification tests
• Any special testing required under the project
  specification
• Shrinkage
• Sulfate resistance
• Chloride ion content

9
Know Class of Concrete Specified Division 03304
Cement Content
Design Strength
W/C
Air
Slump

• 2000
• 3000
• 4000
• 5000
• 6000
• 7000

10
Review Certificates of Compliance

• Cement ASTM C 150, C 595 or C 1157
• Chemical analysis
• Tricalcium aluminate (C3A)
• 8 max. for type II
• 5 max. for type V
• Alkali content
• 0.6 for low alkali cement
• Physical testing
• Fineness
• Compressive strength
• Set time
• Soundness

11
Review Certificates of Compliance

• Fly ash ASTM C 618
• Chemical
• LOI (max. 6)
• Calcium
• Alkalis
• Physical
• Pozzolanic activity
• Fineness
• Foam index (not required)

12
Review Certificates of Compliance

• Admixtures ASTM C 494, C 260
• Aggregates
• General acceptance
• ASTM C 33 compliance
• Current tests
• Specific gravity and absorption
• Sieve analysis
• Moisture contents

13
Mix Design Approval

• Final approval by the Project Engineer is
  required.
• Special attention to
• W/C
• Cement Type
• Aggregate source, size and gradation
• Statistical record of strength or trial batch
  results
• Any special requirements

14
Review Strength Requirements

• Average of 30 tests with Standard Deviation
• 1 in 100 tests expected below fc per ACI 214
• Glitch in current APWA spec
• Calls for ACI 301/318 (1 in 100 to be not more
  than 500 psi below fc)
• Pay reduction schedule in place for lots below
  fc by even a few psi- with rejection of entire
  lot at more than 400 psi (engineers option).

15
Check W/C
16
Review Plant Certifications

• UDOT and APWA require NRMCA equivalent
  certification
• UDOT requires a quality management plan
• ACI certified personnel on site
• Plant inspector may ask to review current status
  of management plan

17
Know Type of Batching

• What type of plant is it ?

Pre-mix
Dry batch
18
Check Materials at Batch Plant

• Cement
• Does the spec require certification with each
  load?
• Is a sample needed?
• If so, is it properly labeled and stored?
• Fly ash and other admixtures

19
Check Materials at Batch Plant

• Aggregates
• Proper size?
• Are gradations up to date?
• Bins properly labeled?
• Moisture content
• Probe or physically determined
• Are compensations (final weights) valid?
• Loader operator.

20
Check Admixtures

• Dosage
• Efficiency adjustments
• Air dosed as needed
• WRA dosage may need to be changed
• High range dosage adjustments
• Dispenser condition and accuracy

21
Check Batching Equipment

• Condition of equipment- NRMCA certification
• Scale and water meter accuracy and calibration
• Moisture meter
• Slump adjustments
• Hot water requirements
• Batch sequence
• Time requirements
• Is the batch print-out working?-Can you read it?

22
Check Delivery Ticket

• Date and time loaded
• Producer and plant
• Job
• Contractor
• Type and source of cement
• Class and source of fly ash

• Water content and (W/C) and tempering water
  permitted
• Admix types/sources
• Size and source of Aggregates
• Quantities of all materials

23
Check Transit Mix Trucks

• NRMCA certification
• Fin cleanliness and condition
• Water meter condition
• Revolution counter
• Hopper wash-down
• Mixing time
• Mixing speed
• Does the driver know what mixing speed is?
• Is the truck empty?

24
AT the Project

• Inspection and Testing

25
Conduct Pre-Construction Meeting

• Inspectors and testers should attend
• Mix selection
• Timing of loads
• What slump is needed ?
• Where will samples be taken ?
• Point of sampling
• Access
• Sample storage
• Who is responsible for accepting or rejecting?

26
Delivery Tickets

• Review to determine
• Truck meets agency requirements
• Proper mix has been delivered
• Time of batching
• Water limit for tempering

27
Testing

• Know where all tests will be performed and where
  tests specimens will be stored.
• Perform all tests within proper time limits

28
Conduct Acceptance Tests

• Sampling Fresh Concrete C 172
• Temperature C 1064
• Concrete
• Air
• Slump C 143
• Air Content
• Pressure method C 231
• Volumetric C 173
• Unit Weight C 138
• Compressive Strength Cylinders C 31 C 39

29
(No Transcript)
30
(No Transcript)
31
(No Transcript)
32
(No Transcript)
33
Maintain Testing Records

• Accuracy
• Record exact locations for concrete in the
  structure or pavement.
• Record data according to the specifications
  (decimals etc.) NO rounding of numbers for air
  content and unit weight.
• Record slump to ¼ inch.

34
Testing Records

• Reporting
• Record all data as soon as possible.
• Testing information is not top secret.
• Should be shared- quality control needs feed-back
  to function properly.
• C 94 requires that the cylinder test reports be
  shared with the concrete producer in a timely
  fashion.

35
Acceptance

• Concrete must meet the specification requirements
  for slump, air, temperature, age and compressive
  strength
• Know who is responsible for product rejection
  (for slump or air out of spec)
• Know the protocol.
• Be prepared to use some judgment.
• Try to get a consensus

36
Placement

• Reinforcing steel
• Formwork
• Conveying equipment
• Consolidation methods
• Finishing
• Technique
• Appearance

37
(No Transcript)
38
(No Transcript)
39
(No Transcript)
40
(No Transcript)
41
(No Transcript)
42
(No Transcript)
43
(No Transcript)
44
(No Transcript)
45
(No Transcript)
46
(No Transcript)
47
(No Transcript)
48
(No Transcript)
49
(No Transcript)
50
(No Transcript)
51
(No Transcript)
52
(No Transcript)
53
(No Transcript)
54
(No Transcript)
55
(No Transcript)
56
(No Transcript)
57
(No Transcript)
58
(No Transcript)
59
(No Transcript)
60
Proper Curing is Essential

• Maintaining
• Moisture Content of Concrete
• Temperature
• Maximize Hydration of Portland Cement
• Maximize Properties of Hardened Concrete

61
Effect of Adequate Curing on Hardened Concrete
Early Cracking Eliminated
Strength Gain Accelerated
Wear Resistance Greatly Improved
Durability Greatly Improved
Watertightness Greatly Improved
62
Curing

• Method
• Satisfactory moisture content
• Duration
• Weather considerations

63
(No Transcript)
64
(No Transcript)
65
(No Transcript)
66
(No Transcript)
67
(No Transcript)
68
(No Transcript)
69
Summary

• Proper concrete mix design
• relies on the individual characteristics and
  condition of the ingredients of the concrete mix

• is influenced by the proportioning and by the
  amount of water added to the cement/aggregate mix
