Wireless Communication Overview

1
Wireless Communication Overview
2
Generic WCS (Wireless Communication System)
Base Station
Base Station
Switch
Handset
Handset
3
Dimensions

• Carrier/Network Operator
• Spectrum, PSTN, Internet, /ISP, Tele Service
  Provider
• Protocols/Standards/Systems
• GSM, AMPS, DECT, PHS, Satellite, ...
• Network Elements
• MSC, BSC, BTS, HLR/VLR, IN Elements, ...
• Services/Applications/Service Platform
• Voice call, data call, add-on services, ...
• Handset/Terminals/Smart Phone/Wireless Info
  Appliance
• OS, User-Interface, Protocol suite
• Subscriber Behavior

4
Essential Functions

• Initialization
• Register
• Bursty Data/Signaling Transmission
• Paging, channel assignment, control signaling,
  signaling data, ...
• Mobility
• Handoff, roaming

5
Wireless Communication Challenges

• Resources
• Bandwidth
• Channel impairment/fading
• Utilization
• Mobility
• Handover, Roaming
• Location management
• User access behavior
• Services
• Security, Data, ...
• Terminal Equipment
• Energy

6
Technology Trend
Analog Voice
Digital Voice
Wireless Multimedia
Narrow band
Wide band
Mobile Phone
Mobile Phone Wireless Data
Wireless Info Appliance
7
High-Tier v.s. Low-Tier Systems

• High-Tier Systems
• Serving a highly mobile population by means of
  sophisticated high-power radios
• Larger cell diameter
• Higher transmitter power
• Low-Tier Systems
• Serving subscribers moving at walking speeds
• Smaller cell diameter
• Lower transmitter power

8
A System View

• High-Tier Systems
• GSM, DAMPS, CDMA
• Satellite Systems
• Low-Tier Systems
• CT-2, DECT, PHS, PACS

9
Existed System Study (1)

• GSM
• (Global System for Mobile Communications)

10
Outline

• Overview
• Architecture
• Numbering Routing
• Essential Functions
• Air Interface
• Dual Band Network Study

11
GSM Overview

• GSM
• Developed by European Community
• Following ISDN
• Classified as Tele services and Data services
• International roaming
• Radio transmission is based on TDMA (Time Divide
  Multiple Access)

12
GSM Air Resource Allocation

• Spectrum
• Uplink Band
• 890 - 915 MHz
• Downlink
• 935-960 MHz
• Spacing
• Duplex spacing 45 MHz
• Channel spacing 200 KHz
• Total channel number 124
• Number of slots per channel

13
GSM Network Components

• MSC Mobile Switching Center
• BSC Base Station Controller
• BTS Base Transceiver Station
• HLR/VLR Home Location Register/Visting Location
  Register
• SIM Card Subscriber Identity Module Card
• Handset
• Service Center

14
GSM System Architecture
HLR/ VLR
UM
A
A-bis
SS7
MSC
BSC
X.25
BTS
OMC (Operation Maintenance Center)
Handset
Operation Terminal
Data Terminal
Radio sub-system
Mobile station
Network sub-system
PSTN
15
SIM Card

• Subscriber Identity Module
• Contains
• phone number (MSISDN)
• international mobile subscriber identity (IMSI)
• status of SIM
• service code
• authentication key
• PIN (personal identification code)
• PUK (personal unlock code)

16
Numbering

• Mobile Subscriber ISDN Number (MSISDN)
• Mapping to Mobile Station Roaming Number (MSRN)
  by HLR
• International Mobile Subscriber Identify (IMSI)
• Stored in SIM/HLR
• Temporary Mobile Subscriber Identity (TMSI)
• Assigned by VLR, Stored in VLR
• International Mobile Equipment Identity (IMEI)
• Unique ID to handset, used by air interface

17
Routing

• Information resident in MS SIM
• IMSI, TMSI, IMEI, and misc. information
• Routing Information used by Network
• MSISDN, MSRN

18
Location Information Hierarchy

• Location Area Hierarchy

HLR
VLR
VLR
MSC1
MSC2
HLR Home Location Register VLR Visitor Location
Register MSC Mobile Switching Center LA
Location Area MS Mobile Station
LA1
LA2
19
Location Information

• Determines subscriber current location
• Inform network when subscriber enters a new cell
• Have to trade-off between paging and location
  update traffic in system planning
• Location info contained in
• Mobile country code, mobile network code,
  location area code, cell ID
• Location information is the major burden for
  network

20
GSM Essential Functions

• Registration/Location Updating
• Establishing Communication Link
• Handover
• Roaming

21
Registration/Location Updating

• Inform system the new location of a MS when it
  changes Location Area (LA)
• MS continuously measures signal strength to
  choose the best radio base station
• The mobile station tunes to a new base station
  with better signal strength

22
Establish Communication Link

• Handset request available channel from BTS
• BTS forward the request to BSC
• BSC chooses an available channel and inform BTS
  to activate the channel
• Information the BSC channel assignment message
  carries
• a reference number
• information about allocated channel (type,
  frequency, time slot, )
• the initial transmission power level to be used
  by the handset

23
Handover

• The process of changing cells during a call is
  called handover in GSM terminology.
• The measurements to choose the best target cell
  are performed by MSs and BTSs.
• The measurements from the MS and the BTS are
  processed in the BSC. This evaluation process is
  called locating.

24
Roaming

• A subscriber moves from the service area of
  his/her home service company(or network) to
  another operating company(or network)

25
Wireless Data
26
Computing Communication
Wireless Information Devices
Laptop
PDA
Mobile Phone
Communicator
Smartphone
Computing
Communication
27
Wireless Voice Data Dominate Wireline
28
Typical Internet Service Requirements

• Long (or continuous) sessions
• Multiple overlay sessions
• High degree of burstiness
• Large span in QoS requirements

Fundamentally difference from voice telephony
29
Challenges

• IP network
• Protocols
• New data services
• Generic service platform
• Information appliances (Handhelds, Palm devices,
  Smart phones, In-Car systems)

Lots of bandwidth
30
Todays GSM Data Services

• SMS (Short Message Service)
• USSD (Unstructured Supplementary Service Data)
• HSCSD (High Speed Circuit Switched Data )
• GPRS (General Packet Radio Services)
• EDGE (Enhanced Data rates for GSM Evolution)

31
Convergence GSM/IP Network

• H.323
• WAP

32
H.323 Architecture
Visiting MS
Home Service System
PSTN
33
WAP (Wireless Application Platform)
Filter
WAP Proxy
Wireless Markup Language
Web Server
Filter
WAP Proxy
34
Future GSM
Internet (TCP/IP)
GPRSUMTS
Co-sited GSM UMTS Base Station Subsystem
GSM mobile
Network Subsystem (GSMUMTS)
SGSN
GGSN
SIM Card
MSC/HLR (GSMUMTS)
GSM/UMTS mobile
GSM Base Station
BSC (GSM)
SIM
HLR
MSC
UMTS mobile
Landline NW (PSTN/ISDN)
UMTS (IMT-2000) Base Station
BSC (UMTS)
IN service control point
35
GSM Radio Steps to 3rd Generation
Introduction of 3rd generation radio 2001 -
2002 New multimedia services Mass market cost of
service (IMT-2000)
Development of Radio Technology
2000 More capacity when needed (GSM384)
1999 Internet-like IP packet services (GPRS)
1998 Landline-like circuit services (HSCSD)
1997 Basic GSM data at 9.6 kb/s
Evolution of GSM Platform
36
Air Interface Protocols

• SS7
• Between PSTN and PLMN ( Public Land Mobile
  Network)
• X.25
• BSC and Operation centers
• A
• Between BSC and MSC
• A-bis
• Between BTS and BSC
• Um
• Radio interface between BTS and Handset

37
Air Interface Messages

• RR Radio Resource Management Messages
• MM Mobility Management Messages
• CM Call Management Messages

38
Air Interface--Channels
Full-rate TCH/F
Two-way
Traffic channels
half-rate TCH/H
Frequency correction FCCH
Synchronization SCH
Broadcast control BCCH
Base-to-mobile
Paging PCH
Signaling channel
Access grant AGCH
Random access RACH
Stand-alone dedicated control SDCCH
Slow associated control SACCH
Two-way
Fast associated control FACCH
39
Dual Band Network
40
Dual Band Network GSM 900 DCS 1800 Air
Interface
41
GSM/DCS Network Differences

• DCS 1800 cells are generally coverage limited
• GSM 900 cells tend to be capacity limited
• Implying a need for more DCS 1800 cells to
  provide similar coverage to a comparable GSM 900

42
Integrate GSM and DCS Networks

• Integrating 900 and 1800 networks by linking
  900/1800 cells to same BSC An Integrated dual
  band network
• Sharing BSC, MSC, and HLR
• Benefits
• Reuse existing resources
• Reuse spectrum means to enlarge the scalability
  of network and to improve the utilization of
  spectrum resource
• Simplify the handoff between networks
• Flexible and changeable infrastructure

43
Integrated Dual Band Network
MSC
BSC
DCS BTS
DCS BTS
DCS BTS
GSM BTS
GSM BTS
GSM BTS
