ICE, WIND,

1
MICROWAVE RADIOMETRY
ICE, WIND, AND ASSORTED PARAMETERS
2
(No Transcript)
3
(No Transcript)
4
(No Transcript)
5
Blackbody Radiation

• According to thermodynamic principles, all matter
  at temperatures greater than absolute zero both
  absorb and emit non-coherent EM energy (noise)
  simultaneously.
• The absorption of EM energy by a body causes its
  physical or thermodynamic temperature to rise
  which, in turn, results in an increase in the
  emitted EM radiation.
• When the body reaches its thermal equilibrium,
  its physical temperature is constant and the rate
  of energy absorbed is exactly matched by the rate
  of energy emitted.

6
(No Transcript)
7
(No Transcript)
8
Microwave Radiometry

• In the microwave region of the EM spectrum,
  physical media radiate energy according to the
  Rayleigh-Jeans Law.
• Microwave Brightness Temperature, TB, of a medium
  is the product of the media emissivity and its
  physical temperature.

9
(No Transcript)
10

• Radiative Transfer Theory states that the TB
  measured by a spaceborne radiometer is the linear
  sum of individual contributions from the
  atmosphere and surface.

11
Microwave Emissivity

• Emissivity varies with
• EM wavelength (defines radiometer operating
  frequency)
• EM polarization incidence angle
• Geophysical parameters associated with the
  physical media.
• Atmospheric microwave emission is non-polarized
• Resonant absorption by water vapor (21 GHz, 183
  GHz, 325 GHz),
• Resonant absorption by oxygen (60 GHZ 120 GHz)
• Non-resonant absorption of hydrometeorological
  parameters (cloud water and rain).

12
Microwave Emissivity cont-1

• Rain increases microwave brightness
• But rain can also reduce microwave emission by
  scattering
• When size of droplets become a significant
  fraction of the EM wavelength.
• Ocean microwave emission is strongly polarized
  and depends upon the dielectric properties of sea
  water.
• Emissivity is a function of salinity, sea surface
  temperature, and small scale ocean wave roughness
  (proportional to the surface frictional wind
  speed).

13
Microwave Emissivity cont-2

• Sea ice microwave emission is weakly polarized
  and depends upon ice type and concentration.
• First year (FY) ice is saline and has a
  emissivity near unity ( gt 95 ).
• Multi-year, MY, sea ice has undergone a
  thaw/freeze cycle and has much less salt content.

• Emissivity of MY ice is less than FY ice
• Microwave brightness contrast is gt100 K between
  open water and FY and MY sea ice.

14
Microwave Emissivity cont-3

• Microwave emission from snow-covered land depends
  upon snow depth
• Microwave emission from dry bare soil has nearly
  unity emissivity.
• TB decreases with increasing free water content
  (soil moisture).
• Vegetation cover also masks the surface
  emissivity for frequencies greater than 2 GHz
• It is not possible to discriminate between
  vegetation types.

15
Microwave Remote Sensing

• Geophysical parameter retrieval involves
  inversion of multi-spectral brightness
  temperature measurements.
• Number of required independent radiometric
  observations is at least equal to the number of
  parameters.
• More independent measurements generally improve
  the accuracy of the retrieval.
• Brightness measurements at different EM
  wavelengths, polarizations, and incidence angles
  constitute independent radiometric measurements.

16
(No Transcript)
17
183 GHz atmos. Water vapor

• 19.35 GHz, 37.0 GHz 85.5 GHz, V H-pol
• 22.235 GHz- V-pol only (atmospheric moisture obs.)

18

• Defense Satellite Meteorological Program (DMSP)
• Special Sensor Microwave/Imager (SSM/I)

19

• Defense Satellite Meteorological Program (DMSP)

20
Overview

• SSM/I operational in July 1987 on the F-8
  satellite.
• Subsequent SSM/I's have flown on F- 10 (Nov.
  1990), F-11 (Dec. 1991), F-12 (Aug 1994), and
  F-13 (Mar. 1995)
• SSM/I is a seven channel passive microwave
  radiometer operating at four frequencies
• 19.35 GHz, 37.0 GHz 85.5 GHz, V H-pol
• 22.235 GHz- V-pol only
• Products include
• Atmos Precipitation, Total Precipitable Water,
  Cloud Liquid Water
• Ocean Surface Wind
• Land/Ice Snow Cover, Sea-Ice

21
SSM/I - Brightness Temperature
22
CLOUD LIQUID WATER

• Integrated cloud liquid water (CLW) is retrieved
  over ocean (due to the low emissivity
  background).
• CLW Algorithm uses measurements at 19, 37, and 85
  GHz. Use of the 85 GHz measurements allows for
  the retrieval of extremely low amounts of CLW.
• Two cloud products (ocean only)
• mean liquid water path (LWP)
• mean cloudiness fraction (CFR)

23
(No Transcript)
24
PRECIPITATION

• SSM/I rainfall algorithm utilizes 85V GHz channel
  to detect the scattering of upwelling radiation
  by precipitation sized ice particles within the
  rain layer.
• Technique is applicable over land and ocean.
• Rain rate derived indirectly based on the
  relationship between the amount of ice in the
  rain layer to the actual rain fall on the
  surface.
• Additionally, over ocean, an emission rain
  algorithm, based upon the absorption of the
  upwelling radiation by rain and cloud water (at
  19 and 37 GHz) is blended with the scattering
  algorithm.

25
PRECIPITATION
26
Precipitation December 1998
27
MICROWAVE WIND PRODUCTS PASSIVE
28
Wind over the oceans

• Wind stress is important for forcing the ocean
• High quality, routine time series (high spatial
  and temporal resolution) needed for weather
  prediction models, ocean models

• Traditional method for ocean wind measurements
• ships
• buoys
• These are limited
• cover limited area

29
Wind

• Scatterometers
• Sky Lab
• Seasat
• ERS-1, and ERS-2
• NSCAT
• SeaWinds
• Microwave
• SMMR
• SSM/I
• Geosat
• Analyses blend in situ, model, and sensor
  results

• Ocean response to winds waves
• capillary to swell
• This provides basis for wind remote sensing
• Sensors
• Radar (meas. Backscatter from capillary waves)
• Microwaves (depends on surface roughness)

30
Wind microwave

• SMMR Scanning Multichannel Microwave Radiometer
• Flew on Nimbus-7
• Data at GSFC, JPL-PO DAAC
• 1979-1984

• SMMR 10 channels that are close to those of the
  SSM/I

31
(No Transcript)
32
Wind microwave

• SSM/I (Special Sensor Microwave / Imager)
• Polar orbiter, near circular orbit,
  sun-synchronous, ca. 820 Km altitude
• Flies on Defense Meteorological Satellite
  Program (DMSP) (F-8, F-10, F-11, F-12, F-13
  satellites)
• Data to Air Force Global Weather Central, the
  Navy Fleet Numerical Oceanography Center (FNOC),
  NGDC

• SSM/I seven-channel, four frequency,
  linearly-polarized, passive microwave radiometric
  system
• microwave brightness temperatures at 19.35,
  22.235, 37.0 and 85.5 GHz

33
Winds microwave

• Microwave data provide a measure of changes in
  the brightness temperature of the surface of the
  ocean, which may be related to the surface
  roughness

• Most current methods use statistical algorithms
  which mean or difference channel brightness
  temperatures Halpern et al., 1991. JPL
  Publication91-8, 110pp Wentz, F., et al., 1986
  JGR 91, C2, 2289 2307.

34
Winds microwave

• Algorithm relates wind speed at 19.5 m above the
  surface to microwave emissivity estimated by
  brightness temperature obtained by two SSM/I
  channels (37 GHz VH), and radiative transfer
  models of atmospheric absorption

• Wind direction not derived from sensors. Rather,
  this is provided by ECMWF or other models or
  analyses.

35
Winds microwave

• The effect of ocean wind speed is to "roughen"
  the calm surface through the formation of
  capillary waves and foam which increases the
  emissivity.
• The 37 GHz channels are the most sensitive to
  this phenomenon.
• Detection of wind speed variations are limited to
  mainly non- raining atmospheric conditions, as
  dense clouds and rain tend to mask the ocean
  surface.

36
Winds microwave

• Atlas et al. 1993 in Atlas of satellite
  observations related to global change, p.
  129.
• Compared SSM/I wind products to buoys and ships
• Results
• Accuracy
• Speed2m/s and
• Direction22 degrees

• In Atlas et al., 93, average wind speed and
  streamline maps are shown. Average resultant
  speeds are underestimates because the maps were
  derived from separate averages of u and v
  components.
• In general, SSM/I winds agree well with ground
  truth, climatologies, and may be used for global
  studies, interannual variation studies, and
  updating models.

37
OCEAN SURFACE WIND SPEED
38
Ocean Surface Wind Speed - Dec. 1998
39
MICROWAVE WIND PRODUCTS ACTIVE SCATTEROMETER
40
Winds scatterometers

• Scatterometer high frequency radar that that
  transmits pulses of energy toward the ocean and
  measures the backscatter from the ocean surface.
• The scatterometer detects wind speed and
  direction over the Earths oceans by analyzing
  the backscatter from the small wind caused
  ripples (cats paws)

• History
• Skylab (1973-1974)
• Seasat (1978)
• ERS-1 and ERS-2
• NSCAT (1996-present)
• SeaWinds (1999)

41
Stick Scatterometers
NSCAT on ADEOS-1 (NASA sensor on Japanese
satellite)
42
Stick Scatterometers
Active Microwave Instrument (AMI) on ERS-1 and 2
43
Scanning microwave scatterometer
QuikScat (NASA)
SeaWinds (NASA on ADEOS-2)
44
(No Transcript)
45
BRAGG ELECTROMAGNETIC SCATTERING
Bragg scattering waves build up or destroy each
other
46
NADIR BACKSCATTERING - PHYSICAL OPTICS
47
CAPILLARY WAVE GROWTH WITH FRICTIION VELOCITY
48
EFFECT OF ATMOSPHERIC STABILITY ON OCEAN WIND
PROFILE
49
LOGARITHMIC RESPONSE OF NRCS TO OCEAN FRICTIONAL
VELOCITY
UPWIND OBSERVATION 30º INCIDENCE ANGLE
50
(No Transcript)
51
NRCS SIGNATURE VS. WIND DIRECTION
52
(No Transcript)
53
NRCS WIND DIRECTION SIGNATURE FOR VERTICAL AND
HORIZONTAL POLARIZATION
54
KU - BAND (14 GHZ) NRCS WIND DIRECTIONAL
SIGNATURE VS. WIND SPEED
55
(No Transcript)
56
Wind speed and direction validation of ERS-1 data
57
NSCAT 1 day coverage
58
(No Transcript)
59
Scalar wind from ERS (1 and 2) satellites and at
Margarita Island Airport
(Sample ERS weekly mean w, 1x1 degree
resolution)
60
Wind microwave

• Www sites
• SSM/I
• http//podaac.jpl.nasa.gov2031/SENSOR_DOCS/ssmi.h
  tml
• http//www-nsidc.colorado.edu/NASA/GUIDE/EASE/
• http//www.ngdc.noaa.gov/dmsp/dmsp.html
• http//microwave.msfc.nasa.gov5721/sensor_documen
  ts/ssmi_sensor.html1.
• Http//podaac.jpl.nasa.gov2031/DATASET_DOCS/ssmi_
  wentz.html3.
• SSM/I and SMMR
• http//podaac.jpl.nasa.gov2031/SENSOR_DOCS/smmr.h
  tml
• http//podaac.jpl.nasa.gov/SSMR_Products.htmlProd
  uct30
