Change Analysis

1
Change Analysis

• Land Cover Change in China, 1982 1992

2
Introduction

• Review Change Analysis

3
Introduction

• Review Change Analysis
• Describe AVHRR Data Set

4
Introduction

• Review Change Analysis
• Describe AVHRR Data Set
• Case Study
• Land Cover Change in China

5
Change Analysis

• Remote Sensing Background
• Change Detection Theory
• Change Detection Methodologies
• Change Detection Applications

6
Background Issues

• Remote Sensing

7
Background Issues

• Remote Sensing
• Land Cover Studies

8
Background Issues

• Remote Sensing
• Land Cover Studies
• Vegetation Detection

9
Vegetation Detection

• Normalized Difference Vegetation Index
• NDVI
• NIR Red / NIR Red

10
Change Detection Theory

• Overview

11
Change Detection Theory

• Overview
• Change / Background

12
Background

• Differences in atmospheric conditions
• Differences in sun angle
• Differences in sensor calibrations
• Differences in spatial registration
• Extraneous factors

13
Change Detection Theory

• Overview
• Change / Background
• Threshold

14
Change Detection Theory

• Overview
• Change / Background
• Threshold
• Minimizing Background

15
Change Detection Theory

• Overview
• Change / Background
• Threshold
• Minimizing Background
• Procedure

16
Procedure

• Pre-processing of data
• Change detection procedure
• Threshold of change
• Resulting image, table,
• Presentation of results

17
Change Detection Methodology

• Pairwise Comparisons
• Multiple Image Comparisons

18
Change Detection Methodology

• Pairwise Comparisons
• Cross Classification
• Image Differencing
• Image Ratio
• Image Regression
• Change Vector Analysis

19
Pairwise Comparisons

• Image Differencing
• (Image 3 Image 1 - Image 2 )
• (Change 1992 AVHRR 1982 AVHRR)
• Dxkij xkij (t2) - xkij (t1)

20
Change Detection Methodology

• Multiple Image Comparisons
• Image Deviation
• Temporal Profiling
• Principal Components Analysis

21
Change Detection Methodology

• Principal Components Analysis
• Set of Image In
• Reconfigured Set Out
• Based on Variance Explained
• Output for Each Component
• Graph Image

22
Change Detection Applications

• Environmental Applications
• Global Change Applications
• Hazards Applications
• Agricultural Applications

23
Case Study Land Cover Change in China

• Study Area
• AVHRR Data
• Change Detection Methodology
• Results / Conclusion
• Future Research

24
NOAA - AVHRR Data

• NOAA
• National Oceanic and Atmospheric Administration
• AVHRR
• Advanced Very High Resolution Radiometer

25
NOAA - AVHRR Data

• Platform Characteristics
• Sensor Characteristics
• Data Characteristics
• Data Issues
• Applications

26
Platform Characteristics

• NOAA Satellite Series
• Meteorological Satellite
• 850 km Altitude
• Sun-Synchronous Polar Orbit
• 1430 Overpass Time (-7, -9, -11, -14)

27
Sensor Characteristics

• Wide Instantaneous Field of View
• 2800 km Wide Swaths
• Daily Coverage
• 5 Channels of Data

28
Data Characteristics

• Temporal Resolution daily
• Spatial Resolution 1.1 km
• Spectral Resolution 5 Channels
• Data History 1981 present

29
AVHRR Channels

• Optical
• Channel 1, red (0.58-0.68 µm)
• Channel 2, near infrared (0.725-1.1 µm)
• Channel 3, middle IR (3.55-3.93 µm)
• Thermal
• Channel 4 (10.5-11.5 µm)
• Channel 5 (11.5-12.5 µm)

30
Data Issues

• Solar Zenith Angle and Illumination
• Map Projections and Navigation
• Satellite (Sensor) Drift
• Satellite Calibration
• Satellite Changeover
• Atmospheric Disturbance - Cloud Cover

31
Data Applications

• Meteorological Applications
• Oceanographic Applications
• Terrestrial Applications
• Vegetation Analysis
• Global Change Studies

32
Vegetation Analysis

• NDVI - Normalized Difference Vegetation Index
• NIR Red / NIR Red
• MVC - Maximum Value Composite
• GVI - Global Vegetation Index

33
Goodes Projection
34
(No Transcript)
35
January
36
February
37
March
38
April
39
May
40
June
41
July
42
August
43
September
44
October
45
November
46
December
47
(No Transcript)
48
(No Transcript)
49
(No Transcript)
50
Research Data

• Pathfinder AVHRR Landcover (PAL) data
• PAL Monthly MVC 8km (1982 1992)
• Finer scale LAC, and TM data
• Ancillary Data (China Maps, Field Work)

51
Data Issues

• Time Frame of Data
• Access to Data
• Noise in Data
• Data Projection
• Raster Vector Data
• Multiple Scales

52
Methodology

• Data Formatting
• Monthly MVC Data, Annual Average Data
• Principal Components Analysis
• Time Series Analysis
• Simple Differencing
• Annual Average Data
• Nested Scales

53
The Research

• Data Formatting
• Different Scenario Analysis
• Pursue Most Promising
• Validate Results
• Interactive Discussions
• Conference Papers
• Presentation

54
The Results

• Principal Components Analysis Results
• Simple Differencing Results
• Areas of Declining NDVI Forest cover
• Areas of Increasing NDVI Cultivated land
  Grasslands

55
The Results
56
Land Cover Change 1982 - 92
57
Further Research

• Land Cover Change in China in the 1990s
• Photosynthetic Biogeography of China
• Land Cover Change in the Middle East 1982 1999
• Visualization of Data

58
(No Transcript)
