Quadrics, Inc. June 2006 Confidential slide 1

1
QsNetIII and QsTenG Networks for High
Performance Computing
12th June 2006
2
AGENDA

• Company introduction
• QsTenG Roadmap
• QsNetIII Roadmap

3
COMPANY
4
Summary

• Established in 1996, with locations in the US,
  UK, Italy and China
• Leading supplier and developer of high
  performance networking products and resource
  management software
• Subsidiary of Alenia Aeronautica and wholly owned
  by Finmeccanica. One of the largest industrial
  group in Europe in the defense, energy and
  security industries.
• Developing proprietary HPC network and industry
  standard network products (10 GigE first)
• Strategic market expansion investments in USA
  (Quadrics, Inc.), Asia Pacific and Europe.
• Currently 50 employees (70 engineers)

5
History

• Quadrics RD Team out of Meiko
• 1996 Incorporation as UK Limited Company, part of
  the Finmeccanica Group (SIFI.MI Italian Stock
  Exchange)
• 1998 Manufacture in US through Solectron
• 1999 Compaq OEM agreement
• 2000 Compaq Third Party Manufacturing Agreement
  (Royalty)
• 2001 Shipment Direct from US to US customers
• 2005 Incorporation of Quadrics, Inc.
• Focus on High Performance Interconnects and
  Resource Cluster Management with a mission to be
  the market leader in such solutions

6
Org Chart
7
Strategy - Roadmap
8
QsTenG
9
QsTenG - Overview

• 10 Gbit/s Ethernet layer 2 switch family
• Data centre and clustering market
• QS-TG108 switch up to 96 ports, copper CX4
• Low latency - 0.5?s to 1.5 ?s port to port
• Compact switch chassis (8U)
• Can be used with standard 10 Gbps Ethernet NICs

10
QS-TG108 Switch - Architecture

• 12 ports microchip building block
• Two stage fat-tree topology
• Scalable 8-96 ports

• 450ns per stage latency
• Source routed

Building blocks
Backplane links
CX4 copper cables
Computing nodes
11
QS-TG108 - Physical Design

• 8U chassis
• 1U PSU subsystem
• Front to back airflow
• All connections on rear of switch

12
QSTG108 - Rear View

• 1 to 12 line cards
• (part ID QM601)
• 1 to 2 control cards
• (part ID QM602)

13
QM601 - 8 Ports Line Card

• 8 CX4 ports to front panel
• 4 CX4 ports to backplane
• Control processor

14
QM602 - Control Card

• Master control processor
• External control and management 1 Gbps Ethernet
  connection
• 12 CX4 backplane connections

15
QSTG108 - RAS Features

• Redundant control architecture
• 1 from 2 (2 from 3) redundant power supply
• Dual sequential fans

16
QS-TG108 Control Structure

• Embedded Linux control processor for each switch
  card
• Switch configuration
• Stats gathering
• Control card QM602
• Single point of control
• SNMP switch agent
• Fail-over to controller on alternate QM602
• Dual 1 Gbps Ethernet control interfaces

17
QsTenG Firmware

• Embedded Linux control software
• SNMP Device management support
• Power on self test
• Hardware diagnostics
• Performance monitoring

18
QsTenG Software

• MPI-2 common to QsNet and QsTenG
• Adapter specific drivers
• Quadrics Resource Management System (RMS)
• 24 ? 7 production cluster management

19
QsTenG CX4 Adapters

• QsTenG family of switches will operate with all
  standard 10 Gbps Ethernet adapters
• Intel validated
• Chelsio validated
• Myricom validated
• Neterion validation about to start
• Neteffect validation about to start

20
Managed Layer 2 Protocol Support Features

• LVL7 FASTPATH Software Certified protocol
  support for routing and management including
• VLAN - Network grouping/segmentation
• IEEE 802.3ac - VLAN Tagging
• IEEE 802.1v - Protocol-based VLAN
• IEEE 802.1Q - Virtual LAN with port based VLANs
• Spanning Trees - Broadcast storm/loop avoidance
• IEEE 802.1S Multiple Spanning Tree
• IEEE 802.1W - Rapid Spanning Tree
• IEEE 802.1D - Spanning Tree
• Flow Control
• IEEE 802.3x - Flow control
• Priorities
• IEEE 802.1p Ethernet Priority with User
  Provisioning Mapping

21
Managed Layer 2 Protocol Support Features Cont

• GARP - Attribute register/de-register
• IGMP - Snooping - Multicast membership
• Link aggregation - Channel bonding
• IEEE 802.3ad Link Aggregation
• Port mirroring - Copy for analysis
• Jumbo Ethernet Frames
• Power management for individual slots
• Fan control
• Redundancy (Cold Failover)
• Hot plug

22
Federation Support Features

• Federation of multiple Switches
• Quadrics Internal Software development
• Federation Support
• Support for 2000 ports
• Fat Tree Topology

23
QsTenG Summary

• A new generation of 10 Gbps Ethernet switch for
  new classes of bandwidth hungry applications.
• Takes Quadrics scalable switch design into the
  standards based interconnect market.

24
QsNetIII
25
QsNetIII Overview

• New host adapter based on Elan5 microchip
• PCI Express 16x, DDR
• New custom fabric based on Elite5 microchip
• High radix switches
• DDR CX4 links
• Common mechanics and control structure
• 128 node building block (8U)

26
Elan5 Overview (product ID QM700)

• 2 ? QsNetIII link
• Multiple Thread processors
• Local memory (1Mbytes)
• Buffer space, routes, page tables
• Memory Management
• 4 pages sizes 4M-32G
• TLB (64 ? 16 pages)
• Host Interface
• PCI-Express 16x
• DDR support

27
Elan5 Thread Processor

• Two thread instructions per cycle
• 500-600 MHz clock
• 128 registers
• 16K instruction cache
• 8K data buffers
• Assembling network packets
• Checksum and CRC generators on write port
• DMA read, write, set event, wait event

28
Elite5 - Overview

• 16 x4, 32 x2 switch component
• Or multiple 8,4,2,1 switches
• Physical layer DDR XAUI
• 4 x 6.25Gbit/s
• 2.5Gbytes/s peak in each direction
• Broadcast barrier support

29
Elite 5 Switch Packaging, cards

• 16 ports link card (Part ID QM701)
• Building block for
• 256 ports stand alone switch
• 128 ports to computing nodes, 128 ports to top
  level switches chassis
• Top switch card (Part ID QM702)
• Building block for
• 256 ports stand alone switch
• Federated networks
• Top switch card (Part ID QM703)
• Federated networks

30
QsNetIII 128 Ports chassis

• Building block for federated networks
• ?8 1024-way systems
• ?16 2048-way systems
• x32 4096-way systems
• x64 8192-way systems
• 128 ports to nodes, 128 backplane links to top
  level switching cards
• 2 stage fat tree
• 9U high

31
QsNetIII 256 Ports chassis

• High Density stand alone switch
• 800 Gbyte/sec bi-section bandwidth
• 2 stage fat tree
• 14U high
• Can be used to provide multiple ?32 and ?64 top
  switches for very large systems

32
4096 Way System 1U Nodes

• 128 node scalable units
• Each scalable unit has a node level switch
• Upgradable bisectional bandwidths
• 1/8 ¼ ½ full

33
QsNetIII 4096 Port Network Topology
34
4096 1U SYSTEM - FLOOR PLAN
System size 10m ? 20m (33' ? 66') with an aisle
spacing of 5'. Maximum cable length is
approximately 13m (43')
35
Possible Lustre configuration with 1/8
bisectional bandwidth

• 48 Lustre storage servers (2 meta dataservers, 2
  management nodes and a small number of login
  nodes).
• Divided equally between the first and last node
  switches.
• Should be configured in pairs (with one server
  from each pair attached to each node switch).
• This configuration will maximise the Lustre I/O
  bandwidth with sparse connectivity between the
  node switches.
• If all 4096 ports are used the filesystem will
  share uplink bandwidth with the nodes attached to
  its node switch.

36
Quadrics Products Compared
