IMT2000 System Overview

1

• IMT-2000 System Overview
• Youngnam Han
• ICU
• Tel [phone]
• Fax [phone]
• E-mail ynhan_at_icu.ac.kr

2
Contents

• Introduction
• Market Forecast
• Standardization of IMT-2000
• Standard Organizations
• Standards by ITU-R 18th Meeting
• FDD-CDMA Features of WCDMA cdma2000
• TDD-CDMA System
• Status for IMT-2000 in Korea
• System Development
• Standardization
• System Implementation
• Conclusions

3
Introduction

• Known as FPLMTS with the same system concept as
  the UMTS of ETSI for creating a globally
  compatible public mobile system
• A multi-function, multi-service,
  multi-application digital system that will use
  end-of-the-century technology to support
  universal roaming and offer broadband multimedia
  services requiring up to 2 Mb/s throughput
• Minimum capability set
• Indoor 2Mb/s
• Indoor to Outdoor/Pedestrian 384 Kb/sec
• Mobile 144Kb/sec

4

• An opportunity to exploit 2 GHz band with a
  unified and universal personal mobile
  telecommunication system for multi-operator
  environment
• System based on a single or a multiple standard
• Frequency allocation
• 230 MHz in the frequency band of 1885 2025
  MHz, 2110 2200 MHz with 19802010 MHz and
  21702200 MHz for satellite (WRC-92)
• Current allocation of frequency bands requires
  frequency band harmonization worldwide
• Asymmetric bandwidth allocation(140 MHz, 90 MHz)
  results in FDD and TDD mode of operation
• Additional global identification of 160 MHz based
  on recent market forecast (ITU-R SG8/1)

5
Spectrum Allocation
ITU/R Korea
MSS
IMT-2000
ETSI (EU)
UMTS
MSS
IMT-2000
MSS

Japan
PCS
MSS
MSS
USA
2200 MHz
1800
2100
1850
1900
1950
2000
2050
2150
MSS Req.2, DECT, UMTS/DECT, UMTS, PHS
6

• Service Categories
• Mobility services
• Terminal mobility
• Location information
• Interactive services
• conversational service real time end-to-end
  information transfer
• message service store-and-forward, mailbox
  and/or message handling
• retrieval and storage service
• Distributive Service
• One-to-Multi point transmission (Multicasting)
• Broadcasting
• Telecommunication Services

7
Market Forecast
Users in Million
Data excerpt from UMTS Forum News letter
8
Standardization Milestones in ITU-R

• Call For Proposal 97. 3
• Proposal Submission 97.3.-98.6.
• 11 Proposals for Terrestrial Systems
• Evaluation 97.10.-98.9.
• REVAL(RTT Evaluation)
• Harmonization 97.10.-99.3.
• RKEY (RTT Key Technologies)
• Specification 99.1.-99.12.
• 5 RSPCs(RTT Specifications) for terrestrial and 2
  for satellite at 18th Helsinki Meeting
• Release 99

9

• Final Approval of Radio Standards May 00
• Approval by Radio communication Assembly
• Decision on Additional Spectrum June 00
• World Radio Conference-2000
• Additional releases of IMT-2000 Specifications
  with Updates and Enhancements 2000 Onwards
• Modifications by SDOs
• Release 2000 2000.12.

10
ITU-R RTT Proposals

• Terrestrial components
• IMT-2000 CDMA Direct Spread UTRA FDD or WCDMA
• IMT-2000 CDMA Multi-Carrier cdma2000
• IMT-2000 CDMA TDD UTRA TDD and TD-SCDMA
• IMT-2000 TDMA Single-Carrier UWC-136
• IMT-2000 TDMA Multi-Carrier (FDMA/TDMA) DECT
• Satellite components
• Satellite Radio Interface A Specification
• SW-CDMA UTRA FDD or WCDMA
• Satellite Radio Interface B Specification
• W-C/TDMA ETSI by Y2000

11
Standard Development Organizations(SDOs)

• 3GPP 3GPP2
• Established based on ITU-T/R family concept
• 3GPP (3rd generation partnership project)
• Global specifications for GSM/MAP network
  evolution to 3G and the UTRA RTT System based on
  ETSI UMTS WCDMA FDD TDD
• 3GPP participants ETSI, ARIB/TTC, TTA, T1P1
• 3GPP2
• Global specifications for ANSI/TIA/EIA-41 network
  evolution to 3G and global specifications for the
  RTTs supported by ANSI/TIA/EIA-41
• 3GPP2 participants TIA, TTA, ARIB/TTC, ETSI

12
Standard Development Organizations(SDOs)

• OHG(operators harmonization group)
• Harmonization of CDMA technologies proposed to
  ITU-R early 1999
• Proposed system through harmonization
• MC CDMA based on cdma2000
• DS CDMA based on WCDMA with 3.84 Mcps
• TDD mode based on WCDMA/TDD with 3.84 Mcps
• G3G(global 3rd generation) Standards

Specification with hooks
Dec. 1999
DS/FDD TDD
Feb. 2000
Extensions for ANSI-41
Mar. 2000
Specification with hooks
MC
Extensions for GSM
Jun. 2000
13
G3G Modular Protocol Structure
14
Footprints to IS2000
15
Footprints of WCDMA
Europe
Japan
CoDiT (Code Division Test Bed)
Wideband CDMA by NTT DoCoMo
Wideband CDMA by ETSI
WCDMA
16
Modular IMT-2000 Harmonization G3G
3G Family Roaming
Ntwk to Ntwk Interfaces
Evolved ANSI-41
IP-based Networks
Evolved GSM(MAP)
Flexible Connection between RTT Modes and Core
Networks based on operator needs
TDMA MC
CDMA TDD
TDMA SC
WCDMA (DS)
cdma2000 (MC)
17
Systems Comparison
18
3GPP(WCDMA FDD)
3GPP2(cdma2000) Detection FL Coherent(Co. Pilot
Ch.) Coherent (Co. Pilot Ch.) RL
Coherent(Pilot Symbol) Coherent (Pilot
Channel) Power Ctrl FL CL(1.5Kb/s, SIR of CPCH)
CL(800b/s,SIR of CPCH) RL OL
CL OL CL Multi-rate VSF
Multi-code VSF Rate Detection Var. length
rate info. Blind(Fund.ch.),
Scheduled(Sup.ch.) Rate Matching Symbol Rep.,
puncturing Seq. Sym. Rep. DTX
Puncturing Coding TCH Conv. /K9,
r1/2, 1/3 Conv./K9, r1/4,1/3,1/2 Turbo(32
k and up) Turbo(16k and up) CCH Conv.
/K9,r1/2 Conv./K4, r1/4(RL)
K9, r1/2(FL) RA Method AiSMA with pwr ramp
Reservation MA Fwd. Tx. Div. TxAA
STD(CL), OTD(OL)
STTD TSTD(OL)
19
Characteristics of WCDMA/FDD(DL)

• BS asynchronous system
• Cell searcher through synchronization codes
• Transmission diversity
• Performance enhancement
• OL STTD, CL combined TxAA and STD
• Dedicated pilot symbol
• power estimation for fast down link power control
• Pilot estimation for adaptive beam forming
• TFCI(transport format combination indicators)
• Rate information transmission

20
Characteristics of WCDMA/FDD(DL)

• Efficient power control timing
• one power control group delay
• Channelization by orthogonal variable spreading
  factor codes
• Turbo codes for traffic channel bit rate of 32K
  and up
• High service flexibility with support of multiple
  parallel variable-rate services on one connection
  (voice and data simultaneously)

21
Characteristics of WCDMA FDD (UL)

• Coherent detection with pilot/TPC/TFCI
• Performance enhancement
• Improved reverse link power control performance
  with continuous pilot
• Hearing-aid problem resolution for voice service
• AiSMA(acquisition indication sense MA)
• Acquisition indication based random access
  mechanism with preamble power ramping
• Slotted ALOHA /CD
• Improving throughput via acquisition indication
  transmitted by BS
• Capacity increase through interference reduction
  by preamble access

22
Characteristics of WCDMA FDD (UL)

• Spectrally efficient modulation
• HPSK(OCQPSK)
• Combination of QPSK and p/2 BPSK in phase
  constellation
• Peak-to-average ratio reduction by 1 dB
• TFCI
• Efficient power control timing
• one power control group delay
• Channelization by OVSF Code
• Turbo codes for traffic channel bit rate of
• 32K and up

23
Inter-frequency Handover
WCDMA Key Feature Handover
24
Characteristics of cdma2000 (FL)

• Multi-Carrier DS/CDMA
• 1.2288 Mcps per 1.25 MHz carrier with N carriers
• Auxiliary pilot
• Beam forming for adaptive array antenna
• Forward transmit diversity
• OTD(Orthogonal Transmit Diversity)
  Multicarrier
• Transmit Diversity
• Quick paging channel (QPCH)
• Significantly prolongs standby time of MS in
  slotted
• mode
• Orthogonal forward link channels with Walsh
• functions

25
Characteristics of cdma2000 (FL)

• QPSK data modulation
• doubles the number of Walsh channels
• Quasi-orthogonal function
• With code shortage (e.g. due to DCCH usage)
• Forward error correction
• Convolution codes (K9) for voice and low rate
  data
• Turbo Codes(K4) for data rates above 14.4 kb/s
• Fast forward power control
• 800 Hz update rate
• Common pilot PCB based measurement

26
Characteristics of cdma2000(RL)

• Coherent link with parallel pilot /PCB channel
• Modulation HPSK(OCQPSK)
• Code multiplexed channels by Walsh codes
• Orthogonalization
• Pilot/PCB channel
• Fundamental channel voice, low rate data,
  signaling
• Supplemental channel high rate data
• Up to 2 supplemental channels
• Dedicated control channel MAC control,
  signaling
• RsMA(Reservation MA)
• Improved packet transmission

27
cdma2000 MC Mode

• MC Deployment
• Orthogonality maintained on FL enables overlay of
  wider bandwidth on top of 1.25 MHz system
• cdma2000 MC extensions
• cdma2000 3X MC FL and cdma2000 1X RL
• cdma2000 3X MC
• Coupling 1X and 3X together
• MC FL can be sent through different PAs, which
  dont have intermodulation between them
• Asymmetric traffic characteristics can be taken
  into account
• Less out-of-band interference

28
cdma2000 MC Mode
1.25MHz
RL
0
1
5
6
7
8
2
3
4
9
10 MHz
29
cdma2000 MC Mode

• cdma2000 Multi-Carrier Extensions

FL
30
TDD-CDMA System Concepts

• Reciprocity of forward and reverse channel
• Both MS and BS use a single frequency channel

time
31

• Cell radius
• Guard time length limited by transmission delay
• Cell radius limited by the round trip delay

32
Features of TDD-CDMA

• Benefits
• Pre-Rake
• Antenna Diversity
• Open loop power control
• Problems
• Synchronization and interference to outage
• adjacent MSs with different asymmetries
• adjacent BSs with the same frequency band
• UMTS WCDMA/FDD and WCDMA/TDD
• FDD Large cells, high mobility with moderate
  data rate
• TDD Small cells, low mobility with high data
  rate and asymmetric service

33

• HCS TDD cell overlaid onto a FDD cell
• Potential interference problems to outage
• Overall system capacity increase w/o additional
  BW allocation
• Handover between TDD and FDD

34
Research Development Issues

• Radio Channel Model
• Various environment
• Indoor, Indoor/Outdoor and Pedestrian,Vehicular
• Millimeter Wave Propagation
• Radio Transmission Technology
• Physical Layer
• Spreading Direct Sequence and Multi-carrier
• Fast cell search techniques WCDMA
• Channel coding (Turbo Code) for multimedia
  traffic
• Robust decoding algorithm
• Power Control Fast forward power control
• MAI reduction techniques
• Adaptive array antenna (beam forming)
• Interference cancellation techniques

35

• Radio Resource management
• Idle Mode Tasks
• Cell Selection/reselection
• Location Registration
• Call Admission Control
• RRC Connection Mobility Handover
• Inter-frequency handover
• Intersystem handover (e.g., 2G to and from 3G)
• Radio Bearer Control
• Control UE and system resources
• Resource Allocation Code allocation
• Power management
• Radio link surveillance for Tx diversity mode
  selection

36

• Optimal operation
• Optimal parameter selection
• Hierarchical cell structure
• Overlay cell (various 3Gs, IS95 and 3G)
• Hot spot cell
• Networks
• Wireless ATM
• Mobile IP (Mobile Internet) to All IP
• Future Radio System Concepts
• Software Defined Radio(SDR)
• Cognitive Radio

37
Status of IMT-2000 in Korea

• System Development
• Project for a prototype system development
• finished with a system based on Global CDMA I
  (similar to IS-2000) by ETRI
• Grand Consortium supported by MIC and Industries
  including Motorola and Ericsson in 1996
• Project for a system development based on W-CDMA
• Started in September, 1999 at ETRI
• Consortium supported mainly by Industries
  including
• 2 Supporters for infrastructure development
  Samsung, Hyundai
• 3 Supporters for mobile unit Samsung, Hyundai,
  and PanTech

38

• Implementation scenario
• Milestone announced by MIC (Sept. 1999)
• June 00 Decision will be made on the number of
  Licensees and method of allocating spectrum bands
• September 00 Call For Proposal
• December 00 License awarding with frequency
  allocation
• January 02 Launching IMT-2000 Service
• May 02 (World cup Soccer Game) Nationwide
  Commercial Service
• Issues to be resolved
• Debate on the service category
• License awarding process
• Frequency auction
• Beauty contest

39
Conclusions

• CDMA Technology Trends
• Narrowband DS/CDMA(IS-95) to Wideband DS/CDMA and
  MC-DS/CDMA(W-CDMA, IS2000)
• Averaging Effect (more widespread)
• How to achieve widespread
• MC(Multi-carrier) or DS(Direct Sequence)
• Inter BS Synchronization
• Synchronous (GPS)
• Asynchronous cell search by codes

40
Conclusions

• Open Questions
• Service characterization
• Revolution or evolution
• Need more carriers into the field of wireless
  communication ?
• Spectrum allocation
• How many operators for IMT-2000?
• Future reuse of 2nd Gen. bands The
  identification of existing 2nd gen. bands for
  IMT-2000 according to market evolution

41

• Additional Issues
• Additional spectrum for IMT-2000 (UMTS)
• Global harmonization minimum of 160 MHz
  additional spectrum for terrestrial component and
  2500-2520/2670-2790 MHz for MSS allocation
• 2520-2670 MHz is considered the best candidate
  with part(s) of the band 2700-2900 MHz a
  possible global candidate
• 403 MHz for Y2005 and 582 MHz for Y2010 estimated
  by EU
• Time of Deployment
