Title: Introduction to the OGC Web Processing Service WPS


1
Introduction to the OGC Web Processing Service
(WPS)
  • GIP Meeting
  • 20 April 2006
  • Theodor Foerster

2
Contents
  • Motivation
  • WPS in detail
  • Pitfalls
  • Conclusion

3
Situation
  • Spatial data is available on the web
  • Through OGC web services (WFS, WCS)
  • Network computational capacity available
  • But users want to have information

4
Motivation
  • Execute spatial processes as web services
  • Platform independent
  • Availability (worldwide 24/7)
  • Maintenance
  • Reusability
  • ?Processing on the web is the next logical step

5
OGC WPS - history
  • Founded by the CGDI (2004)
  • Refined within an OGC interoperability experiment
  • Discussion paper published in end 2005 under
    05-007r4
  • Awaiting adaptation for version 0.

6
Notion of the WPS
  • Service communication based on HTTP and XML
  • No limitations on certain types of processes
  • No limitations on the data
  • Supports raster and vector data
  • Literal values (e.g. buffer size)

7
WPS operations
  • GetCapabilities
  • Service description
  • Access description
  • Brief process descriptions
  • DescribeProcess
  • Full process description
  • Execute
  • Process execution

8
WPS in action - Buffering
Client
WPS
http//geoserver8080/wps/WebProcessingService? RE
QUESTGetCapabilities SERVICEWPS
http//geoserver8080/wps/WebProcessingService? RE
QUESTDescribeProcess IdentifierBuffer SERVICE
WPS VERSION0.4.0
ltCapabilities version"0.4.0gt ltowsServiceIdenti
ficationgt ltowsTitle/gt ltowsAbstract/gt
ltowsKeywords/gt lt/owsServiceIdentificationgt lt
owsServiceProvider/gt ltowsServiceContact/gt
lt/owsServiceProvidergt ltowsOperationsMetadatagt
ltowsOperation name"Execute/gt
lt/owsOperationsMetadatagt ltProcessOfferingsgt ltP
rocessgt ltowsIdentifiergtBufferlt/owsIdentifiergt
lt/Processgt lt/ProcessOfferingsgt lt/Capabilitiesgt
ltExecuteResponsegt ltowsIdentifiergtBufferlt/owsIden
tifiergt ltStatus/gt ltDataInputsgt lt/DataInputsgt ltOu
tputDefinitionsgt lt/OutputDefinitionsgt ltProcessOu
tputsgt ltOutputgt ltowsIdentifiergtBufferResultlt/ows
Identifiergt ltComplexValue schema
schemaNSgt XML_Geometries lt/ComplexValuegt lt/Out
putgt lt/ProcessOutputsgt lt/ExecuteResponsegt
ltProcessDescriptionsgt ltProcessDescription
ltowsIdentifiergtBufferlt/owsIdentifiergt
ltDataInputsgt ltInputgt ltowsIdentifiergtgeometrylt
/owsIdentifiergt ltComplexData defaultSchemasche
maNS"/gt ltMinimumOccursgt1lt/MinimumOccursgt
lt/Inputgt ltInputgt ltowsIdentifiergtwidthlt/owsIde
ntifiergt ltLiteralDatagt ltowsDataType
owsreference"xsint"/gt ltProcessOutputsgt
ltOutputgt ltowsIdentifiergtBufferResultlt/owsIdenti
fiergt ltComplexOutput defaultSchemaschemaNS/gt
lt/ProcessDescriptionsgt
ltExecutegt ltowsIdentifiergtBufferlt/owsIdentifiergt
ltDataInputsgt ltInputgt ltowsIdentifiergtgeometry
lt/owsIdentifiergt ltComplexValue
schemaschemaNSgt XML_Geometries
lt/ComplexValuegt lt/Inputgt ltInputgt
ltowsIdentifiergtwidthlt/owsIdentifiergt
ltLiteralValuegt100lt/LiteralValuegt lt/Inputgt lt/DataIn
putsgt lt/Executegt
ltGetCapabilitiesgt request
ltGetCapabilitiesgt response
ltDescribeProcessgt request
ltDescribeProcessgt response
ltExecutegt request
ltExecutegt response
Network
Inspired by P. Schuts presentation at the OGC
TC Meeting in Huntsville 2006 WPS RFC responses
9
Additional Features
  • Supports long-term processes by storing
  • Handles drawback of HTTP
  • Avoids recalculation
  • Status of processes is callable
  • Supports chaining (limited)
  • For data retrieval processing
  • Standardized error messages

10
Discovered pitfalls
  • No advanced chaining available
  • Semantic descriptions of processes are missing
  • No sophisticated communication pattern
    incorporated
  • No key advantage over SOAP

11
Implementation features - DEMO
  • WPS identified as a basic module for
    generalization processing in the web
  • Written in Java
  • Published in 52n incubator
  • Includes server and client (based on JUMP)
    implementation
  • Based on open source APIs only
  • Provides a pluggable mechanism

12
Conclusion
  • WPS just evolving
  • Many open issues
  • Web Coverage Processing Service introduces
    additional ideas
  • Will be part of ITCs 52n Working group on Geo
    Processing Service

13
Thanks
  • Further information under
  • www.incubator52n.de gt Processing
  • Thanks for your attention!
