Spreadsheets and Microsoft Excel

1
Spreadsheets andMicrosoft Excel
2
Introduction

• A spreadsheet (called a worksheet in Excel) is a
  two-dimensional array of cells containing data to
  be computed and analyzed.
• Each cell may contain text, often used as row or
  column headings, numerical values, or formulas,
  which are used to compute other numerical values.
• Cells may contain other types of data too.

3

• Here is a particular example, including
  additional formatting features, like text that
  spans multiple cells and color

4
Formula Bar
5

• The real power of spreadsheets comes from the use
  of formulas, which tell Excel how the values
  displayed in certain cells are to be computed
  from the values displayed in other cells.
• To use formulas, we need to first understand how
  to refer to the values in individual cells, or
  cell references.

6

• For example, the cell containing Adamss overall
  score is referred to as cell E6 because its in
  column E and row 6.
• If we make E6 the active cell by moving the
  cursor there and clicking, Excel displays this

7
(No Transcript)
8

• In particular, what we see in the formula bar is
• B4B6C4C6D4D6
• This means that the value 88.0 displayed in cell
  E6 is actually computed from the values displayed
  in other cells.
• To understand this particular formula, first
  ignore the signs. Theyre important to
  understand eventually, but for now, pretend
  theyre not there.

9

• What this formula says is, to determine the value
  to display in cell E6
• Multiply the value in cell B4 times the value in
  cell B6.
• Multiply the value in cell C4 times the value in
  cell C6.
• Multiply the value in cell D4 times the value in
  cell D6.
• Then add these three values together.

10

• That is, the value in cell E6 is computed as
• (0.25)(100)(0.25)(90)(0.50)(81)
• 88.0

11

• The beauty of using a formula in a spreadsheet is
  that if any cells values change, all other cells
  whose values depend on the changed values
  (through a formula like this one) are changed
  themselves, entirely automatically.
• For example, suppose we find that Adams should
  have gotten 85 rather than 81 on the final exam.
  As soon as we edit the value in cell D6 to make
  it 85, the spreadsheet looks like this

12
(No Transcript)
13

• Adams overall score is automatically increased
  from 88.0 to 90.0 by Excel.

14

• Now, what about those signs?
• Suppose we look at how Bakers overall score is
  computed by making C7 the active cell

15
(No Transcript)
16

• What we see in the formula bar in this case is
• B4B7C4C7D4D7
• This differs from the formula found in cell E6 by
  using the corresponding values from row 7 rather
  than row 6. That is, to compute Bakers overall
  score, we obviously want to use Bakers three
  test results, not Adamss.

17

• Likewise, for each student, a slightly different
  formula must be used, taking into account the
  values in the row representing that particular
  students test scores.
• Does this mean the user must enter a different
  formula for each student?
• No, because of the notion of relative vs.
  absolute cell references.

18

• In the formula
• B4B6C4C6D4D6
• the cell references B6, C6, and D6 are relative,
  while the references to cells B4, C4, and D4 are
  absolute. This is what the signs do create an
  absolute cell reference.

19

• When the formula
• B4B6C4C6D4D6
• is entered into cell E6, the reference to cell
  B6, for example, is interpreted as the cell 3
  columns to the left of this cell and in the same
  row.
• Copying this formula to cell E7 then has the same
  effect there, which amounts to changing B6, C6,
  and D6 into B7, C7, and D7, respectively.

20

• A relative cell reference refers to a cells
  location relative to the cell where the formula
  is entered.
• The absence of a sign, as in B6, indicates a
  relative reference.

21

• On the other hand, in the formula
• B4B6C4C6D4D6
• the use of signs, as in B4, indicates an
  absolute cell reference.
• No matter which cell this formula is entered in,
  B4 always refers to the value in cell B4.

22

• In this particular example, this is what we want
  because the cells B4, C4, and D4 contain the
  weightings to be applied in computing the overall
  score for every student.

23

• Note that the sign precedes both the column and
  row in an absolute reference.
• Another type of reference, called a mixed
  reference, like B4 or B4, is also possible, but
  its less commonly used and perhaps a little more
  subtle to understand.
• (In fact, in this example, wed still get the
  right result if we used B4, C4, and D4, making
  only the row absolute.)

24
What makes spreadsheets powerful

• The use of formulas to allow automatic
  calculation of some cells values in terms of
  other cells values
• The use of relative (in addition to absolute)
  cell references to allow essentially the same
  formula to be used throughout the spreadsheet.

25
Additional features of Excel

• Ability to plot spreadsheet data easily using a
  wide variety of graphical representations (called
  charts in Excel).
• Large number of built-in mathematical functions
  for use in cell formulas.
• Ability to solve equations and mathematical
  optimization problems.
• Ability to use a spreadsheet like a simple
  database and perform data analysis on it.

26
Excel terminology and basics

• Excel uses the term worksheet to mean what is
  more generally called a spreadsheet.
• Excel uses the term chart to mean any of the
  possible graphs or charts that can be created
  using Excel.
• The term workbook is then used to mean any Excel
  file, which may contain several worksheets and/or
  several charts.

27
(No Transcript)
28

• You can enter and edit data on several worksheets
  simultaneously and perform calculations based on
  data from multiple worksheets.

29

• When you create a chart, you can place the chart
  on the worksheet with its related data or on a
  separate chart sheet.
• The names of the sheets appear on tabs at the
  bottom of the workbook window.
• To move from sheet to sheet, click the sheet
  tabs.
• The name of the active sheet is bold.

30
Names of worksheets within a workbook.
31
Whats displayed vs. whats really there

• Think of every cell in a worksheet as having
• a surface layer, consisting of whats displayed
  for that cell and
• an underlying layer, consisting of either a
  formula or internal representation of a constant
  value.

32

• If the underlying content of a cell is a formula,
  the surface content is the computed value,
  formatted according to the users specifications.
• In our earlier example, cell E6 has as its
  underlying contents the formula we gave, but what
  is displayed on the worksheet is the computed
  result of applying this formula. It is also
  formatted to display the value to one decimal
  place.

33

• However, it is also possible to have the formulas
  themselves displayed, rather than the computed
  values, by checking the appropriate box in the
  Tools gt Options dialog box

34
(No Transcript)
35

• Even when the contents of a cell is a constant,
  the value you see on the screen depends on how
  you choose to format and display the stored
  value.
• For example, a cell that displays a date as
  "6/22/96" also contains a serial number that is
  the underlying stored value for the date in the
  cell.

36

• You can change the surface display of the date to
  another format (for example, to "22-Jun-96"), but
  changing the surface display of a value on a
  worksheet does not change the underlying stored
  value.

37

• Another example is the use of format. In the
  earlier sample worksheet, the contents of cell B4
  is displayed as 25, but internally its just the
  same as 0.25.
