1Effect of Ripple-Induced Ion Thermal Transport on
H-mode Performance V. Parail, T. Johnson, T.
Kiviniemi, J. Lonnroth, P. de Vries, D. Howell,
Y. Kamada, S. Konovalov, N. Oyama, G. Saibene, K.
Shinohara and EFDA JET contributors
2Outlook
- Ripple losses of thermal ions experimental
evidence and prospect to use it for ELM
mitigation - Orbit Following Monte Carlo code ASCOT and
simulation of thermal ion ripple losses in
plasmas with JET and JT-60U magnetic coils - Predictive transport modelling of JET plasmas
with ripple-induced transport - Summary.
3Ripple-induced transport
- Magnetic field in a tokamak varies in both
poloidal and toroidal directions
BB01ecos(q)dsin(Nf) - Accordingly, there are three different group of
particles - Passing particles (practically not influenced by
ripples) - Banana particles (experience stochastic
ripple-banana diffusion) - Ripple trapped particles (experience direct or
diffusive losses due to uncompensated vertical
drift)
4Thermal ion ripple losses- experimental evidence
Ripple-induced losses are usually considered as a
negative feature, leading to
- prompt losses of fast ions (NBI or a-particles),
which above all can damage vacuum vessel - large ripples lead to deterioration of edge
pedestal and loss of H-mode - reduce co-NBI plasma rotation and can even
reverse the sign of toroidal rotation - Recent JET/JT-60U identity experiments reveal
significant differences in plasma performance and
ELM behaviour in otherwise identical plasmas,
which might be attributed to higher ripple
amplitude in JT-60U
G. Saibene et al. IAEA, 2004
5Thermal ion ripple losses- experimental evidence
On the other hand, presence of moderate ripples
might bring some essential benefits
- JT-60U type-I ELMs are smaller, more frequent and
benign than their JET counterpart - JT-60U is the only big tokamak, which manages to
keep both ETB and ITB in a steady state stable
co-existence - JT-60U recently reported reaching QH-mode with
co-injection NBI - Some experiments with moderate ripples (JET,
1995) or stochastic magnetic limiter (DIII-D,
2004) reported some improvement in ELMy H-mode
performance
6JET RIP-II (1995) H-mode confinement and ELMs
- Sub-threshold (d0) NBI power.
- dfd16, f(Iodd-Ieven)/(IoddIeven)
- Sweep in d shows transition to H-mode at 0.8
ripple at the outer midplane separatrix at
constant PNBI - fELM ? for d/d16 ?(0 to 0.3) and plasma
parameters improved! - For d/d16 gt0.3, H-mode plasma performance
degraded - Note d/d16 0.3 gives in JET the same ripple
at outer midplane as that of JT-60U
B. Tubbing et al,, EPS 1995
7Why ripple transport might be important for
H-mode?
- Since transport within the ETB is small (of the
order of cneo), strong pressure gradient and
current develops - As soon as edge parameters exceed stability
limit, an ELM develops to remove excessive
pressure and current - Even small additional transport within ETB can
change plasma dynamics
Ripple-induced transport
8Orbit Following Monte Carlo code ASCOT was used
to simulate thermal ion ripple losses in plasmas
with JET and JT-60U magnetic configurations
- JET shot 60856 belongs to JET/JT-60U identity
plasma. - Ripple-induced transport in plasma with JET coils
is outboard midplane localised. - Same plasma with JT-60U coils should have much
larger ripple transport near x-point
See also T. Kiviniemi et al., P2.009, Tuesday
9ASCOT simulations
- We conclude that
- both diffusive and convective (direct) ripple
losses are higher in JT-60U coil configuration
even if ripple amplitude is the same at the outer
mid-plane - diffusive losses extend deep inside ETB for both
configurations - direct losses are very edge-localised and depend
strongly on ion collisionality
Ion thermal conduction c (m2/s) - solid
lines Direct escape rate ndlnn/dt (500s-1)-
dashed lines
10 Predictive modelling of JET plasma with ripple
losses
- Information from ASCOT was used to perform
predictive transport modelling of ELMy H-mode
JET/JT-60U plasma with realistic level and
distribution of ripple losses - Flux surface averaged additional ion thermal
transport implemented in the JETTO transport code
in the following way - Direct losses assumed to be edge localised and
are implemented in t-approximation d(niTi)/dt
-n niTi - Diffusive losses assumed to have a wide radial
distribution (wider than ETB) - Bohm/gyroBohm or Weiland model used for core
transport with ETB assumed to have neo-classical
level of transport - ELMs are triggered by ballooning mode
11Predictive modelling of JET plasma with ripple
losses
- We first test narrow edge-localised direct
losses in t-approximation - Flattening of the pressure gradient near the
separatrix leads to effective narrowing of the
pedestal and subsequent reduction of the energy
stored in the pedestal - Stiffness of core transport propagates this
reduction deeper into the core
Red lines - no ripple losses Blue lines -
nmax100s-1 Green lines - nmax300s-1
12Predictive modelling of JET plasma with ripple
losses
- Narrow edge-localised ripple losses reduces
performance and increases ELM frequency - Energy losses during the ELM are reduced, which
leads to smaller, more benign ELMs
Red lines - no ripple losses Blue lines -
nmax100s-1 Green lines - nmax300s-1
13Predictive modelling of JET plasma with ripple
losses
- We assume that ripple losses are diffusive with
wide ripple localisation - since transport is nearly uniform within ETB,
pressure profile just before ELM is practically
the same for all levels of ripple losses - What is different however its the ELM
frequency, which goes down when we increase
ripple transport
Red lines - no ripple losses Blue lines -
Dcmax1m2/s Green lines - Dcmax1.5m2/s
14Predictive modelling of JET plasma with ripple
losses
- The ELM frequency decreases due to larger edge
losses between ELMs with increased ripple
transport - The time-average pressure and plasma energy
content increase with increased ripple losses
(even if max. pressure stays the same) - A reduction in the ELM frequency and rise in the
energy content were seen in JET ripple
experiments in 1995 - This result resembles the improved performance
obtained with a stochastic magnetic boundary in
DIII-D (T. Evans et al., 2004 IAEA Fusion Energy
Conference).
Red lines - no ripple losses Blue lines -
Dcmax1m2/s Green lines - Dcmax1.5m2/s
15- SUMMARY
- Magnetic ripple is not necessarily a deficient
feature of the tokamak if carefully controlled,
it might serve as a valuable tool for ELM
mitigation - Magnetic ripple losses increase thermal ion
transport only and it might be better to use it
in combination with stochastic magnetic limiter - Present study is limited to transport and MHD
analyses and should be extended to take into
account such important effects as plasma
rotation, radial electric field generation,
particle diffusion etc. - Experiments on JET and JT-60U are under
preparation to elucidate the role of controlled
magnetic ripple in ELMy H-mode performance
16Discussion
17Ripple well trapping
Ripple-induced transport (2)
- Toroidal symmetry is broken for locally trapped
particles, so orbits are not confined. - The motion is a sum of
- Oscillation between turning points
- Vertical drift
- Detrapped by
- Collisions
- Moving towards smaller d
- These losses can be either convective or
diffusive depending on collisionality
18Ripple Perturbations of Banana Orbits
Ripple-induced transport (3)
- Ripples perturb banana orbits at their banana
tips, moving them across flux surfaces. - If the unperturbed tip appear at a ripple
maximum, then the reflection appear earlier and
vice versa. - This is a diffusive process
-
191
- Similar ripple magnitude
- Plasma shapes
- Field line geometry
0.5lt BT ripple lt1 outer midplane But small in
x-point region
20JET JT60-U shape and 0.3 d/d16
JET 32 coils ripple is 0.1
1
0.1
1
Note for the same ripple, fast ion losses may be
different (NB - ICRF). In JT-60U losses are high
also because NB are ?
