Title: Model Checking Java Programs


1
Model Checking Java Programs
  • David Park, Ulrich Stern, Jens Skakkebaek, and
    David L. Dill
  • Stanford University

2
Introduction
  • Can model checking be usefully applied to
    programs?
  • Model checking background
  • Model checking software
  • A Java model checker
  • Research directions

3
Background on model checking
4
Model Checking
  • Model checking analyzes the reachable state
    space of a system for certain properties.
  • Analysis may
  • enumerate states and
  • may also look for paths (e.g., unfair cycles)
  • State set representation can be
  • explicit (e.g., hash table of states) E.g.,
    SPIN, Mur?
  • symbolic (e.g., a Boolean function represented as
    a Boolean decision diagram BDD) SMV, nuSMV,
    VIS

5
Explicit-state vs. symbolic
  • Explicit state model checking has several
    advantages
  • More predictable (hard to diagnose reasons for
    BDD blowup).
  • Avoid difficulties of translating everything to
    Boolean functions.
  • Easier to deal with dynamic features of software
    (e.g. heap-allocated objects).

6
Trivial Mur? example
  • One state variable, two rules
  • count gt 0 --gt count count - 1
  • count lt 10 --gt count count 1

0
. . .
1
2
3
10
7
Basic explicit model checking
On-the-fly search procedure Initialize Queue
is empty Table is empty push s0 onto
Queue Loop while Queue not empty do remove
s from Queue if s is NOT already in Table
then enter s in Table for all
enabled rules r at s do s succ(s,r)
insert s into Queue
8
Sweet spot for model checking
  • Designs that are control-dominated and
    nondeterministic
  • (Nondeterminism stems from concurrency and
    environmental behavior)
  • Designers cant foresee all cases and
    interactions
  • Directed or random testing gets poor coverage
  • (there arent even good coverage metrics)
  • Simple static analysis methods either miss too
    many bugs or report too many false errors.
  • Even running a prototype results in infrequent,
    unrepeatable, hard-to-diagnose failures.

9
Perspectives on model checking
  • As a testing method
  • Model checking is more expensive and more
    thorough
  • Tests generated automatically
  • States are saved to avoid redundant work
  • As a static analysis method
  • Model checking enumerates paths more precisely
    than traditional static analysis
  • Hence, it is more accurate and more costly.

10
The three big problems
  • Computational complexity (e.g., the state
    explosion problem)
  • Finding properties to check
  • Describing/constraining environment

11
Model checking of software
12
The Key Requirement
  • A new verification technique will not be adopted
    unless the benefits outweigh the costs.

13
Special problems of software
  • Bugs are less expensive in software than hardware
    or protocols
  • Field upgrades are often relatively inexpensive
  • Dynamic structures
  • Heap
  • Recursion
  • Dynamically allocated threads
  • Large state spaces
  • Complex environment
  • OS
  • Hardware
  • User

14
Bugs are inexpensive
  • Cost of verification must be minimized
  • Verifying code instead of high-level specs
    reduces specification burden
  • Checking implicit properties (e.g., deadlock)
    reduces cost
  • Other costs must be displaced (e.g., manual
    testing)
  • Target applications that have relatively high
    cost
  • Safety critical
  • Embedded real-time systems
  • Other cases security?

15
Dynamic stuff
  • Heap
  • Recursion
  • Dynamically allocated Threads
  • Eliminate artificial limitations of existing
    model checkers
  • Allow dynamic arrays
  • No a priori limit on state space, but thats ok.

16
Large state spaces
  • Large state spaces
  • Software complexity is not highly constrained by
    physical resources
  • Target embedded applications, which are somewhat
    resource-constrained (but less so each day).
  • Use available model checking optimizations

17
Complex environment
  • OS
  • Hardware
  • User
  • Hope that detailed constraints arent needed
  • Bite the bullet and write specifications

18
A Java model checker
19
Java Model checking
  • Why Java?
  • Lots of interest
  • Well-defined thread model
  • Possibly to be used for embedded real-time
    applications in future.

20
Value of model checking for Java
  • Concurrency problems still very hard to test and
    debug
  • Nondeterminism from scheduling
  • Seemingly reliable applications may break when on
    new hardware, JVM, or under different scheduling
    load.
  • Unpredictable, non-repeatable failures.
  • Other sources of nondeterminism
  • Interactions with user, system calls

21
Status of project
  • Mostly an integration of existing ideas
  • Prototype is implemented
  • Implements a large subset of Java including most
    advanced features of Java.
  • Inheritance, overriding, overloading, exception
    handling
  • Can deal with small programs written by others
  • Cant deal with native code in libraries, etc.

22
Properties checked
  • Goal Keep specification simple
  • Check properties that dont have to be explicitly
    specified
  • Programmers are comfortable with in-line
    assertions.
  • Checker looks for
  • deadlock
  • assertion failures
  • selected exceptions array bounds, run-time type
    errors.
  • . . . more coming soon.

23
Translation strategy
  • Translate statements to SAL guarded commands
  • Nondeterminism of guarded commands used to model
    scheduler, possible results of API calls.
  • Implement JVM run-time in SAL
  • Heap, stack, are implemented as dynamic arrays
  • Classes, stack frames implemented as records

24
Processing steps
Java Program
Java Byte-code
Jimple
SAL Level 1
SAL Level 0
C
Model Checker
Error Trace
25
Java to SAL translation
  • Jimple statements SAL guarded commands
  • Example

i0 1is translated into(PCTID label_0)
--gt next(Stack)TIDSP.localVariables.i0
1 next(PC)TID label_1where PC
program counterTID thread identifier of
current threadlabel_0 SAL label of the
statement i0 1SP stack pointer
26
Optimization Atomic Blocks
  • Idea (Bruening, 1999) execute large blocks of
    code without interleaving at the statement level.
  • Dont need to save or copy intermediate states
    (just save state at end of block).
  • Avoid state explosion from fine-grained
    interleaving.

vs.
27
Atomic Blocks
  • Assumption all accesses to shared variables are
    locked.
  • This can and should be checked during
    verification using same method as in Eraser.
  • Blocks are broken immediately after unlock
    events.
  • Not necessary to break at lock. There may be
    multiple locks and lots of other statements in
    the block.
  • This would miss deadlocks,
  • . . . but there is a more sophisticated deadlock
    check based on circular wait conditions that
    catches all of them.
  • If a block fails to acquire a lock, it is aborted

28
Atomic Blocks
  • Model checker does the optimization on-the-fly
  • execution continues until unlock. Then state is
    saved and other threads can be executed.
  • This is a special form of persistent set
    reduction (Wolper and Godefroid).

29
Savings from atomic blocks
30
Optimization Hash Compaction
  • Idea Instead of saving (large) states in state
    table, store (small) signatures (WolperLeroy,
    SternDill).
  • Tradeoff May result in missed errors because
    state search falsely thinks it has seen a state
    before.
  • Probability of missed error can be bounded
  • 5-byte signatures, 80 million states P(omission)
    lt 0.13.
  • Outcomes
  • Error found (guaranteed correct)
  • Ran out of space, no errors (inconclusive)
  • Searched all states, no errors (almost guaranteed
    correct).

31
Related work
  • Eraser Savage et al., 1997
  • Checks unlocked variables, but doesnt replace
    test generation.
  • Verisoft Godefroid, 1996, Rivet Bruening,
    1999, Stoller 2000
  • Systematically exercises design, but doesnt
    check previously visited states (may do redundant
    work)
  • Java PathFinder (NASA)
  • Similar goals, different optimizations, no SAL,
    no C
  • dSPIN - dynamic data structures in SPIN (but no
    special optimizations)

32
The Future
33
The three big problems (again)
  • Computational complexity (e.g., the state
    explosion problem)
  • Finding properties to check
  • Describing/constraining environment
  • More research is needed on all of these problems,
    in addition to integrating existing techniques.

34
Computational complexity
  • This problem requires an assault from many
    directions.
  • Reduce the problem before model checking
  • Slicing based on property being checked.
  • Data and control abstraction.
  • E.g., Bandera system.
  • Additional model checker optimizations
  • Better persistent set reductions
  • Heap-based optimization
  • symmetry
  • early garbage collection
  • Partial verification
  • Provide guidance to most interesting parts of
    state space

35
Finding properties to check
  • Race detection
  • Eraser model - but requiring Java locks on all
    shared variables is neither necessary nor
    sufficient
  • Misses higher-level locking constructs
  • Misses higher-level atomicity requirements
  • Possibilities of new models lock ordering,
    happens before
  • Check wider range of exceptions
  • Specify and check requirements of standard
    libraries

36
Environmental specification
  • Write more robust programs
  • Detect and report bad environment behavior
  • Code to do this can be used by verifier to
    exclude false errors
  • Specify reusable constraints for common cases
    (e.g., standard libraries)
  • Slicing and abstraction can immunize verification
    from irrelevant environment problems.
  • Better solutions are needed.

37
Model checking static analysis
  • How can static analysis help with the previous
    problems?
  • Should model checking be integrated with (or
    absorbed into) static analysis?

38
Feasibility of model extraction
  • Work with Dawson Engler and David Lie of Stanford
  • FLASH multiprocessor cache coherence protocols
    implemented in C
  • Weird resource constraints
  • Very hard to debug when it crashes
  • 10-30K lines of code
  • Code has been worked over very thoroughly

39
Feasibility of model extraction
  • Used xg compiler to extract a Mur? model
  • xg allows user to write state machines that
    traverse C data flow graph
  • Identifies messages, protocol state transitions
  • Ignores everything else (ad hoc slicing)
  • Method is specific to these protocols
  • Method is neither sound nor complete
  • 9 Bugs found

40
Web page
  • http//verify.stanford.edu
