1
Design of the case studiesEccentrically Braced
Steel Frames
OPUS - OPtimizing the seismic performance of
steel and steel-concrete strUctures by
Standardizing material quality control
  • Walter Salvatore, Massimo Badalassi University of
    Pisa, Department of Structural Engineering
  • Aurelio Braconi Riva Group - Corporate
    Research Policies

Pisa, October 15th, 2007
2
Introduction
  • The initial design of the Eccentrically Braced
    steel frame is presented two frames have been
    designed
  • Frame 1 in which long/intermediate links are
    considered (bending)
  • Frame 2 in which short links are considered
    (shear).
  • The design has been executed using a p.g.a. equal
    to 0.25g
  • Other two frames will be then designed using a
    p.g.a. equal to 0.10g
  • The seismic analysis of the frames has been
    realized using the lateral force method
  • When the design of all the frames will be
    completed (designing also the structural
    connections rigid and full strength), respective
    non-linear structural models will be realized

3
Geometry of the case study
  • Lateral view
  • Materials
  • Steel profiles S355
  • Concrete slabC25/30

4
Geometry of the case study
  • Plan view
  • Slab type

5
Loads
  • Dead Load concrete slab self weight 3,00 kN/m2
  • superimposed load 2,00 kN/m2
  • partition walls 0,80 kN/m2
  • Live load office category B 3,00 kN/m2
  • Wind load Wind Zone 2 (qref) 0,40 kN/m2
  • according to the value proposed by RWTH
  • Snow load Snow Zone 2 1,00 kN/m2
  • according to the value proposed by RWTH

6
Loads
  • Damage limit state
  • Drift limits imposed by EC8 ductile
    non-structural elements (0,005 h)
  • Earthquake

7
Position of the secondary beam and braces
  • Bracing systems
  • Presence of secondary beam in correspondence of
    the link could interfere with the flexural/shear
    behavior of the link

8
Position of the secondary beam
  • The secondary beam could be doubled to move the
    vertical load away from the link
  • There are only some general prescriptions in the
    EC8 concerning with doubler paltes or holes
  • The slab will not change.

9
Frame (1) bending link selected profiles
  • Main beam for exterior frame IPE500
  • Main beam for interior frame IPE500
  • Beam containing the link sized according to
    EC8 requirements
  • Main beam simply supported. Secondary beams
    designed as continuous

10
Frame (1) selected profiles
  • Interior and exterior column are realized using
    HE300B
  • Braces are realized with HE200B
  • Braces are sized using maximum force (capacity
    design) the same for the columns

11
Frame (1) selected profiles
  • Top floor
  • The design of main beams and secondary beams have
    been controlled by the vertical drift limitations
  • During the design the following drift limits have
    been assumed according to EN1991 and National
    Italian Regulations

12
Frame (1) capacity design and over-strength
  • For a homogenous spreading of plasticity in the
    seismic link along the height of the frame the
    over strength factor Wi for each link must be
    defined.
  • The difference between the minimum W and each Wi
    must be less than 25
  • The sizing of link become critic, conditioning
    the design of all other elements through the
    capacity design of braces and columns

13
Frame (2) shear link selected profiles
  • Main beam for exterior frame IPE500
  • Main beam for interior frame IPE500
  • Beam containing the link sized according to
    EC8 requirements
  • Main beam simply supported. Secondary beams
    designed as continuous

14
Frame (2) selected profiles
  • Interior column are realized using HE300B while
    exterior using HE320B
  • Braces are realized with HE200B and HEB220B
  • Braces are sized using maximum force (capacity
    design) the same for the columns

15
Frame (2) selected profiles
16
Frame (2) selected profiles
HE260 B
HE260 B
HE320 B
HE300 B
HE320 B
HE300 B
HE300 B
HE260 B
HE260 B
HE260 B
HE260 B
HE300 B
HE320 B
HE320 B
HE300 B
HE300 B
HE280 B
HE280 B
HE320 B
HE320 B
HE300 B
HE300 B
HE300 B
HE280 B
HE280 B
17
Frame (2) selected profiles
  • Top floor
  • The design of main beams and secondary beams have
    been controlled by the vertical drift limitations
  • During the design the following drift limits have
    been assumed according to EN1991 and National
    Italian Regulations

18
Frame (2) capacity design and over-strength
  • For a homogenous spreading of plasticity in the
    seismic link along the height of the frame the
    over strength factor Wi for each link must be
    defined.
  • The difference between the minimum W and each Wi
    must be less than 25
  • The sizing of link become critic, conditioning
    the design of all other elements through the
    capacity design of braces and columns

19
Design of the concrete slab
  • The types of slab section designed for the EBF is
    characterized by a prefabricated lab with steel
    trussed girder (as reinforcement for the casting
    phase propped or unpropped).
  • For an optimized design of the trussed girder an
    interaction domain between shear and bending
    moment has been defined

Shear limit for avoiding instability of diagonals
Stability upper bar
Resistance of lower bar
20
Tests on concrete slabs
  • Simply supported r.c. slab (Sagging moment
    condition)

2 tests
  • Cantilever scheme (Hogging moment condition)

2 tests
Designed section
21
Conclusions
  • homogeneous distribution of the plastic
    deformation through the structure W impose a
    strict control during the sizing of the link
    profile (25 of variation between Wi)
  • interaction between static load combination and
    seismic load combination could produce high
    values of Wi
  • An optimization of the structural behaviour could
    be obtained using short and long link in the
    structure (to be evaluated)
  • using simply supported beams cannot optimize the
    structural size under vertical load conditions
  • the presence of secondary beam, also if not
    specified in the EC8, in correspondence of the
    link should be avoided.

22
Work to be completed
  • Completing of the design of the case studies with
    the design of the structural connections

Base joint
Brace to column connection
Brace to beam connection
Beam to column connection
  • design of the EBF in low seismicity areas
  • design of the car park
  • definition of the non-linear models

23
Software and Computers
  • The department of structural engineering has the
    following software for the execution of numerical
    analyses
  • Ansys (finite elements concentrated and
    distributed plasticity some fiber element
    simple hysteretic laws)
  • Ruaumoko (structural models - various hysteretic
    laws)
  • OpenSees (finite elements - concentrated and
    distributed plasticity, fiber elements, various
    hysteretic laws)
  • ADINA (finite elements concentrated and
    distributed plasticity some fiber element
    simple hysteretic laws)
  • Hardaware
  • Personal computers of the internal calculation
    centre
  • A work station with four CPUs Intel XEON for the
    execution of the parallel calculation
