Project EMD-MLR Decision Tree Classifiers (Part
1)

• UCF
• October 15, 2004

2
Presentation Outline

• Introduction to Pattern Recognition
• Introduction to the Decision Tree Classifier
• Important Tree Functions
• Growing Phase
• Pruning Phase
• Classify Phase
• Growing Phase
• Split Criteria
• Stopping Criteria
• Leaf Node Assignment

3
Presentation Outline

• Pruning Phase
• How the Pruning Phase Works
• Classify Phase
• Data with Categorical Attributes
• Data with non-uniform misclassification costs
• Computational Complexity of the Decision Tree
  Classifier

4
Pattern Recognition

• The ease with which we recognize a face,
  understand spoken words, read handwritten
  characters, identify our keys in our pocket by
  feel and decide whether an apple is ripe by its
  smell belies the astounding complex processes
  that underlie these acts of pattern recognition
  (Duda and Hart, 2001)

5
Pattern RecognitionDefinition

• Pattern Recognition the act of taking in raw
  data and taking an action based on the category
  of the pattern -- has been crucial for our
  survival-- and over the years we have tried to
  develop algorithms that duplicate the amazing
  ability of humans to recognize patterns(Duda and
  Hart, 2001)

6
Pattern RecognitionAlgorithms

• These algorithms are referred to asPattern
  Recognition Algorithms orPattern
  Classification Algorithms
• An example of a pattern recognition or pattern
  classification algorithm is the decision tree
  algorithm (decision tree classifier)

7
Pattern RecognitionExample

• To understand the complexity of a pattern
  recognition system let us consider a simple
  example, that of recognizing the type of an Iris
  plant

8
Pattern Recognition A case study Iris Data

• Iris data consists of 150 data-points of three
  different types of flowers
• Iris Virginica
• Iris Setosa
• Iris Versicolor
• Analogy Failed/Non-Failed Blades
• Each datum has four attributes
• Sepal Length (cm) (Feature 1)
• Sepal Width (cm) (Feature 2)
• Petal Length (cm) (Feature 3)
• Petal Width (cm) (Feature 4)
• Analogy Operating Hours, Starts, etc.

9
Pattern Recognition Components of a Pattern
Recognition System
Problem Data
Feature Extraction
Feature Selection
Pattern Classification
Pattern Classes
10
Pattern Recognition Feature Extraction,
Selection and Classification

• The feature extraction module has the purpose of
  extracting (or collecting) some important
  information for the task at hand
• The feature selection module has the purpose of
  extracting the features that are important to
  achieve the objective of interest
• The classifier module has the purpose of
  classifying the data relying on the information
  conveyed by the features selected

11
Pattern Recognition Feature Extraction Iris
Data

• In our case the features have already been
  extracted from the data and they are
• Sepal Length (Feature 1)
• Sepal Width (Feature 2)
• Petal Length (Feature 3)
• Petal Width (Feature 4)
• Analogy Features already extracted for the blade
  data include Operating Hours (OH), Various Types
  of Trips (TR), etc.

12
Pattern Recognition Feature Selection Iris Data

• In this case we are trying to determine which
  features are the most important in recognizing
  (classifying) the type of the iris plant
• Colored Scatter plots (2-D plots) of 2 features
  at a time might be useful (see next slide)
• Analogy Scatter Plots of Blade Feature Data,
  such as Operating Hours (OH), Trips (TR), Fired
  Aborts (FA)

13
Pattern Recognition Iris Data Feature Selection
14
Pattern Recognition Histogram of the Petal
Length Feature
15
Pattern Recognition Histogram of the Petal Width
Feature
16
Pattern Recognition Simple Classifier Model
(Model 1)
17
Pattern Recognition Simple Classifier Model
(Model 2)
18
Pattern Recognition More Complex Classifier
Model (Model 3)
19
Pattern RecognitionPerformance of Model 1
Separating Planes for testing data
20
Pattern Recognition Performance of Model 2
21
Pattern Recognition Performance of Model 3
22
Pattern Recognition Selection of a Classifier
Model

• A classifier model is normally selected based on
  the following measures of goodness
• Performance of the classifier model on previously
  unseen data
• Simplicity of the classifier
• Other measures of goodness might be of interest
  to the designer, such as
• Computational Complexity of the Classifier
• Robustness of the classifier in the presence of
  noise

23
Pattern Recognition SystemSelection of a
Classifier Model

• An example of a classifier model is a classifier
  model called
• Decision Tree Classifier

24
Decision Tree Classifier General Overview

• The method for constructing a decision tree
  classifier from a collection of data is easy to
  understand
• Data consist of data attributes (e.g., operating
  hours, number of starts) and the class label
  (scrapped versus non-scrapped blade).
• Initially all the data belong to the same set,
  located at the root of the tree
• Then, a data attribute is chosen, and a test on
  this attribute, to split the data into smaller
  subsets of higher percentages of one-class
  labels, is employed

Decision Trees help you understand what type of
data attributes and attribute values lead to
certain class labels
25
Decision Tree ClassifierGraphic Representation
of a Tree Classifier
Node 0 Root node Nodes 1,2 children of node
0 Node 0 parent of nodes 1 2 Nodes 1,3,4
leaves of the tree
0
Branch of the Tree
Node of the Tree
2
1
4
3
26
Decision Tree ClassifierOperational Phases of
the Tree Classifier

• The decision tree has three distinct but
  interrelated phases. These are
• Growing Phase
• Pruning Phase
• Test (Classify/Performance) Phase

27
Decision Tree ClassifierGrowing Phase of the
Decision Tree Classifier
0
2
1
4
3
28
Decision Tree ClassifierPruning Phase of the
Decision Tree Classifier
0
2
1
4
3
29
Decision Tree ClassifierAdvantages of a Decision
Tree Classifier

• It requires easy to understand elements for its
  design, such as
• A set of questions Q
• A rule for selecting the best split at any node
• A criterion for choosing the right size tree
• It can be applied to any data structure through
  the appropriate formulation of the set of
  questions Q

30
Decision Tree ClassifierAdvantages of a Decision
Tree Classifier

• It handles both ordered and categorical
  variables
• Ordered Variable A variable assuming values from
  the set1, 2, 3, 4, 5, 6,
• Categorical Variable A variable assuming values
  from the set green, red, blue, orange,
• The final classification has a simple form which
  can be compactly stored to efficiently classify
  new data

31
Decision Tree ClassifierAdvantages of a Decision
Tree Classifier

• It does automatic stepwise variable selection and
  complexity reduction
• It gives, with no additional effort, not only a
  classification, but also an estimate of the
  misclassification probability for the object

32
Decision Tree ClassifierAdvantages of a Decision
Tree Classifier

• It is invariant under all monotone
  transformations of the individual ordered
  variables
• E.g.After multiplying a specific feature by a
  constant (say, change its measurement units), the
  resulting decision tree remains unchanged
• It is extremely robust to outliers and
  misclassified points in the training set, used
  for the trees design

33
Decision Tree ClassifierAdvantages of a Decision
Tree Classifier

• The tree procedure gives easily understood and
  interpreted information regarding the predictive
  structure of the data
• Given a decision tree, you can extract simple
  IF-THEN rules, that show you how the thought
  process of the tree, when it classifies.
• It has been used successfully in a variety of
  applications (see following slides)

34
Decision Tree ClassifierApplications of a
Decision Tree Classifier

• Medical Applications
• Wisconsin Breast Cancer (predict whether a tissue
  sample taken from a patient is malignant or
  benign two classes, nine numerical attributes)
• Bupa Livers Disorder (predict whether or not a
  male patient has a liver disorder based on blood
  tests and alcohol consumption two classes, six
  numerical attributes)

35
Decision Tree ClassifierApplications of a
Decision Tree Classifier

• Medical Applications
• PIMA Indian Diabetes (the patients are females at
  least 21 years old of Pima Indian heritage living
  near Phoenix, Arizona the problem is to predict
  whether a patient would test positive for
  diabetes there are two classes, seven numerical
  attributes)
• Heart Disease (the problem here is to predict the
  presence or absence of heart disease based on
  various medical tests there are two classes,
  seven numerical attributes and six categorical
  attributes)

36
Decision Tree ClassifierApplications of a
Decision Tree Classifier

• Image Recognition Applications
• Satellite Image (this dataset gives the
  multi-spectral values of pixels within 3x3
  neighborhoods in a satellite image, and the
  classification associated with the central pixel
  the aim is to predict the classification given
  the multi-spectral values. There are six classes
  and thirty six numerical attributes)
• Image Segmentation (this is a database of seven
  outdoor images every pixel should be classified
  as brickface, sky, foliage, cement, window, path,
  or grass there are seven classes and nineteen
  numerical attributes)

37
Decision Tree ClassifierApplications of a
Decision Tree Classifier

• Other Applications
• Boston Housing (this dataset gives housing values
  in Boston suburbs there are three classes,
  twelve numerical attributes, one binary
  attribute)
• Congressional Voting Records (this database gives
  the votes of each member of the U.S. House of
  Representatives of the 98th Congress on sixteen
  key issues the problem is to classify a
  congressman as a Democrat, or a Republican based
  on the sixteen votes there are two classes,
  sixteen categorical attributes (yea, nay,
  neither)

38
Decision Tree Classifier Growing Phase

• The growing phase of the tree revolves around
  three elements
• The selection of the splits
• The decision of when to designate a node terminal
  or to continue splitting it
• How to determine the class assignments of the
  terminal nodes

39
Decision Tree Classifier Selection of Splits

• What is a split?
• Each node of the tree represents a box (rectangle
  in 2 dimensions) in the feature space.
• Growing of the tree can be accomplished by
  splitting the box into 2 new boxes.
• The node t representing the original box becomes
  the parent node of the two nodes (children tL
  and tR) representing the 2 new boxes.
• A rectangle can be split in two ways across the
  x1 or the x2 dimension

40
Decision Tree ClassifierSelection of Splits

• What is a split? (continued)
• A box in n dimensions can be split in many
  different ways.
• The dimension along which we perform the split is
  called split attribute or split feature.
• The specific value at which the split occurs is
  called split value.
• What do we accomplish by splitting?
• The growing of a tree, whose terminal nodes
  represent very specific rules.
• Smaller rectangles that contain patterns, most of
  which are of the same class label, will provide
  us with very specific, accurate classification
  rules.
• How do we select a good split?
• We select a split attribute and corresponding
  split value so that the resulting children nodes
  are purer.

41
Decision Tree Classifier Selection of Splits

• Define by the proportion of class j
  cases at node t of the tree
• Define also by a measure of impurity for
  node t of the decision tree. Note that
• is a nonnegative function
• it depends on the probabilities
  , where J is the number of different
  classes
• It achieves its maximum value (equal to 1) when
  the are all equal to
• It achieves its minimum value (equal to 0) when
  one of the is equal to 1 and the
  rest of the are equal to 0

42
Decision Tree Classifier Examples of impurity
measures

• The Entropy impurity measure
• The Gini Function impurity measure

43
Decision Tree Classifier Entropy Gini Impurity
Functions
44
Decision Tree Classifier Selection of Splits

• Selection procedure
• Given a node t select the split attribute n and
  the split value s so that the difference between
  the impurity of t and the average impurity of the
  children tL and tR is maximized, viz.

45
Decision Tree Classifier Selection of Splits An
Example

• Example
• Let a node t be represented by the rectangle
  0?x1?10, 0?x2?10 containing 50 patterns of
  class 1 (blue) and 50 patterns of class 2 (red).
• Lets consider splitting t along the x1
  attribute.

46
Decision Tree Classifier Differences between
Impurity Functions

• Difference in impurities versus x1
• Best split value is 5.146 for both impurity
  functions

47
Decision Tree Classifier Differences between
Impurity Functions

• Entropy and Gini impurities are qualitatively
  similar and, therefore, most often they give
  similar, if not identical, splits.

48
Decision Tree Classifier Resubstitution Error
as Impurity Function

• Another candidate function that seems natural to
  be used as a node impurity measure would be the
  Resubstitution Error (misclassification error on
  the training set)

49
Decision Tree Classifier Resubstitution Error
as Impurity Function

• Most of the times using the resubstitution error
  (RE) will provide the same best split as when
  using the Gini or entropy impurity (Case A)
• However, there are a number of occasions, where
  the difference in impurity ?i(n,st) as measured
  by the RE is locally flat (regions of same
  values), implying a variety of equally good
  splits. (Case B)Among those equally good splits
  there is usually one or two that intuitively
  would seem more reasonable. These latter splits
  are typically easier to identify via the Gini or
  entropy impurities
• The phenomenon of non-uniqueness of best splits,
  which rarely occurs when using the Gini or
  entropy impurities, makes the RE less
  suitable/convenient to determine splits

50
Decision Tree Classifier Resubstitution Error
as Impurity Function

• Case A
• RE, Gini, entropy suggest a unique best split.
• It is quite common that all three impurity
  measures may suggest similar if not identical
  splits.

51
Decision Tree Classifier Resubstitution Error
as Impurity Function

• Case B
• RE claims all splits are equivalent!
• Gini entropy suggest only two equivalent
  splits, which intuitively are quite reasonable.

52
Decision Tree Classifier An Example
53
Decision Tree ClassifierAn Example
54
Decision Tree Classifier The first Split Level 0

• We are at the root of the tree with data 1, 2,
  3, 4, 5 of Class A and data (6, 7, 8, 9, 10 of
  class B
• The possible x-splits that we need to consider
  are
• The possible y-splits that we need to consider
  are

55
Decision Tree ClassifierChange in Impurity for
x-splits Level 0
56
Decision Tree ClassifierChange in Impurity for
y-splits
57
Decision Tree Classifier Calculation of the
impurity difference

• Best Split
• Left Node Data 1, 2, 4 , Right Node Data
  3, 5, 6, 7, 8, 9,10
• Impurity of Parent
• Impurity of left child

58
Decision Tree Classifier Calculation of the
Impurity Difference

• Impurity of the right child
• Average Impurity of the left and right child
• Difference in Impurity

59
Decision Tree Classifier Picture of how the best
1st split looks
1,2,3,4,5 A 6,7,8,9,10 B
x gt 0.35
x lt 0.35
1, 2, 4 - A
3,5 A 6,7,8,9,10 - B
Numerals ? data Letters ? class label
60
Decision Tree ClassifierPicture of how another
1st split looks
Numerals ? data Letters ? class label
61
Decision Tree ClassifierPicture of how another
1st split looks
Numerals ? data Letters ? class label
62
Decision Tree ClassifierPicture of how another
1st split looks
Numerals ? data Letters ? class label
63
Decision Tree ClassifierThe second Split Level 1

• The left node (child) of the tree has data 1, 2,
  4 of the same classification (class A). So, no
  further splitting of the data residing in the
  left node is needed.
• The right node (child) of the tree has data 3,
  5, 6, 7, 8, 9, 10 of which data 3, 5 are of
  class A and data 6, 7, 8, 9, 10 are of class B.
  So further splitting of the data residing in the
  right node is needed.
• The possible x-splits that we need to consider
  are
• The possible y-splits that we need to consider
  are

64
Decision Tree Classifier Change in Impurity for
x-splits Level 1, right node
65
Decision Tree ClassifierChange in Impurity for
y-splits Level 1, right node
66
Decision Tree Classifier Picture of how 2nd
split looks
1,2,3,4,5 A 6,7,8,9,10 - B
3,5 A 6,7,8,9,10 - B
1, 2, 4 - A
x gt0.5
x lt 0.5
3,5 A 7,9 - B
6,8,10 - B
Numerals ? data Letters ? class label
67
Decision Tree ClassifierPicture of how 3rd split
looks
1,2,3,4,5 A 6,7,8,9,10 - B
3,5 A 6,7,8,9,10 - B
1, 2, 4 - A
3,5 A 7,9 - B
6,8,10 - B
y gt 0.5
y lt 0.5
5 A 7,9 - B
3 A
Numerals ? data Letters ? class label
68
Decision Tree ClassifierPicture of how 4th split
looks
1,2,3,4,5 A 6,7,8,9,10 - B
3,5 A 6,7,8,9,10 - B
1, 2, 4 - A
3,5 A 7,9 - B
6,8,10 - B
5 A 7,9 - B
3 A
x gt 0.4
x lt 0.4
5 A 7 - B
9 B
Numerals ? data Letters ? class label
69
Decision Tree Classifier Picture of how 5th
split looks
1,2,3,4,5 A 6,7,8,9,10 - B
3,5 A 6,7,8,9,10 - B
1, 2, 4 - A
3,5 A 7,9 - B
6,8,10 - B
5 A 7,9 - B
3 A
5 A 7 - B
9 A
y gt 0.6
y lt 0.6
7 B
5 A
Numerals ? data Letters ? class label
70
Decision Tree Classifier Understanding Split
Choices
Pr(Class 1) 0.5 Pr(Class 2) 0.5
Pr(Class 1) Pr(Class 2)
Pr(Class 1) Pr(Class 2)
is the portion of class 1 data going to
the left child is the portion of class 2
data going to the left child is the
portion of class 1 data going to the right child
is the portion of class 2 data going to
the right child
71
Decision TreesUnderstanding Split ChoicesPr
(Class 1) 0.5, Pr (Class 2)0.5 An Example
72
Decision TreesUnderstanding Split ChoicesPr
(Class 1) 0.5, Pr (Class 2)0.5 An Example
Pr(Class 1) 0.5 Pr(Class 2) 0.5
Pr(Class 1) 0.05 Pr(Class 2) 0.4
Pr(Class 1) 0.45 Pr(Class 2) 0.1
73
Decision TreesUnderstanding Split ChoicesPr
(Class 1) 0.5, Pr (Class 2)0.5 An Example
74
Decision Tree Classifier Understanding Split
Choices
Pr(Class 1) 0.6 Pr(Class 2) 0.4
Pr(Class 1) Pr(Class 2)
Pr(Class 1) Pr(Class 2)
is the portion of class 1 data going to
the left child is the portion of class 2
data going to the left child is the
portion of class 1 data going to the right child
is the portion of class 2 data going to
the right child
75
Decision TreesUnderstanding Split ChoicesPr
(Class 1) 0.6, Pr (Class 2)0.4
76
Decision Tree Classifier Understanding Split
Choices
Pr(Class 1) 0.7 Pr(Class 2) 0.3
Pr(Class 1) Pr(Class 2)
Pr(Class 1) Pr(Class 2)
is the portion of class 1 data going to
the left child is the portion of class 2
data going to the left child is the
portion of class 1 data going to the right child
is the portion of class 2 data going to
the right child
77
Decision TreesUnderstanding Split ChoicesPr
(Class 1) 0.7, Pr (Class 2)0.3
78
Decision Tree Classifier Understanding Split
Choices
Pr(Class 1) 0.8 Pr(Class 2) 0.2
Pr(Class 1) Pr(Class 2)
Pr(Class 1) Pr(Class 2)
is the portion of class 1 data going to
the left child is the portion of class 2
data going to the left child is the
portion of class 1 data going to the right child
is the portion of class 2 data going to
the right child
79
Decision TreesUnderstanding Split ChoicesPr
(Class 1) 0.8, Pr (Class 2)0.2
80
Decision Tree ClassifierUnderstanding Split
Choices
Pr(Class 1) 0.9 Pr(Class 2) 0.1
Pr(Class 1) Pr(Class 2)
Pr(Class 1) Pr(Class 2)
is the portion of class 1 data going to
the left child is the portion of class 2
data going to the left child is the
portion of class 1 data going to the right child
is the portion of class 2 data going to
the right child
81
Decision TreesUnderstanding Split ChoicesPr
(Class 1) 0.9, Pr (Class 2)0.1
82
Decision Tree Classifier -Terminal Node Issue
When does the tree stops growing?
1,2,3,4,5 A 6,7,8,9,10 - B

• Criterion 1 (Stop Min Records)
• The number of records in an node is below a
  minimum number of records threshold
• The minimum number of records criterion is
  checked first

3,5 A 6,7,8,9,10 - B
1, 2, 4 - A
3,5 A 7,9 - B
6,8,10 - B
y gt 0.5
y lt 0.5
5 A 7,9 - B
3 A
Stop Beta 0.0 Stop Purity 100 Stop Min
Records 2
Stop Reason Reached Min Records
83
Decision Tree Classifier -Terminal Node
IssueWhen does the tree stops growing?

• Criterion 2 (Stop Purity)
• We have reached an acceptable purity level
• The purity level stop criterion
• is checked second

1,2,3,4,5 A 6,7,8,9,10 - B
x gt 0.35
x lt 0.35
1, 2, 4 - A
3,5 A 6,7,8,9,10 - B
Stop Beta 0.0 Stop Purity 100 Stop Min
Records 2
Stop Reason Reached Purity Level
84
Decision Tree Classifier -Terminal Node Issue
When does the tree stops growing?

• Criterion 3 (Stop Beta)
• The maximum difference in impurity between parent
  and children is smaller than an allowable
  difference threshold
• The maximum difference in impurity stop criterion
  is checked third

1,2,3,4,5 A 6,7,8,9,10 B
x lt 0.35
x gt 0.35
3,5 - A 6,7,8,9,10 - B
1, 2, 4 - A
Stop Reason Reached threshold for Beta
Stop Beta 0.3 Stop Purity 100 Stop Min.
Records 2
85
Decision Tree Classifier Class Node Assignments
1,2,3,4,5 A 6,7,8,9,10 - B

• In the figure to the right the class assignment
  for the right node of the tree is Class B
  because the majority class is Class B.
• The right node has 5 records from Class B and 2
  records from Class A

x gt 0.35
x lt 0.35
1, 2, 4 - A
3,5 A 6,7,8,9,10 - B
Class Assignment Majority Class Class A
Class Assignment Majority Class Class B
