Title: Tracking code development for FFAGs


1
Tracking code development for FFAGs
  • S. Machida
  • ASTeC/RAL
  • 2 November, 2005
  • http//hadron.kek.jp/machida/doc/nufact/
  • ffag/machida_021105.ppt pdf

2
Longitudinal acceptance
b0.25
b0.20
b0.10
b0.15
Each line is trajectory starting from (0,dp/p),
where dp/p is every 0.01 step.
3
Emittance evolution
Less tilted (-50).
Initial ellipse is tilted as about the same slope
of separatrix.
More tilted (50).
4
Summary
  • Momentum acceptance is higher with less b
    parameter. With b0.2, dp/p-0.05 is achieved.
    It is still a bit less compared with
    ShaneEberhard calculation (dp/p-0.06).
    However, that may be attributed to the different
    models, one is analytic with symmetric TOF
    parabola, and the other is brute force
    integration.
  • Longitudinal bunch with lt-0.1ns and dp/p0.025
    are accelerated with tilted initial ellipse.
