10 Optics Part 1

1
10 - Optics Part 1
2
Preliminaries
Reflection (Hero(n) of Alexandria ) ?1?1
Only determines direction of reflection, not SPD
3
Refraction
v speed of light in mediun (material) c speed
of light in vacuum v c/n n index of
refraction of medium
4
Trigonometry refresher Given the right triangle
shown here sin(B) b/c cos(B) a/c tan(B)
b/a
Snells Law of Refraction n1 sin ?1 n2 sin ?2
5
Characteristic Frequencies
Electric charges in matter respond to a driving
force of the electromagnetic wave. Greatest
response at some favored or resonant frequency
?0
6
Selective Absorption
Damping force diminishes oscillations - Damped
oscillations
(hard to illustrate without demonstration movies
7
Dispersion
Light of different wavelengths will be refracted
by different angles Amount of refraction depends
on the nature of the material normal dispersion -
more refraction at higher frequencies (shorter
wavelengths) anomalous dispersion - more
refraction at lower frequencies (longer
wavelengths)
8
(a) the amplitude and phase of a damped driven
oscillator
(c) n index of refraction k the
absorption coefficient
(b) dielectric functions
(d) also determines reflectance, too!
