MICE Management

1
MICE Management
Paul Drumm MICE-UK May 2006
2
Items

• Responsibility rearrangements
• Chris Nelson ?Yury
• Chris
• Hall Infrastructure
• Interface to the cooling channel
• CN (TJ, SY) group to oversee coordinate
  integration
• Yury
• Focus on hydrogen system

3
Items

• Tracker Review (more later)
• TB (PD, ABl, ABr, ME, WLSY)
• GG, PS
• Review encouraged by progress
• Main points
• number of suggestions
• document and prove the QA procedures with new
  station
• risk strategy

4
Beam line geometry
Support Rails
5
Items

• ISIS
• Pion capture to decay solenoid
• EID
• Decay Solenoid Cryogenics
• Liverpool
• Beam components in MICE hall
• Three stands, rails (Q207)
• MICE Installation infrastructure
• (rail system)

6
Items

• ISIS Shutdown
• First indication during Osaka meeting
• Now confirmed
• Starts 22nd December 2006
• Ends 31st August 2007
• Additional shutdown
• Mid Oct-mid November 2006
• Probably ditto in 2007

7
Schedule status

• Within schedule little slack
• Completion of the hall work
• waiting for feedback of key information
• Stairs
• Mezzanine (Hydrogen System Access)
• Platform (support for MICE)
• Window for Solenoid Commissioning with Cryogenics

8
Items

• Interlocks
• Developed a philosophy
• Four areas access control
• ISIS
• Solenoid Shielded area
• Hall
• Outside
• Ensuring initial integrity is non-trivial

9
Items
A
Internal
External
B
MuonSolenoid
D
MBL
ISIS RING
RF
B
!
H
Target
Cable route (below ground)
Fire escape
C
10
Milestones

• Completion of hall work
• Target test on balance, go for October?
• Delivery, Installation and handover of Cryogenics
• Start of Shutdown
• Delivery of beam line components (Sync)
• Tracker
• ToF/MuCal DAQ Frascati test beam

11
RD Milestones

• Hydrogen System
• Delivery of hydride bed
• Full response to hydrogen review, Hazop ...
• Tender for RD system, cryostat
• RF Power System
• Low power system
• RF Tubes (4616) ?
• HV System ?
• Assembled 300kW system
• Power into load June 06

12
Financial Status

• Last FY under spend
• largely staff travel
• Large items
• Decay solenoid cryogenics
• 100 (200k)
• RF equipment
• 100k amplifiers
• Phase 2 ISIS Contribution (30k)
• Optical Fibre, Cryo-coolers
• 40k 90k (WFL Contribution)
• In progress Beam line power supplies
• (100k?)
