Vmax Indoor Vacuum Circuitbreakers for Primary Distribution

1
VmaxIndoor Vacuum Circuit-breakersfor Primary
Distribution
2
Vmax

• Versions
• 12 kV 17.5 kV 630 ..1250 A 16 .. 31.5 kA
• Fixed and withdrawable versions with front
  operating mechanism
• Withdrawable for UniGear type ZS1 switchgear
  (width 550 mm)
• Withdrawable for PowerBox cubicle (width 600 mm)

• Compliance to IEC 62271-100 STDs

3
Vmax
Open/close auxiliary contacts Additional shunt
tripping release Locking magnet in the
actuator Opening pushbutton Closing
pushbutton Shunt tripping release Built-in lever
for closing spring manual charging Shunt closing
release Signalling device for closing springs
charged/discharged Mechanical operation
counter Geared motor for closing spring charging
4
Vmax

• Fields of application
• Power distribution
• Cable control and protection
• Overhead control and protection
• Transformation and distribution substations
• Motor and transformer control and protection
• Generator control and protection
• Capacitor bank control and protection

5
Vmax

• Targets
• Applications where space saving is a premium
• Compact dimensions compared to existing VD4
• Freestanding vacuum interrupters
• Moulded case design

6
Vmax
Features

• Vacuum interruption technique
• Contacts in vacuum protected against oxidation
  and contamination
• Sealed for life vacuum interrupters
• Limited switching energy
• EL mechanical actuator family, already used and
  tested within new VD4 series, with stored
  energy and with anti-pumping device supplied as
  standard
• Same kinematic chain of new VD4 VG vacuum
  interrupter family, already used and tested
  within in new VD4 series
• 15,000 mechanical operations
• Easy customization with a complete range of
  accessories
• Locks to prevent incorrect and hazardous
  operations
• LCA according to ISO 14040 STDs
• Recyclable components plastic components marked
  acc. ISO 11469 to make easy the recycling at the
  end of the products life cycle

7
Vmax
Overview
8
Vmax
Standard equipment

• Mechanical signalling device for cb open/closed
• Mechanical signalling device for closing spring
  charged/discharged
• Opening and closing pushbuttons
• Mechanical operation counter
• Built-in lever for manually charging of closing
  spring
• Anti-pumping mechanical built-in function
• 5 5 auxiliary contacts
• Connection terminals and terminal board for
  auxiliary circuits (for fixed c.b.)
• Isolating contacts, cord with connector (plug
  only), racking-in/out lever (for withdrawable
  c.b.)

9
Vmax
Other accessories, on request

• Shunt tripping release
• Additional shunt tripping release
• Shunt closing release
• Opening solenoid (e.g. for PR512 relay)
• Undervoltage release (with or without electronic
  time delay which must be mounted externally in
  relation to the circuit breaker)
• Mechanical override for undervoltage release
• Opening/closing pushbutton protection
• Opening/closing pushbutton padlocks
• Key-lock in open position
• 5 extra auxiliary contacts

10
Vmax
Other accessories, on request

• Motorgear for closing spring charging
• Signalling contact closing spring charged
• Signalling contact closing spring discharged
• Locking magnet in the truck to prevent racking-in
  with auxiliary circuits disconnected (for
  withdrawable c.b.)
• Transmitted contacts in the truck for signalling
  inserted or isolated circuit breaker (for
  withdrawable c.b.)
• To prevent racking-out/in with the circuit
  breaker closed and to prevent closing operation
  during the translation, interlock for fixed
  circuit breaker which is converted in
  withdrawable ones by the customer

11
Vmax

• Compared to VD4, Vmax cannot be fitted with
• Transient contact with momentary closing during
  circuit breaker opening
• Motorized truck

12
Vmax Main Competitors

• Cutler-Hammer
• T-VAC (), T-VACR () according to IEC STDs
• 7.2 .. 17.5 kV, 630 .. 1250 A, 16 .. 25 kA
• VCP-T (), VCP-TR () according to ANSI STDs
• 4.76 .. 15 kV, 600 .. 1200 A, 16 .. 25 kA
• () fixed construction
• () withdrawable construction cassette
• Pole distance 130 mm
• Self-powered O.R. series Digitrip
• Type LSIG
• Type LSIG metering communication

13
Vmax Main Competitors

• Schneider Electric (Evolis) up to 24 kV
  comparison up to 17.5 kV
• 7.2 .. 17.5 kV, 630 .. 2500 A, 25 .. 40 kA,
• pole distance 145 185 240 mm
• 3 sizes (P1, P2, P3)

14
Vmax Main Competitors

• Siemens SION ( 7.2 24 kV)
• 7.2 17.5 kV, 800 3150A, 12.5 40 kA
• Pole distance 150 160 - 210 mm
• 24 kV, 800 2500A, 12.5 25 kA
• Pole distance 210-275 mm

15
Vmax Life cycle assessment

• LCA study according to ISO 14040
• recyclable components
• plastic components marked according to ISO 11469
  to simplify the end of life management

16
