Chapter 28 Magnetic Induction

1
Chapter 28Magnetic Induction
2
Topics

• Magnetic Flux
• Faradays Lenzs Laws
• Inductance
• Magnetic Energy

3
Magnetic Flux
The magnetic flux through a surface is defined by
In the 1830s, Michael Faraday and Joseph Henry
discovered that a changing magnetic flux can
induce currents
4
Magnetic Flux
The unit of magnetic flux is T m2, that is, a
weber (Wb)
Usually, an engineer is interested in the flux
through a surface bounded by a wire
5
Magnetic Flux
For a constant magnetic field, the flux through
a wire loop of area A is
6
Magnetic Flux
For N loops of wire, and a constant magnetic
field, the flux is N times greater that is, it is
7
Magnets _at_ CERN
8
Magnetic Flux CMS
9
Magnetic Flux CMS
10
Magnetic Flux CMS
The magnetic field of a solenoid is
Flux
For CMS B 4 T I 20,000 A l 12.5 m r 3
m
11
Magnetic Flux CMS
Putting in the numbers for CMS, we get
Flux
For CMS B 4 T I 20,000 A l 12.5 m r 3
m
12
Faradays Law
Faraday and Henry discovered that a changing flux
through a wire loop creates an electric
field, which, in turn, induces an emf (a
potential) in the wire
13
Faradays Law
The experimental observations can be summarized
in the following law
Faradays Law
14
Lenzs Law
The induced emf is such as to oppose the change
that produces it
15
Lenzs Law
B2 is the magnetic field caused by current
induced in the wire. By Lenzs law, this field
acts in a direction opposite the
changing magnetic field B1
16
Lenzs Law
We use the right-hand rule to determine the
direction of the current I
17
Example Induced emf
A conductor moving through a magnetic field will
have an electric field induced in it, given by qE
q v B, that is, E v B
18
Example Induced emf
The induced potential difference is then DV E
l v B l, once the current stops.
19
Inductance
The magnetic flux through a coil is proportional
to the current flowing through it, so we can
write The proportionality constant L is
called the self-inductance of the coil, whose
unit is the henry (H 1 Wb/A )
20
Inductance
Example Self-inductance of a long solenoid
that is,
21
Inductance
Consider a changing magnetic flux through a coil
But, since
we find a self-induced emf of
22
Magnetic Energy
Consider a circuit containing a resistor R and a
coil of self-inductance L. From Kirchoffs
loop rule, we can write
23
Magnetic Energy
Multiply throughout by I and re-arrange
battery power joule heating power in coil
24
Magnetic Energy
Therefore, the energy stored in the inductor (the
coil in this case) is found by integrating the
power in the coil with respect to time
25
Magnetic Energy CMS
The energy stored in the CMS solenoid is
For CMS B 4 T I 20,000 A l 12.5 m r 3
m
This is enough to melt 18 tons of gold!
