Transport of Bacterial Endospores in Silica Sand

1
Transport of Bacterial Endospores in Silica Sand

• Sibylle Tesar, Fulbright Scholar
• Dr. Barbara Williams, Faculty
• Dr. Robin Nimmer, Res. Supp. Sci.
• Angelina Cernick, Undergraduate
• Kristina Beaulieau, NSF REU

Department of Biological and Agricultural
Engineering University of Idaho
2
Outline

• Research Goals transport mechanisms /
  endospores
• Background transport mechanisms / endospores
• Research Questions preliminary
• Methods sporulation / saturated column tests /
  breakthrough curves / depth distribution data
• Preliminary Results
• Preliminary Conclusions
• Future Work B. cereus, other microbes

3
Research Goals Spore Transport in Porous Media

• Mechanistic Goal Contribute to the lively
  debate of attachment versus straining
• Microbe-specific goal Bacterial endospore
• Practical Applications
• Drinking water protection - groundwater
• Shallow recharge
• Septic drainfield setbacks
• Surface water filtration
• Riverbank or riverbed filtration

4
Outline

• Research Goals transport mechanisms /
  endospores
• Background transport mechanisms / endospores
• Research Questions preliminary
• Methods sporulation / saturated column tests /
  breakthrough curves / depth distribution data
• Preliminary Results
• Preliminary Conclusions
• Future Work B. cereus, other microbes

5
Terminology Mechanisms for Retention

• Attachment adhesion sorption
• Function of collision, collector efficiency,
  sticking efficiency
• Mechanical filtration complete retention of
  particles that are larger than all of the soil
  pores (formation of filter cake)
• Straining physical trapping in geometric
  corners
• Particles can be smaller than smallest pore
  openings
• Requires grain-grain contact
• Only occurs in some fraction of soil pore space,
  transport occurs elsewhere

Bradford et al, WRR, 2006
6
Strained versus Mechanically Filtered
dp/d50 ? .005
7
Background

• Clean-bed Filtration Theory
• Depends on mechanism of attachment / detachment
• Deviation from Clean Bed Filtration Theory
• Unfavorable attachment condition neg-neg
• Fine sand and large colloids (dp/d50 ? .005)

8
Explanations for Deviation from CFT

• Attachment w/ porous media charge variability
  Johnson and Elimelech, 1995
• Attachment w/ heterogeneity in surface charge
  characteristics of colloids Li et al, 2004
• Attachment w/ deposition of colloids in a
  secondary energy minimum Tufenkji et al. 2003,
  Redman et al., 2004
• All of the above Tufenkji and Elimelech, 2005
• Attachment w/ straining Foppen et al, 2005,
  Bradford et al, 2006a, b

9
Theory (cont.)
Aqueous Phase Colloid Mass Balance Equation-
Bradford et al., 2003

• Where
• ?w volumetric water content -
• t time T
• C colloid concentration in the aqueous phase
  N L-3
• JT total colloid flux N L-2 T-1
• EattSW colloid attachment mass transfer
  between solid/water phases N L-3 T-1
• EstrSW colloid straining mass transfer between
  solid/water phases N L-3 T-1

10
Research Goals Endospore Transport

• Endospore-forming bacteria have two viable modes
• Vegetative cell (growing)
• Endospore (dormant) formed as survival
  mechanism
• Endospores have the potential to be more mobile
  than their vegetative cell counterparts
• smaller size
• potentially less adhesion

11
Bacterial Endospores

• Formed as a survival mechanism
• Cryptobiotic no sign of life - dormant mode

http//www.textbookofbacteriology.net/
12
Differences between endospores and vegetative
cells in Bacillus species
http//www.textbookofbacteriology.net
13
Differences between endospores and vegetative
cells in Bacillus species
14
In terms of physical passage through the pore
space
the spore has a shorter aspect ratio than the
vegetative cell.

• B. cereus spore properties
• Food poisoning pathogen
• Length 1-2 mm, Width 0.5-0.75 mm
• Hydrophobic
• Isoelectric point pH 3

15
Outline

• Research Goals transport mechanisms /
  endospores
• Background transport mechanisms / endospores
• Research Questions preliminary
• Methods sporulation / saturated column tests /
  breakthrough curves / depth distribution data
• Preliminary Results
• Preliminary Conclusions
• Future Work B. cereus, other microbes

16
Preliminary Research Questions

• Do spores obey CFT, exhibiting more retention in
  higher ionic strength solution or does spore
  transport deviate from CFT theory as do other
  negatively charged particles (unfavorable
  attachment)?
• Future Do vegetative cells and endospores have
  a different charge?
• Future Do vegetative cells exhibit more
  attachment than endospores?

17
Outline

• Research Goals transport mechanisms /
  endospores
• Background transport mechanisms / endospores
• Research Questions preliminary
• Methods sporulation / saturated column tests /
  breakthrough curves / depth distribution data
• Preliminary Results
• Preliminary Conclusions
• Future Work B. cereus, other microbes

18
Materials Sand Properties

• Saturated conductivity Ksat 1.8x10-4 m/sec
• Dry bulk density
• rb 1.65 g/cm3
• Porosity
• n 0.34
• dp/d50 ? .0017

19
Method Constant Head, Sand Column
20
Breakthrough (C/Co) of B. cereus spores as a
function of ionic strength
Artificial groundwater
DDI
21
Column Dissection
22
Column Dissection

• Drain column to field capacity, in the flow
  direction.
• Dissect into seven 2 cm increments
• STR 1 Gently place sand, allowing bridging and
  loose packing, in a funnel that has been plugged
  with Scotchbritetm pad
• STR 2 Wash off the strained bacteria by pouring
  the solution (the solution used in that
  particular experiment) over the sand into a
  graduated cylinder
• ATT To remove the attached bacteria, place a
  known amount of 2 Tweentm 80 solution into a
  beaker containing the sand. Stir then sonicate.
• Used optical density (OD) measurements in
  addition to plate counting to enumerate.

(Tween and sonication proven not to affect
germination efficiency)
23
Depth Distribution Data
Strained spores in AGW run
24
Depth Distribution Data
Attached spores in AGW run
25
Depth Distribution Data
Strained and attached fractions combined
26
Outline

• Research Goals transport mechanisms /
  endospores
• Background transport mechanisms / endospores
• Research Questions preliminary
• Methods sporulation / saturated column tests /
  breakthrough curves / depth distribution data
• Preliminary Results
• Preliminary Conclusions
• Future Work B. cereus, other microbes

27
Preliminary Conclusions

• Breakthrough curve data are consistent with CFT
  higher ionic strength, more retention
• Depth distribution data show deviation from CFT
  not exponential with depth

28
Outline

• Research Goals transport mechanisms /
  endospores
• Background transport mechanisms / endospores
• Research Questions preliminary
• Methods sporulation / saturated column tests /
  breakthrough curves / depth distribution data
• Preliminary Results
• Preliminary Conclusions
• Future Work B. cereus, other microbes

29
Future Work

• Compare attachment/straining of spores versus
  vegetative cells
• Column experiments
• Micromodels and photographs
• Wet AFM
• Compare zeta potential
• pH and more ionic strength effects
• Different endospore bacteria, such as S.
  pasteurii, for biomineralization

30
Acknowledgements

• Dr. Ron Crawford, Director, Environmental
  Biotechnology Institute, UI
• Nick Benardini, PhD Candidate, MMBB
• Elizabeth Scherling, MS, BAE
• Dr. Markus Tuller, PSES
• David Christian, Research Support Sci.

31
Funding Acknowledgements

• Fulbright Scholars Program
• USDA Hatch
• UI URO Seed Grant Program
• NSF REU program

32
References

• Bradford, S.A., J. imunek, M. Bettahar, M.
  vanGenuchten, and S.R. Yates. 2003. Modeling
  colloid attachment, straining, and exclusion in
  saturated porous media. Environmental Science
  and Technology 37 2242-2250.
• Bradford, S.A., J. imunek, M. Bettahar, M.Th.
  vanGenuchten, and S.R. Yates. 2006a.
  Significance of straining in colloid deposition
  evidence and implications. Water Resources
  Research, 42doi10.1029/2005WR004791.
• Bradford, S.A., J. imunek, and S.L. Walker.
  2006b. Transport and straining of E. coli
  0157H7 in saturated porous media. Water
  Resources Research (in review).
• Li, X., TD. Scheibe, and W.P. Johnson. 2004.
  Apparent decreases in colloid deposition rate
  coefficient with distance of transport under
  unfavorable deposition conditions a general
  phenomenon. Environ. Sci. Technol., 38
  5616-5625.
• Redman, J.A., S.L. Walker, and M. Elimelech.
  2004. Bacterial adhesion and transport in porous
  media Role of the secondary energy minimum,
  Environ. Sci. Technol., 381777-1785.
• Tufenkji, N., J.A. Redman, and M. Elimelech.
  2003. Interpreting deposition patterns of
  microbial particles in laboratory-scale column
  experiments, Environ. Sci. Technol., 37 616-623.
• Tufenkji, N., Elimelech, M. 2005. Breakdown of
  colloid filtration theory Role of the secondary
  energy minimum and surface charge
  heterogeneities. Langmuir 21 841-852.
