CS415Minithreads Project 2 Context Switch and
Stack Initialization

• Ken Hopkinson
• hopkik_at_cs.cornell.edu

2
What You Have to Do

• Lay the foundation for Minithreads, a user-level
  threads package, on Windows NT
• In this assignment we will be creating code for
  context switching and stack initialization

3
What well cover

• What order to do things in
• How context switching works
• How yielding between threads works
• Minithread implementation hints

4
Thread Review

• A process is a task plus at least one thread
• A task consists of a code section, data section,
  and a set of operating system resources
• A thread is basic unit of CPU utilization
  consisting of a program counter, a register set,
  and a stack space
• These definitions can be found in sections 4 and
  5 of your book where they are explained in more
  detail

5
Threads Continued

• Threads can be based either at the user- or
  kernel-level
• Kernel-level threads are scheduled by the Kernel
  (advantage), but require protected operating
  system actions to switch contexts (disadvantage)
• User-level threads are managed by the threads
  parent process. Context switches are very fast
  and do not involve the operating system
  (advantage). The operating system only sees
  processes, not threads, so scheduling can be
  unfair and system calls from one thread will
  block all threads associated with its parent
  process as well. (disadvantage)

6
Minithreads Project 2 Part A

• Windows NT lacks support for user-level threads
• We will create our own user-level thread package,
  called Minithreads, in this course
• In Project 1, you dissected setjmp/longjmp to
  learn how to change a programs program counter,
  register set, and stack position (the components
  of a thread)
• In Project 2 we will use this knowledge to
  implement context switching. We will also create
  multiple stacks and learn how to switch between
  them.

7
Project 2, step-by-step

• Implement stack initialization
• Implement context switching
• Use test code to be sure you have done your work
  correctly
• Note Your responsibilities are limited to the
  minithread.h and minithread.c files. Everything
  else is there so that you can test your code.

8
Threads and their stacks

• NT gives you an initial stack
• Subsequent stacks must be allocated on the
  processs heap using malloc

0
code
2000
heap
stack
50000
9
Stack Space Alignment

• Stack space needs to be aligned on 32-bit word
  boundaries
• malloc allocates space properly aligned at its
  starting address
• The ending allocated address is not necessarily
  aligned properly
• Be sure to set the top of the stack to an aligned
  location at or below the end of the dynamically
  allocated stack space
• Note CS, DS, and SS are all initialized to the
  same value in VC so you do not need to worry
  about them even though malloc works from DS while
  stacks are in SSs domain.

10
Stack Routines

• allocate_stack(stack_pointer_t stackbase,
  stack_pointer_t stacktop) Allocate a new stack
  space of size STACK_SIZE.
• stackbase points to the low end of the stack
  address range.
• stacktop is the highest aligned address in the
  stack address range.
• minithread_free_stack(stack_pointer_t
  stackbase) Free an allocated stack
• minithread_initialize_stack has been implemented
  for you

11
An initialized stack
stack_base (lowest memory address)
Stack initialized to look as if minithread_switch
had been called
final_proc addr
base_arg1
stack_top
base_arg2
final_proc addr
final_arg1
original stack_top (highest memory address)
final_arg2
12
Stack Initialization Limitations

• Our context switching operates similarly to a
  setjmp followed by a longjmp
• When a return occurs, the final_proc address is
  popped off of the stack but there is no
  restoration to the next frame
• To do so, we would need a third procedure (or a
  modified final_proc) to restore stack space
  appropriately
• It is not important to do so in Project2 since
  the final procedure there uses no arguments

13
Threads

• minithread_type Includes a stack base, stack
  top, and process context (to be filled in by you)
• minithread_t allocate_minithread() Allocate a
  new minithread and return it
• minithread_initialize_thread(minithread_t
  thread, proc_t base_proc) Initialize a new
  thread using the current register set for the
  register values. Exceptions eip the base_proc
  address. esp, ebp need to be set according to
  the new threads initialized stack

14
Context switching

• minithread_switch(old_thread, new_thread)
• Swaps execution contexts with a thread from the
  run queue
• registers
• program counter
• stack pointer

15
Context switching
?
old_thread_sp_ptr
new_thread_sp_ptr
ESP
16
Save old context
?
old_thread_sp_ptr
new_thread_sp_ptr
ESP
17
Change stack pointers
old_thread_sp_ptr
new_thread_sp_ptr
ESP
18
Restore new context
old_thread_sp_ptr
new_thread_sp_ptr
ESP
19
Project 2 Part B

• We briefly discussed Purify in the last lecture
• It is a great tool for memory debugging
  effectively adding many of the valuable memory
  safety and management routines that Java provides
• In Part B of Project 2, you will get some
  hands-on experience using Purify

20
Building the Purify.exe File

• Get the purify.zip archive from the course web
  page
• Place the buggy.c and purify.mak files in the
  same directory
• Open buggy.c up and look at what it does
• Type nmake /f purify.mak in that directory to
  build the purify.exe executable

21
Purifying Buggy.C

• The buggy.c file has a number of memory problems
• To find them, open Purify from the Rational
  Development Studio 1.5 section of the Programs
  menu on any of the Windows NT Machines in the
  Undergraduate Lab
• Choose Run from the Purify menu setting the
  working directory and program executable
  appropriately when prompted

22
Purifys Opening Screen
23
Sample Purify Output
24
Part B Continued

• Purify will begin by instrumenting the purify.exe
  executable
• Purify will continue by running purify.exe noting
  any memory errors and warnings that it might find
• In Part B, you are asked to answer questions
  based on the Purify output

25
Summary

• Implement context switching
• Implement stack initialization code
• Create code to allocate and initialize three
  stacks, start threads of execution, and swap
  between them
• Explore the Purify environment to help make life
  easier in future projects in Project 2 Part B
• In Project 3, you will be building on Project 2
  to create a simple (non-preemptive) user-level
  threads package
