Windows Security Internals

1
Advanced.Net Programming
Jan eda Monster Technologies
2
Agenda of workshop
3
Windos PE file format
Native PE file format
MS-DOS Stub
PE
COFF Header
Section Tables
Code and data
4
Executing assembly

• What happens when assembly is started?
• How does an system recognizes .NET environment?
• Is it secure?
• What would you recommend to your client regarding
  Windows environment? (when no flameware is
  involved ? )

5
Starting CLR

• When starting a managed application this triggers
  mscoree.dll
• _CorExeMain or _Cor
• Mscoree.dll loads CLR
• Native support just from Win XP and Win 2003 and
  higher
• Open to attacks
• Configuration

ltconfigurationgt ltstartupgt ltsupportedRuntime
version"v2.0.40607"gtlt/supportedRuntimegt
lt/startupgt lt/configurationgt
6
Assembly in .NET
MS-DOS Stub
MS-DOS Stub
PE Header
PE Header
CLR Header
CLR Header
Metadata
Manifest
Metadata
IL Code
IL Code
7
Executing assembly cont.
Windows environment
CLR
Sample.exe
CLR loads Manifest Metadata
Windows loads PE header
Is it safe for all Windows versions?
Application domain is created and IL code loaded
Gets entry point to start Mscoree.dll
Loads CLR
8
How assembly is compiled?

• If C compiler is used then its open to hacking
  throw stub attack
• C compiler generates own umanaged entry point
  to start mscoree.dll gt this opens space for
  trojan horses
• This is true just for older Windows versions
  before Windows XP (WinXP provide new system
  loader that automaticaly recognizes .NET
  assemblies)
• For Windows XP is Code Access Security active
  since assembly is started (and CLR loaded).

9
Private Assemblies (PA)

• Placed in the root, or sub directory structure of
  the application
• Will not be shared by multiple applications
• Enables XCopy deployment and Delete uninstall

10
Shared Assemblies (SA)

• Designed for use by multiple applications
• Ex Mscorlib.dll
• Each SA is assigned a strong name based on the
  public key and the originator name
• Shared assemblies have version numbers

11
Global Assembly Cache (GAC)

• Central Repository of shared assemblies
• Currently stored in c\winnt\assembly
• gacutil.exe, MSI, or Explorer can be used to
  install assemblies in the GAC
• Use gacutil l to explore the GAC

12
Exploring GAC

• Regsvr32 u shfusion.dll
• Regsvr32 shfusion.dll
• Not recommended for Windows 2003 environment
• There are new versions of this library gt
  connected to iexplore process gt system GUI may
  not be accessible

13
Strong Names Code Signing

• Build Shared Assembly using Public / Private key
  pair
• Contents of each related file are hashed as their
  name is added to the metadata tables.
• PE file contents hashed with Private key, hash
  value is stored in the file.
• Public key value is stored in the file.
• Combination of filename and Public Key become the
  shared name. Guaranteed unique.
• Created within IDE or with Sn.exe

14
Strong Names Benefits

• Guarantee name uniqueness by relying on unique
  key-pairs.
• Prevent others from "taking over your
  namespace."
• Protect the version lineage of an assembly
• Guaranteed that the contents of the assembly have
  not been changed since it was built
• Integrity checking is done on all shared
  assemblies using strong / shared names

15
Versioning

• Version Policies are applied by the Runtime to
  Shared Assemblies only
• Version number bindings are captured at compile
  time
• Version policies are set administratively using
  the assemblys .config files ltBinding Policygt
  section

16
IL Virtual Machine
Memory Generally Available
Memory local to current method
Static Fields
Method Argument Table
Evaluation Stack
Dynamic Memory Pool
Managed Heap
Local Variable Table
17
A Threads Stack
Windows Process
void M1() String name Joe M2(name)
... return
name (String)
return address
void M2(String s) Int32 length s.Length
Int32 tally ... return
CLR (Thread Pool Managed Heap)
18
Lets do some testing

• using System
• class Program
• static int a 1
• static int b 2
•       static int Test()
•
•             a b
•             return 3
•
•       static void Main(string args)
•
•             a0 Test()
•             Console.WriteLine(a0)
•

19
Simple Class Hierarchy
class Employee public Int32
GetYearsEmployed() ... public virtual
String GenProgressReport() ... public
static Employee Lookup(String name) ...
class Manager Employee public override
String GenProgressReport() ...
20
Instance Method Mapping Using this
public Int32 GetYearsEmployed() public
(static) Int32 GetYearsEmployed(Employee
this) public virtual String GenProgressReport()
public (static) String GenProgressReport(Emplo
yee this) public static Employee
Lookup(String name) public static Employee
Lookup(String name)
Employee e new Employee() e.GetYearsEmployed()
e.GenProgressReport()
Employee e new Employee() Employee.GetYearsEmpl
oyed(e) Employee.GenProgressReport(e)

• this is what makes instance data available to
  instance methods

21
IL Instructions ToCall A Method

• Call
• Is usable for static, instance, and virtual
  instance methods
• No null check for the this pointer (for instance
  methods)
• Used to call virtual methods non-polymorphically
• base.OnPaint()
• Callvirt
• Usable for instance and virtual methods only
• Slower perf
• Null check for all instance methods
• Polymorphs for virtual methods
• No polymorphic behavior for non-virtual methods
• C and VB use callvirt to perform a null check
  when calling instance methods

22
class App static void Main() Object
o new Object() o.GetHashCode() //
Virtual o.GetType() // Non-virtual
instance Console.WriteLine(1) // Static

.method private hidebysig static void Main() cil
managed .entrypoint // Code size 27
(0x1b) .maxstack 1 .locals init (object
V_0) IL_0000 newobj instance void
System.Object.ctor() IL_0005 stloc.0
IL_0006 ldloc.0 IL_0007 callvirt instance
int32 System.ObjectGetHashCode() IL_000c
pop IL_000d ldloc.0 IL_000e callvirt
instance class System.Type System.ObjectGetType(
) IL_0013 pop IL_0014 ldc.i4.1 IL_0015
call void System.ConsoleWriteLine(int32)
IL_001a ret // end of method AppMain
23
Memory Code, Types, Objects
Windows Process
Stack
null
Jitted Code
5
0
Jitted Code
void M3() Employee e Int32 year e new
Manager() e Employee.Lookup(Joe) year
e.GetYearsEmployed() e.GenProgressReport()
Jitted Code
Jitted Code
CLR (Thread Pool Managed Heap)
24
Garbage Collection

• Garbage Collection is the process of recovering
  managed memory that is no longer being used
• Garbage Collection is automatically handled by
  the runtime
• Garbage Collection can be forced programmatically
  (but should not be)

25
Traditional Heaps

• Heap Manager keeps list of free and used blocks
• On an Memory Allocation, manager searches lists
  for a space big enough for requested block
• On a Deallocation, manager must check if newly
  freed block should be merged with an adjacent
  free block
• Result gt Work on Allocs Deallocs
• Doesnt scale well on multi-threaded or
  multi-proc systems

26
What techniques were used?

• Reference counting
• Typical for COM environment based on C/C
  pointer style
• Some automatic techniques as
• Smart pointers (ATL)
• Auto-reference counting (VB6)
• Suitable only for client-server pattern
• Open to deadlocks by cycle references

B
X
A
C
27
The Managed Heap

• How many managed heaps are there? Important!!!!
• All reference types are allocated on the managed
  heap
• Your code never frees an object
• The GC frees objects when they are no longer
  reachable
• Each process gets its own managed heap
• Virtual address space region, sparsely allocated
• The new operator always allocates objects at the
  end
• If heap is full, a GC occurs
• Reality GC occurs when generation 0 is full

NextObjPtr
28
How GC controls application?

• Hijacking
• GC overwrites return address from a method with
  address of one of its methods. After method is
  executed gt control is traversed to GC.
• Safe Points
• Points where JIT decides that are safe to suspend
  a thread and start GC. JIT compiler inserts code
  here.
• Interruptible code
• The simplest technique available only in .NET
  1.0. GC suspends all threads and inspects memory
  by method table produced by JIT to find variables
  that are in scope.

29
Roots and GC Preparation

• Every application has a set of Roots
• A Root is a memory location that can refer to an
  object
• Or, the memory location can contain null
• Roots can be any of the following
• Global static fields, local parameters, local
  variables, CPU registers
• When a method is JIT compiled, the JIT compiler
  creates a table indicating the methods roots
• The GC uses this table
• The table looks something like this...

Start Offset End Offset Roots________________ 0x00
000000 0x00000020 this, arg1, arg2, ECX,
EDX 0x00000021 0x00000122 this, arg2, fs,
EBX 0x00000123 0x00000145 fs
30
When a GC Starts...

• All objects in heap are considered garbage
• The GC assumes that no roots refer to objects
• GC examines roots and marks each reachable object
• If a GC starts and the CPUs IP is at 0x00000100,
  the objects pointed to by the this parameter,
  arg2 parameter, fs local variable, and the EBX
  register are roots these objects are marked as
  in use
• As reachable objects are found, GC uses metadata
  to check each objects fields for references to
  other objects
• These objects are marked in use too, and so on
• GC walks up the threads call stack determining
  roots for the calling methods by accessing each
  methods table
• For objects already in use, fields arent
  checked
• Improves performance
• Prevents infinite loops due to circular
  references
• The GC uses other means to obtain the set of
  roots stored in global and static variables

31
Generations in GC
Heap begins with one and new generation
References to objects are kept alive
GC defragments and compacts references
Objects are joined into newer generation
New objects are allocated in new generation
32
Allocation on Managed Heap
O1
Cursor
33
Allocation on Managed Heap
O1
O2
Cursor
34
Allocation on Managed Heap
O1
O2
O4
O5
O6
O3
O7
Cursor
35
Garbage Collection

• At some point the Garbage Collection algorithm
  decides that memory has grown too much
• A Collection is triggered
• All Unreferenced (garbage) objects deleted from
  the heap
• What are Unreferenced Objects
• Determined through the creation of a reference
  tree

36
Garbage Collection

• Attempt to create object at end of heap triggers
  garbage collection
• Builds reference tree starting with roots
• Global and static object pointers, CPU registers
  containing heap pointers, etc.
• Begins building the tree with the first root,
  recursively moving on to all objects that object
  referenced etc.
• Then on to the next root until finished

37
Garbage Collection Triggered
O1
O2
O4
O5
O6
O3
O7
GC ROOTS(References) Globals Statics Locals
CPU Registers
38
Garbage Collection

• When finished deletes garbage
• Moves all code down filling GCd areas in the
  heap
• Cursor reset to beginning of free memory

39
Garbage Collection Triggered
O1
O2
O4
O5
O6
O3
O7
GC ROOTS(References) Globals Statics Locals
CPU Registers
40
Garbage Collected
O1
O2
O4
O5
O6
GC ROOTS(References) Globals Statics Locals
CPU Registers
41
Garbage Collection

• Pointers adjusted appropriately including objects
  containing pointers to other objects
• Operation that triggered the garbage collection
  is retried

42
Compacting the Heap

• After all roots have been checked and all objects
  have been marked in use...
• The GC walks linearly through heap for free gaps
  and shifts reachable objects down (simple memory
  copy)
• As objects are shifted down in memory, roots are
  updated to point to the objects new memory
  address
• After all objects have been shifted...
• The NextObjPtr pointer is positioned after last
  object
• The new operation that caused the GC is retried
• This time, there should be available memory in
  the heap and the object construction should
  succeed
• If not, an OutOfMemoryException is thrown

43
How does GC work here?

• using System
• namespace ConsoleApplication1
• class Program
• static void Main(string args)
• // allocate and forget the objects
  immediately
• // AllocForget()
• // allocate array and overwrite
  random objects with new ones
• AllocOver()
• public static void AllocForget()
• for ( )
• new object()

44
How does GC work here?
45
How does GC work here?
46
Server vs. Workstation

• Mscoree chooses workstation or server mode
• Workstation optimized for front-end, interactive
  apps
• Server optimized for throughput
• Server optimized for multi-CPUs computers

ltconfigurationgt ltruntimegt ltgcServer
enabledtrue" /gt lt/ runtimegt lt/configurationgt
47
Server vs. Workstation

• There are three modes of GC available
• Can be checked programmatically by
  System.Environment.IsServerGC

48
Garbage Collector - CPUs

• When working on multiple CPUs garbage collector
  can have different behavior
• This is for server mode
• CLR allocates separate heaps for each physical
  CPU
• Called arenas
• Allows lock-free allocation
• GC is done in parallel
• Each CPU cleans up its own heap

49
GC isnt perfect!

• How much memory does GC thinks this occupies?
• GC doesnt see the image

Gen0 heap
Bitmap object (40 bytes)
Bitmap buffer (20MB)
50
How to educate GC?

• AddMemoryPressure
• Be VERY careful when using it

• class Bitmap IDisposable
• FileInfo file
• public Bitmap(string path)
• file new FileInfo(path)
• GC.AddMemoryPressure(file.Length)
• ...
• override void Dispose()
• GC.RemoveMemoryPressure(file.Length)

51
Limited resouces and GC

• Some resources have a hard upper limit
• Database connections, GDI handles etc.
• Forcing GC can help free them up
• In .NET2.0 HandleCollector attemtps to help
• Monitors a count of add/remove calls
• Calls GC.Collect when count gt threshold
• Must have rights to run interop

static readonly HandleCollector conns new
HandleCollector(DB, 4, 10) public class
MyConnection IDisposable public
MyConnection() conns.Add() public override
void Dispose() conns.Remove()
52
GC Dos and Donts

• Dont call GC.Collect
• Dont use finalizers unless you are absolutely
  sure what you are doing
• Do call Debug.Assert(false) in finalizers
• Do call GC.SupressFinalize from
  IDisposable.Dispose
• Do use performance counters to measure changes

53
Cleaning Up

• Traditional Languages (C COM based languages
  like VB) provide Deterministic Finalization
• When an object goes out of scope, the objects
  Destructor is executed
• The CLRs Garbage Collected environment does not
  provide this
• The replacement
• Finalization and the Dispose pattern

54
Why Do I Care?

• Who cares about destructors in a Garbage
  Collected environment?
• Not all resources are managed
• Database connections
• Windows Handles
• Etc
• The Finalize method allows you to clean up
  these resources, but
• If you wait for objects to Finalize, you may end
  up in a resource starved situation

55
Finalization

• After an object is marked for collection (but
  before it is collected), it may be finalized
• Finalization happens eventually
• Only objects with Finalize methods get treated
  this way
• Finalization is expensive
• Objects get shuffled around on lists at GC time
• Since the Finalization happens after the object
  is marked, it cant be collected until the next
  GC operation
• Delaying the GC for that object

56
Finalization queue
Application threads
Garbage Collection
Objects placed on freachable
Calling finalizers
Finished garbage Collection
57
Update info on finalization queue!

• Finalization queue is used for Finalize methods
• According to further testing finally blocks are
  not included in finalization queue as was
  presented
• Correct definition is that finalization queue is
  related ONLY to finalizers and it doesnt affect
  finally

58
The Dispose Pattern

• The Frameworks answer to Determistic
  Finalization
• Allows aggressive disposal of objects that use
  unmanaged resources
• Not needed for objects that only have managed
  data members
• Objects that use unmanaged resources should
  implement the IDisposable interface
• IDisposableDispose()
• Well documented
• Example Create a Windows.Forms application

59
Using Disposable Objects

• In VB
• In C

Dim X as New DisposableTypeTry do something
with X Finally X.Dispose()End Try using
(DisposableType x new DisposableType)
//do something with X
60
Equivalence vs. Identity

• Different instances of objects with same values,
  but different memory addresses gt not the same
  objects!
• This is equivalence
• To check objects equivalence System.Object.Equal
  virtual method should be implemented for specific
  reference type
• When references of objects point to the same
  address space gt this is one and the same object
• Can be checked by the method System.Object.Referen
  ceEquals, GC.ReferenceEquals

61
A
x 0
B
y 0
C
D
x 5
x 3
y 0
y 2
62
Object equals

• Equals
• Memory address

63
Cloning

• Implementation of System.ICloneable interface gt
  Clone method
• Shallow copy vs. Deep copy

64
Shallow copy
x 0
y 0
Class Data
A
Just Reference
B
x 0
y 0
65
Shallow copy
66
Deep copy
x 0
y 0
Class Data
A
Class Data
B
x 0
y 0
67
Memory referencesConsider design

• Strong references

68
Memory referencesConsider design

• Weak references

69
Multithreading

• What is a multithreading and how does it work in
  Windows and CLR?
• How many threads are in this app?

using System namespace ConsoleApplication1
class Program static void
Main(string args)
Console.Read()
70
Native threads in .NET

• Lets enumerate native threads in .NET application

71
Threads in CLR

• Managed threads are different from native ones
• There are two types of managed threads
• Thread-pool threads (System.Threading.ThreadPool)
• Background threads
• Limited number of threads in pool (OS dependant)
• Can be changed by hacking into CLR
• Non-thread pool threads
• All new Thread() instances

72
Max. of threads in pool
73
How to use thread pool?

• Thread pool has background threads gt process is
  not alive when there are just background threads
• Why does a thread pool exists?
• Number of thread in pool is changing depending on
  number of CPU and OS
• ThreadPool is suitable for background
  asynchronous operations

74
ThreadPool
75
Synchronization in CLR

• CLR provides several thread synchronization
  techniques
• Monitor
• Most common
• Integrated
• Other techniques
• Mutex class for deadlock-free multiple lock
  acquisition
• Events
• Multi-reader/single-writer support
• WaitHandles
• ReadWriteLocks very strong feature
• Semaphores

76
Monitor

• Used to work with protected code sections
• Thread sychronization primitives control access
  of threads to objects
• Lock statements are finally compiled

lock (x) // some code goes here
object temp x Monitor.Enter(temp) // some
code goes here // using temp finally
Monitor.Exit(temp)
lock (typeof(x)) // some code goes here
77
Deadlocks

• Deadlocks gt2 threads are waiting cyclically for
  each other
• Mutexes can be used to protect from deadlocks

First thread lock(x) // do something with
x lock(y) // work with x and y Second
thread lock(y) lock(x) // work with x and
y
WaitHandle mutexes new WaitHandle2 mutexes
0 mutexY mutexes1 mutexX WaitHandle.WaitA
ll(mutexes) // do something with x and
y mutexX.ReleaseMutex() mutexY.ReleaseMutex()
78
Races

• Races conditions occur when result of some code
  depends on unpredictable timing factors

lock(x) // do something with x lock(y)
lock(x) // work with x and y
