CSE8380 Parallel and Distributed Processing Presentation

1
CSE8380 Parallel and Distributed Processing
Presentation

• Hong Yue
• Department of Computer Science Engineering
• Southern Methodist University

2
Parallel Processing Multianalysis--- Compare
Parallel Processing with Sequential Processing
3
Why did I select this topic?
4
Outline

• Definition
• Characteristics of Parallel Processing and
  Sequential Processing
• Implementation of Parallel Processing and
  Sequential Processing
• Performance of Parallel Processing and Sequential
  Processing
• Parallel Processing Evaluation
• Major Application of parallel processing

5
Definition

• Parallel Processing Definition
• Parallel Processing refers to the
  simultaneous use of multiple processors to
  execute the same task in order to obtain faster
  results. These processors either communicate each
  other to solve a problem or work completely
  independent, under the control of another
  processor which divides the problem into a number
  of parts to other processors and collects results
  from them.

6
Definition .2

• Sequential Processing Definition
• Sequential processing refers to a computer
  architecture in which a single processor carries
  out a single task by series of operations in
  sequence. It is also called serial processing.

7
Characteristics of Parallel Processing and
Sequential Processing

• Characteristics of Parallel Processing
• ? Each processor can perform tasks
• concurrently.
• ? Tasks may need to be synchronized.
• ? Processors usually share resources, such as
  data, disks, and other devices.

8
Characteristics of Parallel Processing and
Sequential Processing .2

• Characteristics of Sequential Processing
• ? Only one single processor performs task.
• ? The single processor performs a single
• task.
• ? Task is executed in sequence.

9
Implementation of parallel processing and
sequential processing

• Executing single task
• In sequential processing, the task is
  executed as a single large task.
• In parallel processing, the task is divided
  into multiple smaller tasks, and each component
  task is executed on a separate processor.

10
Implementation of parallel processing and
sequential processing.2
11
Implementation of parallel processing and
sequential processing .3

12
Implementation of parallel processing and
sequential processing.4

• Executing multiple independent task
• ? In sequential processing, independent tasks
  compete for a single resource. Only task 1 runs
  without having to wait. Task 2 must wait until
  task 1 has completed task 3 must wait until
  tasks 1 and 2 have completed, and so on.

13
Implementation of parallel processing and
sequential processing .5

• Executing multiple independent task
• ? By contrast, in parallel processing, for
  example, a parallel server on a symmetric
  multiprocessor, more CPU power is assigned to the
  tasks. Each independent task executes immediately
  on its own processor no wait time is involved.

14
Implementation of parallel processing and
sequential processing .6

15
Implementation of parallel processing and
sequential processing .7

16
Performance of parallel processing and sequential
processing

• Sequential Processing Performance
• ? Take long time to execute task.
• ? Cant handle too large task.
• ? Cant handle large loads well.
• ? Return is diminishing.
• ? More increasingly expensive to make a
  single processor faster.

17
Performance of parallel processing and sequential
processing .2

• Solution
• using parallel processing - use lots of
  relatively fast, cheap processors in parallel.

18
Performance of parallel processing and sequential
processing .3

• Parallel Processing Performance
• ? Cheaper, in terms of price and performance.
• ? Faster than equivalently expensive
  uniprocessor machines.
• ? Scalable. The performance of a particular
  program may be improved by execution on a large
  machine.

19
Performance of parallel processing and sequential
processing .4

• Parallel Processing Performance
• ? Reliable. In theory if processors fail we
  can simply use others.
• ? Can handle bigger problems.
• ? Communicate with each other readily,
  important in calculations.

20
Parallel Processing Evaluation

• Several ways to evaluate the parallel processing
  performance
• ? Scale-up
• ? Speedup
• ? Efficiency
• ? Overall solution time
• ? Price/performance

21
Parallel Processing Evaluation .2

• Scale-up
• Scale-up is enhanced throughput, refers to
  the ability of a system n times larger to perform
  an n times larger job, in the same time period as
  the original system. With added hardware, a
  formula for scale-up holds the time constant, and
  measures the increased size of the job which can
  be done.

22
Parallel Processing Evaluation .3

•


23
Parallel Processing Evaluation .4

• Scale-up measurement formula

24
Parallel Processing Evaluation .5

• For example, if the uniprocessor system can
  process 100 transactions in a given amount of
  time, and the parallel system can process 200
  transactions in this amount of time, then the
  value of scale-up would be equal to 200/100 2.
• Value 2 indicates the ideal of linear scale-up
  when twice as much, hardware can process twice
  the data volume in the same amount of time.

25
Parallel Processing Evaluation .6

• Speedup
• Speedup, the improved response time, defined
  as the time it takes a program to execute in
  sequential (with one processor) divided by the
  time it takes to execute in parallel (with many
  processors). It can be achieved by two ways
  breaking up a large task into many small
  fragments and reducing wait time.

26
Parallel Processing Evaluation .7

27
Parallel Processing Evaluation .8

• Speedup measurement formula

28
Parallel Processing Evaluation .9

• For example, if the uniprocessor took 40 seconds
  to perform a task, and two parallel systems took
  20 seconds, then the value of speedup 40 / 20
  2.
• Value 2 indicates the ideal of linear speedup
  when twice as much, hardware can perform the same
  task in half the time.

29
Parallel Processing Evaluation .10
Table 1 Scale-up and Speedup for Different Types
of Workload
30
Parallel Processing Evaluation .11
Figure 7 Linear and actual speedup
31
Parallel Processing Evaluation .12

• Amdahls Law
• Amdahl's Law is a law governing the speedup
  of using parallel processors on a problem, versus
  using only one sequential processor. Amdahls law
  attempts to give a maximum bound for speedup from
  the nature of the algorithm

32
Parallel Processing Evaluation .13

• Amdahls Law

33
Parallel Processing Evaluation .14

Figure 8 Example speedup Amdahl Gustafson
34
Parallel Processing Evaluation .15

• Gustafsons Law
• If the size of a problem is scaled up as the
  number of processors increases, speedup very
  close to the ideal speedup is possible.
• That is, a problem size is virtually never
  independent of the number of processors.

35
Parallel Processing Evaluation .16

• Gustafsons Law

36
Parallel Processing Evaluation .17

• Efficiency
• The relative efficiency can be a useful
  measure as to what percentage of a processors
  time is being spent in useful computation.

37
Parallel Processing Evaluation .18

Figure 9 Optimum efficiency actual efficiency
38
Parallel Processing Evaluation .19

Figure 10 Optimum number of processors in actual
speedup
39
Parallel Processing Evaluation .20

• Problems in Parallel Processing
• Parallel processing is like a dogs walking on
  its hind legs. It is not done well, but you are
  surprised to find it done at all.
• ----Steve Fiddes (University of Bristol)

40
Parallel Processing Evaluation .21

• Problems in Parallel Processing
• ? Its software is heavily platform-dependent
  and has to be written for a specific machine.
• ? It also requires a different, more
  difficult method of programming, since the
  software needs to appropriately, through
  algorithms, divide the work across each
  processor.

41
Parallel Processing Evaluation .22

• Problems in Parallel Processing
• ? There isn't a wide array of shrink-wrapped
  software ready for use with parallel machines.
• ? Parallelization is problem-dependent and
  cannot be automated.
• ? Speedup is not guaranteed.

42
Parallel Processing Evaluation .23

• Solution 1
• ? Decide which architecture is most appropriate
  for a given application.
• The characteristics of application should
  drive decision as to how it should be
  parallelized the form of the parallelization
  should then determine what kind of underlying
  system, both hardware and software, is best
  suited to running your parallelized application.

43
Parallel Processing Evaluation .24

• Solution 2
• ? Clustering

44
Major Applications of parallel processing

• Clustering
• ? Clustering is a form of parallel processing
  that takes a group of workstations connected
  together in a local-area network and applies
  middleware to make them act like a parallel
  machine.

45
Major Applications of parallel processing .2

• Clustering
• Clustering is a form of parallel processing
  that takes a group of workstations connected
  together in a local-area network and applies
  middleware to make them act like a parallel
  machine.

46
Major Applications of parallel processing .3

• Clustering
• ? Parallel processing using Linux Clusters
  can yield supercomputer performance for some
  programs that perform complex computations or
  operate on large data sets. And it can accomplish
  this task by using cheap hardware.
• ? Clustering can be used at night when
  networks are idle, it is an inexpensive
  alternative to parallel-processing machines.

47
Major Applications of parallel processing .4

• Clustering can work with two separate but similar
  implementations
• ? A Parallel Virtual Machine (PVM), is an
  environment that allows messages to pass between
  computers as it would in an actual parallel
  machine.
• ? A Message-Passing Interface (MPI), allows
  programmers to create message-passing parallel
  applications, using parallel input/output
  functions and dynamic process management.

48
Reference

• Andrew Boucher, Parallel Machines
• Stephane vialle, Past and Future Parallelism
  Challenges to Encompass sequential Processor
  evolution
