Stochastic Language Generation for Spoken Dialog Systems

1
Stochastic Language Generation for Spoken Dialog
Systems

• Alice Oh
• aliceo_at_cs.cmu.edu
• 24 October 2009

2
Communicator Project

• A spoken dialog system in which users engage in a
  telephone conversation with the system using
  natural language to solve a complex travel
  reservation task
• Components
• Sphinx-II speech recognizer
• Phoenix semantic parser
• Domain agents
• Agenda-based dialog manager
• Stochastic natural language generator
• Festival domain-dependent Text-to-Speech
• Want to know more? Call toll-free at
  1-877-CMU-PLAN

3
Natural Language Generation

• Natural Language Understanding (NLU)
• Words ? Semantic (syntactic) representation
• Natural Language Generation (NLG)
• Semantic (syntactic) Represetation ? Words
• There has been active research in machine
  translation and automatic summarization (e.g.,
  stock quotes, weather, medical information)
  communities.
• NLG is often divided into 3 steps
• Text planning
• Content planning
• Sentence realization

4
Current Approaches

• Traditional (rule-based) NLG
• hand-crafted generation grammar rules and other
  knowledge
• input a very richly specified set of semantic
  and syntactic features
• Example
• (h / possibleltlatent
• domain (h2 / obligatoryltnecessary
• domain (e / eat,take in
• agent you
• patient (c / poulet))))
• You may have to eat chicken
• Template-based NLG
• simple to build
• input a dialog act, and/or a set of slot-value
  pairs
• from a Nitrogen demo website,
  http//www.isi.edu/natural-language/projects/nitro
  gen/

5
Problem Statement

• To build a generation engine for a dialog system
  that can combine the advantages, as well as
  overcome the difficulties, of the two current
  approaches (template-based generation, and
  traditional, linguistic NLG)

6
Our Approach

• We designed a corpus-driven stochastic generation
  engine that takes advantage of the
  characteristics of task-oriented conversational
  systems. Some of those characteristics are that
• Spoken language is often grammatically imperfect
• Spoken utterances are much shorter in length
• Task-oriented dialogs are very focused and to the
  point (no flowery speech)
• There are well-defined subtopics within the task,
  so the language can be selectively modeled

7
Stochastic NLG overview

• Language Model an n-gram language model built
  from a corpus of travel reservation dialogs
• Generation given an utterance class, randomly
  generates a set of candidate utterances based on
  the LM distributions
• Scoring based on a set of rules, scores the
  candidates and picks the best one
• Slot filling substitute slots in the utterance
  with the appropriate values in the input frame

8
Stochastic NLG can also be thought of as a way to
automatically build templates from a corpus

• If you set n equal to a large enough number, most
  utterances generated by LM-NLG will be exact
  duplicates of the utterances in the corpus.

9
Stochastic NLG Language Model

• Human-Human dialogs in travel reservations
• (Leah, ATIS/American Express dialogs)

10
Tags

• Utterance classes (29)
• query_arrive_city inform_airport
• query_arrive_time inform_confirm_utterance
• query_arrive_time inform_epilogue
• query_confirm inform_flight
• query_depart_date inform_flight_another
• query_depart_time inform_flight_earlier
• query_pay_by_card inform_flight_earliest
• query_preferred_airport inform_flight_later
• query_return_date inform_flight_latest
• query_return_time inform_not_avail
• hotel_car_info inform_num_flights
• hotel_hotel_chain inform_price
• hotel_hotel_info other
• hotel_need_car
• hotel_need_hotel
• hotel_where

• Attributes (24)
• airline flight_num
• am hotel
• arrive_airport hotel_city
• arrive_city hotel_price
• arrive_date name
• arrive_time num_flights
• car_company pm
• car_price price
• connect_airline
• connect_airport
• connect_city
• depart_airport
• depart_city
• depart_date
• depart_time
• depart_tod

11
Tagging

• CMU corpus tagged manually
• SRI corpus tagged semi-automatically using
  trigram language models built from CMU corpus

12
Stochastic NLG Generation

• Given an utterance class, randomly generates a
  set of candidate utterances based on the LM
  distributions
• Generation stops when an utterance has penalty
  score of 0 or the maximum number of iterations
  (50) has been reached
• Average time 75 msec for Communicator dialogs

13
Stochastic NLG Scoring

• Assign various penalty scores for
• unusual length of utterance (thresholds for
  too-long and too-short)
• slot in the generated utterance with an invalid
  (or no) value in the input frame
• a new and required attribute in the input
  frame thats missing from the generated utterance
• repeated slots in the generated utterance
• Pick the utterance with the lowest penalty (or
  stop generating at an utterance with 0 penalty)

14
Stochastic NLG Slot Filling

• Substitute slots in the utterance with the
  appropriate values in the input frame
• Example
• What time do you need to arrive in arrive_city?
• What time do you need to arrive in New York?

15
Examples

• Corpus
• What time do you want to depart depart_city?
• What time on depart_date would you like to
  depart?
• What time would you like to leave?
• What time do you want to depart on depart_date?
• Output (different from corpus)
• What time would you like to depart?
• What time on depart_date would you like to
  depart depart_city?
• What time on depart_date would you like to
  depart on depart_date?

16
Rejected Examples

• Not enough info
• There is a flight at depart_time ampm.
• Contains attributes not specified in the frame
• I have an airline flight at depart_time
  ampm from depart_city arriving at
  arrive_time ampm with a stop-over in
  connect_city at connect_airport.
• Scoring to get the best utterance is important!

17
Evaluation

• User satisfaction questionnaire
• Comparative evaluation
• two systems with different NLG
• human reading the output, teasing out TTS
• compare task completion, as well as user
  satisfaction
• Batch-mode generation, output evaluated by a
  human grader

18
Preliminary Evaluation

• Batch-mode generation using two systems,
  comparative evaluation of output by human
  subjects
• User Preferences (49 utterances total)
• Weak preference for Stochastic NLG (p 0.18)

subject
stochastic
templates
difference
1
41
8
33
2
34
15
19
3
17
32
-15
4
32
17
15
5
30
17
13
6
27
19
8
7
8
41
-33
average
27
21.29
5.71
19
Evaluation

• Must be able to evaluate generation independent
  of the rest of the dialog system
• Comparative evaluation using dialog transcripts
• need 15-20 subjects
• 8-10 dialogs system output generated batch-mode
  by two different engines
• Evaluation of human travel agent utterances
• Do users rate them well?
• Is it good enough to model human utterances?

20
Stochastic NLG Advantages

• corpus-driven
• easy to build (minimal knowledge engineering)
• fast prototyping
• minimal input (speech act, slot values)
• natural output
• leverages data-collecting/tagging effort

21
Stochastic NLG Shortcomings

• What might sound natural (imperfect grammar,
  intentional omission of words, etc.) for a human
  speaker may sound awkward (or wrong) for the
  system.
• It is difficult to define utterance boundaries
  and utterance classes. Some utterances in the
  corpus may be a conjunction of more than one
  utterance class.
• Factors other than the utterance class may affect
  the words (e.g., discourse history).
• Some sophistication built into traditional NLG
  engines is not available (e.g., aggregation,
  anaphorization).

22
Future Work

• How big of a corpus do we need?
• How much of it needs manual tagging?
• How does the n in n-gram affect the output?
• What happens to output when two different human
  speakers are modeled in one model?
• Can we replace scoring with a search algorithm?
