Influenza Surveillance Systems in an International Setting

1
Influenza Surveillance Systems in an
International Setting

• Case Study 1

2
Learning Objectives

• Define the surveillance objectives, methods of
  hospital selection, and key data collection
  priorities for sentinel surveillance for seasonal
  influenza and severe respiratory diseases
• List appropriate surveillance strategies and
  trigger criteria needed for the early detection
  of Influenza A(H5N1) in hospitals and communities
• List appropriate surveillance strategies and
  trigger criteria needed for a broader pandemic
  early warning system
• Describe how a sentinel site surveillance system
  for influenza provides an important support
  function for a pandemic early warning system
• Identify five ways to enhance human, avian, and
  pandemic influenza surveillance activities in
  areas where there are known Influenza A(H5N1)
  outbreaks in poultry

3
Outline

• Introduction to the scenario
• Routine Surveillance for Respiratory Disease and
  Seasonal Influenza
• Influenza A(H5N1) and Pandemic Early Warning
  Surveillance

4
Introduction
5
Introduction to the Republic of Pegu

• Developing country
• Southeast Asia
• 21 provinces
• Population 50 million

6
Geography
Monsoon climate
Bordered by 5 countries

• Population
• 75 rural
• No highway access

Migrants
7
Health Care

• Kinds of facilities
• Teaching hospitals
• Specialist hospitals
• Provincial hospitals
• District hospitals
• Local health stations
• Traditional clinics
• 12 traditional medicine hospitals

• Each province
• 16-50 bed hospital
• Each district
• Medical officer, public health, and medicine

8
Influenza Laboratory Testing
National Laboratory PCR Diagnosis
Closest WHO Reference Laboratory is in a
neighboring country
Regional Laboratories Serological Diagnosis
No laboratory testing
Provincial Hospital
Traditional Hospital
9
Surveillance Infrastructure

• National notifiable disease surveillance system
• Immediate reporting
• Diphtheria
• Cholera
• Yellow fever
• Routine reporting (3 days)
• Standard reporting form

10
Part I Routine Surveillance for Respiratory
Disease and Seasonal Influenza
11
Question 1

• The main goals of routine (seasonal) influenza
  surveillance include all of the following EXCEPT
• Describe virus circulation and provide virus
  isolates for vaccine development
• Provide rapid response to seasonal outbreaks
• Define the epidemiology and patterns of viral
  circulation
• Provide a support mechanism for pandemic early
  warning and monitoring systems
• Answer b.

12
Question 2

• What surveillance approach might be used to
  achieve these goals?
• Universal surveillance
• Sentinel site surveillance
• Influenza registry
• Laboratory-based reporting
• Answer b.
• Sentinel site surveillance for
• Hospitalizations due to respiratory disease
• Outpatient visits for influenza-like illness

13
Arrival in Pegu

• You are to
• Evaluate the influenza and respiratory disease
  surveillance infrastructure
• Work with the MOH to develop a protocol to
  implement a sustainable national influenza
  surveillance system

14
The Pegu Deputy Director

• Situation Due to mass poultry die-offs
• Team Chief Surveillance Officer and the Director
  of Epidemiology, and you
• Develop guidelines for expanding their national
  pneumonia and influenza surveillance system
• Use money from World Bank to develop pandemic
  early warning network

15
Current Case Identification

• Clinician initiated pnuemonia and influenza
  surveillance among hospitalized patients
• Doctors select hospitalized patients
• No case definitions
• Nasopharyngeal and serum specimens submitted to
  regional laboratories
• Regional laboratories test sera
• National laboratories test high-priority
  specimens and confirm positive influenza A
  results from regional laboratories

16
Current Laboratory Testing

• Regional laboratories test clinical specimens
• Acute and convalescent samples for serum
  specimens
• 90 of specimens tested within 9 days
• National laboratory conducts PCR for severe cases
• Confirmatory tests within 24-48 hours
• Detailed characterization performed at WHO
  reference laboratory
• Number of influenza A specimens shared with WHO
  unknown

17
Current Surveillance Reports

• Routine reports monthly
• Based on total counts of patients discharged with
  pneumonia, ARI, or clinician-defined influenza
• Data presented by
• Age
• Gender
• 1 diagnosed with laboratory confirmed influenza
• 3-4 of specimens tested at National Laboratory
  are influenza positive, annually

18
Current Data Collection on Pneumonia Cases

• Standard patient-level data form for any patient
  tested for influenza
• Consistent and accurate data entry
• Case demographics
• Date of admission
• Date of data entry
• Limited completeness / updating of fields
• Specimen collection
• Date of illness onset
• Fever
• Final laboratory results

19
Your Data Collection

• All 21 provincial hospitals submit P I data
• 4 of 6 you visited report data monthly
• Criteria for pneumonia discharge are unclear
• National laboratory confirms influenza A, B, and
  subtypes
• Involvement with WHO FluNet unclear
• Data do not suggest seasonality
• Two hospitals account for 70 of pneumonia cases
• Feedback to physicians occurs rarely, if ever

20
Question 3

• Does this system achieve the objectives for
  seasonal/human influenza surveillance that were
  discussed earlier? Why or why not?
• Before we answer

21
Remember.

• Does this system achieve the objectives for
  seasonal/human influenza surveillance that were
  discussed earlier? Why or why not?
• Objectives of virologic surveillance
• Describe the epidemiology and burden of disease
  of influenza, and
• Provide virologic isolates for vaccine development

22
Question 3

• Does this system achieve the objectives for
  seasonal/human influenza surveillance that were
  discussed earlier? Why or why not?
• Consider
• Timeliness

• Answer
• Not many metrics have been defined
• Lag of up to 9 days for testing refrigerated
  specimens is long
• May affect influenza confirmation rate

23
Question 3

• What might be appropriate indicators for
  timeliness?
• Data reporting, time from
• From sentinel site to the next administrative
  level
• From administrative level to the national level
• Time interval between date of onset of fever and
  specimen collection
• Specimen testing, time from
• Collection to laboratory
• Receipt of specimen to test result
• Laboratory result to informing referring
  institution and physician

24
Question 3

• Does this system achieve the objectives for
  seasonal/human influenza surveillance that were
  discussed earlier? Why or why not?
• Consider
• Timeliness
• Acceptability

• Answer
• Lack of feedback to physicians limits
  acceptability to physicians

25
Question 3

• Does this system achieve the objectives for
  seasonal/human influenza surveillance that were
  discussed earlier? Why or why not?
• Consider
• Timeliness
• Acceptability
• Representativeness

• Answer
• Large of cases from only 2 hospitals
• Many hospitals not reporting regularly
• Need more information to determine
  representativeness of population

26
Question 3

• Does this system achieve the objectives for
  seasonal/human influenza surveillance that were
  discussed earlier? Why or why not?
• Consider
• Timeliness
• Acceptability
• Representativeness
• Completeness

• Answer
• Some sites over-represented compared to others
• Laboratory data variable
• Need to re-train clinicians and data-entry staff

27
Question 3

• Does this system achieve the objectives for
  seasonal/human influenza surveillance that were
  discussed earlier? Why or why not?
• Consider
• Timeliness
• Acceptability
• Representativeness
• Data Validity / Data Quality

• Answer
• No case definition limits ability to
• Determine baseline
• Interpret trends
• Estimate rates of illness
• Assess risk factors
• Incomplete reporting by most facilities
• Long refrigeration affects specimen quality

28
Question 3

• Does this system achieve the objectives for
  seasonal/human influenza surveillance that were
  discussed earlier? Why or why not?
• Consider
• Timeliness
• Acceptability
• Representativeness
• Data Validity /
• Data Quality
• Flexibility

• Answer
• With appropriate laboratory facilities, the
  system may be flexible enough to identify
  respiratory pathogens in circulation
• With case definitions, the system could be
  expanded to capture a wider range of diseases

29
Your Recommendations

• Develop a standard case definition for severe
  acute respiratory illness
• Formally identify sentinel sites
• Training for sentinel site clinicians
• Routinely send influenza isolates to WHO
  collaborating centers, and enter into WHO/Flu-Net
• Implement a plan for regular feedback of
  surveillance information to clinicians
• Immediate notification and response for high
  priority cases and clusters

30
Your Recommendations

• Performance indicators for objective monitoring
  and evaluation
• Increase laboratory PCR testing
• Additional laboratory quality control

31
Your Next Task

• Work with MOH of Pegu
• Write a formal set of national guidelines
• Outline the approach to establish sentinel
  surveillance
• Standard case definition of SARI among
  hospitalized inpatients
• Standard case definition if ILI among outpatients

32
Question 4

• What criteria will you use to decide where
  sentinel hospitals should be located?
• Answer
• Representative of a defined population
• Reasonable logistics within the hospital for
• Case identification
• Specimen collection
• Specimen transportation
• Politically acceptable
• Practically Feasible
• Added benefit Location in high risk location

Number of facilities selected will be based on
local resources Each facility should have a
focal point to oversee collection and reporting
of data and specimens
33
CDC/WHO SARI Case Definitionfor persons gt 5
years old

• Lower respiratory tract illness consisting of ALL
  of the following
• Sudden onset of fever over 38C, AND
• Cough or sore throat, AND
• Shortness of breath or difficulty breathing, AND
• Requiring hospital admission

34
CDC/WHO Case Definitionfor persons lt 5 years old

• Any child 2 months to 5 years of age with cough
  or difficult breathing and
• breathing faster than 50 breaths / minute (2 12
  months)
• breathing faster than 40 breaths / minute ( 1 5
  years)
• or,
•  Any child 2 months to 5 years of age with cough
  or difficulty breathing and any of the following
  general danger signs
• Unable to drink or breastfeed
• Vomits everything
• Convulsions
• Lethargic or unconscious
• Chest indrawing or stridor in a calm child
• AND Requiring hospitalization

35
Question 5

• Which of the following are reasons why good SARI
  case definitions are a key data collection
  priority in Pegu?
• The use of a SARI case definition provides some
  standardization of reporting across hospitals and
  regions.
• Testing defined SARI cases will yield circulating
  pathogens and strains
• Surveillance using a good SARI case definition
  will yield a better understanding of epidemiology
  and burden of respiratory disease
• It could detect emergence of a new pathogen
• All of the above
• Answer e.

36
Question 6

• True or False
• One drawback of Pegus case definition is that it
  is not sensitive enough
• Answer
• False. Pegus case definition is sensitive. This
  is actually a drawback because the countrys
  single national laboratory could become
  overwhelmed with cases

37
Question 7

• What kinds of data should be collected from the
  SARI cases from which specimens are being
  collected and why?
• Consider
• General information

• Answer
• Unique identification number
• Medical record number
• Name (and parents name, if a minor)
• Date of Birth
• Sex
• Address
• Date of onset of symptoms
• Date of collection of epidemiologic data
• Part of an outbreak investigation
• Inpatient or outpatient

38
Question 7

• What kinds of data should be collected from the
  SARI cases from which specimens are being
  collected?
• Consider
• General information
• Specimen

• Answer
• Throat swab date of collection
• Nasal swab date of collection
• Other specimen (if collected) date of collection

39
Question 7

• What kinds of data should be collected from the
  SARI cases from which specimens are being
  collected?
• Consider
• General information
• Specimen
• Clinical signs, symptoms

• Answer
• Fever gt38
• Cough
• Sore throat
• SOB/Difficulty breathing
• IMCI danger signs (per WHO protocols)
• Diarrhea

40
Question 7

• What kinds of data should be collected from the
  SARI cases from which specimens are being
  collected?
• Consider
• General information
• Specimen
• Clinical signs, symptoms
• Risk factor information

• Answer
• Occupation
• Contact with
• Suspected H5N1 cases
• Sick or dead poultry or wild birds
• Severe respiratory illness cases
• Travel
• Eating raw or undercooked poultry products

41
Question 7

• What kinds of data should be collected from the
  SARI cases from which specimens are being
  collected?
• Consider
• General information
• Specimen
• Clinical signs, symptoms
• Risk factor information
• Pre-existing medical

• Answer
• Liver disease
• Kidney disease
• Immune compromised state
• Neuromuscular dysfunction
• Diabetes
• Heart disease
• Lung disease
• Smoking history

42
Question 7

• What kinds of data should be collected from the
  SARI cases from which specimens are being
  collected?
• Consider
• General information
• Specimen
• Clinical signs, symptoms
• Risk factor information
• Pre-existing medical
• Treatment history

• Answer
• Vaccination against influenza within the past
  year
• Currently taking anti viral medicine

43
Question 7 Key Points

• Laboratory-Epidemiology link is critical
• There must be a system in place where the same
  unique identifier is place on both sets of data

44
Chief Surveillance Officer Response

• Concerned about having too many hospitals report
  too many SARI cases, overwhelming the laboratory
• Random sampling at hospitals may be complicated
  for staff
• Instead suggests sampling all SARI cases from a
  few hospitals

45
Surveillance for Less Severe Influenza

• Chief Surveillance Officer would like to include
  less severe, more common, influenza cases in the
  system
• Can be provided by outpatient surveillance
• WHO criteria for influenza-like illness
• Sudden onset of fever over 38C
• Cough or sore throat
• Absence of other diagnoses

46
Question 8

• How could the sentinel site system be expanded to
  include some less severe influenza cases?
• Answer
• Implement ILI surveillance in outpatient clinics
  of SARI sentinel-site hospitals
• Weekly counts of ILI outpatient visits testing
  positive for influenza
• Choose small sample of cases for specimen and
  epidemiologic data collection

47
SARI and ILI Surveillance

• Outpatient ILI surveillance at 5 SARI sentinel
  site hospitals
• Systematically select first 2 cases each day for
  laboratory and epidemiologic investigation
• Sentinel hospitals will provide weekly tally of
  total ILI cases at facilities

48
Part II Influenza A(H5N1) and Pandemic Early
Warning Surveillance
49
Media Reports

• Mass deaths of flocks of chickens, geese,
  waterfowl
• Southeastern Pegu
• Ministry of Agriculture investigation
• 3 chicken samples weakly positive for Influenza
  A (H5N1)
• No systematic avian surveillance exists

50
Question 9

• Are you confident that a hospitalized human case
  of Influenza A(H5N1) would be recognized and
  responded to? Why or why not?
• Answer No.
• There is no system of 24-hr SARI notification and
  prioritization for influenza A (H5N1) testing
• Rapid detection is needed Treatment is most
  effective if given within 48 hours, but
  infectiousness may occur 24 hrs prior to onset
  need to quickly identify cases and contacts

51
Question 10

• How might surveillance for seasonal influenza
  support efforts to recognize an emerging pandemic
  or detect human cases of Influenza A (H5N1)?
• By counting cases
• By creating a logistical network
• By establishing case definitions and reporting
  criteria
• By tapping into Pegus health budget
• By enhancing laboratory capacity
• None of the above
• Answer b, d.

52
Question 10 Additional Answers

• During a pandemic, data from the routine sentinel
  site surveillance system will help describe the
• Changing geographic location of the virus
• Trend in cases
• Severity of the pandemic

53
Question 10 Key Points

• As routine SARI surveillance is instituted, data
  will be more complete and standardized
• Sentinel-based surveillance is feasible for most
  countries to track a pandemic

54
Your Recommendations

• Clinicians at sentinel hospitals and non
  sentinel-site hospitals need to be trained in
  influenza A (H5N1) screening criteria
• Criteria can elevate index of suspicion about
  SARI cases
• Surveillance officer agrees that trigger criteria
  could help prioritize SARI cases for immediate
  laboratory testing

55
Question 11

• True or False The proposed epidemiologic
  trigger criteria below could be used to
  prioritize SARI cases for immediate reporting and
  laboratory testing for Influenza A (H5N1)
• Travel within last 3 weeks to an area with known
  H5N1 circulation
• Hospitalized for SARI
• Meets the WHO suspect, probable, or confirmed
  H5N1case definition
• Close contact with WHO suspect, probable, or
  confirmed case
• Occupational exposure
• SARI in a previously healthy individual
• Consumption of raw /undercooked poultry or wild
  bird products
• Handling samples (animal or human) suspected of
  containing H5N1 virus in a laboratory or other
  setting

Answers   1. False 2. False 3. True 4. True 5.
True 6. False 7. True 8. True
56
Chief Surveillance Officer Response

• What if the next pandemic isnt caused by
  Influenza A (H5N1), but some other respiratory
  pathogen that isnt associated with poultry or
  wild bird exposure?
• We should learn our lesson from SARS and design
  a system that can also detect a respiratory
  pathogen that is spreading between humans and
  causing severe disease.

57
Question 12

• Consider the following series of questions about
  epidemiologic trigger criteria that might raise
  the index of suspicion about whether a
  respiratory pathogen of pandemic potential could
  be circulating in the population.
• Clusters of 2 or more SARI cases occurring within
  7-10 days of each other are suspicious under all
  circumstances EXCEPT
• If they are in a family
• If they all have a social connection
• If they all ate cooked chicken
• If they all have an occupational connection
• Answer C

58
Question 13

• Consider the following series of questions about
  potential epidemiologic trigger criteria
• SARI in health care workers who care for patients
  with ______.
• Pneumonia
• Chronic respiratory disease
• Poultry exposure
• Previous hospitalization
• Answer a. Pneumonia

59
Question 14

• Consider the following series of questions about
  potential epidemiologic trigger criteria
• Changes in the _________of SARI cases such as a
  shift in the age group affected or changes in
  mortality rates
• severity
• recommended treatment
• epidemiology
• clinical presentation
• Answer e. epidemiology

60
Question 15

• Consider the following series of questions about
  potential epidemiologic trigger criteria
• Any unexplained death due to SARI in persons
  _____________.
• aged 5-40
• aged lt 5
• without underlying medical conditions
• in countries with known circulation of possible
  pandemic respiratory viruses
• Answer a.

61
Question 16

• Consider the following series of questions about
  potential epidemiologic trigger criteria
• An increase in the numbers of cases occurring in
  a facility compared to the same season in a
  previous year is considered a potential trigger
  for raising the index of suspicion about whether
  a respiratory pathogen of pandemic potential
  could be circulating in the population.
• True
• False
• Answer a. True

62
Questions 12-16 Key Points

• Surveillance for CLUSTERS of SARI is critical
• Even for an influenza A(H5N1) pandemic, most
  cases would not have a poultry link
• See Trigger Criteria Summary Handout

63
Trigger Criteria Decisions

• National clinician education about trigger
  criteria and reporting
• At hospitals within the sentinel system
• At hospitals outside the sentinel system
• Cases meeting criteria
• Immediate notification to Provincial Medical
  Officer via toll-free phone number
• Oropharyngeal and nasopharyngeal swabs

64
Finalize the Guidelines

• Trigger cases can facilitate timely diagnosis of
  other respiratory pathogens of pandemic
  potential, if negative for influenza
• Detailed laboratory testing algorithm is planned
• WHO case definitions used for international
  reporting purposes

65
Laboratory Samples

• H5-positive poultry specimens
• From southeastern province, Pelu Jaghai
• Sent to WHO reference laboratory
• Province is rural
• Hospital care may not be sought
• Community-level surveillance needed

66
Question 17

• How could Influenza A (H5N1) and pandemic early
  warning surveillance be expanded beyond the
  hospitals in Pegu? Match the method on the left
  with its description on the right.

67
Pegu Accomplishments

• MOH will train a team in each province, using
  polio surveillance officer as bird flu person
• Surveillance foundations in place
• Case definitions
• WHO reporting
• Early warning system plans
• Trigger criteria for laboratory testing and
  public health investigation
• Gatekeeper training
• Sentinel sites

68
The next day

• Pelu Jaghai reports another large poultry die-off
• In farms in backyard populations
• Specimens from Ministry of Agriculture sent to
  the National Laboratory
• Ministry of Health wants to establish active
  human surveillance

69
Question 18

• Which of the following are surveillance
  enhancements for human disease that could be
  recommended for the affected province?
• Teach Pegus traditional healing methods to it
  regional epidemiologists
• Door to door surveillance for ill people and
  chickens
• Initiate school-wide influenza shots
• SARI surveillance among healthcare workers at
  local facilities
• Active case finding among the occupationally
  exposed
• Dismiss rumors of clusters within health care
  workers, families or village contacts
• Recruit private practices, NGOs, religious
  institutions, and schools into the surveillance
  system for H5N1 and pandemic trigger criteria
• Refresher training on reporting procedures
• Confirm availability of telephone reporting
  hotlines

70
Question 18 Key Points

• Active surveillance is key in this context
• Make surveillance more active in the hospital and
  community settings
• Backyard poultry husbandry may not be known to
  authorities
• Poultry workers and community need to know
  importance of seeking treatment
• Make healthcare facilities aware of community
  education and reporting mechanisms
• Village health monitors and leaders can be
  important sources of information for outside
  investigators

71
Later that evening

• You learn of two possible human cases in
  neighboring Dava Ghar province
• No poultry outbreaks have ever been reported
  here!
• You are asked to extend your stay and participate
  in the outbreak investigation
• You travel with the District Epidemiologist and
  two local officials to Dava Ghar Province

72
Continue to Outbreak Investigation Case Study
