USEPA Region 2 Vapor Intrusion Study

1
USEPA Region 2Vapor Intrusion Study

• Cayuga Groundwater Contamination Site
• March 4, 2009

2
Site Background

• 2001 to Present EPA Field Study
• Installed 23 Multi-level monitoring wells
• Seven Rounds of groundwater sampling (gt500
  groundwater samples)
• Quarterly water level measurement and geophysics
  support from USGS
• Surface water/sediment samples (Owasco Outlet,
  Crane Brook, Union Springs)

3
Site Background (contd)

• Cayuga County DOH 1999-2008 - Multiple rounds of
  residential well sampling (gt600 samples)
• Remedial report and risk evaluations in progress

4
Monitoring Wells
5
Site Overview
6
Ongoing Field Study Efforts

• Additional field work under NYSDEC/EPA
• Additional monitoring wells
• Additional groundwater sampling
• Geophysical survey
• Hydraulic testing

7
Vapor Intrusion Study

• EPA field study indicates that chlorinated
  volatile organic compounds (CVOCs) are present in
  groundwater
• CVOC-contaminated groundwater extends from West
  Genesee St. to Union Springs
• CVOCs in groundwater can form vapors that migrate
  in the subsurface
• Potential exists for vapors to enter buildings
• Vapor sampling is being conducted to determine if
  vapors are present in buildings

8
Vapor Sampling Locations

• Selection of locations based on existing data
• Location of CVOCs in groundwater
• Location of CVOCs in surface water
• Residential well data
• Human health risk evaluation
• Geologic/Hydrogeologic factors
• Depth to contaminated groundwater (lt100 feet)
• Degree of bedrock fracturing
• Presence of clean groundwater above contaminated
  zones

9
Vapor Sampling Locations (contd)

• Three areas identified that meet initial
  criteria
• South of West Genesee Street
• Pinckney Road/Overbrook Drive Area
• Union Springs

10
South of West Genesee Street

• Insert Figure 1

11
Pinckney/Overbrook Area (east)

• Insert Figure 2

12
Pinckney Road (West)
13
Union Springs Area (south)

• Insert Figure 3

14
Union Springs Area (north)
15
Residential Vapor Intrusion Sampling Procedures

• Presented by
• Gary Newhart EPA

16
Ventilation
Ventilation
Interior space
Ambient air
Ambient air
Vadose Zone
Subslab soil gas intruding into interior space
Groundwater Contamination
Vapor Pathway into Buildings
17
Key Questions for Vapor Intrusion Impacts

• Does groundwater or soil contamination exist?
• Yes, in this case, so we move to the next step
• Does subsurface gas contamination exist above
  guidelines?
• Answered through collection of subslab soil gas
• 3. If subsurface gas does exist above guidelines,
  is it entering the interior space?
• Answered through collection of indoor air samples
• 4. If gas contamination exists in the residence,
  are the concentrations elevated and related to
  contamination
• - Answered by comparing results to health-based
  guidelines and conducting lifestyle and
  ambient investigation

18
Monitoring and Sampling Strategy

• Initial Sampling
• - Subslab Location Ambient (outdoor)
• 2. Subsequent SUMMA Canister Sampling
• - Subslab Location
• - Basement Location
• - First Floor Location

19
Indoor Air and Sub-Slab Soil Gas Activities
20
Drilling
21
Placement and Cementing of the Probe
22
Connection of the 3-Way Valve
23
Vapor Sampling Apparatus
24
(No Transcript)
25
Vapor Mitigation System
26
What is a VI Matrix and how is it developed?

• Chemical-specific
• Considers potential health effects from long-term
  exposures for residents including children and
  adults
• Exposure Frequency of 24 hours/day and 350
  days/year
• Exposure Duration is 30 years
• Has comparison values for subslab soil gas and
  indoor air

27
Step 1. Does the subslab concentration exceed x
ug/m3? No Vapor intrusion investigation is
over for this building Yes Consider indoor air
sampling
Vapor Intrusion Matrix for a Carcinogenic Chemical
Step 2. Evaluate subslab and indoor air
concentrations.
Sub-slab Soil Gas Concentration Indoor Air Concentration (ug/m3) Indoor Air Concentration (ug/m3) Indoor Air Concentration (ug/m3)
Sub-slab Soil Gas Concentration
(1) No Action (2) Investigate (3) Investigate
(4) Monitor (5) Monitor or Pursue Remediation (6) Investigate or Pursue Remediation
(7) Monitor or Pursue Remediation (8) Pursue_ Remediation or Monitor (9) Pursue Remediation
28
Vapor Intrusion Matrix for a Non-Carcinogenic
Chemical
Step 1. Does the subslab concentration exceed x
ug/m3? No Vapor intrusion investigation is
over for this building Yes Consider indoor air
sampling
Step 2. Evaluate subslab and indoor air
concentrations.
Sub-slab Soil Gas Concentration Indoor Air Concentration (ug/m3) Indoor Air Concentration (ug/m3)
Sub-slab Soil Gas Concentration
(1) No Action (2) Investigate
(3) Monitor/ Remediate (4) Remediate
29
VI Decisions

• VI Profile
• Subslab
• Indoor/Basement
• Indoor/First Floor Living Space
• Ambient Concentrations
• Confounding Internal Sources
• Confounding External Sources

30
Key Points in VI Decisions

• Decision to remediate is not based on one piece
  of information
• Complexity and uncertainty is associated with the
  fate and transport mechanism of vapors
• Multiple lines of evidence are used in the
  decision making
• Rely on VI Team to ensure consistency in
  decisions within EPA Region 2

31
Contact Information

• USEPA Remedial Project Manager - Isabel Rodrigues
  [phone]
• USEPA Community Involvement Coordinator Mike
  Basile - [phone]
• New York State DOH Krista Anders (518)
  402-7860
• New York State DEC Kevin Kelley (315)
  426-7421
• Cayuga County DOH Eileen OConner (315)
  253-1405
