DISTAL SPINAL MUSCULAR ATROPHY and related disorders

1
DISTAL SPINAL MUSCULARATROPHY and related
disorders

• Louis VIOLLET
• SUMMER SCHOOL MYOLOGY 2004

2
SMA -DEFINITION

• Anterior horn cell degeneration
• leading to
• progressive
• muscular atrophy
• with
• trunk and limb
• paralysis

3
Neuronal loss
Muscle atrophy
4
SMA- DIAGNOSISPhysical examination
neurophysiology

• 1-Muscle weakness
• 2-No sensory impairment
• 3-Progressive pattern
• 4-Denervation (EMG and/or muscle biopsy)
• 5-No nerve demyelination (NCV)
• 6-Normal distal sensory potentials

5
SMA CLASSIFICATION3 major criteria

• 1-Distribution of paralysis
• Proximal
• Distal
• 2-Mode of inheritance
• Autosomal dominant
• Autosomal recessive
• 3-Age at onset
• Ante or perinatal period
• Infancy/childhood
• Adulthood

6
CLINICAL HETEROGENEITY


-Distribution of paralyses
-Mode of inheritance


-Age at onset


-CNS abnormalities
7
Classical SMA and atypical SMA
AR Proximal SMA (Werdnig Hoffmann and Kugelberg
Welander) SMNdel 95
Distal SMA
Bulbospinal SMA
SMA with CNS involvement
Others
8
DISTAL SMA-Distal HMN- Spinal CMT-
Clinical features (Harding, 1980)

• dHMN type I AD CMT-like

• dHMN type II AD Belgian type
• dHMN type III AR  Chronic AR distal
  SMA
• dHMN type IV AR,  Severe AR distal SMA
• dHMN type V AD,  upper limb
  predominance
• dHMN type VI AR,  SMARD
• dHMN type VII AD,  vocal cord paralysis

• dHMNj (jerash type)AR  with upper neuron
  involvement
• X-linked dHMN XR, Brazilian type

9
AUTOSOMAL DOMINANT DISTAL SMA(Distal HMN type I)

• Onset 2-20 years
• Lower limb predominance
• Pes cavus
• No proximal weakness
• Rare scoliosis
• Low progression
•  CMT-like  but normal SAPs

10
AUTOSOMAL DOMINANT DISTAL SMA (distal HMN type I)
11
AD Distal HMN type I GENETICS
No genetic linkage, no gene identified BUT,
recently in some in sporadic cases
identification of mutations in the
HSPB1gene,(or HSP27) encoding a Small 27 kDa
Heat Shock Protein B1 affecting the assembly of
neurofilaments NB These mutations have been
also found in sporadic cases of axonal CMT !
12
AD distal SMA - Distal HMN type II(Belgian
family. Timmerman et al, 1996)

• Onset 20-40 years (big toe and feet extensor
  muscles)
• Lower limb predominance
• No pes cavus
• Proximal involvement

13
AD Distal HMN type II GENETICS

• Genetic localization 12q24.3
• Mutations in the HSPB8 gene (or HSP22) encoding a

• Small 22 kDa Heat Shock Protein
• NB -HSPB8 and HSPB1 are interacting proteins
• -Mutations in HSPB8 leads to intracellular
  agregates
• -Heat Shock Proteins are implicated in
  neurodegenerative disorders

14
AD distal SMA with upper limb predominance-Distal
HMN type V-
Age at onset 5-20 years Clinical and genetic
heterogeneity
15
7p-linked Distal HMN type V
CLINICAL PICTURE -Upper limb weaknessgtgtlower
limb -Slow progression
GENETICS -Linkage to the 7p14 region -Mutations
in the gene Glycyl tRNA synthetase
16
Non7p-linked Distal HMN type V
CLINICAL PICTURE -Intra-familial heterogeneity
-Lower limb paralysis /-
GENETICS -Linkage to the 11q13 region in one
family -Mutations in the gene BSCL2 (Berardinelli
-Seip Congenital Lipodystrophy gene)
17
BSCL2 one gene, 3 disorders
1-Berardinelli-Seip Congenital lipodystrophy,
Autosomal Recessive 2-Distal HMN type V linked
to 11q13 Autosomal Dominant 3-SILVER syndrome
(Hereditary spastic paraplegia with hand muscles
atrophy) Autosomal Dominant
BSCL2 encodes the SEIPIN protein
-Integral protein of the endoplasmic
reticulum -Mutations of SEIPIN leads to agregate
formation and neurodegeneration
18
AD distal SMA with vocal cord paralysis-dHMN
type VII-

• CLINICAL PICTURE
• onset 10-20 years (wasting of the small muscles
  of the hand and thenar eminence)
• Subsequently weakness of the distal muscles of
  the lower limbs
• Hoarse voice
• Slow progression

19
AD Distal HMN type VII GENETICS

• Genetic localization 2q14
• Mutations in the gene encoding
• the DYNACTIN2 protein (also called
  DYNAMITIN)
• Mutations affect the microtubule binding
  domain
• Dysfunction of dynactin-mediated transport
  is
• responsible for human motor neuron
  disease

20
Autosomal Recessive Distal Spinal Muscular
Atrophy in Childhood
-Spinal Muscular Atrophy with Respiratory
Distress -Chronic Autosomal Recessive Distal
SMA -Jerash-type Autosomal Recessive Distal SMA
21
SMARD
22
SMARD
Synonyms -Distal SMA with Neonatal
Respiratory Distress -Diaphragmatic
distal SMA -dHMN type VI

• 1 of early onset SMAs
• Very severe phenotype
• Autosomal recessive transmission

23
SMARD

• Low weight at birth
• Normal alert
• Hypotonia at birth
• Bilateral clubfeet
• Grasping fingers
• -Rapidly progressive course
• -EMG denervation
• -No sensory defect
• - Nerve conduction velocities

24

• -Acute respiratory distress
• -Due to bilateral diaphragmatic paralysis
  occurring in the first weeks of life
• No chest deformity
• Masking the neurological symptoms
• Leading to permanent assisted ventilation

25
SMARD
PROXIMAL SMA type I
26
SMARD-GENETICS

• Linkage to 11q13 IGHMBP2 gene mutations
• (Grohmann et al. 2001)
• IGHMBP2- unknown function
• -RNA helicase domains
• -Ubiquitous expression
• -Homologous to the neuromuscular
  degeneration mouse (nmd) gene.
• Genetic heterogeneity

27
SMARD 1 OUR EXPERIENCE AT NECKER ENFANTS MALADES
HOSPITAL
-SMA Diaphragmatic paralysis -No homozygous SMN
gene deletion -No SMA carrier status
28 cases collected since 1990
9 novel IGHMBP2 mutations detected in 5 SMARD1
children
28
IGHMBP2 gene mutations
  Q196R L251P
D565B
R603C
P216L
C496X L577P R637C
R790X
DEAD/DEAH Box Helicase
AAA ATPase
Znf
Putative DNA Helicase
R3H
Q41X H213
A320X E514K
V580I A43X L236X
L361P C496X
DelA661
DelAA983/984 DelT1463
(Grohmann K, 2001 Pitt M, 2003)
29
CHRONIC DSMA
30
Lower limb paralysis
AR CHRONIC DSMA - DIAGNOSIS

• First symptom (6 months to 24 months)
• Bilateral feet paralysis
• peroneal muscles
• intrinsic foot muscles
• floppy feet attitude
• foot drop contracture
• Walking disability and frequent falls

31
Upper limb paralysis
AR CHRONIC DSMA - DIAGNOSIS

• Occurring later and less severe than feet
  paralysis
• bilateral hands paralysis
• wrist and fingers extensor muscles
• intrinsic muscles
• falling hand attitude
• grasping fingers

32
(No Transcript)
33
Proximal muscles involvement
AR CHRONIC DSMA - DIAGNOSIS

• Always present
• Less severe than distal
• Limb girdle weakness
• hyperlordosis
• kyphoscoliosis
• No chest deformity

34
AR CHRONIC DSMA

• - Normal intelligence
• - No pyramidal sign
• - Abolished or decreased
• osteotendinous reflexes
• - No sensory trouble
• - No fasciculation
• - No facial weakness

35
Neurological Investigations

• Neurophysiology
• diffuse and progressive denervation on EMG
• normal or slightly reduced motor NCV
• normal sensory potentials and normal sensory NCV
• Muscular biopsy
• neurogenic atrophy
• Sural nerve biopsy
• strictly normal

Chronic AR Distal SMA
36
AR CHRONIC DSMA -EVOLUTION
-Progressive course during childhood -Relative
stabilization at adult stage -Walking loss 60
of adult cases -Severe scoliosis
37
AR CHRONIC DSMA -EVOLUTION
-Bilateral diaphragmatic paralysis -Often
misdiagnosed -Sometimes revealed by an acute
respiratory distress
38
Pedigree 1
Whole genome scan (GENESCAN)
39
(No Transcript)
40
Lod score at locus D11S4136
4.59 4,11 3,62
41
19 pedigrees collected since 1999
42
REFINEMENT OF THE GENETIC INTERVAL
D11S1889 D11S913 D11S4113 D11S1337 D11S4136
D11S1314 D11S4184 D11S1369 D11S916

• Haplotype analysis at the 11q13 locus
• in the collected pedigrees

• Evidence of homozygosity
• in the 11q13.3 region
• in 2 inbred families

• Generation of 5 microsatellite markers in this
  locus
• DSM2, DSM3, DSM4, DSMX, DSMY

43
Fine chromosomal localization of Chronic DSMA
at11q13.3
DSM4
DSMX
D11S1369 D11S4184
DSMY

DSM3
Cen
Tel
IGHMBP2 gene exclusion
44
Alleles at the D11S1369, DSM4 and D11S4184 loci
D11S1314 1 D11S1369 2 DSM4
3 D11S4184 4 DSM2 1
6 2 1 3 1
6 2 1 3 1
8 1 2 4 10
5 1 4 3 9
4 2 3 4 2
4 2 3 4 2
4 2 3 4 2
4 1 1 3 2
5 1 4 3 9
5 1 4 3 9
5 1 4 3 9
5 3 4 3 13
D11S1314 1 D11S1369 2 DSM4
3 D11S4184 4 DSM2 11
1 2 3 4 11
10 4 2 4 7
45
Family A
Childhood onset DSMA
Adult onset DSMA
46
Adult onset AR DSMA

• 19 -23 years
• pretibial muscles weakness
• intrinsic feet muscles atrophy
• intrinsic hand muscles atrophy
• normal osteotendinous reflexes
• Progressive pelvic girdle weakness
• Normal respiratory function

Onset
Evolution
47
(No Transcript)
48
dHMNj (jerash type)

• AR, onset 6-10 years
• Pyramidal signs
• Pes cavus
• Lower limb predominance
• Secondary upper limb
• involvement
• Linkage to 9p21

49
DISTAL SMA-Distal HMN- Spinal CMT-

• Clinical features(Harding)
  Loci Gènes
• dHMN type I AD, onset 2-20 years ?
  ?(HSPB8)
• dHMN type II AD, onset 20-40 years 12q24
  HSPB1
• dHMN type III AR, onset 2-10 years
• dHMN type IV AR, onset 4 months-10 years
  ? ?
• dHMN type V AD, onset 5-20 years
  7p15 Glycyl tRNA Sase
• 11q13 BSCL2
• dHMN type VI AR, onset before 2 years
  11q13 IGHMBP2
• dHMN type VII AD, onset 10-20 years
  2q14 Dynactin
• dHMNj (jerash type) AR, onset 6-10 years
  9p21 ?
• Xlinked dHMN(Brazil) 1-10 years
  Xq13-q21 ?

11q13.3 ?
50
Scapuloperoneal SMA

• Type I (Kaiser family)
• Onset 4-70 years
• Autosomal dominant
• Linked to 12q24.1-24.31
• Type II
• Onset 2-5 years
• -Autosomal recessive
• No linkage

51
BULBO-SPINAL MUSCULAR ATROPHY

• Adult onset
• X-linked BSMA with gynecomastia
• located on chromosome X
• Androgen receptor gene mutation (unstable
  repeats)
• Autosomal recessive BSMA with rigid spine and
  nasal voice
• Autosomal dominant BSMA in adult

52
BULBO-SPINAL MUSCULAR ATROPHY-CHILDHOOD ONSET

• Fazio-Londe disease
• First symptoms 2-12 years
• Progressive voice change and swallowing
  difficulties
• Ophtalmoplegia
• Atrophy of the tongue with fasciculations
• Spreading paralysis to shoulder girdle
• Normal intelligence
• Autosomal recessive inheritance
• No genetic localization

53
BULBO-SPINAL MUSCULAR ATROPHY-CHILDHOOD ONSET

• Brown-Vialetto-Van Laere disease
• First symptoms 2-5 years
• Bilateral sensorineural deafness
• 7th, and 9th to 12th cranial nerves involved
• Spreading paralysis to shoulder girdle, arms and
  chest with diaphragmatic weakness
• Autosomal recessive inheritance

54
SMA CNS INVOLVEMENT

• SMA OLIVO-PONTO-CEREBELLAR HYPOPLASIA (Norman
  syndrom)
• -Autosomal recessive
• -2 types
• PCH1 -congenital onset
• -death before 1 year of life
• -global cerebellar hypoplasia
• PCH2 -progressive microcephaly
• -extra pyramidal dyskinesia
• -epilepsia and mental retardation
• -No genetic localization

55
INTERESTS OF ATYPICAL SMA GENETIC STUDIES
-Diagnosis of rare disoders and genetic
counselling -Understanding the motor neuron
degeneration mecanisms -by the identification of
novel proteins -by the identification of
neuronal metabolic pathways -apoptosis,
-axonal transport, -mRNA processing,
-axonal growth and maintenance, -etc
56
CONCLUSION-ATYPICAL SMA

• Rare phenotypes
• Clinical heterogeneity
• Diagnosis usually easy
• physical examination
• pictures/video records
• EMG , NCV studies (motor sensory NCV)
• Large multiplex pedigrees are necessary to
  initiate genetic mapping
• International collaborative studies

57
Distal SMA-Recruitment of additional
pedigrees(viollet_at_necker.fr)

• Distal predominance of motor weakness (but
  proximal weakness could be present )
• Adulthood or childhood
• Diaphragmatic insufficiency if severe form
• Neurogenic EMG pattern, with analysis of nerve
  condution velocities and distal sensory action
  potentials (SAP)
• No SMN gene deletion
