Comp. Genomics

1
Comp. Genomics

• Recitation 2 (week 3)
• 19/3/09

2
Outline

• Finding repeats
• Branch Bound for MSA
• Multiple hypotheses testing

3
Exercise Finding repeats

• Basic objective find a pair of subsequences
  within S with maximum similarity
• Simple (albeit wrong) idea Find an optimal
  alignment of S with itself!
• (Why is this wrong?)
• But using local alignment is still a good idea

4
Variant 1

• First specification the two subsequences may
  overlap
• Solution Change the local alignment algorithm
• Compute only the upper triangular submatrix
  (V(i,j), where jgti).
• Set diagonal values to 0
• Complexity O(n2) time and O(n) space

5
Variant 2

• Ssecond specification the two sequences may not
  overlap
• Solution Absence of overlap means that k exists
  such that one string is in S1..k and another in
  Sk1..n
• Check local alignments between S1..k and
  Sk1..n for all 1ltkltn
• Pick the highest-scoring alignment
• Complexity O(n3) time and O(n) space

6
Second Variant, Pictorially
7
Third Variant

• Specification the two sequences must be
  consecutive (tandem repeat)
• Solution Similar to variant 2, but somewhat
  ends-free seek a global alignment between
  S1..k and Sk1..n,
• No penalties for gaps in the beginning of S1..k
• No penalties for gaps in the end of Sk1..n
• Complexity O(n3) time and O(n) space

8
Variant 3
9
Branch and Bound algorithms

• Another heuristic for hard problems
• Idea
• Compute some rough bound on the score
• Start exploring the complete solution space
• Do not explore regions that definitely score
  worse than the bound
• Maybe improve the bound as you go along
• Guarantees optimal solution
• Does not guarantee runtime
• Good bound is essential for good performance

10
Slightly more formal

• Branch enumerate all possible next steps from
  current partial solution
• Bound if a partial solution violates some
  constraint, e.g., an upper bound on cost,
  drop/prune the branch (dont follow it further)
• Backtracking once a branch is pruned, move back
  to the previous partial solution and try another
  branch (depth-first branch-and-bound)

11
Example TSP

• Traveling salesperson problem
• Input Directed full graph with weights on the
  edges
• Tour a directed cycle visiting every node
  exactly once
• Problem find a tour of minimum cost
• NP-Hard (reduction from directed Hamiltonial
  cycle)
• Difficult to approximate
• Good example of enumeration

12
Example TSP

• Find me a tour of 10 cities in 2500 miles

13
Reminder The hypercube

• Dynamic programming extension
• Exponential in the number of sequences

Source Ralf Zimmer slides
14
BB for MSA

• Carillo and Lipman (88)
• See scribe for full details
• The bound
• Every multiple alignment induces k(k-1)/2
  pairwise alignments
• Neither of those is better than the optimal
  pairwise alignment (Why?)
• The branching
• Compute the complete hypercube, just ignoring
  regions above the bound

15
BB for MSA
16
(Some) gory details

• Requires a forward recurrence once cell
  D(i,j,k) is computed it is transmitted forward
  to the next cells
• The cube cells stored in a queue
• The next computed cell is picked up from the top
  of the queue
• (Easy) to show that once a cell reaches the top
  of the queue, it has received transmissions
  from all its relevant neighbors

17
(Some) gory details

• da,b(i,j) is the optimal distance between
  S1i..n and S2j..n (suffixes aligned) (Easy to
  compute?)
• Assume we found some MSA with score z (e.g., by
  an iterative alignment)
• Key lemma if D(i,j,k)d1,2(i,j)d1,3(i,k)d2,3(j,
  k)gtz
• then D(i,j,k) is not on any optimal path and
  thus we need not send it forward.

18
(Some) gory details

• In practice, Carillo-Lipman can align 6 sequences
  of about 200 characters in a practical amount
  of time
• Probably impractical for larger numbers
• Is optimality that important?

19
Review

• What is a null hypothesis?
• A statisticians way of characterizing chance.

• Generally, a mathematical model of randomness
  with respect to a particular set of observations.
• The purpose of most statistical tests is to
  determine whether the observed data can be
  explained by the null hypothesis.

20
Empirical score distribution

• The picture shows a distribution of scores from a
  real database search using BLAST.
• This distribution contains scores from
  non-homologous and homologous pairs.

High scores from homology.
21
Empirical null score distribution

• This distribution is similar to the previous one,
  but generated using a randomized sequence
  database.

22
Review

• What is a p-value?
• The probability of observing an effect as strong
  or stronger than you observed, given the null
  hypothesis. I.e., How likely is this effect to
  occur by chance?
• Pr(x gt Snull)

23
Review

• If BLAST returns a score of 75, how would you
  compute the corresponding p-value?
• First, compute many BLAST scores using random
  queries and a random database.
• Summarize those scores into a distribution.
• Compute the area of the distribution to the right
  of the observed score (more details to come).

24
Review

• What is the name of the distribution created by
  sequence similarity scores, and what does it
  look like?
• Extreme value distribution, or Gumbel
  distribution.
• It looks similar to a normal distribution, but it
  has a larger tail on the right.

25
Extreme value distribution

• The distribution of the maximum of a series of
  independently and identically distributed (i.i.d)
  variables
• Actually a family of distributions (Fréchet,
  Weibull and Gumbel)

Location
Scale
Shape
26
What p-value is significant?

• The most common thresholds are 0.01 and 0.05.
• A threshold of 0.05 means you are 95 sure that
  the result is significant.
• Is 95 enough? It depends upon the cost
  associated with making a mistake.
• Examples of costs
• Doing expensive wet lab validation.
• Making clinical treatment decisions.
• Misleading the scientific community.
• Most sequence analysis uses more stringent
  thresholds because the p-values are not very
  accurate.

27
Multiple testing

• Say that you perform a statistical test with a
  0.05 threshold, but you repeat the test on twenty
  different observations.
• Assume that all of the observations are
  explainable by the null hypothesis.
• What is the chance that at least one of the
  observations will receive a p-value less than
  0.05?

28
Multiple testing

• Say that you perform a statistical test with a
  0.05 threshold, but you repeat the test on twenty
  different observations. Assuming that all of the
  observations are explainable by the null
  hypothesis, what is the chance that at least one
  of the observations will receive a p-value less
  than 0.05?
• Pr(making a mistake) 0.05
• Pr(not making a mistake) 0.95
• Pr(not making any mistake) 0.9520 0.358
• Pr(making at least one mistake) 1 - 0.358
  0.642
• There is a 64.2 chance of making at least one
  mistake.

29
Bonferroni correction

• Assume that individual tests are independent. (Is
  this a reasonable assumption?)
• Divide the desired p-value threshold by the
  number of tests performed.
• For the previous example, 0.05 / 20 0.0025.
• Pr(making a mistake) 0.0025
• Pr(not making a mistake) 0.9975
• Pr(not making any mistake) 0.997520 0.9512
• Pr(making at least one mistake) 1 - 0.9512
  0.0488

30
Database searching

• Say that you search the non-redundant protein
  database at NCBI, containing roughly one million
  sequences. What p-value threshold should you use?

31
Database searching

• Say that you search the non-redundant protein
  database at NCBI, containing roughly one million
  sequences. What p-value threshold should you
  use?
• Say that you want to use a conservative p-value
  of 0.001.
• Recall that you would observe such a p-value by
  chance approximately every 1000 times in a random
  database.
• A Bonferroni correction would suggest using a
  p-value threshold of 0.001 / 1,000,000
  0.000000001 10-9.

32
E-values

• A p-value is the probability of making a mistake.
• The E-value is a version of the p-value that is
  corrected for multiple tests it is essentially
  the converse of the Bonferroni correction.
• The E-value is computed by multiplying the
  p-value times the size of the database.
• The E-value is the expected number of times that
  the given score would appear in a random database
  of the given size.
• Thus, for a p-value of 0.001 and a database of
  1,000,000 sequences, the corresponding E-value is
  0.001 1,000,000 1,000.

33
E-value vs. Bonferroni

• You observe among n repetitions of a test a
  particular p-value p. You want a significance
  threshold a.
• Bonferroni Divide the significance threshold by
  a
• p lt a/n.
• E-value Multiply the p-value by n.
• pn lt a.

BLAST actually calculates E-values in a
slightly more complex way.
34
(No Transcript)
35
(No Transcript)
36
(No Transcript)
37
False discovery rate
5 FP 13 TP

• The false discovery rate (FDR) is the percentage
  of examples above a given position in the ranked
  list that are expected to be false positives.

33 TN 5 FN
FDR FP / (FP TP) 5/18 27.8
38
Bonferroni vs. FDR

• Bonferroni controls the family-wise error rate
  i.e., the probability of at least one false
  positive.
• FDR is the proportion of false positives among
  the examples that are flagged as true.

39
Controlling the FDR

• Order the unadjusted p-values p1 ? p2 ? ? pm.
• To control FDR at level a,
• Reject the null hypothesis for j 1, , j.
• This approach is conservative if many examples
  are true.

(Benjamini Hochberg, 1995)
40
Q-value software
http//faculty.washington.edu/jstorey/qvalue/
41
Significance Summary

• Selecting a significance threshold requires
  evaluating the cost of making a mistake.
• Bonferroni correction Divide the desired p-value
  threshold by the number of statistical tests
  performed.
• The E-value is the expected number of times that
  the given score would appear in a random database
  of the given size.
