Title: Pecan Irrigation


1
Pecan Irrigation
Michael Kizer OSU Extension Irrigation Specialist
2
Irrigation Water Management
  • Good irrigation water management is efficiently
    supplying the proper amount of water to a crop at
    the proper time so that optimum production
    results with minimum expense.

3
Irrigation Application Depth(the proper amount)
  • Crop rooting depth
  • Soil water holding capacity
  • Allowable water deficit

4
Pecan Root System
  • Effective Rooting Depth 4 - 6 feet
  • Majority of root volume in upper 2 feet
  • Local features (bedrock, etc) may limit depth
  • Spread horizontally until competition is met
  • Root growth affected by
  • irrigation depth
  • irrigation frequency
  • application pattern

5
Soil Water Holding Capacity
6
(No Transcript)
7
(No Transcript)
8
Maximum Allowable Deficit
  • Depleting soil water in the pecan root zone by
    more than 50 can lead to
  • slowed tree growth
  • reduced nut yield
  • blanking abortion

9
Example 1
  • Pecan effective root depth 4 feet
  • Durant loam 2.2 in/ft
  • Max. Allowable Deficit 50 depletion
  • 4 ft x 2.2 in/ft x 50/100 4.4 in
  • The trees can remove 5.5 inches of water from
    this soil before they become seriously stressed
    for moisture.

10
Example 2
  • Pecan effective root depth 4 feet
  • Eufala fine sand 0.8 in/ft
  • Max. Allowable Deficit 50 depletion
  • 4 ft x 0.8 in/ft x 50/100 1.6 in
  • The trees can remove 1.6 inches of water from
    this soil before they become seriously stressed
    for moisture.

11
Irrigation Interval(the proper time)
  • How long will it take to deplete 1.6 inches of
    soil water?
  • It depends on the evapotranspiration (ET) rate.

12
Evapotranspiration Rate
  • Weather conditions - Solar radiation -
    Air temperature - Wind speed -
    Relative humidity
  • Cultural Practices - Nutritional
    management - Pest stresses - Irrigation
    amount frequency

13
Irrigation Interval(the proper time)
  • How long will it take to deplete 1.6 inches of
    soil water?
  • At ET0.31 in/day it will take about 5 days.

14
(No Transcript)
15
(No Transcript)
16
Mesonet Ag. Weather Page
  • http//agweather.mesonet.org

17
(No Transcript)
18
(No Transcript)
19
(No Transcript)
20
Tensiometer for measuring soil water potential
21
Electrical resistance blocks w/ meters
22
Irrigation Water QualitySalinity
  • Pecans are moderately sensitive to salinity
  • Threshold ECe for yield reduction 1.9
    dS/m (1900 ?mho/cm)
  • Yield reduction rate 16 / added dS/m
  • 50 yield reduction _at_ ECe 4.9 dS/m
    Note (1dS/m 1 mmho/cm 1000 ?mho/cm)

23
Irrigation Water QualityBoron
  • Pecans are very sensitive to boron
  • Threshold soil boron concentration for onset of
    yield reduction 1.0 mg/L

24
Irrigation Water Testing Before you go very
far in an irrigation development plan, get an
irrigation water test for 15 from the OSU Soil,
Water Forage Analytical Lab. through your
County Extension Educator
25
Irrigation System Options
  • Flood irrigation
  • Sprinkler irrigation -Solid set
    sprinklers -Traveling volume gun
  • Microirrigation

26
Flood Irrigation
  • Furrow systems
  • Low initial cost (in most cases)
  • Low pressure/energy requirement
  • Low application efficiency

27
Rainbird 30, 14 and 65 impact sprinkler heads
28
Typical solid set sprinkler field layout
29
Solid Set Sprinklers
  • Irrigate trees and cover crop
  • Low labor requirement
  • Moderate pressure/energy requirement
  • Moderately efficient application (70-80)
  • Non-portable (permanent system)
  • Limits orchard access (temporary system)

30
Turbine-driven hard-hose traveling gun sprinkler
31
Typical traveling volume gun field layout
32
Traveling Gun Sprinklers
  • Portable
  • Adaptable to irregularly shaped fields
  • Irrigates both trees and cover crop
  • High pressure (120 psi at hose inlet)
  • Lower application efficiency (60-70)
  • Less suitable as trees mature

33
Micro-sprinklers w/ spinner and fixed diffusers
34
Micro-sprinkler w/ fixed, grooved diffuser plate
on a stake w/supply tube
35
On-line, button-type drip emitters
36
Single multi-outlet, pressure-compensating
emitters on PE tubing
37
Drip tape w/ turbulent flow emitter manufactured
in tube seam (T-Tape)
Drip tape w/ PVC emitter welded in seamless PE
tube (Netafim Typhoon)
38
Pre-set Pressure Regulators for Microirrigation
Note 2.31 ft of elevation increase 1 psi in
pressure decrease 2.31 ft of
elevation decrease 1 psi in pressure increase
39
Zone 2
Zone 1
40
Microirrigation system with multi-emitter
pigtail around tree
41
Microirrigation Systems
  • Highly efficient application (90)
  • Low pressure/energy requirement
  • Low operating labor requirement
  • High initial cost
  • Non-portable system
  • Best suited to irrigate trees only
  • Clean water required (filtration)

42
Backflow Prevention
  • Protects water source from contamination by
    non-potable water in case of unexpected pressure
    loss in the system. Required by federal law on
    irrigation systems which apply fertilizer and
    pesticides.
  • Gooseneck pipe loop with Pressure Vacuum Breaker
  • Reduced Pressure Zone device (RPZ)
  • Double check valve (Not approved for public
    water systems)

43
2 ft min. above highest outlet
Gooseneck pipe loop w/ PVB backflow preventer
44
Reduced Pressure Zone (RPZ) Backflow Preventer
45
Good Irrigation Management
  • Know your soil
  • water holding capacity
  • infiltration rate
  • Know your crop
  • rooting depth
  • max. allowable deficit
  • Know your soil water status or ET rate
  • Know your irrigation system
  • application rate

46
Good Irrigation Management
  • Saves water
  • Reduces nutrient and pesticide leaching
  • Improves quality productivity of the crop
  • Saves You Money

47
http//biosystems.okstate.edu/Home/mkizer/index.ht
m
48
The End
