Outlier Detection Using SemiDiscrete Decomposition

1
Outlier Detection Using SemiDiscrete Decomposition
S. McConnell and D.B. Skillicorn

• Presented by Bryan Decaire

2
Dataset / Table

• n rows (objects) each with m columns
  (attributes)
• each object a point in m-dimensional space
• clustering a method to find some structure in the
  data
• high dimensional spaces are difficult to work
  with
• distance between nearest and farthest neighbor
  almost the same
• large m creates problems (large gt 15)
• Dimension-reduction techniques (e.g. SVD)

3
SVD

• Transforms from an m-dimensional space to new
  m-dimensional space
• A USVt
• A is an n x m matrix
• U is an n x m matrix
• S is an m x m, diagonal matrix, non-negative, r
  decreasing singular values where r is the rank of
  A (r m)
• V is an m x m matrix

4
SVD

• Properties of new space are
• Axes (U and V) are orthonormal
• Axes are ordered such that variation that exists
  is ordered from largest to smallest
• Later dimensions may thus be ignored
• Rank k (k r) approximation to A
• Multiply the following
• first k columns of U
• upper left k x k submatrix of S
• First k columns of V, transposed

5
SDD

• Weak analogue of SVD
• Axes are NOT orthonormal
• Coordinates of points are from set -1, 0, 1
• Compact representation of transformed space
  (2-bits/element of X and Y)
• O(nm)3 complexity

6
SDD

• Mixed integer programming (MIP) problem
• Linear programming problem
• linear function to be optimized
• problem constraints
• non-negative variables
• Mixed integer because some of the decision
  variables are constrained to have only integer
  values at the optimal solution

7
SDD - Equation

• Ak Xk Dk Yk
• equation for a k-dimension SDD
• Ak is an n x m matrix
• Xk is an n x k matrix, elements are -1, 0, 1
• Dk is a k x k diagonal matrix
• Yk is a k x m, elements are -1, 0, 1
• k is no longer related to the rank of matrix A

8
SDD - Algorithm

• Let Ak kth term approximation
• Let Rk residual at the kth step
• Let xi be the ith column of X, di the ith
  diagonal element of D, and yi the ith row of Y
• X, D, Y are initialized to 0
• For (i 1 to k)
• Ak-1 X D Y
• Rk A Ak-1
• Find a triple (xi, di, yi) that minimizes Ri
  dixiyi F
• Choose an initial yi
• Solve for xi and di using selected yi
• Solve for yi using di and xi from previous step
• Repeat until convergence criteria is met

9
SDD - Properties

• Rows of X represent the coordinates of the object
  in the new space defined by Y
• Unsupervised learning of a ternary decision tree
• objects divided by value in column 1
• continue dividing objects by values in each
  successive column
• clusters identified via decision tree creation
• leaves require examination
• does not contain every possible branch
• New data classification would be unknown

10
SDD - Example

• Given a matrix A as

11
SDD Example (cont)

• The first five columns of X
• The first five columns of Y
• The values of D are

12
SDD Example (cont)

• Resultant Decision Tree

13
SDD Example Analysis

• The first approximation subtracted from A
• A1 d1 x1 y1
• A A1

14
SDD Example Analysis (cont)

• A
• A A1

15
SDD Example Analysis (cont)

• General Effect Find regions where the
  difference in values is large
• Volume of the difference is key
• Both magnitude of difference and
• Region of occurrence impact decision
• 2-Norm as objective function implies height has a
  greater impact than region
• Tends to find outlier clusters in data
• SDD is a form of bump hunting
• Finds regions that are above/below the rest of
  the data

16
Observations

• When structure of dataset is many small clusters
• SVD and SDD produce similar results
• SVD is an accurate low-dimensional representation
• SDD recognizes the clusters as bumps
• Example comparison plot of sparse clusters on a
  text dataset. SVD generated the coordinates
  while SDD set shape and color

17
Observations (cont)

• SDD useful in latent semantic indexing (LSI)
• Document-text matrices tend to contain many small
  clusters
• SDD is an outlier detector
• Emphasizes most unusual patterns in a dataset

18
SDD - Problems

• Algorithm is sensitive to initial choice of yi
• Largest possible slice not always removed
• Therefore, values of D are not always decreasing
• Authors propose a reorder of the D values after
  the algorithm completes by accounting for the
  total effect of the individual slice
• D values are dependent upon the current matrix
  state
• Reordering at the end cannot reproduce the same
  results as having chosen a different removal
  order
• Computation of D is dependent on the average
  height of clusters being removed
• Partitioning of the original matrix may not be
  optimal

19
Example Outlier Discovery

• In a geochemical dataset containing 1670 sample
  points, measuring the concentration of 33
  elements
• No other technique found outlier clusters such as
  these

20
Example Outlier Discovery

• In a dataset containing observed properties of
  galaxies, with 8 attributes and 460 rows
• SDD partitioned a single SVD cluster into a set
  of subclusters reflecting finer detail

21
Related Work

• PRIM is a bump hunting technique
• Top-down, removing slices in a single dimension
• Rule-based techniques
• Some use exhaustive search, may not scale well
• SVD based
• Principal Direction Divisive Partitioning
• Partitions a dataset based on variation of the
  direction of the first singular value axis,
  repeats for each subpartition independently

22
Related Work

• Comparison of PDDP and SDD
• Given a dataset A

23
Related Work (cont)
24
Conclusion

• SVD
• Space transforming technique
• Models decreasing amounts of variation
• SDD is a bump hunting technique
• Finds regions with large values and extracts them
• Removes bumps with largest volume
• Detects outliers
• SVD and SDD
• Agree on datasets that contain many small
  clusters
• Disagree on datasets that contain few large
  clusters
